Condition: refurbished (used), Year of construction: 2022, turning diameter over bed: 540 mm turning diameter over slide rest: 280 mm turning length: 1.500 mm turning diameter in the recess: 580 Working travel of the lower slide max. approx.: 415 mm adjustment of upper support, max. approx.: 140 mm turning speed range: 0 - 1.800 U/min diam. of main spinde: 135 mm spindle bore: 68 mm internal taper diameter: 73 mm Hnedpjxwx Nvjfx Ah Uew bed width: 403 mm Equipped with: Three jaw chucks FORKARDT 250 Digital read out 3 axis fixed steady rest feed safety chip tray several tool holders, 6 chisel holders, 1 holder for clamping sleeve

Condition: used, Parallel Lathe CAZENEUVE HB 575 x 1500 mm Between points: 1500 mm Maxi Ø on bench: Ø 575 mm Hnsdpsxwcwdsfx Ah Ujw Maxi Ø over saddle: Ø 300 mm Spindle diameter: Ø 51 mm Spindle speed: from 25 to 2000 RPM Square turret 3-jaws chuck: Ø 350 mm Spindle motor: 8,8 kW Threadings: Metric + Whitworth Tailstock: CM5 Auto Feeds longitudinal + transversal Straight Bed Lubricant tank Lubricant pump Voltage: 220 V Tri Dimensions (L x W x H): 3000 x 1300 x 1800 mm Weight: approx 2,2 T

Condition: excellent (used), spindle bore: 51 mm, turning length: 1,500 mm, Cazeneuve HB 575 Conventional Lathe – 1500 mm. The Cazeneuve HB series is renowned for its stability, accuracy, and user-friendliness. This HB 575 features a center distance of 1500 mm, making it suitable for both general machining, batch production, and repair applications. The machine is equipped with a robust, wide bed and a smooth, quiet spindle transmission, delivering excellent surface finish even during heavy-duty machining operations. Main specifications: Swing over bed: Ø 575 mm. Swing over cross slide: approx. Ø 300 mm. Distance between centers: 1500 mm. Spindle bore: Ø 51 mm. Spindle speed range: approx. 32 – 2,500 rpm, 18 speeds. Cross slide travel: approx. 300 mm. Hnsdsxv D N Sjpfx Ah Uew Tailstock quill taper: MT5. Machine weight: approx. 2,000 kg.

Condition: used, Year of construction: 1996, functionality: fully functional, turning diameter over cross slide: 320 mm, spindle bore: 78 mm, turning diameter: 500 mm, turning length: 1,500 mm, total length: 3,080 mm, total width: 1,280 mm, total height: 1,450 mm, spindle speed (max.): 2,240 rpm, spindle speed (min.): 14 rpm, metric thread steps: 55, rotational speed (max.): 2,240 rpm, rotational speed (min.): 14 rpm, type of input current: three-phase, swing diameter over bed slide: 560 mm, overall weight: 2,760 kg, rapid traverse X-axis: 2 m/min, rapid traverse Z-axis: 4 m/min, three-jaw chuck diameter: 315 mm, spindle mount: MK 6, spindle motor power: 7,500 W, power of feed motor: 550 W, For sale: Lathe Tos SUI 50 A with leadscrew/feedshaft - Heidenhain length measuring system ND 930 - Heidenhain glass scales LS603 installed at the bed and cross slide - Multifix quick-change tool post, size C (by HAASE) with 4 holders 30mm and 1 boring bar holder Ø40mm - 3-jaw scroll chuck, diameter 315mm, internal bore 108mm - Bar passage approx. 78mm - Swing over bed 500mm Hnsdpfx Ahsxvyxce Ujw - Tailstock Morse taper MK5 - Coolant reservoir with pump (pump not working) - Includes accessories as shown in the pictures - All slideways are in good condition - The lathe itself is fully functional and in well-maintained condition - Drive belt replaced in 2024, oils checked regularly Year of manufacture: 1996

Condition: like new (used), Year of construction: 2007, turning diameter over cross slide: 350 mm, spindle bore: 102 mm, turning diameter: 540 mm, turning length: 1,500 mm, A very nice OMG Zanoletti lathe with few operating hours. Equipped with a Röhm Enduro 315 chuck with various jaws, a precision Parat quick-change toolpost with 7 holders, a 2-axis Heidenhain digital readout, cooling system, lighting, 6 leveling feet, and instruction manual. Hnsdsxuq Ncspfx Ah Uow

Condition: ready for operation (used), Year of construction: 1985, Immediately available ex location: VDF Boehringer L & Z Sliding Bed Lathe Hedpfx Ahexud R He Uenw Type: V 800 SB Year of manufacture: 1985 Centre height: 400 mm Swing over bed: 800 mm Spindle bore: 128 mm Drive power: 30 kW Spindle speeds: 24 – 1120 rpm Workpiece weight between centres: 4,000 kg Swing with bed slid in the offset: 1,800 mm Swing with bed slid: 1,800 mm turning diameter Swing over short cross-slide: 575 mm Swing over long cross-slide: 515 mm Weight: 13 t Lots of accessories: chucks, faceplates, Multifix tool holders, inserts Price: €17,500.—plus VAT, ex location

Condition: good (used), Centre height: 290 mm Swing over bed: 580 mm Centre distance: 3000 mm Equipped with a flat belt grinder, e.g. for shaft or pipe grinding Hodpfx Asxtu Eroh Ujnw Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: ready for operation (used), Year of construction: 1985, turning diameter over cross slide: 290 mm, spindle bore: 58 mm, turning diameter: 520 mm, center width: 1,000 mm, spindle speed (max.): 2,000 rpm, Heidenhain digital readout, 2 axes Capacity: 1000x520 mm, 290 mm on cross-slide Hsdpfx Ahexr E Hde Usnw Spindle bore: 58 mm Multifix turret type C

Condition: good (used), Year of construction: 2012, 750mm Swing, 500mm max. machining diameter, 1300mm max turning length, 3000rpm main spindle, 65mm bar capacity, Hodpfoxqyg Nox Ah Usnw 8,000rpm milling 20kW, C axis 0.001 degrees, Y axis - 90/+120mm, 40 station ATC, , milling speed 4,000rpm, 30kW spindle motors, FANUC 31i control, 3 Jaw Power Chuck, Swarf Conveyor, Coolant, tool setter, parts catcher, barfeed unit.

Condition: new, Year of construction: 1970, turning diameter over bed 540 mm turning diameter over slide rest 365 mm turning length 2000 mm turning diameter in the gap 800 mm turning speeds 18 - 1400 U/min centre height 270 mm spindle bore 90 mm total power requirement 11,0 kW weight of the machine ca. 2,6 t dimensions of the machine ca. 3,7 x 1,4 x 1,8 m - Multifix Size B - 3-Jaw Chuck 315mm - Chuck Guard - Emergency Stop Device - Foot Switch - Chip Tray - Centering Center Hjdpfxexpiz Te Ah Uenw

Condition: ready for operation (used), turning diameter over cross slide: 800 mm, turning diameter: 800 mm, turning diameter over bed slide: 560 mm, Center Lathe VDF V6 Hedpsxpilljfx Ah Ujnw Distance between centers: 5000 mm Turning diameter: Over guides: 800 mm Over carriage: 560 mm Spindle speed: 560 rpm Motor power: 11 kW Accessories: Steady rests: 330 mm and 420 mm

Condition: repair required (used), Type: DA 260F /2 Machine No.: 007 233 /01 Year of manufacture: 1990 Technical data: Centre distance: 2000 mm Centre height: 260 mm Hnodpjxpgrcsfx Ah Ujw Spindle bore: 71 mm Drive power: 7.5 kW Current condition: - Machine bed is in good condition - Frequency converter does not work – the machine keeps shutting down; it simply stops. - Feed mechanism in the headstock needs to be repaired.

Condition: used, Year of construction: 2008, functionality: fully functional, turning diameter over cross slide: 380 mm, spindle bore: 72 mm, turning diameter: 580 mm, center height: 290 mm, turning length: 1,500 mm, bed width: 400 mm, Turning diameter in gap: 780 mm, overall weight: 3,200 kg, Centre height: 290 mm. Swing over cross slide: 380 mm. Swing in gap Ø: Ø780 mm. Distance between centers: 1500 mm. Spindlebore: 72 mm. RPM.: 25-2000 (Variable). Width of bed: 400 mm. Tail stock taper: 5 Motor: 11 kW. Digital readout: Newall C80 (X & Y). Hodoxpf D Dopfx Ah Uenw Year: 2008 Country of origin: Bulgaria. Size (L x W x H): 3100 x 1300 x 1600 mm. Weight: 3200 kg. Ø315 mm. selfcentering chuck, variable speed in 3 gears. Automatic feed and rapid speed through joystick. With quick tool changer. All our machines are tested and serviced before delivery.

Condition: used, functionality: fully functional, turning diameter over cross slide: 375 mm, spindle bore: 90 mm, turning diameter: 560 mm, turning diameter over bed slide: 560 mm, center height: 280 mm, turning length: 2,000 mm, spindle speed (max.): 1,250 rpm, spindle speed (min.): 25 rpm, bed width: 385 mm, overall weight: 3,400 kg, Centre height: 280 mm. Swing over cross slide: 375 mm. Swing in gap Ø: Ø830 mm. Distance between centers: 2000 mm. Spindlebore: 90 mm. RPM.: 25-1250. Width of bed: 385 mm. Tail stock taper: 5 Motor: 11 kW. Digital readout: Electronica EL-400 (X & Y). Country of origin:Germany. Size (L x W x H): 3650 x 1250 x 2000 mm. Weight: 3400 kg. With gap, quick tool changer, steady rest and Ø400 mm. 4-jaw independant chuck. All our machines are tested and serviced before delivery. Hsdpfexpf A Hox Ah Ujnw

Condition: used, greates pass round over bed 540 mm swing diameter over face slide 370 mm centre distance 3000 mm centre height 270 mm turning dia. in gap 815 mm bed width 344 mm spindle bore 88 mm spindle diameter in front bearing 133 mm spindle taper 11" D1 Camlock turning speed range 18-1400 U/min turning speeds 16 3-jaw chuck Röhm Ø 315 longitudinal feeds: 0,06-1,0 mm face feeds 0,03-0,5 mm metric threading 0,4-14 mm inch threading 2-72 G/1" thread - module 0,3-3,5 mm thread - DP 8-60 Pitch tailstock quill diameter 75 mm quill stroke 230 mm taper of tail spindle MK 5 slide valve travel 280 mm upper head travel 150 mm Overall size ca. 4700 x 1100 x 1400 mm Hnodpfxoxnqzxs Ah Ujw weight ca. 3200 kg power capacity 9,4 kW Accessories: 3-axis digital display Fagor Röhm wedge bar chuck Ø 315 mm Multifix steel holder size C incl. 6 interchangeable cassettes Rotating center point Turning chuck guard Rear chip guard Coolant device Work light manual available

Condition: used, Parallel Lathe CAZENEUVE type HB 575 Between points: 2000 mm Maxi Ø on bench: 575 mm Maxi Ø over saddle: 300 mm Spindle diameter: Ø 51 mm Rotation: from 20 to 1600 RPM Hnodjxnpxiepfx Ah Uew Turret TRIPAN 411 3-jaws chuck Ø 200 mm Spindle motor: 15 CV ThreadingsMetric + Whitworth Tailstock CM5 Lubricant tank Lubricant pump Supplied with 3 TRIPAN tool holders Voltage: 380 V Length: 3500 mm Width with tank: 1500 mm Total height: 1400 mm Weight: approx 3 T

Condition: used, Parallel Lathe MULLER & PESANT Between points: 2500 mm Hnjdpfxoxnpwre Ah Uow Maxi Ø on bench: 520 mm Maxi Ø over saddle: 280 mm Maxi diameter in brocken bed: 700 mm Spindle diameter: Ø 56 mm Spindle speed: from 12,5 to 1000 RPM TRIPAN Turret 3-jaws chuck Ø 250 mm Tailstock CM4 Auto feeds longitudinal + transversal Lubricant pump Voltage: 380 V Dimensions (L x W x H): 4000 x 1500 x 1600 mm Weight: approx 3,5 T

Condition: used, Parallel Lathe WMW NILES type DLZ 500 IV L 1000 Between points: 1000 mm Maxi Ø on bench: 500 mm Hnodexnpf Njpfx Ah Uew Maxi Ø over saddle: 300 mm Spindle diameter: Ø 50 mm Spindle speed: from 28 to 1400 RPM 3-jaws chuck Ø 200 mm Threadings: Metric + Whitworth Tailstock CM4 Auto Feeds transverse + longitudinal + rapid Lubricant pump Voltage: 380 V Dimensions (L x W x H): 3000 x 1400 x 1500 mm Weight: approx 2,5 T

Condition: used, Labor E275 lathe equipped with a Fagor control system In good condition, available for inspection Includes 3-jaw chuck, rests, cooling, and books Turning diameter above the bed: 550 mm Turning diameter above the slide: 375 mm Center length: 2000 mm Hnjdpfx Aexm Ugveh Usw Through diameter: 105 mm Spindle speed: 0-2500 rpm

Condition: new, Bernardo Universal Lathe Titan 560 x 3000 Pro Vario Technical Specifications Centre distance: 3000 mm Centre height: 280 mm Swing over bed: 560 mm Swing over gap: 785 mm Swing over cross slide: 350 mm Bed width: 350 mm Spindle bore: 105 mm Spindle mount: DIN 55029, D1 – 8 Speed range: 25 – 220 / 220 – 1500 rpm Longitudinal feed range (42): 0.055 – 3.061 mm/rev Cross feed range (42): 0.025 – 1.384 mm/rev Metric threads (41): 0.1 – 14 mm Inch threads (60): 2 – 112 TPI Quill diameter: 75 mm Quill stroke: 185 mm Quill taper: MT 5 Motor power: 7.5 kW (10.0 HP) Machine dimensions (L): 4340 mm Width x Height: 1150 x 1610 mm Weight: approx. 3000 kg Features • Standard with Delta frequency inverter for high torque at low speed and nearly constant speed under load • Stepless speed control, with digital speed readout • Versatile applications in general engineering, production, single-part manufacture, etc. • Removable gap bridge allows machining of large-diameter workpieces • Rapid traverse longitudinally and in cross direction as standard, reducing non-productive time • Modern main spindle bearing with precision angular contact ball bearings • The machine bed is made from a single casting, extremely torsion-resistant and low-vibration, providing the foundation for precise turning • Tailstock is adjustable for taper turning • Central lubrication system for carriage Scope of delivery • 3-axis digital readout ES-12 V with LCD display • 3-jaw chuck PS3-315 mm / D8 • Fixed steady rest – max. workpiece diameter 180 mm • Travelling steady rest – max. workpiece diameter 120 mm • Foot pedal with CE-compliant brake function • Safety guard for quick-change tool post • LED machine lamp • Initial fill with Shell Tellus 46 • Faceplate 450 mm • 2 centre points • Frequency inverter • Digital speed readout • Safety slip clutch • Rapid traverse longitudinally and in cross direction • Coolant system Hjdpfx Ahoxl Tdqs Uenw • Quick-change tool post with 4 holders • Change gears • Reducing sleeve • Chip guard tool kit

Condition: new, Bernardo Universal Lathe Titan 560 x 2000 Pro Vario Technical Specifications Center Distance: 2000 mm Center Height: 280 mm Swing Over Bed: 560 mm Swing Over Gap: 785 mm Swing Over Cross Slide: 350 mm Bed Width: 350 mm Spindle Bore: 105 mm Spindle Mount: DIN 55029, D1 – 8 Speed Range: 25 – 220 / 220 – 1500 rpm Longitudinal Feed Range (42): 0.055 – 3.061 mm/rev Cross Feed Range (42): 0.025 – 1.384 mm/rev Metric Threads (41): 0.1 – 14 mm Inch Threads (60): 2 – 112 TPI Quill Diameter: 75 mm Quill Travel: 185 mm Quill Taper: MK 5 Motor Power: 7.5 kW (10.0 HP) Machine Dimensions Length: 3340 mm Width x Height: 1150 x 1610 mm Weight approx.: 2720 kg Features • Standard with Delta frequency inverter for high torque at low speeds and nearly constant speed under load • Infinitely variable speed control, with digital readout of set speed • Versatile applications in general engineering, production, one-off manufacturing, etc. • Removable gap bridge for machining large-diameter workpieces • Standard rapid traverse in longitudinal and cross directions for reduced non-productive times • Modern main spindle bearing with angular contact ball bearings in precision design • The machine bed is cast in one piece, extremely torsion-resistant and low-vibration, ensuring a key requirement for precise turning • Tailstock offset for taper turning • Central lubrication for the carriage Scope of Delivery • 3-axis ES-12 V digital readout with LCD display • 315 mm / D8 3-jaw chuck PS3 • Fixed steady rest – max. passage diameter: 180 mm • Follow steady rest – max. passage diameter: 120 mm • Foot pedal with braking function (CE compliant) • Safety guard for quick-change toolpost • LED machine light • Initial fill with Shell Tellus 46 • 450 mm face plate • 2 live centers • Frequency inverter • Digital speed display • Slip clutch • Rapid traverse longitudinal and cross • Coolant device Hnedpfjxl Tc Tox Ah Uew • Quick-change toolpost with 4 holders • Change gears • Reducing sleeve • Chip guard • Operating tools

Condition: new, Bernardo Universal Lathe Titan 560 x 1500 Pro Vario Technical Specifications Distance between centres: 1500 mm Centre height: 280 mm Swing over bed: 560 mm Swing over gap: 785 mm Swing over cross slide: 350 mm Bed width: 350 mm Spindle bore: 105 mm Spindle mount: DIN 55029, D1 – 8 Speed range: 25 – 220 / 220 – 1500 rpm Longitudinal feed range (42): 0.055 – 3.061 mm/rev Cross feed range (42): 0.025 – 1.384 mm/rev Metric threads (41): 0.1 – 14 mm Inch threads (60): 2 – 112 TPI Quill diameter: 75 mm Quill travel: 185 mm Quill taper: MK 5 Motor power: 7.5 kW (10.0 HP) Machine dimensions: length 2840 mm; width x height 1150 x 1610 mm Weight approx.: 2420 kg Features • Supplied as standard with Delta frequency inverter for high torque at low speeds and nearly constant speed under load • Infinitely variable speed control, actual speed is displayed digitally • Versatile applications in general engineering, production, single-part manufacturing, etc. • Removable gap bridge enables machining of workpieces with large diameters • Standard with rapid traverse in both longitudinal and cross directions to reduce non-productive times • Modern main spindle bearing with precision angular contact ball bearings • The machine bed is cast in one piece, extremely torsion-resistant and vibration-damping, ensuring the necessary prerequisites for precise turning • Tailstock can be offset for taper turning • Central lubrication of the carriage Scope of Delivery • 3-axis digital readout ES-12 V with LCD display • 3-jaw chuck PS3-315 mm / D8 • Fixed steady rest – max. workpiece diameter 180 mm • Follow rest – max. workpiece diameter 120 mm • Foot pedal with brake function according to CE • Safety guard for quick-change tool post • LED machine light • Initial filling with Shell Tellus 46 • Face plate 450 mm • 2 live centres • Frequency inverter • Digital speed display • Slip clutch Hnsdsxl Tcyepfx Ah Usw • Rapid traverse longitudinal and cross • Coolant system • Quick-change tool post with 4 holders • Change gears • Reducing sleeve • Chip guard rear wall • Operating tools

Condition: ready for operation (used), turning diameter over bed 500 mm turning diameter over slide rest 310 mm turning length 3000 mm turning diameter in the gap 750 mm centre height 250 mm turning speeds 20-1000 U/min no. of turning speeds 18 spindle bore 56 mm longitudinal feed 0,045-1,09 mm/U face feed 0,025-0,625 mm/U number of feeds 55 total power requirement 4 kW weight of the machine ca. 2,37 t dimensions of the machine ca. 4,9 x 1,1 x 1,3 m Hjdpoxl E Saefx Ah Uenw

Condition: new, Bernardo Production Lathe Goliath 500 x 2000 Technical Specifications Distance between centers: 2000 mm Center height: 250 mm Swing over bed: 500 mm Swing over gap*: 720 mm Swing over cross slide: 310 mm Bed width: 400 mm Spindle bore: 80 mm Spindle mount: DIN 55029, D1-8 Spindle speed range (24): 9 – 1600 rpm Longitudinal feed range (80): 0.063 – 6.43 mm/rev Cross feed range (80): 0.027 – 2.73 mm/rev Metric threads (46): 1 – 224 mm Inch threads (44): 1/8 – 28 tpi Quill diameter: 75 mm Quill stroke: 150 mm Quill taper: MT 5 Motor power: 7.5 kW (10.0 HP) Machine dimensions (W x D x H): 3520 x 1240 x 1550 mm Weight approx.: 3375 kg * Removable gap section: 200 mm Features • Versatile applications in general mechanical engineering, production, single-part manufacturing, etc. • Machine bed cast in one piece is extremely torsion-resistant and low in vibration, providing the essential requirement for precise turning • Modern main spindle bearing with precision angular contact ball bearings • Central, user-friendly control for feeds and threads, with lead and feed screw • Rapid traverse for longitudinal and cross feeds as standard, to reduce auxiliary times • Large dimensioned, hardened, and precision-ground gears • Removable gap bridge allows machining of large-diameter workpieces • Sliding tailstock for taper turning, handwheel with adjustable fine scaling (0.02 mm) • Electromechanical foot brake to minimize non-productive time • Excellent machining performance also in facing operations Scope of delivery • Slip clutch • Rapid traverse, longitudinal and cross • LED machine lamp Hjdpoxl D Aqjfx Ah Ujnw • 3-axis ES-12 V digital readout with LCD display • 3-jaw chuck PS3-250 mm / D8 • Faceplate 400 mm • Fixed steady rest – max. passage diameter 200 mm • Traveling steady rest – max. passage diameter 110 mm • 1 live center / 1 revolving center • Motor with magnetic brake, CE-compliant • Foot pedal with brake function, CE-compliant • Initial fill with Shell Tellus 46 • Coolant system • Quick-change toolpost with 4 tool holders • Safety guard for quick-change toolpost • Reducing sleeve • Chip guard • Service tools

Condition: new, Bernardo Goliath 500 x 1500 Production Lathe Technical Specifications Centre distance: 1500 mm Centre height: 250 mm Swing diameter over bed: 500 mm Swing diameter over gap*: 720 mm Swing diameter over cross slide: 310 mm Bed width: 400 mm Spindle bore: 80 mm Spindle mount: DIN 55029, D1-8 Speed range (24 steps): 9 – 1600 rpm Longitudinal feed range (80 steps): 0.063 – 6.43 mm/rev Cross feed range (80 steps): 0.027 – 2.73 mm/rev Metric threads (46): 1 – 224 mm Inch threads (44): 1/8 – 28 TPI Quill diameter: 75 mm Quill stroke: 150 mm Quill taper: MT 5 Motor power: 7.5 kW (10.0 HP) Machine dimensions (L x W x H): 3020 x 1240 x 1550 mm Weight approx.: 3285 kg * Removable gap bed section length: 200 mm Features • Versatile applications in general mechanical engineering, production, single-part manufacturing, etc. • One-piece cast machine bed ensures maximum rigidity and minimal vibration, providing the essential prerequisite for precise turning • Modern precision angular contact ball bearing spindle bearings • Central, user-friendly feed and thread control, with lead and feed shafts • Rapid traverse in longitudinal and cross directions as standard to reduce idle time • Large-dimension, hardened and precision-ground gears • Removable gap bridge allows machining of large-diameter workpieces • Adjustable tailstock for taper turning, handwheel with fine graduation (0.02 mm) • Electromechanical foot brake to minimise non-productive time • Excellent cutting performance, even during facing operations Scope of delivery Hnjdpjxl D Akefx Ah Ujw • Slip clutch • Rapid traverse longitudinal and cross • LED machine lamp • 3-axis digital readout ES-12V with LCD display • 3-jaw chuck PS3-250 mm / D8 • Face plate 400 mm • Fixed steady rest – max. through diameter 200 mm • Follow rest – max. through diameter 110 mm • 1 live centre / 1 revolving centre • Motor with magnetic brake as per CE standards • Foot pedal with brake function as per CE • Initial fill with Shell Tellus 46 • Coolant system • Quick-change tool post with 4 holders • Safety device for quick-change tool post • Reducing sleeve • Chip guard (rear) • Operating tools
