Passform Holztechnik GmbH

Condition: used, Year of construction: 1985, Used machine Year of manufacture: 1985 Universal dowel drilling machine with swiveling drilling unit with fully automatic control with 2 safety pneumatic clamps Lsdpoyvl Hzefx Ab Ejri Drill motor 2.2 kW with 21 spindles Spindle pitch: 32 mm with attached oil damper Height adjustment: 80 mm Drilling depth: 80 mm Weight: 420 kg Availability: short notice Location: Röllbach

Condition: used, Year of construction: 1984, Dowel boring machine Year of manufacture: 1984 Suitable for: Row drilling Cabinets Fittings Lrodoyulftepfx Ab Eoi Frames Standard swiveling device Max. passage: 820 mm Working width: 704 mm 23 drilling spindles; 32 mm spacing; drill attachment with M 10 thread, left and right Max. drill diameter: 40 mm Drilling depth horizontal: 120 mm Vertical: 80 mm Max. clamping height: 92 mm Motor power: 2.2 kW Air consumption at 6 bar approx. 6 l per cycle Weight approx. 340 kg Availability: short-term Location: Flörsheim

Condition: excellent (used), DB5 dowel hole drilling machine & row drilling machine - 21 drilling spindles - 32mm spindle pitch - 380 volts - 2.2 kW - Dimensions: length 1400mm x depth 900mm x height 1300mm Lrjdpeytvarsfx Ab Eoi - 2 pcs longitudinal stops

Condition: repair required (used), Year of construction: 1998, functionality: limited functionality, 2 drilling spindles, individually selectable 1 glue gun (note: glue pump missing) Dowel insertion tool for 8 x 40 mm dowels Ljdpfoytq R Eox Ab Eeri The following issues were identified during testing: - Glue specification missing - Center stop rule missing - On the left working field, the front stops do not engage; instead, they lower when drilling on the right field - SPS module Beckhoff repeatedly fails. Machine must then be restarted. - Rubber pads under the hold-downs are missing. When inserting the dowels, the parts deform because the surface is too smooth

Condition: used, Year of construction: 2014, complete in standard configuration with: - Fully automatic electronic control with foot pedal for clamping-drilling-unclamping, electric jog operation, - Automatic return of the drilling unit after reaching the preset drilling depth - Automatic extension of drilling depth when end-grain drilling saves the need to adjust drilling depth from flat to end-grain drilling. (+10 mm, e.g. with dowel length 35 mm, drilling depth flat side 14 mm, drilling depth end-grain 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drill feed 0-70 mm) incl. 21 quick-change chucks (Ganner system) for easy bit changes. - Simple swiveling of the drilling unit from 0° to 90°, supported by gas cylinder. - 1 clamping beam, movable in Y-axis with 3 pneumatic clamping cylinders, for workpiece height up to max. 80 mm. - Ideal stop system consisting of: - 1 stop fence 1800 mm for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops, with quick-change system, easily swappable from right to left for mirror-image shelf drilling in carcass constructions, also suitable for line boring in System 32. - Side stops and position settings, as well as drilling height position via support table using mechanical digital counters. - Side stops can be easily swiveled away, for the quickest changeover from carcass to frame and line boring. - Clamping arms for clamping beam designed for line boring positions up to max. 300 mm. - Ideal three-stage... Weight: approx. 400 kg gross, approx. 350 kg net. Dimensions (L x W x H): 1.35 m x 1.25 m x 1.40 m Equipment: 1 extraction hood, dust tested, ø 120 mm. 1 set for line boring in System 32 complete with: 1 base fence 1050 mm (aluminum profile 40x40 mm), 1 setting gauge for line boring. 1 frame dowel device complete with: 1 center stop, 1 round stop rod 850 mm long, 2 stops. Location: Nattheim. Lrsdpfx Ajyrqubjb Eoi

Condition: used, Used machine Lrodpoyq T Iujfx Ab Esi Equipment and technical data: - Universal dowel drilling machine for horizontal and vertical drilling - Working width 720 mm - With drilling beam, drive motor 3 HP, 2800 rpm - 23 drilling spindles, drilling pitch 32 mm - Pneumatic workpiece clamping via foot pedal - 2 stop rails 1000 mm - with undercarriage Availability: short-term Storage location: 63934 Röllbach

Condition: used, Year of construction: 2016, working length 20-1250 mm working width 50-800 mm working thickness 10-60 mm Lrsdpfsym Rqrsx Ab Eei cnc controlled in X / Y / Z 3 spindle drilling head machine without the gluing pump

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, The HOMAG WEEKE OPTIMAT ABD 150 is a high-performance CNC machine designed for precise drilling, dowel insertion, and hardware fitting in furniture production and panel processing. This machine is ideal for cabinet makers, furniture manufacturers, and industrial woodworking operations requiring accurate and efficient automated processing. The machine features: CNC-controlled drilling and inserting unit Lrsdpfx Ajym Nvtsb Eji Integrated glue and dowel insertion system Robust industrial construction Compact footprint Easy-to-use control panel CE certified The machine has been regularly maintained and is ready for operation.

Condition: used, Year of construction: 2017, functionality: fully functional, feed length X-axis: 1,200 mm, feed length Y-axis: 800 mm, feed length Z-axis: 45 mm, drilling depth: 45 mm, type of input current: three-phase, compressed air connection: 7 bar, input voltage: 400 V, workpiece height (max.): 45 mm, operating pressure: 7 bar, input frequency: 50 Hz, input current: 10 A, The KOCH SPRINT-PTP Basic is a high-precision CNC point-to-point drilling and dowel insertion machine designed for efficient production in furniture and cabinet manufacturing. Built in 2017 by the renowned German manufacturer KOCH Maschinenfabrik, this machine ensures reliable and accurate drilling, gluing, and dowel insertion operations. It is ideal for small to medium-sized woodworking companies looking to automate and increase productivity in carcass and panel production. The machine features a horizontal drilling unit with dowel vibration system, glue injector, and four horizontal clamps with central zero positioning for precise workpiece alignment. The mechanical Z-axis readout allows accurate depth control. Equipped with a 15” screen and Windows (7) -based control system, the machine offers user-friendly operation and easy programming. Technical Data Working range X-axis: 20 – 1200 mm Working range Y-axis: 110 – 800 mm Lsdpfx Absylhkae Esri Working range Z-axis: 14 – 45 mm Power: 5 kW Voltage: 400 V Frequency: 50 Hz Max. current: 10 A Compressed air requirement: max. 7 bar Year of manufacture: 2017 The machine is in good working condition.

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 432.08.202.22, drilling depth: 70 mm, input voltage: 400 V, pressure: 8 bar, input frequency: 50 Hz, power: 1.5 kW (2.04 HP), The FD 921 is equipped with 21 drilling spindles set at a 32 mm pitch. Drill bits up to a diameter of 35 mm can be used for drilling dowel holes, line bore holes, and cup hinges. The large cast iron table, side stops, pneumatic workpiece clamps, and ergonomic controls make the FD 921 a premium dowel boring machine. Further technical data: Number of drill heads: 21 (11 right-hand, 10 left-hand rotation) Lrjdpfx Aeyf A N Deb Esi Axis distance between drill heads: 32 mm Max. workpiece size: 850x3000 mm Max. workpiece height: 65 mm Required air pressure: 6-8 bar Accessories: - 11 tool holders with 5 mm right-hand dowel drill bits - 10 tool holders with 5 mm left-hand dowel drill bits - Positioning system for side stop with 8 stops - Additional pneumatic clamps - Mitre stop for FD 21 - Bracket for side stops and further accessories - Gauge for transferring the position of the cast stops - Coupling system for table extension

Condition: good (used), Year of construction: 2008, functionality: fully functional, Used machine Lrsdpfx Ajx Tcwleb Eoi WEEKE ABD 250 - Year of manufacture: 2008 - Availability approx. March/April 2026 - Automatic dowel insertion with glue - 3 horizontal drilling spindles - 3 vertical drilling spindles - Maximum workpiece dimensions: 2500/800/60 mm

Condition: good (used), functionality: fully functional, Swing type row drilling machine, 19 spindles, pneumatic clamping Ledpfjx Rbklsx Ab Esri

Condition: used, Year of construction: 2023, New exhibition machine: List price €4,271 net Standard equipment: - Thread cutting device - Control panel with OLED display - Robust, high-quality drill head cover with ergonomically angled front - LED lighting - Quick-adjust and ergonomic drilling depth stop - Continuously variable speed control via central rotary knob - Emergency stop mushroom button - Thermal overload protection - Spindle stop - Drill guard with electrical interlock - Connection cable with Schuko plug - 3-year warranty for single-shift operation Technical data: Spindle: B16 Drilling depth (mm): 60 Maximum thread cutting capacity (depending on pitch): up to M10 Digital speed display Digital drilling depth display Drilling depth stop: positive-locking ring Manual feed Table height adjustment via rack and pinion Motor: Three-phase, frequency-controlled Power supply: 230 V (kW): 0.54 Continuous/normal drilling capacity (mm): 13/15 (in E335/ST60) Throat (mm): 220 Column diameter (mm): 70 Usable table surface (W x L) (mm): 300 x 250 Distance spindle – work surface (mm): max. 750 Center offset (mm): 20 T-slot size, spacing (mm), number: 2, 125 Dimension width (mm): 13/26 Spindle speed stepless electric (rpm): 40–4,000 Machine dimensions (mm): Without safety cover: 420 x 540 x 1,780 Lrsdpfox Hwp Njx Ab Eji With safety cover: 572 x 936 x 2,142 Weight (kg): 85 Incl. drilling package 1 #296590: Machine vice Flott [felix] 2.0 80 and quick-release drill chuck 1–13 mm (accuracy 0.17 mm) Location: Rieth

Condition: used, Year of construction: 1977, operating hours: 250 h, functionality: fully functional, machine/vehicle number: 704384, drilling depth: 80 mm, total length: 1,500 mm, total height: 1,200 mm, overall weight: 640 kg, drill spindle length: 100 mm, compressed air connection: 5 bar, working width: 1,200 mm, height adjustment type: mechanical, space requirement width: 1,200 mm, pressure: 5 bar, power: 4.4 kW (5.98 HP), Machine in excellent condition. Inspection by appointment. Lredpfx Abox Dbg Re Esi

Condition: ready for operation (used), Year of construction: 1979, functionality: fully functional, compressed air connection: 5 bar, From business closure Schleicher dowel drilling machine DBS 1000 Year of manufacture: 1979 Also ideal for line boring with 5mm holes, 32mm spacing Comes with 25 pcs. 5mm carbide-tipped brad point drills and 8mm carbide drills, Ledpfxox Avf Ss Ab Eeri as well as 16mm and 35mm drill bits for cup hinges and other drill bits Pneumatically tiltable to horizontal/vertical position Machine is mobile Payment in cash upon collection No warranty

Condition: used, Year of construction: 1981, Used machine Year of manufacture: 1981 Universal dowel boring machine with a swiveling drilling unit with fully automatic control with 2 safety pneumatic clamps Drilling gearbox motor 2.2 kW with 21 spindles Spindle pitch 32 mm with built-in oil damping Lrsdpfx Absxx D D Ie Eei Height adjustment 80 mm Drilling depth 80 mm With chassis Weight 420 kg Availability: short-term Location: Flörsheim

Condition: like new (used), DEMONSTRATION MACHINE For sale is a Felder FD-21 dowel boring machine. The machine is in use in our showroom and is therefore in mint condition. Lrsdpfx Aexxi T Ueb Eei Technical data: - Version with 21 spindles - 2 hold-down clamps - 2 stops, each 1.5 m, for line boring - 2 side stops with reading optics - Indexing system for side stop with 8 positions - Motor power: 2 HP - Year of manufacture: 2025 The machine is located in A-5431 Kuchl and can be inspected and picked up during our opening hours at any time. Subject to prior sale! Related terms: dowel milling machine, drilling machine, line boring Reference: R-A0117

Condition: used, Year of construction: 1997, Used machine Lrjdpfx Asxwz Ihjb Eoi Year of manufacture: 1997 Condition: well-maintained Equipment and technical data: - Number of drilling spindles: 21 pcs, 32 mm pitch - Drilling direction: from below and end-face - Swivel: 0–90 degrees via handwheel - Pneumatic material clamps: 3 pcs - Passage: max. 100 mm height and max. 640 mm width - Motor: 1.5 kW - Extraction connection diameter: 120 mm - Includes a variety of stops (see pictures) Availability: approx. mid-April 2026 Storage location: Hesse

Condition: used, Year of construction: 2018, 1 x CNC-CONTROLLED DRILLING, GLUING AND DOWEL INSERTING MACHINE GANNOMAT "INDEX 130 PRO" (with options as Index 180 Pro) 400V, 3Ph, 50Hz complete in standard design with: - Support with linear guide consisting of: 1 x single-spindle horizontal drilling unit, 1.1 kW motor, tool speed selectable via operator software (3000/5000/8000 rpm) 1 x blow-out, gluing and dowel inserting station in reinforced design for dowels Æ 8 mm, dowel length 30 mm - fully automatic, electronically controlled central lubrication - X-axis NC controlled, with working length 1300 mm, travel speed max. 78 m/min. - Z-axis, position via support table 5-40 mm programmable with NC-controlled Z-axis option - Dowel driving overhang of 7-20 mm, programmable with NC-controlled Y-axis option, drilling depth of 0-35 mm (with drill length GL 70 mm) is automatically set with driving overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GL/WATER selector switch for rinsing the glue system, 1 stainless steel container each for 5 kg glue and 5 l water - Control lamp for residual glue quantity display in the glue container - 1 side stop left, 1 side stop right and 1 center stop (all removable) - 4 start buttons for individual working with 1-4 workpieces - 4 pcs. Pneumatic inclined clamping cylinder 10° for workpiece thicknesses up to max. 80 mm, workpiece length (Y) min. 70 mm - 1 pc. suction funnel, connection Æ 80 mm - 1 pc. TCT control with: built-in industrial PC, incl. Soft PLC type Beckhoff TWINCAT, operating temperature range 0-50°C, TFT industrial display 15" resistive touchscreen, resolution 1024 x 768, CPU 2 GHz, 256 MB RAM, 2x network interface adapters, IDE hard disk, 4x USB rear, 1x USB front, operating system: WINDOWS 7 - programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE or GRID dimensioning, automatic workpiece mirroring and work step optimization, 4 work fields can be assigned with different programs, graphic workpiece display, parametric programming, 0-point shift, programmable work lists, error diagnosis with plain text OPTIONS: 1 electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 glue nozzle 4 vertical inclined clamping cylinders 10° with holder, additionally, (total 8 clamping cylinders) 1 surcharge for machine bed length 1800 mm with working length 1800 mm 1 surcharge for: 1 horizontal drilling unit, motor 1.5 kW, with multi-spindle drilling head with 3 individually controllable drilling spindles, pitch 32 mm arranged in X-axis, tool speed 3000 rpm. (The standard working length is not reduced) 1 Y-axis NC-controlled, with recirculating ball screw and dynamic traversing speed of 300 mm/sec. The dowel driving overhang 7-30 mm and the drill hole depth 0-42 mm can be programmed via software. (with drill length GL 77 mm) for vertical drilling unit drilling from TOP, Y-axis position 5-42 mm 1 surcharge Y-axis NC-controlled position 5-62 mm instead of 5-42 mm 1 surcharge for: 1 vertical drilling unit drilling from TOP, motor 1.5 kW, with multi-spindle drilling head with 3 individually accessible drilling spindles, 32 mm pitch arranged in X-axis, tool speed 3000 rpm. Y-axis position 5-42 mm, workpiece length (Y) min. 130 mm, (the standard working length is not reduced) 1 Z-axis NC-controlled, with K Lrodoxwaz Hjpfx Ab Eji

Condition: ready for operation (used), Year of construction: 1994, functionality: unexamined, Pneumatic drilling stroke Pneumatic workpiece clamping 2 tables, each 500 x 280 mm Tables inclinable 2 drilling motors, each 2.2 kW 2 drilling gearboxes, each with 6 spindles Spindle distance: 25/35/40/47/52 mm Digital display for width adjustment Lsdpfsxu Ecksx Ab Eeri Weight approx. 400 kg

Condition: not inspected (used), Year of construction: 1977, functionality: unexamined, Max. working width: 740 mm Max. pass-through width: 820 mm Motor: 2.2 kW 23 drilling spindles Horizontal drilling depth: 120 mm Vertical drilling depth: 80 mm Ledpfjxuggwsx Ab Eeri Weight: approx. 350 kg

Condition: used, Year of construction: 1999, functionality: fully functional, overall weight: 600 kg, number of spindles: 21, SCM MB 63 multi-spindle drill, 21 spindles, 1.5 kW power, fully functional Lrsdpfx Aboxqx U Ee Esi

Condition: used, Year of construction: 2024, Dowel Hole Drilling Machine GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW" complete in standard configuration, equipped with: - Fully automatic electronic control with pulse operation via foot pedal for clamp-drill-release sequence, including electrical skip operation. - Automatic return of the drilling unit after reaching the preset drilling depth. - Automatic drilling depth extension for end-face drilling. This saves the need to adjust the drilling depth when switching from flat-face to end-face drilling (+10 mm, e.g., with dowel length 35 mm, flat-face drilling depth 14 mm, end-face drilling depth 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drilling feed 0-70 mm). Includes 21 quick-change chucks (Ganner system) for easy drill bit changeover. - Easy pivoting of the drilling unit from 0° to 90°, assisted by gas cylinders. Ledpsxnlflofx Ab Eori - 1 clamping beam movable on Y-axis with 3 pneumatic clamping cylinders, for workpieces up to max. 80 mm height. Ideal fence system consisting of: - 1 stop ruler, 1800 mm, for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops. - Quick-change system, easily switchable from right to left stop for mirrored drilling of shelves in carcass construction; also suitable for line boring in system 32. - Side stops and position adjustments, as well as drilling height position, via mechanical digital counters on the support table. - Side stops can be easily folded away for fastest set-up change from carcass to frame or line drilling. - Clamping arms for the clamping beam enable line boring positions up to max. 300 mm. - Optimized three-stage tool system. Includes 1 set of dowel drill bits: - 5 carbide dowel bits, Ø 8x77 mm, right - 4 carbide dowel bits, Ø 8x77 mm, left Basic machine Dowel Hole Drilling Machine GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW" complete in standard version, equipped with: - Fully automatic electronic control with pulse operation via foot pedal for clamp-drill-release, electrical skip operation. - Automatic return of the drilling unit after reaching the preset drilling depth. - Automatic extension of drilling depth for end drilling saves the need to adjust depth when switching from flat to end drilling (+10 mm, e.g. for dowel length 35 mm, flat-side depth 14 mm and end-side depth 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drilling feed 0-70 mm). Includes 21 quick-change chucks (Ganner system) for easy drill changeover. - Easy pivoting of the drilling unit from 0° to 90°, gas spring assisted. - 1 clamping beam, Y-axis adjustable, with 3 pneumatic clamps for workpieces up to max. 80 mm high. - Ideal stop system comprising: - 1 stop ruler, 1800 mm, for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops, quick-change system, easily switched from right to left for mirrored shelf drilling in carcass constructions, also usable for line boring in system 32. - Side stops and adjustable positions, as well as drill height position, via mechanical digital counters on the support table. - Side stops can be folded away easily for shortest retool time from carcass to frame and line boring operations. - Clamping arms for the clamp beam suitable for line-boring positions up to max. 300 mm. - Three-stage optimized tool system. Extraction funnel, dust tested, Ø 120 mm 1 set for line boring in system.

Condition: like new (used), functionality: fully functional, Dübellock drilling machine Ayen 23, complete equipment, partly new drill bits Ledpfxjxg N Dpe Ab Eori

Condition: good (used), Year of construction: 2007, functionality: fully functional, NC-controlled drilling and dowel-inserting machine Manufacturer: Weeke Model: Optimat ABD 150 Year of manufacture: 2007 Workpiece dimensions: Length: 20 - 1250 mm Width: 100 - 800 mm Thickness: 10 - 60 mm Active center stop: maximum length 600 mm Equipment: - Horizontal drilling unit with 3 individually selectable spindles, spindle pitch 32 mm - 1 dowel insertion unit (spaced 32 mm from the first drilling spindle) - Glue nozzle with adjustable glue output - Glue flow monitoring - Mist oiler for glue nozzle Lredpfxoxdl Rae Ab Eji - Standard dowel sizes: 8x30 mm / 8x35 mm - Vibratory feeder for automatic dowel feed 1. BASE MACHINE - Rigid welded steel frame construction - Axis travel in X, Y, and Z directions - Ball screw drives (Y- and Z-axis) and rack and pinion drive (X-axis) - Digital AC servo motor - Support table with left and right side stops and rear fence - Pneumatic center stop, manually actuated via selector switch - 6 overhead pneumatic clamps, manually adjustable - Centralized lubrication system power control PC85T Modern control system based on Windows PC
