TGW belt conveyor belt transfer GF 3520-490-360

TGW

Condition: used, Year of construction: 2004, Curved roller conveyor, curved track, curved roller conveyor, curved roller conveyor, curved roller conveyor, roller curve, curved conveyor with drive, roller conveyor -Manufacturer: TGW, Curved roller conveyor without drive -Rolls: Ø 50/77 mm, width up to 410 mm -Transport dimensions: 1490/480/H190 mm -Weight: 33 kg Gjdpfxer Htngs Achsiw

Condition: good (used), functionality: fully functional, roll diameter: 50 mm, roll width: 600 mm, roll pitch: 60 mm, total width: 680 mm, total height: 120 mm, total length: 2,975 mm, conveying length: 2,975 mm, construction width: 680 mm, construction height: 120 mm, Item no.: 1000003760 Inclined roller conveyor, powered - 3,000 mm Technical data: Manufacturer: TGW Year of construction: 2006 Overall dimensions: approx. 2,975 x 680 x 120 mm (LxWxH) Width incl. cheek: 680 mm Gedpfsiaugyjx Achoiw Side panel height: 115 mm Width incl. drive: 680 mm Conveyor length: 2,975 mm Conveyor width: 600 mm Roller type: Steel Rollers per axle: 1 piece Roller pitch: 60 mm Roller diameter: 50 mm Drive type: Flat belt Motor: Gear motor Motor data: SEW, 0.37 kw, 50 Hz Conveying speed: 0.48 m/s, constant Special features: Inclined roller conveyor on the left in the direction of travel Condition: Used / fully functional Function test: OK OPTIONAL: Supports (height freely selectable), side guides, emergency stop button, frequency converter

Condition: excellent (used), Year of construction: 2004, Curved roller conveyor, curved track, curved roller conveyor, curved roller conveyor, curved roller conveyor, roller curve, curved conveyor with drive, roller conveyor -Manufacturer: TGW, Curved roller conveyor ZKRF in-out-KRF with drive -Rolls: Ø 50/77 mm, width up to 410 mm Giedpor Htm Rsfx Achsw -Speed: 30 m/min -Drive: SEW-Eurodrive 0.37 kW, see photo nameplate -Transport dimensions: 2120/480/H300 mm -Weight: 93 kg with pallet

Condition: used, quantity 23 Set Various grooving cutters for sale as a set Hünnema: -> 1x GH7 - 15° Ø18-20 -> 4x 6P9 - 15° Ø18-19 - A54W -> 1x 5P9 - 15° Ø15-17 - A34 WGW: -> 4x 5P9 - Ø13-15 - W50 Gedpfx Acszf Npijhsiw TGW: -> 4x 4P9 - Ø13-15 - W50 -> 1x 5P9 - Ø16-17 - W53 -> 8x 6P9 - Ø18-19 - S54

Condition: used, Year of construction: 2012, TGW curves roller conveyors 45° left Order no. 150072 Item 03.0721 year of manufacture: 2012- working width: 345 mm plastic rollers working width: 400 mm metal rollers total width: 480 mm inner radius: 1050 mm speed: 0.45 m / sec lateral guide on both sides Rollers: conical plastic molded rollers: Metal Optional: 3 supports Shipping dimensions: Lxwxh 2200 x 800 x 400 mm: 90 kg Für eine individuelle, fachmännische Beratung setzten Sie sich einfach mit uns in Verbindung. Kontaktieren Sie uns einfach telefonisch oder per Mail. Wir helfen Ihnen gerne bei der Planung und Umsetzung Ihrer Projekte. Wir freuen uns darauf von Ihnen zu hören. Gijdpsk Aa Nqofx Achjw Mit freundlichen Grüßen Ihr Team der Dr. Sonntag GmbH & Co. KG Ihr Spezialist und Ansprechpartner für Intralogistik

Condition: good (used), Year of construction: 2014, Over 4,000 m of conveying system technology, TGW, nominal width (NB) mostly 470 mm and also 620 mm – used. Price ex works (net): only €525,000, disassembled, packed, and loaded, including feet, etc.! Price for larger portions available upon request! Manufacturer: TGW Year of manufacture: 2014 Components, e.g.: BFT2000 KRF curved roller conveyor BFT2000 ZKRF infeed/outfeed curved roller conveyor BFT2000 RFM roller conveyor multi BFT2000 GF belt conveyor BFT2000 ART all-round roller table Internal chute BFT2000 RB roller track BFT2000 PAS pop-up sorter BFT2000 ZAS timing belt infeed/outfeed module BFT2000 KUS chain transfer unit Gisdpfx Ajzbyb Aschew Some Transnorm belt curves, 180 degrees, approx. 6-7 pieces with a relatively small radius Optionally including 2 lifters Sale without control system (light barriers, sensors, scanners, control cabinets, etc.), but these are available for an additional charge! Condition: good Available: from Q4 2026 Location: Hamburg P.S. Upon request, we will gladly send you the 396-page product list or a shorter AI summary!

Condition: used, Year of construction: 2000, TGW Roller Conveyor 2400-475-420 Giodsxv Hayopfx Achow RA2436 Make: TGW Year of manufacture: 2000 Roller width (RB): 420 mm Nominal/outer width (NB): 475 mm Module length: 2400 mm Diameter rollers: 50 mm Distance between rollers: 75 mm frame height: 115 mm 40 modules available. Optional: Drive station with deflection supports Side guide adapted conveyor speed range with frequency converter Price plus VAT ex central warehouse Dr. Sonntag GmbH & Co. KG 97076 Würzburg For individual, expert advice, simply get in touch with us. Simply contact us by phone or email. We will be happy to help you plan and implement your projects. We look forward to hearing from you. With kind regards Your team at Dr. Sonntag GmbH & Co. KG Your specialist and contact for intralogistics

Condition: used, Year of construction: 2012, TGW alignment conveyor inclined roller conveyor 1750-475-420 RA2406 Make: TGW Year of manufacture: 2012 Roller width (RB): 420 mm Nominal/outer width (NB): 475 mm Length: 1750 mm Diameter rollers: 50 mm Distance between rollers: 60 mm Roller conveyor motor: SEW drive motor Godpfxowhtcze Achjiw frame height: 130 mm Conveyor speed: contact us Angle rollers: ca. 5° Optional: supports Side guide adapted conveyor speed range with frequency converter Price plus VAT ex central warehouse Dr. Sonntag GmbH & Co. KG 97076 Würzburg For individual, expert advice, simply get in touch with us. Simply contact us by phone or email. We will be happy to help you plan and implement your projects. We look forward to hearing from you. With kind regards Your team at Dr. Sonntag GmbH & Co. KG Your specialist and contact for intralogistics

Condition: good (used), Year of construction: 2011, AKL, TGW with 3 Mustang stacker cranes, 22,756 storage locations, container size 60 x 40 x 35 cm – used - : Price ex location: only €99,500 (net), plus dismantling and additional costs! Manufacturer: TGW Type: AKL Year of construction: 2011 Device type: Mustang stacker crane Number of stacker cranes: 3 units Aisles: 3 System dimensions (L x W x H): 64 x 13 x 7.90 m Storage locations: 22,756 Payload: 50 kg per container Load units (max. dimensions): 600 mm x 400 mm x 350 mm Double-deep storage Condition: good Available: immediately Location: Würzburg area Plan available as DWG file – further technical documentation also available Mustang Stacker Crane Base unit: The single-mast Mustang stacker crane is designed for automated storage and retrieval of containers in a high-bay or flow-through warehouse. This storage system can also be utilized for supplying workstations on assembly lines. Device type combination Mustang_L HS 7.8m & 1 KTC (6x4 2L 2x50kg) // Mustang_L HS & KTC (6x TGW Total weight (incl. payload): 1,665 kg Lifting load total (incl. payload): 396 kg Payload (incl. load handling device): 100 kg Travel speed in x: 4.80 m/s Travel acceleration in x: 2.80 m/s² Travel deceleration in x: 2.80 m/s² End positioning time in x: 1.5 s Lifting speed in y: 3.00 m/s Lifting acceleration in y: 3.00 m/s² Lifting deceleration in y: 3.00 m/s² End positioning time in y: 0.5 s Dwell time: 1.0 s Theoretical operating cycle time: 56.2 s Crane cycles: 58 per hour Gsdoyhxm Ijpfx Achjiw Conveyed and stored goods FLG 2: Load handling devices (LHM): Plastic trays, occasionally loaded with cartons or containers Dimensions L x W x H: 600 mm x 400 mm x 350 mm Possible overhangs included: max. 5 mm Total weight: min. 2 kg / max. 50 kg per LHM Load: plastic parts Special features: Load handling devices have a flat, smooth, dry, oil- and grease-free bottom. The maximum deflection at total weight as stated is 5 mm. These carriers are placed on only 3 levels. Equipment performance Stacker crane: 122 putaway and retrieval cycles per hour in double cycle mode, including 61 relocations in accordance with FEM 9.851 Lifter: 210 containers/hour from top to bottom and 210 from bottom to top Availability: The guaranteed system availability after successful commissioning is 98%, in accordance with FEM 9221 and 9222.

Condition: excellent (used), Belt conveyors available immediately – ISC RECYCLE We offer several used belt conveyors, refurbished and in very good condition, available immediately for your intralogistics projects. Ideal for: • Order picking lines • Automated conveying • Facility expansions • Optimization of logistics flows Available equipment: Belt conveyors • Usable width: 430 and 660 mm • Length: 2365 to 4695 mm • Very good condition Possibility of integration with: • Power cabinet • Control cabinet - Standard legs and guides included - Control cards and sensors integrated - Equipment available immediately - Price on request Gisdpfjy Tx E Ejx Achsw - Shipping possible ISC RECYCLE – Second-hand intralogistics solutions.

Condition: good (used), Year of construction: 2016, Material Handling System, TGW, nominal width 420mm, approx. 1,100m – used – Ex-works price (net): now only €99,000 instead of €269,000 – dismantled, packed and loaded, including controls, supports, etc.! Manufacturer: TGW Year of manufacture: 2016 Condition: good Available: immediately Location: Niedernberg warehouse Excerpt from Hall 2 inventory: Approx. 42 units Type: KRC KingDrive Roller Conveyor A and T Nominal width (NB): 420mm Roller pitch: 110mm Zone length: 990mm Gijdpoy Iv Eljfx Achsw Number of KDRs per zone: 2 units Roller type: steel Conveying speed: variable, e.g., 0.47m/s Acceleration / deceleration: 1.5 m/s² Available in various versions Similar to above, only: Approx. 38 units Type: KRC KingDrive Roller Conveyor A and T Zone length: 660mm Similar to above, only: Approx. 4 units Type: KRC KingDrive Roller Conveyor A and T Zone length: 880mm 800mm = approx. 8 units 770mm = approx. 3 units 412.5mm = approx. 1 unit 330mm = approx. 23 units KCS KingDrive Infeed/Outfeed: approx. 8 units 420mm KCC KingDrive Curve Conveyor A and T, 90 degrees = approx. 6 units 420mm 45 degrees: approx. 3 units 30 degrees: approx. 2 units 55 degrees: approx. 1 unit Roller tracks, length approx. 100mm = approx. 33 units 420mm, plastic rollers, non-driven Toothed belt diverter/inserter K: approx. 5 units 420mm Toothed belt transfer unit K: approx. 14 units 420mm, module length: 800mm PWT Pop-Up Roller Transfer: approx. 4 units Belt conveyors: approx. 18 units BFT2000 GF Belt Conveyor Nominal width 420mm
