Hydraulic cylinders

DIMTER

Condition: used, Year of construction: 2001, Electrical cabinet from Dimter OptiCut 602R Gisdpfxsxp Uxws Adnjp Electrical diagrams available Parts list available

Condition: ready for operation (used), Year of construction: 2003, This DIMTER S50 Opticut was manufactured in 2003. A robust optimizing cross-cut saw, it features a processing length of 5 m and a saw blade diameter of 500 mm. A new Movidrive converter was installed in 2018, enhancing its performance. If you are looking to get high-quality cutting capabilities, consider the DIMTER S50 Opticut machine we have for sale. Contact us for more information about this machine. Gisdpfx Aex D Hxrsdnep Application Types Sawing (Wood)

Year of construction: 1998, condition: ready for operation (used), spindle motor power: 11,000 W, spindle speed (max.): 6,000 rpm, This Weinig Unicontrol 10-5 was manufactured in 1998. A robust used window manufacturing machine, it features a working width of 40-220 mm and motor powers up to 15 kW for various machining units. It includes advanced features like a synchronization device, electronic height adjustment, and an automatic turning system for efficient one-man operation. If you are looking to get high-quality milling capabilities, consider the Weinig Unicontrol 10-5 machine we have for sale. Contact us for more information. • Capacities • Working width: 40–220 mm • Working height (longitudinal machining): 40–100 mm • Working height (cross machining): 40–100 mm (counter wood height 80 mm) • Workpiece length (longitudinal): min. 220 mm + 2 x tenon length • Workpiece length (cross): min. 275 mm + 1 x tenon length with 320 mm tool diameter • Feed (cross machining) • Motor power: 0.3 kW • Feed speed: 3–25 m/min • Workpiece clamping: 2 clamping claws • Length stop: with scale and reading magnifier for frame or sash outer dimensions • Counter: pneumatically clocked, 4 positions (not for studio windows), up to wood height max. 80 mm • Double part package: single or double part feeding, with cross separation and retention system • 1st piece (lying on the stop) wood width: 55–90 mm • 2nd piece wood width: 130 mm • Feed (longitudinal machining) • Motor power: 2.2 kW • Feed speed: 4–18 m/min (infinitely variable via frequency converter) • Feed roller spacing: 100/120 mm • Feed roller width: 30/50 mm • Feed roller diameter: 95 mm • Machining units • Crosscut saw • Motor power: 3 kW • Spindle diameter: 40 mm • Spindle speed: 2800 rpm • Tool swing: max. 400 mm • Axial adjustment: pneumatic against 4-fold turret • 1st spindle with tenon and slot • Motor power: 11 kW • Spindle diameter: 50 mm • Spindle speed: 3250 rpm • Tool swing: max. 320 mm • Tool clamping length: 320 mm • Axial adjustment range: 240 mm • Number of tools: 4 x 80 mm • Axial adjustment: hydraulic • 1st profiling spindle • Motor power: 11 kW • Spindle diameter: 50 mm Gjdpfjx S Sk Eox Adnsip • Spindle speed: 6000 rpm • Tool diameter: max. 232 mm • Tool zero swing circle: 130–140 mm • Tool clamping length: 320 mm • Axial/radial adjustment range: 240/80 mm • Number of tool positions: 4 x 80 mm • Axial adjustment: hydraulic • 2nd profiling spindle • Motor power: 11 kW • Spindle diameter: 50 mm • Spindle speed: 6000 rpm • Tool diameter: max. 232 mm • Tool zero circle: 130–140 mm • Tool clamping length: 320 mm • Axial/radial adjustment range: 240/80 mm • Number of tool positions: 4 x 80 mm • Axial adjustment: hydraulic • Mechanical spindle brakes • For profiling spindle(s) • For crosscut saw and profiling/sawing units • Profile milling unit (horizontal, top; in front of last profiling spindle) • Radially indexed: 2 positions • Axially indexed: 2 positions • Motor power: 3 kW • Spindle diameter: 40 mm • Spindle speed: 5850 rpm • Tool swing: 130 mm • Tool clamping length: 40 mm • Axial adjustment range: 52 mm • Radial adjustment range: 125 mm • Profile milling unit (vertical, right; at end of machine) • Radially indexed: 2 positions • Axially indexed: 2 positions • Motor power: 3 kW • Spindle diameter: 40 mm • Spindle speed: 5850 rpm • Tool swing: 210 mm • Tool clamping length: 160 mm • Axial adjustment range: 90 mm • Radial adjustment range: 100 mm • Length tenoning and slotting spindle (640 mm tool clamping length, instead of 320 mm spindle) • Motor power: 15 kW • Spindle speed: 2925 rpm • Number of tool positions: 8 x 80 mm

Condition: ready for operation (used), Year of construction: 2018, Optimizing Cross-Cut Saw manufactured in 2018. This WEINIG DIMTER Opticut S90 features a saw blade diameter of 500 mm and a maximum cutting height of 120 mm. It accommodates input lengths from 400 to 6,300 mm and widths from 20 to 300 mm. If you are looking to get high-quality cutting capabilities, consider the WEINIG DIMTER Opticut S90 machine we have for sale. Contact us for further details. • Saw blade • Diameter: 500 mm • Bore: 30 mm • Adjustable saw blade speed: 40–100% via frequency converter • Workpiece capacity • Input length (min/max): 400–6,300 mm • Width (min/max): 20–300 mm • Thickness (min/max): 10–120 mm • Maximum cutting height: 120 mm • Minimum cross-section: 20 x 10 mm • Maximum cross-section 1: 215 x 120 mm • Maximum cross-section 2: 300 x 40 mm • Permissible timber curvature: max 2 mm/m or 8 mm over entire length • Table inclination: 10° • Motion and accuracy • Positioning speed (reverse stroke): max approx. 180 m/min • Positioning speed (forward stroke): max approx. 60 m/min • Positioning accuracy: +/- 0.1 mm • Motors and power • Pusher motor power: 5.1 kW • Saw motor power: 7.5 kW • Total electrical load: approx. 15 kW • Control and interface • Control unit: OptiCom Pro with 18.5" touch screen • Screen resolution: 1366 x 768 pixels Godpfx Aeylmmmjdneip • Protection class (front): IP65 • Interface: USB port and Ethernet network connection • Data format: CSV (ASCII) for import/export • Utilities and environment • Voltage: 400 V / 50 Hz • Operating pressure: 6–8 bar (min.) • Air consumption: approx. 250 NL/min • Extraction connection: diameter 125 mm • Required extraction performance: speed approx. 30 m/s; volume approx. 1,300 m³/h • Noise level (idling): ≤ 85 dBA

Year of construction: 1997, condition: ready for operation (used), overall weight: 10,500 kg, total height: 2,000 mm, This Grecon Dimter FDL-F 205/600/500 was manufactured in 1997. It is designed for woodworking applications, offering robust performance and reliability. Ideal for handling a variety of wood processing tasks efficiently. Contact us for more information about this machine. Additional equipment • Press (Face Press): Pressing Pressure 6 - 12 t and power consumption of 52 kW • Compressed Air Consumption: 350 NL/min for milling machine, 500 NL/min for press • Suction Volume: 10600 m³/h • The machine ensures fast transport cycles with precise alignment Giodpfx Aoyabawjdnjp • Includes a hydraulic pressing system for continuous jointing • Features integrated dust extraction and suction systems Machine Benefits Technical Machine Benefits • Feeding & transport: conveyor belt with a speed of 75 m/min and power of 11 kw / feeding & transport: conveyor belt with a speed of 75 m/min and power of 11 kw / threading station max feed speed: 120 m/min, power consumption 22 kw • Workpiece dimensions: length: 150 - 2000 mm / width: 50 - 205 mm / height: 35 - 50 mm 60 / final length: 3000 - 00 mm • Milling machine: turbo milling combination with power consumption of 63 kw / milling spindle motor: 22 kw, 3000 rpm / chipper motor: 55 kw, 2880 rpm Dimensions Machine Depth 18500 mm

Year of construction: 2005, condition: ready for operation (used), This WEINIG Unimat 500 was manufactured in 2005. A robust woodworking machine featuring a working range of 230 x 120 mm and five spindles, it ensures efficient processing with variable feed speeds from 4 to 30 m/min. Spindle power outputs include 4 kW for infeed and outfeed, and 7.5 kW for right/left and top spindles. Consider the opportunity to buy this WEINIG Unimat 500 woodworking machine. Contact us for more information about this machine. Additional equipment • Includes approx. 70 cutter heads Z4 Giedpfx Adoyaihpensp • Several hundred new serrated-back knife blanks Machine Benefits Qualitative Machine Benefits • Groove guidance and hydraulic nuts Technical Machine Benefits • Working range (wxh): 230 x 120 mm • Number of spindles: 5 • Variable feed speed: 4 – 30 m/min • Spindle power output: bottom (infeed): 4 kw / right / left: 7. 5 kw each / top: 7. 5 kw / bottom (outfeed): 4 kw

Condition: ready for operation (used), Year of construction: 2007, This DIMTER PROFIPRESS L2500 was manufactured in 2007. A robust used gluing press, it features a press bed of approximately 2500 x 1300 mm and a stable base frame. It includes a motor-driven multifunctional pusher and an automatic gluing station with a precision glue head. Ideal for both softwood and hardwood, it ensures even pressure distribution and high vertical pressure for low offset. Contact us for more information about this machine. • Workpiece capacity: • Lamella widths (for panels): 30–150 mm • Thicknesses: 11–60 mm • Input length: 800–2500 mm • Panel width: variable, up to max. 1300 mm Gedex D I Nrspfx Adnoip • Filling width per cycle: min. 650 mm / max. 1300 mm • Max. filling area per cycle: 3.25 m² • Note: Max. usable press width depends on individual lamella widths • In multi-lane operation, filling widths may vary by max. 15 mm • Minimum contact surface per press filling: ≥ 100 cm² • Press performance: • Specific pressing pressure (at 2500 x 60 mm): up to 1.6 N/mm² • Press bed and construction: • Press bed area: approx. 2500 x 1300 mm • Stable base frame with lower press table in stainless steel (ground electrode) • Upper pressure plate with hydraulic motor “anti-reb” feature for high vertical pressure and low offset • Special hydraulic pressure elements ensure even pressure over the joint and compensate tolerances • Quick-change stop ruler sets for panel thicknesses 19–40 mm; hydraulically movable to the current filling width • Integrated hydraulic unit for press force and hydraulic motors • Electrical: • Operating voltage: approx. 400 V / 50 Hz • Electrical connection value of press (without options): 7 kW • Electrical connection value for 40 kW HF generator: 56 kW • Controls and safety: • Control cabinet and control panel • Protective cover Additional equipment • Collection table extended to 3700 x 1300 mm (with stainless steel wood support) • Motor-driven multifunctional pusher • Additional individual pressure elements from above • Automatic gluing station with precision glue head • Feed system for different widths • Camera • Washing and rinsing device for glue head • Modem with software for online connection

Condition: good (used), Year of construction: 2005, I sell the automatic pneumatic end cutting saw Weinig Grecon Dimter Opticut 200 Elite Year 2005 Motor power 7,5kW Godpfxextxg Ho Adnsip Input table automatic feeding 5,10m (throughfeed system) Outut table automatic 6 pcs. kickers on left outfeed table Optimising with mistakes deffect reading and automatic cutting sequence modes. Available immediately. CE version. Documentation included.

Condition: good (used), The machine has been overhauled many new parts new cables new hydraulic station The machine has been checked, is functional, Gisdpev Ihdzefx Adnsp We can send a video.

Condition: used, Year of construction: 2001, Wood dimensions to be processed: Input lengths min/max 500 - 6500 mm Full optimization up to max. 1500 mm Input widths min/max 40 - 300 mm Input thicknesses min/max 15 - 120 mm Wood cross-sections max. 300 x 40 mm max. 200 x 120 mm Fixed lengths after sawing min. 510 - 2800 mm Special application: Cutting blocks, length min/max. 100 - 200 mm (Caution: Multiple block lengths at the sorting line; blocks are transported to the end of the sorting line and fall into the customer's grid box). Cutting/cutting tolerance +/- 0.8 - 1.5 mm (for wood types with minimal resin content and an even surface. Tolerance up to 1 m fixed length, max. tolerance for longer pieces up to 2.5 m). Thickness tolerance +/- 3 mm. Curvature of the wood in all directions: max. 10 mm per meter in length. Wood types: soft or hardwood. System performance: Feed speed, continuously adjustable up to max. 230 m/cutting cycle 0.6 - 1. To obtain the practical output per day, an effectiveness factor dependent on the customer's production conditions must be calculated. Infeed and saw height: 900 mm (placed on customer's platform, saw requires concrete base). Sorting working height. 2000 mm Connection values: Total electrical connection value approx. 18 kW Operating voltage 380 Volt / 50 Hz Voltage fluctuations max. 5% Air consumption approx. 1200 NL/operating pressure approx. 8 bar Extraction speed approx. 30 m/nd Color pebble gray RAL 7032 and blue NCS 5030-R 80 B POSITION OVERVIEW: Item 1 Infeed and marking station with 1 side support table, adjustable 1 table as stop edge Item 2 Support roller without drive, front side in front of sheet metal table for easier feeding Item 3 Length measuring station with built-in fluorescence camera for detecting error markings Item 4 Automatic width measurement, contactless Item 5 OptiCut 304 optimizing cross-cut saw - right-hand version with built-in waste chute including equipment package for large wood cross-sections Graphic input terminal (16 x 40 characters, Numeric keypad) with software package for optimization and system control. Available for processing: - max. 16 product groups - max. 8 grades per product group - max. 200 fixed lengths per product group Item 6: Outfeed conveyor as sorting station with drive unit, length 7500 m Item 7: 2 ejectors mounted on the outfeed conveyor Storage location: Nattheim Giodpfx Adew Sy T Henep
