Condition: excellent (used), Year of construction: 2010, Maximum drilling diameter: 20 - 252 mm Drilling diameter in concrete: 20 - 150 mm Number of gears: 3 Electrical connection: 220 V, 2300 W Holjznvrpshcdwwofl Weight: 7.4 kg

Year of construction: 2023, operating hours: 139,959 h, condition: used, Serial number: 750 Complete installation: - BySmart 3015 Fiber 10.000 - ByTrans Modular - BySort 3015 - Tower-Linie 3015 1T Working Area & Cutting Range: Nominal sheet dimensions (X × Y): 3000 × 1500 mm. Max. cutting range (X × Y × Z): 3048 × 1524 × 100 mm. Max. weight on shuttle table: 1,100 kg (fully loaded shuttle table). Table changeover time: Approximately 27 seconds. Dynamics & Speed Drive: High-rigidity gantry system. Hslezyq H Sehcdwwsfl Max. axis speed (parallel X, Y): 100 m/min. Max. simultaneous positioning speed: 140 m/min. Maximum axis acceleration: Up to 12 m/s², ensuring fast corner and hole processing. Accuracy (according to ISO 230-2) Positioning accuracy (Pa): ± 0.1 mm. Repeatability (Ps): ± 0.05 mm. Edge detection accuracy: ± 0.5 mm using the automatic optical measurement sensors on the cutting head Laser Cutting Head & Technology (2023 Standard) Cutting Head: Original Bystronic Engineered fiber cutting head with automatic focal point adjustment (Autofocus). Nozzle Handling: Automatic nozzle centering and automatic nozzle changer (depending on the selected factory options). BeamShaper (Optional): Adjusts the laser beam profiles for better cutting quality and higher speeds in thick carbon steel Laser Power: 10 kW Carbon Steel (Mild Steel): Up to 25 mm (30 mm with BeamShaper). Stainless Steel: Up to 30 mm. Aluminum: Up to 30 mm. Brass / Copper: Up to 15 mm / 12 mm. Control & SoftwareCNC control: ByVision Cutting with a 21.5-inch HD touchscreen mounted directly on the machine. Software Integration: Fully compatible with BySoft CAM (automatic nesting, cutting path optimization, and integration with the Bytrans extended automation systems). Cutting hours: 1399,59 Operating hours: 19720,58 Pneumatic pre-pressure: nominal 6 bar Pneumatic pressure cut-off point: 5 bar Power: 400 V/50 Hz Maximum positioning speed: X/Y axes parallel: 100 m/min Maximum positioning speed: X/Y axes simultaneous: 140 m/min Maximum axis acceleration: 8 m/s² Maximum laser power: 10 kW Power range: 1,000 to 10,00 Online auction of modern and very well maintained metalworking machines (e.g. 2023 BYSTRONIC BYSMART FIBER 3015 10kW laser incl. tower- and sheet storage modules complete, 2x 2023 BYSTRONIC XPERT PRO press brakes, 3x 2023 VALK WELDING incl. PANASONIC welding robots, Q-FIN deburring and finishing, KASTO automatic saws, SIEGMUND welding clamping tables, HAAS machine tools etc.), previously in use at Lemken, the well-known manufacturer of agricultural equipment - including plows and seeders - in Dinteloord, The Netherlands, due to the relocation of the manufacturing. The online auction opens Thursday 3 September and closes Thursday 8 October. Register your account via our website and place your bid. For viewings and inspections check the auction information on the website. Viewing day is on: - Tuesday 6 October Dome Auctions is an innovative auction platform dedicated exclusively to the industrial sector. By focusing on machinery sales from business closures, restructurings, and bankruptcies, we provide a trusted marketplace where buyers and sellers connect with...

Condition: excellent (used), Year of construction: 2016, Manufacturer: Atlas Copco Year of manufacture: 2016 Model: C50 Holhcdwjzypxaowjfl

Condition: like new (used), functionality: fully functional, color: orange, Year of construction: 2014, Our company is offering for sale a Sandvik DD210V One Boom Face Drill Rig for tunnels up to 25 m² UNIVERSAL 360 GRADE, "as new" condition,purchased directly from France and not used. The sale is due to the postponement of a planned project. Price: €330,000 Location: Albania Condition: As new – fully original machine, inspected, tested, and repainted. Main Technical Data: Manufacturer: Sandvik , Model: DD210V One Boom Face Drill Rig for gallery section up to 25m2, Year of manufacture: 2014, Operating hours:935 hours (767 drilling only), Engine: Deutz water-cooled, Power (Power Pack 1): 45 kW (60 hp), Electrical supply: 380V–440V, 60Hz; Boom: B14NV; Feed (Left): NTV 6/10 Split feed; Drifter (Left): HL510Bar; Ansul Fire Suppression System. Hjlhoxpvyvscdwwsfl

Condition: used, Year of construction: 2004, operating hours: 4,147 h, functionality: fully functional, machine/vehicle number: DRI 04320080, mileage: 100 km, overall weight: 7,000 kg, fuel type: diesel, color: blue, operation weight: 14,000 kg, maximum load weight: 15,000 kg, chain condition: 70 %, bar diameter (max.): 61 mm, pipe diameter (max.): 400 mm, Equipment: cabin, crane, hammer hydraulics, hydraulics, rubber tracks, German horizontal directional drilling (HDD) machine for drilling up to 200 meters in length, with a drilling/pulling force of 15 tons + impact (28 tons) from a hydraulic hammer. Rubber tracks for speeds up to 3 km/h. Designed for laying pipes up to 400 mm in diameter underground. Drilling depth up to 1-10 meters with wireless navigation. Manufacturer: TRACTO-TECHNIK GmbH & Co, 2004. 4147 operating hours. Components and assemblies: Trailer with hydraulic drive, HATZ diesel engine, 4 cylinders, cabin, 3 boxes with drill rods (each box contains 48 rods x 3 m) = 144 rods (432 meters). Control options: 1. Manipulator for feeding drill rods. 2. Semi-automatic rod tightening and pulling. Mixing plant (8056D) with hydraulic power unit (TT-M2) DRI 8904.B, Deutz engine, 4 cylinders, diesel, with bentonite pump P-72, 320 l/min, with two bentonite preparation tanks of 4000 liters each, with two BÖRGER rotary pumps for mixing. Cable for connection to the mixing plant. Drum with bentonite hose. 2 drilling heads. Reamer Ø110. Swivel 5t. Reamers Ø280 with swivel, Ø315 with swivel, Ø385 with swivel. Eclipse navigation system. New spare working components (adapter, probe housing, bushing). Hfjlhcdey H H Uuowwol

Condition: used, Year of construction: 2018, power: 29.5 kW (40.11 HP), overall weight: 2,160 kg, Due to internal restructuring, we are offering the following machine from our inventory for sale: Description: HDD drilling rig Machine type: Grundodrill 4X Serial number: 4X1826295M Year of manufacture: 2018 Weight: 2,160 kg Engine power: 29.5 kW Maximum operating pressure: 310 bar Length: 3,500 mm Width: 1,200 mm Height: 1,710 mm Maintenance and service were recently carried out by TRACTO. The unit is in working condition. Interested parties are welcome to submit their price expectations or make an offer. Helhjy Nmffscdwwsfl If you have any questions or require further information, please send us a message or give us a call.

Condition: ready for operation (used), functionality: fully functional, gearing type: mechanical, fuel type: diesel, color: white, overall weight: 58,000 kg, empty load weight: 44,000 kg, first registration: 01/2001, mast type: telescopic, suspension: steel, Year of construction: 2001, operating hours: 15,000 h, machine/vehicle number: 03/2001, Equipment: cabin, onboard computer, steel tracks, trailer coupling, The LLAMADA model P130TT piling rig is designed for the execution of bored piles (CFA) or displacement piles, with a maximum depth of 23 m and diameters ranging from Ø 350 mm to Ø 1000 mm. It is an ideal machine for operation in areas with limited space, due to its light weight and small dimensions, as well as its high stability, high efficiency and quick assembly. Parameters: Drilling depth up to 23 meters Maximum CFA pile diameter: 1000 mm Maximum CMC pile diameter: 520 mm Hjlhcezu S Rzjdwwefl Head torque: 18 tm at a rotational speed of 9 rpm Maximum rotation speed: 18 rpm at a rotational torque of 9 tm Clamping force: 12 t Auxiliary winch: 3.2-ton lifting capacity Concrete discharge pipe diameter: 125 mm Machine weight for transport: 50 t Maximum mast tilt on the xx, yy axes: 3 degrees. Maximum length of augers that can be mounted: 24 meters Deutz BF-10L-513 engine power: 263 kW at 2300 rpm Track width: 700 mm Ground pressure per track: 0.8 kg/cm² This offer relates to the purchase of 3 identical machines simultaneously, at a total price of 449,999 EUR for the complete set. The first machine is fully functional – ready for operation, while the other two require refurbishment/commissioning.

Year of construction: 1997, condition: ready for operation (used), With articulated carrier DC26, load: 108kW, max. driving speed 16km/h, tyre size: 14.00 R24 A, 2x drill arm BUT 35, Diesel Power Generator Deutz BF4M 1013C, drill mounts BMH 6414, max. drill rod length: 4321mm, max. drilling depth: 4020mm, loading platform HL 210, CE standard, air/water flushing, heat exchanger and high-pressure pump Swellex, without drill hammers. Hfelel Tn Epjhcdwwel

Year of construction: 2001, condition: ready for operation (used), Motor power: 179kW, length: 9655mm, width: 2490mm, height: 2630mm, weight: 18.7t, with documentation. Holsnxk H Nohcdwwefl

Condition: excellent (used), Year of construction: 2012, operating hours: 5,656 h, functionality: fully functional, overall weight: 2,800 kg, fuel type: diesel, color: yellow, axle configuration: 2 axles, empty load weight: 2,800 kg, fuel: diesel, gearing type: hydrostat, number of seats: 1, Equipment: additional headlights, hydraulics, low noise, rubber tracks, The authorized SUBARU dealer in Łaziska Górne has a 2012 Vermeer D9x13 Series 2 horizontal directional drilling rig for sale, with 5650 operating hours. We specialize in importing and selling Vermeer and Ditch Witch drilling rigs. The machine is on-site, has been inspected, and is ready for operation. We offer all forms of payment: Leasing, credit, cash, and bank transfer. With cash or bank transfer payment, you can drive the machine away from the showroom immediately. In addition, we handle insurance – we will calculate the cheapest premium for any vehicle – CHECK US OUT! We also deliver paid-for cars and trucks to the specified address throughout Europe. For more information about our services, please contact our sales representatives. Technical specifications of the Vermeer D9x13 Series 2: Engine: Kubota V1505T Diesel, turbocharged Engine power: 47 hp / 35 kW Push/pull force: 40 kN / 9000 lbs Maximum torque: 1763 Nm Spindle rotation speed: up to 220 rpm Maximum carriage speed: 42.7 m/min Drilling fluid pump: 34.1 l/min or 56.8 l/min, depending on the version Maximum drilling fluid pressure: 51.7 bar Drilling fluid tank on the machine: 94.6 l Drill rods: Vermeer Firestick, length 1.8 m, diameter 42 mm Machine length: 3.80 m Transport width: 0.90 m Maximum working width: 1.08 m Height: 1.75 m Weight with drill rods: approximately 2860 kg Additionally available: We also have a small Ditch Witch FT5 drilling fluid tank/mixer from 2021, which is a perfect match for this model and constitutes a practical set for carrying out small and medium-sized directional drilling projects. Ditch Witch FT5 – basic data: Year of manufacture: 2021 Tank capacity: approximately 757 liters / 200 gallons Maximum flow to the drilling rig: approximately 68 l/min Engine: Honda GX160, gasoline Engine power: approximately 5.4 hp Dimensions: approximately 185 × 81 × 136 cm Curb weight: approximately 182 kg It is possible to purchase the drilling rig alone or as a set with the Ditch Witch FT5 drilling fluid tank. The stated price is net and applies to export and to companies. Hslhcdozumt Rswwefl A significant discount is available for individual customers – Please contact us directly by phone to get your best price.

Condition: good (used), Core bit, step chisel, core bit for well construction, core drill, core drilling machine, diamond core bit, core bit for well drilling machine -Drill bit: 3 pieces drill holder plus 1 piece extension adapter -Dimensions: see photos -Delivery/Price: complete -Transport dimensions: 250/250/H280 mm -Weight: 27.3 kg Hfoljvmyruehcdwwjl

Condition: good (used), diamond core drilling machine -Drill stand -vacuum pump -Water pump reservoir Hfslob A H U Ajhcdwwol -Core drill bits: Ø 15/20/3x 25/3x 28/32/40 mm

Condition: good (used), Diamond core drilling machine, core drilling machine -3x: drill stand -Max. Drilling capacity: Ø 60 mm -drilling depth: max. 400 mm -Drive: 1050 W -Speeds: 1500/3000 rpm -Core drill: Ø 18/24/29 mm -Sale: only complete Hslhceb A Idyodwwjfl -Weight: 70 kg

Condition: good (used), Hydraulic cylinders, support cylinders, hydraulic rams, pressure rams Hslhcdecgf Rzewwjfl -Stamp: for Herrenknecht tunneling -Piston diameter: approx. 140 mm -Piston rod: Ø 115 mm -Stroke: 310 mm -Max. Stamp pressure: 500 bar -universal: applicable -Number: 3x cylinders available -Price: per piece -Dimensions: 168/200/H550 mm -Weight: 82 kg/piece

Condition: good (used), Drill bit, step chisel, drill bit for well drilling, core drill, core drilling machine, diamond drill bit, drill bit for well drilling machine -Drill bit: diamond core bit Ø 142 mm -Hole: Ø 125 mm -Dimensions: see photos Hfolhcdwexd Sd Howjl -Dimensions: Ø 142 x 175 mm -Weight: 3.9 kg

Condition: used, Filling system, filling machine, filling station, table filling machine, filling machine, liquid filling machine, filler, dosing computer terminal Hfelhjumpnbscdwwol -Manufacturer: Hilger u. Kern Dopag, dosing computer terminal -Type: ZM 9310-1-0 -Voltage: 230V 50Hz 1A -Connection cable: see photos -Dimensions: 535/330/H170mm -Weight: 9.6 kg

Condition: good (used), Core drill, crown drill, masonry drill, core drilling machine, diamond core bit, drill bit -Core drill bit: Ø 150 mm Hfelhcob A Sm Aedwwsl -Drill bit length: 470 mm -Quick-change mount -Weight: 5 kg

Condition: good (used), portable oxygen breathing apparatus for tunnel boring -for: Herrenkecht tunnel boring machine -System-No: 009-07-06 -in: 2x aluminum cases -various hoses Holob A Ibzjhcdwwjfl -Transport weight: 100 kg

Condition: good (used), Control container, control cabinet -Control cabinet for tunnel boring -comes from the company Lemme Berlin -for bentonite pumps -Control panel -PLC control Hfslob A Su Dshcdwwel -Dimensions: 600/350/H1320 mm -Weight: 60 kg

Condition: good (used), diamond core drilling machine -Drill stand -vacuum pump Hfslhcdodpvwwjwwjl -Core drill: Ø 202 mm (picture) -Machine dimensions: 500 x 370 x H1070 mm -Weight: 53 kg

Condition: good (used), Hydraulic cylinder, support cylinder, hydraulic piston, pressure piston -Stamp: for Herrenknecht tunnel boring -Piston diameter: approx. 150 mm -Piston rod: Ø 110 mm -Stroke: 700 mm -Usable: universal Hfolhcob A Rcuodwwsl -Number: 2 cylinders available -Price: per piece -Dimensions: 950 x 300 mm -Weight: 150 kg/piece

Condition: used, Oil filter system, oil cleaning system, oil transfer system, hydraulic unit, hydraulic pump, hydraulic pump, hydraulic test pump Hfslhcdjd Scprewwsl -Operating pressure: max. 420 bar -Dimensions: 140/68/H245 mm -Weight: 2.3 kg

Condition: used, Year of construction: 2017, operating hours: 13,000 h, BAUER BG 33 H Year of Man. 2017 Base carrier Bauer BT 75 Hfelhcdszqcuiswwol More information upon request.

Condition: used, Year of construction: 2017, operating hours: 15,000 h, BAUER BG 28 H Hfjlhcdszqct Ejwwsl Year of Man. 2017 Base carrier Bauer BT 75 More information upon request.

Year of construction: 2008, operating hours: 13,480 h, condition: used, Field of application: Construction Make of engine: CAT Please contact Mohamad Fattah Ahmad for more information Hfslhoh Tyyzscdwwsl
