Condition: new, Year of construction: 2026, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 500 mm, feed length X-axis: 750 mm, feed length Y-axis: 610 mm, feed length Z-axis: 500 mm, feed rate X-axis: 50 m/min, feed rate Y-axis: 50 m/min, feed rate Z-axis: 50 m/min, torque: 100 Nm, controller manufacturer: HEIDENHAIN, controller model: TNC7, total height: 3,060 mm, total length: 4,204 mm, total width: 3,500 mm, table width: 600 mm, table height: 805 mm, table length: 750 mm, table load: 400 kg, rotational speed (min.): 100 rpm, overall weight: 9,000 kg, spindle speed (min.): 50 rpm, spindle speed (max.): 15,000 rpm, coolant supply: 20 bar, distance table center to spindle nose: 650 mm, spindle motor power: 26 W, number of slots in tool magazine: 40, tool length: 250 mm, tool diameter: 80 mm, tool weight: 800 g, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, - Complete machine with a 5-axis rotary/tilting table with Torque motors - Optical scales for X/Y/Z axes - Direct encoders for B/C axes Tjdpsz Hnx Ajfx Aa Toc - HSK 63A electrospindle - High-pressure coolant system through the spindle, 20 bar - Chip evacuator - Electronic handwheel - Kinematic option - MARPOSS part cycle probe - Top cover - CE marking

Condition: excellent (used), Year of construction: 2014, 5-axis machining center Brand: DMG MORI Type: DMF DMU 75 Monoblock Year: 2014 CNC: Heidenhain iTNC530 Equipped with: Integrated rotary table, dia. 600mm / 600kg 35 kW spindle – 18,000 rpm 60-position tool changer TS 649 probe 3D quickset Center coolant system, 40 bar 600l coolant tank with paper filtration Todpfxez E R D Sj Aa Tsc Infrared tool probe Coolant gun Chip conveyor Specifications: Table surface 800 x 650 mm (dia 600 inclinable) X-axis travel 750 mm Y-axis travel 650 mm Z-axis travel 560 mm B-axis -/+120° C-axis 360,000° Spindle speed 2 - 18,000 rpm Spindle power 35 KW Spindle taper SK 40 Rapid traverse XYZ 40 m/min Machine dimensions approx. 3200 x 2600 x H 2900 mm Weight approx. 11,600 kg

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, Control system: Siemens 840D-SL Tool positions: 160 Todpfxsz E Hxls Aa Tec Tool holder: HSK 63 Spindle speed: 10,000 rpm / 242 Nm Pallet size: 630 x 500 mm Number of pallets: 2 X-axis: 800 mm Y-axis: 800 mm Z-axis: 1000 mm Table load capacity: max. 1000 kg

Condition: good (used), Year of construction: 2019, Universal machining center Machine type: Hedelius Acura 65 Control: Heidenhain TNC 640 Year: 2019 Available after: Dezember 2026 Tjdpfx Asz D Aq Uja Tsc SPECIFICATIONS 5-axis-simultaneous X-Axis: 700 mm Y-Axis: 650 / 465 mm Z-Axis: 600 mm Rapid motion: (X/Y/Z): 40/40/40 m/min. B-Axes: +30° / -115° Spindle speeds: 12.000 rpm Spindle power: 22 kW Torque: 117 Nm Tool: SK 40 Tool capacity: 65 Table size: D: 650 x 540 mm mm Max. Table Load: 500 kg Equipment Chip conveyor 3D-Touch probe: M&H Internal cooling: 25 bar Cooling tank: 500 l Electronical handwheel: HR 510 Oil mist separator Chip rinsing pistol Kinematikset 3D-Formenbauabstimmung Documentation - German

Condition: excellent (used), Year of construction: 2006, Control system: Heidenhain MillPlus IT Travel ranges X/Y/Z: 730 x 510 x 510 mm Spindle speed: 12,000 rpm Tool magazine for 60 tools, SK 40 NC rotary table integrated into a fixed table, diameter 600 mm / 1000 mm x 600 mm Controlled NC swivel milling head (B-axis) incl. hydraulic clamping Swiveling range -120/+30° Tjdpfx Aoz Dk I Uja Tjc 3D quick SET Production package 40 bar/23 l/min (theoretical pump output), tank 600 l Paper band filter Rotating viewing window Chip conveyor

Condition: ready for operation (used), Year of construction: 2002, operating hours: 14,517 h, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 520 mm, feed rate X-axis: 50 m/min, feed rate Y-axis: 50 m/min, feed rate Z-axis: 50 m/min, controller manufacturer: Heidenhain, controller model: iTNC 530, workpiece weight (max.): 350 kg, total height: 2,830 mm, total length: 2,600 mm, total width: 5,644 mm, table width: 500 mm, table length: 700 mm, table load: 350 kg, overall weight: 8,350 kg, spindle speed (max.): 18,000 rpm, operating hours of spindle: 14,517 h, spindle nose: SK40 (DIN69871), number of spindles: 1, number of slots in tool magazine: 32, input voltage: 400 V, Equipment: chip conveyor, documentation/manual, The Deckel Maho DMU 70 eVolution from 2002 is a 5-axis universal machining center that was considered one of the top-of-the-line milling machines at the time. We acquired this machine directly from the factory, and it is still in good working condition! The machine is currently operational at our facility and can be inspected by appointment. Additional options & accessories: - B-axis travel: 0° - 180° - C-axis travel: 360° continuous, resolution 0.001° - Chip conveyor - BEMA programmable coolant nozzle - BLUM tool laser Todpfx Asz Apmisa Tec - SPINVISTA EVO Rotoclear - Approx. 10 SK40 tool holders - Original Deckel Maho documentation and electrical diagrams Weight & dimensions: Approx. 8350 kg Approx. 2600 x 5644 (incl. chip conveyor) 2830mm (L x W x H)

Condition: ready for operation (used), Year of construction: 2004, operating hours: 11,298 h, functionality: fully functional, machine/vehicle number: 665001, travel distance X-axis: 700 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 450 mm, workpiece weight (max.): 2,000 kg, spindle speed (max.): 42,000 rpm, number of slots in tool magazine: 40, No minimum price – guaranteed sale to the highest bidder! Submitting a bid obligates you to collect the item within the period of September 21st to October 1st! TECHNICAL DETAILS Travel in X-axis: 700 mm Travel in Y-axis: 550 mm Travel in Z-axis: 450 mm Feed Axes Max. travel speed X, Y, and Z axes: 30 m/min Max. acceleration X, Y, and Z axes: 15 m/s² Positional accuracy TP according to DIN ISO 230-2: 0.005 mm Repeatability: 0.002 mm Work Table Table length: 850 mm Table width: 700 mm Number of T-slots: 5 T-slot dimensions: 18 H12 Table load: 2,000 kg Max. workpiece weight: 2,000 kg Distance spindle center – table: 550 mm Spindle Spindle mount: HSK-E 40 Spindle speed: 3,000 - 42,000 rpm Spindle power: 17 kW Tool Changer Tool magazine positions: 40 MACHINE DETAILS Machine type: CNC HSC machining center CNC control: Andronic Electrical Connection Data Supply voltage: 400 V Supply frequency: 50 Hz Fuse rating: 32 A (?) Dimensions and Weight Overall length: 3,300 mm Overall width: 2,300 mm Overall height: 2,300 mm Overall weight: 7,700 kg Operating Data Machine operating time: 275 d 5 h 13 min 39 s Spindle operating time: 11,297 h 20 min 11 s EQUIPMENT - Full enclosure - Dust and fluid-proof guides - Oil mist extraction - Compressor cooler - Frequency inverter - Heidenhain glass scales in X, Y, and Z axes - Work light in the interior - Technical documentation - Workbench Todpfx Asz Apllsa Tsc - HSK-E-40 tool holders - Tools - Workbench dimensions: approx. 1,500 × 900 × 1,100 mm External Reference: Demo - Lot 2

Condition: excellent (used), Year of construction: 2004, operating hours: 29,000 h, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 520 mm, controller manufacturer: Haidenhain iTNC 530, rotational speed (min.): 20 rpm, rotational speed (max.): 18,000 rpm, spindle speed (max.): 18,000 rpm, operating hours of spindle: 16,000 h, number of slots in tool magazine: 92, Equipment: chip conveyor, documentation/manual, 5-axis machining center Travel ranges: x = 750 mm, y = 600 mm, z = 520 mm Spindle speed range: 20 – 18,000 rpm Tool holders: HSK63 Laser tool measurement system integrated in the machine High-pressure internal cooling through the spindle center, 40 bar Tsdpfx Ajzz Ahqoa Tjc Tool magazine with 92 positions Year of manufacture: 2004 General overhaul: 2021 The following was done during the overhaul: Hydraulic lines replaced Linear guides and ball screws in the x, y, and z axes replaced, including bearings and timing belts Scrapers and bellows replaced Most recently (2026): Z-axis servo motor repaired Hydraulic unit for lubrication replaced AC servo controller for the x-axis replaced The machine is equipped with a 3D probe and a band filter.

Condition: used, Year of construction: 2014, functionality: fully functional, Milling swivel head: - with torque motor and hydraulic clamping - Swivel range +30/-120°, stepless - 14,000 RPM - 160 Nm torque - Drive power 29 kW - Separate spindle cooling for constant temperature - Tool holder DIN SK40 with air blow-out function Integrated rotary table: - with torque motor and hydraulic clamping - Ø 610 mm - Extended clamping area 1,100 x 610 mm General: Todpfszzp E Nex Aa Tec - 40-position tool changer with dual-arm gripper - Coolant and compressed air gun - Chip conveyor - Coolant system - Electronic handwheel - Work area light Control system: Heidenhain iTnc 530 SmarT.NC HSCI - 15.1'' TFT screen - Ethernet interface - 2x USB port - SmarT.NC-guided programming - Plain text programming - Short sentence processing time - Create a new program while another is being processed - Proven Heidenhain machining cycles - CE certification Options: - Internal cooling system (IKZ), 40 bar, including band filter system - Heidenhain TS640 for DIN SK40 workpiece probing system with infrared transmission - Heidenhain software option 40: DCM Dynamic Collision Monitoring for iTNC 530 - Heidenhain KinematicsOpt incl. Heidenhain calibration sphere KKH 250

Condition: used, Year of construction: 2016, functionality: fully functional, Equipment: chip conveyor, documentation/manual, DMG MORI Machining Center 5-Axis Simultaneous Type: DMU 95 MonoBlock Tsdpozxpt Ujfx Aa Toc Year: 2016

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, 5-axis machining center Hedelius ACURA 65 Control system: TNC 640 Year of manufacture: 2017 Tedpfozwuq Nex Aa Tsc Internal machine number: 72 Travel ranges: X-axis: 700 mm Y-axis H / V: 650 / 465 mm Z-axis: 600 mm Rotary tilting table: Ø 650 x 540 mm Tilting range: +30° to -115° Interference circle diameter: Ø 700 mm Table load: 500 kg Tool holder: DIN 69893-1 HSK-A63 Tool magazine: 65 stations Spindle speed: 50 - 18,000 rpm ZeroClamp, 4-fold 3D measuring probe M&H 25.50 5-axis simultaneous machining ACURA Handheld control unit HR 250 3D mold making alignment ACURA KinematicsOpt TNC640 Collision monitoring ACURA/TNC Compressed air at the spindle head Coolant system 1250l, 25 bar Chip conveyor Exhaust filter Laser light curtain for tools ACURA

Condition: used, Year of construction: 2018, Technical details: x-travel: 670 mm y-travel: 820 mm z-travel: 600 mm control: HEIDENHAIN iTNC 530 table surface area: D= 800 mm KESSLER mm tool taper: HSK 63 Tool changer: 96 pos. table load capacity: 1200 kg turning speeds: 18.000 1/min rapid traverse: 60 m/min total connected load: 90 kVA weight of the machine ca.: 20 t dimensions of the machine ca.: 5 x 2,5 x 3,3 m 5-axis simultaneous machining center, table swivelling (A-axis) + / - 120°, rotary table (C-axis) axis 360 °, internal coolant supply 20 bar, 600 l with paper filter, chipconveyor, 3D infrared touchprobe, laser tool setting BLUM, el. handwheel Heidenhain, chiller for spindle, automatic roof, 5-Achsen Simultan Bearbeitungszentrum, 3x hydr. connection in table-center, 1x pneum. connection in table-center, interface for POS-Robo, POS DCM collision module, POS kinematic module, airblast through spindle, network and USB connection, rotoclear, direct measuring system, Tjdpjzu R Ilsfx Aa Tjc approx. 29.500 h "machine on" , approx. 10.000 h "spindle on" *

Condition: ready for operation (used), Year of construction: 2000, spindle speed (max.): 42,000 rpm, overall weight: 6,500 kg, travel distance X-axis: 760 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 300 mm, number of axes: 3, This Röders RFM760-099 Vertical Machining Center was manufactured in the year 2000. The machine has a spindle speed of 42000 rpm. Machine Benefits Technical Machine Benefits • Tool shrink unit • Dust extraction (graphite) • Tool holders • Software: RMS6V3.15 (211) • Working Area: 760 x 550 x 300 mm • Table Size: 860 x 550 mm • Spindle: Fischer MFW-1230/42 spindle (42,000 rpm, new as of December 2022) • Spindle Taper/Mount: ISO HSK E40 Todpfx Aozun I Nea Tjc • Tool Changer: 25-position tool changer • Laser Tool Measurement: Integrated for length and diameter • Workpiece Measurement: IR 3D probe • Extraction System: Dust extraction (graphite) • Cooling System: Cooling unit and spray cooling for tool/workpiece • Shrink-Fitter: Röders tool shrink-fitter • Chuck: Fixed chuck (new in 2022) • Included Accessories: Milling chuck, consumables, tool holders, and manual service tools • Machine Status: In working order; EROWA clamping system and HD vise have been removed and are excluded from the deal Dimensions Machine Depth 2500 mm

Condition: used, Year of construction: 2008, serial number 1068645 x-travel 2080 mm y-travel 812 mm z-travel 750 mm ja ja Tsdpfjztfvhex Aa Tsc internal cooling ja

Condition: good (used), Year of construction: 2018, Technical details are shown on picture. Machine is in good condition. Tedpfx Aaozrnius Tjc Parts shown by hand not come.

Condition: used, DECKEL MAHO DMC 60 U 5-axis universal machining centre, built 2002. Travels 600 x 700 x 600 mm with rapid traverse up to 40 m/min. The 12.000 rpm motor spindle in SK 40 DIN 69871 delivers 28 kW (40% ED) / 19 kW (100% ED) and is carried by an automatic universal swivel milling head with controlled B axis, working together with an NC rotary table to give full 5-axis capability. Siemens SINUMERIK 840D 3D path control. Rotary pallet changer with 2 pallets of 630 x 500 mm, 600 kg each, plus clamping hydraulics for hydraulically actuated fixtures on the rotary table and pallets. 60-pocket SK 40 magazine with horizontal double-gripper changer. Fitted with internal coolant supply and a 900 l coolant tank, chip conveyor, RotoClear rotating viewing window and Blum laser tool measurement in the work area. Tjdpfx Ajznffrsa Tsc

Condition: excellent (used), Year of construction: 2025, functionality: fully functional, travel distance X-axis: 712 mm, travel distance Y-axis: 540 mm, travel distance Z-axis: 515 mm, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, rapid traverse Z-axis: 36 m/min, controller manufacturer: Siemens und Heidenhain, workpiece height (max.): 400 mm, workpiece diameter (max.): 540 mm, workpiece weight (max.): 200 kg, total height: 3,360 mm, total length: 4,040 mm, total width: 2,770 mm, table load: 200 kg, rotary table diameter: 410 mm, spindle speed (max.): 12,000 rpm, coolant supply: 20 bar, number of spindles: 1, number of slots in tool magazine: 60, tool length: 280 mm, tool diameter: 76 mm, tool weight: 7,000 g, Equipment: chip conveyor, documentation/manual, Machine available with Siemens 828D Technical data 5-SIDE MACHINING • B/C-axis encoder • B-axis +30° to -120° • C-axis 360° • Media preparation table TOOL MAGAZINE CAPACITY • 60-position magazine (chain) • Tool diameter 76 mm • Tool length 280 mm • Tool weight 7 kg LARGE MACHINING AREA • Travel X: 712 Y: 540 Z: 515 • Swivel diameter 540 mm • Workpiece weight 200 kg • Workpiece size ⌀540 mm x 400 mm USER-FRIENDLY DESIGN • Large work area doors • Short distance to the spindle • Good access to the machining area and tool magazine EQUIPMENT • CNC control Siemens 828D (15") or Heidenhain TNC 640 • MPG handwheel • 60-position tool magazine • 12,000 min⁻¹ (taper #40), coupling • Spindle cooler • Air blow-through through the spindle • 20 bar coolant supply • CAN filter for chip flushing/ring cooling Tjdpfezlhvhsx Aa Toc • Automatic central lubrication system • Media preparation table (6 connections) • Glass scales X, Y and Z axis • Chip conveyor • Direct path measuring system C/B axis • Deublin rotary union • CE specification

Condition: used, Year of construction: 2010, functionality: fully functional, travel distance X-axis: 730 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 40 m/min, controller manufacturer: Siemens, controller model: 840D, table width: 500 mm, table length: 500 mm, table load: 300 kg, rotary table diameter: 500 mm, rotational speed (max.): 1,200 rpm, overall weight: 14,000 kg, spindle speed (max.): 12,000 rpm, spindle nose: HSK-A63, number of spindles: 1, number of slots in tool magazine: 181, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, We acquired this machine in working condition directly from production; see the videos of the machine in operation before disassembly! The Mori Seiki NMV 5000 DCG is a high-end (simultaneous) 5-axis machine designed for precision manufacturing in industries where complex shapes and tight tolerances are critical. Includes: KNOLL FKA/500 belt filter system + 3 filter rollers. Filtermist FX5000 emulsion extraction system. Renishaw OMP60 3D probe. Chip conveyor. Spindle cooler. Tsdpfx Aszlf Eaoa Tjc Original Mori Seiki tool storage cabinet. Original documentation + electrical diagrams.

Condition: ready for operation (used), Year of construction: 2010, operating hours: 17,250 h, functionality: fully functional, travel distance X-axis: 710 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 520 mm, controller model: Heidenhain Mill Plus, spindle speed (max.): 18,000 rpm, In 2015, a new spindle was installed! TECHNICAL DETAILS Travel range X-axis: 710 mm Travel range Y-axis: 520 mm Todpszldqnsfx Aa Toc Travel range Z-axis: 520 mm Maximum spindle speed: 18,000 RPM Number of tool magazine slots: 30 Tool holder: SK40 Distance between T-slots: 63 mm Rotational speed of the 4th axis max.: 40 RPM Rotational speed of the 5th axis max.: 40 RPM 4th axis swivel range: 360 x 0.001 degrees 5th axis swivel range: 0 ± 102 x 0.001 degrees MACHINE DETAILS Control system model: Heidenhain - Mill Plus Operating hours: currently 36,500 hours Spindle hours: currently 17,250 hours EQUIPMENT Programmable coolant nozzles Coolant gun Chip conveyor 40 bar internal coolant system with 600 l paper filter system Measuring probe 3D Quickset Laser tool measurement Visiport Handwheel Signal light Operating mode 4

Condition: good (used), Year of construction: 2008, Universal machining center Machine type: DMG DMU 60 monoblock Control: Heidenhain iTNC 530 Year: 2008 Available after: sofort / now SPECIFICATIONS Travel X-Axis: 730 mm Y-Axis: 560 mm Todpfx Aajziy Iqj Toc Z-Axis: 560 mm B-Axes: ° C-Axis: 0,001° Amount of controlled axes: 5 Spindle speeds: 12.000 rpm Tool: SK 40 Toolchanger Tool capacity: 60 NC rotary table: Ø 600 Table size: 1.000 x 600 mm Max. Table Load: 500 kg Equipment Chip conveyor Internal cooling: bar paper band filter Caliper: Heidenhain TS 649 Roto Clear Tool measurement Chip rinsing pistol Oil mist separator Working mode: 4

Condition: used, Year of construction: 2013, x-travel 735 mm y-travel 650 mm z-travel 560 mm control 840D sl FD operate Siemens turning speed range - main spindle max. 18.000 min/-1 power capacity - main spindel 35 / 24 kW max. Torque 119 Nm tool taper HSK-A63 DIN 69893 table diameter 680 mm max. table load 600 kg max. workpiece sizes 650 x 650 x 500 mm swivellable +/- 120 ° rotatable 360 ° number of toolpositions 30 pos. Todpjzipzysfx Aa Toc tool taper HSK-A63 max. tool diameter 80 mm max. tool-dia with free toolbox 160 mm max. tool length 315 mm max. tool weight 8,0 kg change-time chip to chip ca. 4,9 sec feed speeds max. 40.000 mm/min rapid traverse 40 m/min total power requirement 65 kVA weight of the machine ca. 11,6 t dimensions of the machine ca. 4,0 x 3,0 x 2,95 m 5 Axis CNC - MachiningCenter Universal DMG - DMU 65 FD monoBLOCK - Swivel-Rotary-Table - without tools - only 8,444 operating hours - only 2,246 spindle hours - Air blast cooling through spindle center - MDynamics package - Power failure safety package - Coolant ring jet: 7x air jets, 13x water jets - Tropical package (35° – 50° Celsius) - Coolant unit (ICS) with two pressure levels: 40 and 80 bar - Use of special tools (18 kg / 370 mm)

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 700 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 500 mm, spindle speed (max.): 18,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 700 mm Travel range, Y-axis: 1,000 mm Travel range, Z-axis: 500 mm Spindle speed: 1 - 18,000 rpm Tool holder: HSK-A63 Tool magazine capacity: 70 Tool-to-tool change time: 2.5 s Acceleration: 20 m/s² Travel speed: 120 m/min MACHINE DETAILS Number of pallets: 6 EQUIPMENT Integrated workpiece changer system High-dynamic 5-axis machining Weight-optimized kinematics Tedpfx Aszd R R Eea Tsc Linear motor drives

Condition: ready for operation (used), Year of construction: 2017, operating hours: 3,243 h, spindle speed (max.): 20,000 rpm, travel distance X-axis: 750 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 560 mm, controller manufacturer: SIEMENS, controller model: 840D, spindle motor power: 35,000 W, number of slots in tool magazine: 60, number of axes: 5, This 5-axis DMG MORI DMU 75 monoBLOCK was manufactured in 2017. It features a Siemens SINUMERIK 840 D control system and a high-pressure pump for internal coolant supply at 20 bar. The machine includes a 3D measuring probe from Heidenhain and has 60 magazine positions. If you are looking to get high-quality machining capabilities, consider the DMG MORI DMU 75 monoBLOCK universal machining centre we have for sale. Contact us for further details. - Spindle Power: 35 kW (40% duty cycle), 25 kW (100% duty cycle)- Tool Taper: HSK-A 63 according to DIN 69893)- Tool Magazine: Chain magazine with double gripper, 60 tool pockets (HSK-A63)- NC Swivel Rotary Table: Integrated in rigid table, 800 mm x 650 mm- Control System: CELOS with Siemens 840D sl Operate, including 21.5" ERGOline Control with Multi-Touch Screen- Features: MPC (Machine Protection Control), Chip flushing, Integrated coolant tank 500 l- Coolant / Chip Disposal included:* Production Package: Scraper belt chip conveyor with coolant system 600 liters, paper band filter, discharge height 950 mm, width 670 mm* Internal Coolant Supply (IKZ): 40 bar / 20 l/min through spindle center (AD)* External Coolant Supply: 4 bar / 40 l/min* Washdown Pistol with pump (2 bar / 10 l/min)* Oil and Emulsion Mist Extraction System: Mechanical filter, airflow rate 600 m³/h- Measuring / Monitoring:* Infrared Measuring Probe: Heidenhain TS 649 (HSK-A63)* 3D quickSET: Tooling check and inspection of kinematic accuracy for 4/5-axis machine configurations Tedpfjzdzmwox Aa Tsc Technical Specification Through-spindle Coolant Yes Taper Size HSK 63

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, We offer you: CNC bed milling machine Manufacturer: DMG MORI Type: CMX 70 U Year of manufacture: 2022 Control system: Celos with Siemens 840D sl Operate Technical data: Travel distances: X-axis: 750 mm Y-axis: 600 mm Z-axis: 520 mm B-axis: -10 to +95° C-axis: 360° Main spindle: Tool interface: SK 40 Speed range - main spindle: 20 - 15,000 rpm Drive power - main spindle (40/100%): 20 / 14.5 kW Torque - main spindle (40/100%): 121 / 84 Nm Work table: Tsdpozcy I Ssfx Aa Tsc Table size: D 800 x 620 mm Tool changer: Number of tool positions: 30 Max. tool diameter: 80 / 130 mm Max. tool length: 300 mm Max. tool weight: 8 kg Max. magazine load: 120 kg Feed rates: Rapid traverse (x/y/z): 30 m/min Operating hours: approx. 5,300 h Spindle hours: approx. 3,010 h Technical features & accessories: - Direct linear measuring system in x, y, and z, incl. air purging - Compressed air switching via M function - Chip disposal package, includes: - Chip conveyor, tank 300 l - Spray gun - Signal light, 4-color - Tropical package, includes: - Active control cabinet cooling - Additional cooler on the control panel - Hydraulic oil temperature sensor - Cooling unit 3.3 kW for the main drive - Preparation for oil mist separator - Measuring probe kit, manufacturer Heidenhain, includes: - TS460 workpiece measuring probe - Measuring cycles - Tool length/diameter kit, manufacturer Heidenhain, includes: - TT160 for tool measurement - Measuring cycles, incl. tool breakage monitoring - Automation package, includes: - Loading and unloading via automatic magazine door - Automatic closing of the tool magazine - Cabin roof - Electronic handwheel - ATC (Application Tuning Cycle) - Preparation for 3D quickSET Accessories, tools and clamping devices shown in the pictures are only included in the scope of delivery if this is stated in the additional information. Subject to changes and errors in technical data and specifications, as well as prior sale!

Condition: ready for operation (used), Year of construction: 2005, operating hours: 39,256 h, functionality: fully functional, travel distance X-axis: 780 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, controller model: Heidenhain iTNC 530 , rotational speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range X-axis: 780 mm Travel range Y-axis: 560 mm Travel range Z-axis: 560 mm B-axis, infinitely adjustable: 150° (-120°/+30°) Rapid traverse rate (X / Y / Z): 50 m/min Feed rate: 20 - 15,000 mm/min Spindle speed (max.): 12,000 rpm Main spindle drive power: 28 / 19 kW Max. torque: 125 Nm Tool interface: SK 40 Number of pallets: 2 Pallet size: 630 x 500 mm Max. load: 400 kg Table speed range: max. 30 rpm Number of tool positions: 120 Max. tool diameter: 80 mm Max. tool diameter with free adjacent tool pocket: 160 mm Max. tool length: 315 mm Max. tool weight: 8 kg MACHINE DETAILS Control system: Heidenhain iTNC 530 Total power consumption: 64.2 kVA Dimensions & Weight Footprint: approx. 7.0 x 7.0 x 2.8 m Machine weight: approx. 12.0 t Operating Hours Operating hours: 39,256 h Power-on hours: 72,107 h EQUIPMENT Chip conveyor Coolant system High-pressure cooling 40 bar through-spindle coolant Paper band filter Pallet changer, 2 positions Tool breakage monitoring Tedpfxezcqa Sj Aa Tec According to the seller, the spindle was presumably replaced. However, no service report is available to confirm this. The machine's data storage was renewed in January 2026. No CE declaration of conformity is available in DIN A4 or PDF format.
