DN-Machines SA

Condition: used, Year of construction: 2010, travel -x axis 2.500 mm travel -y axis 1.000 mm travel -z axis 1.250 mm control HEIDENHAIN - TNC 530 with NC rotary table 1.000 x 1.000 CNC Bed Type Milling Machine | SORALUCE - TA-25-A equipped with NC swivel rotary table and tool changer. The machine is in good condition and can be inspected under power. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Fodpfx Adoy Aa N Dswjga #Tags: A25A | TA-25 A | TA 25 A

Condition: ready for operation (used), Year of construction: 2000, Available immediately from location: CNC bed milling machine MTE Model Kompakt Plus Fjdpfx Adoyzdy Rjwsga Year of manufacture 2000 Heidenhain TNC 410 Table 2200 x 750 mm Travel X/Y/Z 2000/800/800 mm Table load 4 t Spindle taper SK 50 Hydraulic tool clamping Spindle speeds 40 – 2500 rpm Spindle power 15 kW Total power requirement 30 kW Coolant system Weight 12 t Price: EUR 12,500 — plus VAT, ex location

Condition: excellent (used), Brand: CORREA Model: CF-22 PLUS Cnc: HEINDENHAIN 530 Table dimensions : 2.500 x 700 mm Number of slot: 5 Slot dimensions: 22 mm Axis travels (X,Y,Z) : 2.000 x 800 x 800 mm Head type : Universal manual Tool camping : Hydraulic Fsdpfx Ajyxr Azsdwsga Taper : ISO 50 (DIN 69871) Speed range : 4.000 rpm Spinale power : 22 kw Rapid feeds : 12.000 mm/min Maximum weight on table : 4.000 kg Machine dimensions : 6.605 x 3.315 x 2.730 mm Machine weight : 10 tn Machine equipped with : Fairing Chip conveyor Electronica handwheel

Condition: not inspected (used), Year of construction: 1986, functionality: unexamined, travel distance X-axis: 2,000 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 1,000 mm, rotational speed (max.): 1,700 rpm, controller model: Heidenhain TNC 155, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Fedpfxjyv Ar Us Adwoga X-axis travel: 2,000 mm Y-axis travel: 900 mm Z-axis travel: 1,000 mm Clamping surface: 2,200 x 960 mm Spindle speed range: 20 – 1,700 rpm Tool holder: SK 50 Rapid traverse: 10 m/min Number of milling head positions: 4 MACHINE DETAILS Control model: Heidenhain TNC 155 Dimensions & Weight Space requirement (L x W x H): approx. 7,000 x 4,200 x 2,900 mm Machine weight: approx. 16 t

Condition: ready for operation (used), Year of construction: 2002, operating hours: 41,859 h, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,500 mm, controller manufacturer: Heidenhain, TECHNICAL DETAILS Travel X-axis: 2,000 mm Travel Y-axis: 1,500 mm Travel Z-axis: 1,500 mm Number of stations: 90 Fsdpfx Adjyvt Aqowjga Head and rotary table: 1,600 x 1,450 mm MACHINE DETAILS Control type: CNC Control: Heidenhain Operating hours Control on-time: 106,253 h Machine on-time: 93,170 h Program runtime: 41,859 h

Condition: excellent (used), Year of construction: 2005, operating hours: 8,800 h, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (min.): 4,000 rpm, Correa Prisma with Heidenhain 530 With many SK 50 holders Fgsdpfx Adsyuy Tfowea

Condition: used, Year of construction: 2004, x-travel 1600 mm y-travel 920 mm Fgedpfsyt R E Nsx Adwoa z-travel 900 mm table surface area 1800x700 mm T-slot - distance 120 mm Table load 3000 kg spindle taper ISO 50 power capacity 22/30 kW spindle turning speed range 60-3000 U/min Magnetic clamping plate can be purchased optionally The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1990, x-travel 2800 mm y-travel 1000 mm z-travel 1200 mm table surface area 2000 x 800 mm rotary table dia. 800 mm spindle taper SK 50 spindle turning speed - stepless 50 - 2000 U/min max. torque on the spindle 3000 Nm spindle drive 30 kW feeds longditudinal/cross/vertical 2 - 2000 mm/min rapid motion -longitudinal/cross/vertical 7 m/min control SIEMENS control SINUMERIK 850 M no. of tools in magazin 56 workpiece diameter at full load 114 mm wotkpiece diameter with 2 vacant positions 200 mm workpiece length 400 mm weight of tools max. 16 kg tool changing time ca. 8 - 9 sec internal coolant system feed ja / yes weight of the machine ca. 25,4 t Fgedpoyt Rwlofx Adwea = 5-axis CNC-bed-type milling machine with integrated NC-rotary table and NC-swivelling milling head - Acc.: tool pre-setting device, various tool fixtures, chip conveyor, coolant with high pressure pump and filtration device, electron. handwheel, fixators

Condition: good (used), Year of construction: 2002, travel distance X-axis: 2,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, spindle speed (max.): 4,000 rpm, rotational speed (max.): 4,000 rpm, Bed type milling machine Correa CF22-Plus Travel range: X: 2,000 mm Y: 800 mm Z: 800 mm Manual swivel head Spindle: SK50 Spindle speed: 4,000 rpm Chip conveyor External coolant supply Tool changer: 30-position magazine Control: Heidenhain TNC426 Handwheel Documentation and export possible at extra cost. Machine inspection under power possible. Fgsdpfx Ajytqb Djdwoa We are happy to send you further details or arrange an on-site inspection.

Condition: used, Year of construction: 2001, CNC Fixed Bed Milling Machine CORREA type CF 17 D Year of construction: 2001 Fodpfxoyrf H Ej Adwega Travel X: 2000 mm Travel Y: 800 mm Travel Z: 800 mm Numerical Command: HEIDENHAIN 426 Spindle: ISO 50 Spindle speed: from 20 to 3000 RPM Table size: 2000 x 700 mm Max weight on table: 3500 kg Spindle motor: 17 kW Dimensions (L x W x H): 5300 x 2900 x 2800 mm Weight: 9 T

Condition: used, Year of construction: 1986, x-travel 2400 mm y-travel 2000 mm z-travel 1450 mm table surface area 5000 x 1400 mm spindle taper SK 50 Control Fidia C1 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop Fodpfxsyqwb So Adwsga If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,270 mm, travel distance Z-axis: 1,500 mm, controller model: Heidenhain 530, Equipment: chip conveyor, TECHNICAL DETAILS X-axis travel: 3,000 mm Y-axis travel: 1,270 mm Z-axis travel: 1,500 mm Spindle speed: up to 4,000 rpm Tool holder: SK50 MACHINE DETAILS Fjdpfeymcu Aex Adwjga Control: Heidenhain 530 Internal cooling: 22 bar EQUIPMENT Diagonal milling head with 2.5 x 2.5 indexing Longitudinal chip conveyor

Condition: ready for operation (used), Year of construction: 1990, functionality: fully functional, travel distance X-axis: 2,800 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,200 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 50 rpm, TECHNICAL DETAILS Travel X-axis: 2,800 mm Travel Y-axis: 1,000 mm Travel Z-axis: 1,200 mm Spindle speeds: 50 - 2,000 rpm Spindle torque: 3,000 Nm Spindle taper: SK 50 Feed rate - X / Y / Z axis: 2 - 2,000 mm/min Rapid traverse - X / Y / Z axis: 7,000 mm/min Table clamping surface: 2,000 x 800 mm Rotary table diameter: 800 mm Number of tool magazine stations: 56 Tool diameter (all stations filled): 114 mm Tool diameter (with 2 free positions): 200 mm Max. tool length: 400 mm Max. tool weight: 16 kg Tool change time: approx. 8 - 9 sec Control system: SIEMENS SINUMERIK 850 M MACHINE DETAILS Spindle motor power: 30 kW Dimensions & Weight Dimensions (L x W x H): approx. 6.6 x 3.15 x 2.98 m Machine weight: approx. 25.4 t EQUIPMENT Tool presetting device Various tool holders Chip conveyor Internal coolant supply Coolant system with high-pressure pump and filtration unit Electronic handwheel Fgedpsyl U Thjfx Adwoa Fixators

Condition: good (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: KNC-U 1000, travel distance X-axis: 2,600 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, feed length X-axis: 2,600 mm, feed length Y-axis: 1,000 mm, feed length Z-axis: 1,000 mm, rapid traverse X-axis: 12 m/min, rapid traverse Y-axis: 12 m/min, rapid traverse Z-axis: 12 m/min, feed rate X-axis: 5 m/min, feed rate Y-axis: 5 m/min, feed rate Z-axis: 5 m/min, position of the milling head: 1, table width: 3,600 mm, table load: 8,000 kg, table length: 1,000 mm, table height: 930 mm, total height: 3,160 mm, total width: 5,100 mm, total length: 9,820 mm, KIHEUNG Pegasus KNC-U 1000 CNC bed milling machine with Heidenhain TNC-426 Machine condition: In good condition Manufacturer: KIHEUNG Fgjdpfxsylbico Adwja Model: Pegasus Machine type: KNC-U 1000 Year of manufacture: 1999 Travel X-axis: 2,600 mm Travel Y-axis: 1,000 mm Travel Z-axis: 1,000 mm Feed rate X-axis: 10 - 5,000 mm/min Feed rate Y-axis: 10 - 5,000 mm/min Feed rate Z-axis: 10 - 5,000 mm/min Rapid traverse X-axis: 12 m/min Rapid traverse Y-axis: 12 m/min Rapid traverse Z-axis: 12 m/min Tool holder: SK 50 DIN2080 Speed range: 0 - 4,000 rpm Table size: 3,600 x 900 mm Table working height: 930 mm Table load: 8,000 kg Dimensions: 9,820 x 5,100 x 3,160 mm Weight: 21,500 kg

Condition: reconditioned (used), functionality: fully functional, machine/vehicle number: F39033, KEKEISEN Universal Bed Milling Machine UBF 2000/13, machine no. F39033; well maintained, very good condition, mechanically partly overhauled in 2025 2-axis universal head automatically swivelling, with locking in Hirth coupling Intermediate positions adjustable in 1° steps by jog mode SK50 tool holder according to DIN 69871/872 Longitudinal travel of the table (X-axis) 2000 mm Transverse travel of the headstock (Y-axis) 1000 mm Vertical travel of the headstock (Z-axis) 1300 mm Fgodpfx Asykuxhodwoa Machine table size 2200 x 960 mm, with T-slots 22 mm, spacing 140 mm Rotary table rotation 360° (stepless, with clamping) Rotary table load 5000 kg Spindle power 30 kW (100%ED), max. torque 1180 Nm Spindle speed 20 - 3800 rpm (infinitely variable in 2 ranges), with oil cooling Axis speeds 4 m/min or 10 m/min rapid traverse CNC control Heidenhain TNC 426 CA with electric handwheel HR 330 Drive system make Baumüller Coolant system with inner cooling up to 16 bar. Air/water changeover Purolator double-switching filter with 200 litre collecting tank Tool changer for 30 tools Work area panelling all round, open at the top, with longitudinal chip conveyor Connection data 400 V; 50 Hz; approx. 55 kVA without installation elements (fixators),

Condition: good (used), Year of construction: 2006, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, Travel paths Longitudinal (X): 2500 mm Vertical (Y): 1250 mm Transverse (Z): 1000 mm Table size (rotary): Length: 1000 mm Width: 1000 mm Max. table load: 5000 kg T-slots: 6 x 22 mm H10 Drive power: 100% duty cycle, 24 kW Tool holder: ISO 50, DIN 69871 - AD Spindle speeds: 20 – 4000 rpm Torque: 479 Nm Feed rates (X, Y, Z): 10 – 10,000 mm/min Rapid traverse (X, Y, Z): 25,000 mm/min Weight: approx. 15,000 kg Equipment: - Internal coolant supply according to DIN 69871 Form AD, including minimum quantity oil lubrication with 15 different dosing levels via programmable M-functions; 20 bar - NC rotary table, size 1000 x 1000 mm, integrated as 4th axis into the CNC control. Max. load capacity 5000 kg, positioning accuracy ±5", table surface with 22 mm T-slots. - Chip conveyor for TA-D 25 - Tool changer Fjdpfx Ajykbxzjdwega Accessories - Front-mounted movable control pendant including Heidenhain iTNC 530 control (1 processor) - Portable electronic handwheel HR 420 with 3 m spiral cable (option) - 3D thermal expansion compensation - Automatically indexing milling head / 2 planes with 2.5° indexing (H200) (option) - Distance spindle nose to table edge: 250 mm - NC rotary table, size 1000 x 1000 mm, integrated as 4th axis into the machine control. Max. load capacity 5000 kg, positioning accuracy ±5", table surface with 22 mm T-slots - Coolant system with 150 l tank capacity, delivery pressure 5 bar, delivery rate 50 l/min, discharge via shower ring around spindle - Splash guard enclosure, fully enclosed on 4 sides with front sliding doors and an additional sliding door on the left side column and viewing windows on all 4 sides - Heidenhain drive motors on all axes with digital drive technology - INA linear roller guide system on all axes - Direct linear measuring system Heidenhain on all axes - Telescopic covers for X-axis guideways - Ball screws on X, Y, and Z axes - Automatic cycle lubrication for all axes and moving components - Electrical equipment by Siemens - Hydraulic system by Vickers

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 5220511, travel distance X-axis: 2,600 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 4,000 rpm, workpiece weight (max.): 8,000 kg, TECHNICAL DETAILS Fgjdjygxgzspfx Adwea Travel X-axis: 2,600 mm Travel Y-axis: 1,000 mm Travel Z-axis: 1,000 mm Max. workpiece weight: 8,000 kg Table size: 3,600 x 900 mm Number of T-slots: 6 T-slot width: 22 mm T-slot spacing: 125 mm Spindle taper: ISO 50 DIN 69871 Spindle speed: 4,000 rpm (2 ranges: 0 - 1,000 rpm) Feed rate: 10 - 5,000 mm/min Rapid traverse: 10,000 / 10,000 / 10,000 mm/min MACHINE DETAILS Control: HEIDENHAIN TNC 426 Dimensions & Weight Space requirement: approx. 9.82 x 5.1 x 3.16 m Machine weight: approx. 21.5 t Motor Spindle drive motor: 29 kW Feed drive motor (Y-axis): 20 Nm Feed drive motor (X and Z-axis): 27 Nm Hydraulic motor: 2.2 kW Coolant pump motor: 0.50 kW Lubrication pump motor: 0.09 kW EQUIPMENT Tool changer Both head joints have 2.5°

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,700 mm, travel distance Z-axis: 1,500 mm, Heidenhain 530 Fjdjx I A Hvopfx Adwjga Diagonal milling head with 2.5° x 2.5° indexing Spindle speed up to 6,000 rpm Tool holder SK50 Internal cooling with 36 bar Longitudinal chip conveyor + cross conveyor

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,100 mm, Rotary table 1,250 x 1,400 mm (interference circle 1,700 mm) Heidenhain 530 Diagonal milling head with 1° x 1° indexing Speed up to 5,000 rpm Tool holder SK50 Tool changer with 40 positions Internal coolant supply with 19 bar Chip conveyor in longitudinal direction Fodox Iuccopfx Adwega

Condition: used, Year of construction: 1990, Fixed Bed Milling Machine CORREA A25/25 Travel X: 2500 mm Travel Y: 1200 mm Travel Z: 1000 mm CNC HEIDENHAIN TNC 355 Fgsdpfx Adoxxa R Dswoa Spindle: SA 50 Spindle motor: 30 CV Spindle speed: from 2 to 3000 RPM Table size: 3000 x 1000 mm Year of construction: 1990 Maxi eligible load on table: 7 T Manual Swivel Head Voltage: 380 V Dimensions (L x W x H): 5000 x 3000 x 3000 mm Weight: 16,5 T

Condition: used, Year of construction: 2008, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 5,000 rpm, HEIDENHAIN iTNC 530 CNC X-AXIS TRAVEL: 3000 MM Y-AXIS TRAVEL: 1400 MM Z-AXIS TRAVEL (Vertical): 1500 mm SPINDLE SPEED: 5000 RPM SPINDLE NOSE ATTACHMENT: SK 50 TABLE MEASURES: 3200 X 1100 MM TABLE LOAD CAPACITY: 10,000 KG 24-Place Tool Changer No. 02 Chip Conveyors Automatic Indexed Head a axis 2,5 ° b axis 3 ° YOM 2008 Fgsdoxvrrhepfx Adwsa

Condition: refurbished (used), Year of construction: 1996, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 900 mm, rapid traverse X-axis: 10 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 15 m/min, feed rate X-axis: 5 m/min, feed rate Y-axis: 5 m/min, feed rate Z-axis: 5 m/min, position of the milling head: osa A 105°+ osa B 90°, spindle speed (max.): 3,500 rpm, spindle speed (min.): 3,500 rpm, table width: 800 mm, table load: 8,500 kg, table length: 3,000 mm, table height: 1,000 mm, total height: 3,400 mm, total width: 4,360 mm, total length: 7,760 mm, type of input current: three-phase, rotational speed (max.): 3,500 rpm, workpiece weight (max.): 8,500 kg, overall weight: 18,000 kg, year of last overhaul: 2025, spindle motor power: 22,000 W, power: 22 kW (29.91 HP), Equipment: rotational speed infinitely variable, FSQ 80(100) S/A3 CNC - TOS KUŘIM Bed Milling Machine, Table Length 3m Control System: Heidenhain 415F Complete Mechanical Overhaul: 2024 Availability: IMMEDIATE DELIVERY Warranty: 6 months FSQ 80(100) O/A3 CNC – Technical Specifications: Basic machine data: Manufacturer: TOS Kuřim Overall length: 7,760 mm Overall width: 4,360 mm Fgedpsxp Dkcjfx Adwoa Overall height: 3,400 mm Total weight: 18,000 kg Total power consumption: 40 kVA Working range: Longitudinal travel X-axis: 3,000 mm Cross travel Y-axis: 1,000 mm Vertical travel Z-axis: 900 mm Spindle head (S Head): Max. power: 22 kW Speed range: 16 – 3,500 rpm Number of speed ranges: stepless Spindle rotation around A-axis: 105° Spindle rotation around B-axis: 90° Feed range X – Y / Z: Number of speed ranges / range: stepless / 1 – 5,000 mm/min Rapid traverse Y – Z / X: 10,000 / 15,000 mm/min Table: Table area: 800 x 3,000 mm Max. load: 8,500 kg Control System: Heidenhain 415F Further details on request.

Condition: used, Year of construction: 2008, MILLING MACHINE STS AVANTGARDE HS YEAR: 2008 CNC: SELCA S 4045 DH WORKTABLE DIMENSIONS: 2,200 mm x 1,100 mm TRAVEL PATHS: X: 2,000 mm Y: 1,500 mm Z: 1,500 mm SPINDLE TAPER: ISO 50 MAX. ALLOWABLE LOAD: 6,000 KG AUTOMATIC BI-ROTARY HEAD: A 2.5° - B 2.5° SPINDLE SPEED: 4,000 rpm Fgedpfxsxc Umhj Adwea POWER: 37 KW TOOL MAGAZINE: RANDOM, 24 POSITIONS HIGH PRESSURE: 20 BAR ACCESSORIES: 2-SPEED RANGE SELECTOR CHIP CONVEYOR MACHINE CAN BE SEEN IN OPERATION COMPLETE DOCUMENTATION

Condition: used, TECHNICAL DETAILS TABLE - Table dimensions : 3100/800 [mm] - Maximum weight upon table : 7000 [kg] - Travels on X/Y/Z axes : 3000/1000/1200 [mm] - Rapid traverses rates (X/Y/Z) : 15000/15000/15000 [mm/min] MILLING HEAD Manual head MILLING SPINDLE - Tool holder type : ISO50 * Spindle speeds : 4000 [rpm] * Spindle power : 27 [kW] TOOL CHANGER - Auto. Tool Changer type : Parapluie - Tool magazine capacity : 24 WEIGHT & DIMENSIONS - Machine floor space : 7913/5043 [mm] - Machine height : 3440 [mm] - Machine weight : 13410 [kg] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 38 [kW] MACHINE HOURS Fodpfxsw Tnhbj Adwsga - Number of hours under power : 24689 [h] - Number of working hours : 23809 [h] - Number of spindle hours : 7658 [h] EQUIPMENT - CNC : Heidenhain iTNC530 - Electronic handwheel Interface : RS232/RJ45/USB - Interactive programming - Coolant tank - Tool-holders

Condition: used, Year of construction: 2007, MILLING MACHINE STS AVANTGARDE HS Fgjdowtd Uxepfx Adwea YEAR : 2007 CNC : SELCA S 4045 DH TRAVELS : X : 3,000 mm Y : 1,500 mm Z : 2,000 mm TABLE DIMENSION : 1,500 mm x 1,500 mm MAX. PERMISSIBLE LOAD : 8,000 KG. AUTOMATIC DOUBLE-ROTATION HEAD: A 2.5° - B 2.5° ISO: 50 4,000 rpm 37 KW TOOL MAGAZINE: RANDOM 32 POSITIONS HIGH PRESSURE: 20 BAR ACCESSORIES: 2-SPEED RANGE CHANGE CHIP CONVEYOR MACHINE VISIBLE IN OPERATION COMPLETE WITH ALL DOCUMENTATION
