Eisenführer Metallverarbeitung e. U.

Condition: excellent (used), Year of construction: 2016, overall weight: 420 kg, tool diameter: 420 mm, travel distance X-axis: 210 mm, travel distance Z-axis: 450 mm, ZOLLER venturion 450 – CNC setting and measuring device, year of manufacture 2016, very little use The machine was purchased by the previous owner as an additional device and was practically not used; it was sold because it is no longer needed. Accordingly, the usage is very low – the machine is in new condition and fully functional. It is located in Velten and can be inspected while powered on by arrangement. THE ADVANTAGES - Very little use, new condition, last ZOLLER maintenance 12/2022 - CNC drives in X, Z and C: Cutting edge is automatically approached, focused and measured – independent of the operator, even with multi-cutting tools - Non-contact optics with transmitted and incident light: Contour, breakouts, wear and corner radius are detected - pilot 3.0: automatic cutting edge detection, zero point monitoring, tool and adapter management, test protocol, data transfer to the machines - Immediately ready for use with control unit, label printer and adapters SK 40 / VDI 40 / VDI 50 TECHNICAL DATA - Measuring range Z 450 mm · X radius 210 mm (tool Ø up to 420 mm) · Internal jaw depth Ø 100 mm - max. tool weight 50 kg - 100–240 V~, 50/60 Hz, 1 kVA · Compressed air 6–8 bar - W × D × H 2500 × 810 × 1710 mm · Weight 350 kg + control unit approx. 80 kg EQUIPMENT ACCORDING TO FACTORY EQUIPMENT LIST ZOLLER (05/13/2016) 1. Z05MK446.11 USB camera with optics and integrated LED incident light 2. Z05E6187 Transmitted light "pilot" "DLR" / V-series 3. Z05E6127.11 USB camera with optics and integrated LED incident light 4. V429530-01 HGV-ACE mounting assembly vent. 450+600 Rcedpfx Aj Advkzjbaoh 5. V429515 Accessory kit for drive and ROD "venturion 450/600" 6. N001831 Drive unit linear CNC/"usbmotion" 7. N001831 Drive unit linear CNC/"usbmotion" 8. N001918 Drive unit rotary CNC/"usbmotion" 9. Z05E6024 Foil keyboard "smart-size" for electronics-Z80 10. Z05E7026-01 USB motion controller 11. Z05E6038-00 Valve module Z100-V 12. Z05E6037-20 24V voltage distribution with fuses 13. Z05E6035-10 Lighting module Z100-L 14. Z9700910-36 ZOLLER measuring device control 11th generation panel PC 24" 2980U 15. Z9734883-01 Printer for TH labels, print width 25–108 mm 16. Z9734883-02 Power supply 24V DC 2.5A 60W, 100–240V AC 50/60Hz ADDITIONALLY INCLUDED - Adapters SK 40, VDI 40 and VDI 50 - Control unit on stand with monitor, keyboard and mouse - Software ZOLLER pilot 3.0 - Cables and small parts as shown in the photos Tools and tool holders are not included in the scope of delivery. SERVICE By arrangement: Installation and commissioning · Training · Demonstration under power in Velten · Transport. TRANSACTION Location 16727 Velten near Berlin · FCA Velten incl. loading · 100% prepayment · Delivery 1–2 working days after payment receipt. Data sheet as PDF attached. Technical data according to nameplate, operating manual and factory equipment list (information, not a guarantee of quality according to §§ 434, 443 BGB). Errors and prior sale excepted.

Condition: used, Year of construction: 1978, machine/vehicle number: 27309654, No minimum price – guaranteed sale to the highest bidder! Loading: December 1st to December 10th. TECHNICAL DETAILS General Information Machine Type: 3D Coordinate Measuring Machine Machine Weight: approx. 2 t Travel Ranges X-axis travel: 1,600 mm Y-axis travel: 1,000 mm Z-axis travel: 1,300 mm Working Areas Working area Y-axis: 175–1,210 mm Working area Z-axis: 0–810 mm Baseplate Size of baseplate: 1,500 × 800 × 120 mm Digital Display Digital display: Grundig 3-axis Digimess Dimensions of digital display: 235 × 80 × 130 mm Performance Data Rjdpfj Aa Np Njx Abaech Total power consumption: 0.04 kW Dimensions Space requirement: approx. 2.0 × 1.5 × 1.63 m EQUIPMENT Finely scraped cast plate with 4 adjustable feet, 2,000 × 1,500 mm Approx. 20 different probing and measuring styli Stiefelmayer guide system “A”

Condition: used, Year of construction: 2010, measuring range X-axis 300 mm measuring range Y-axis 1 mm Table dimensions 1 mm tool diameter 600 mm Control Pilot 3 Redpfo Aa A D Tox Abasch measuring range Z-axis 800 mm

Condition: used, Year of construction: 2012, Manufacturer: ZOLLER, Model: Smile 400, Year of manufacture: 2012, including evaluation unit, touch screen monitor, multi-function device, manufacturer: Brother, model: MFC 9465CDN, label printer. Rcsdpsz Tpw Uefx Abaeh +++ Attention: This item is part of an online auction! +++

Condition: used, Year of construction: 2004, DMG Prima 225/465 microset high precision tool presetter with PC, dual screens, printer, keyboard, mouse, Dymo label printer & assorted location pots. Rcjdpjz Hz Ausfx Abajh Maximum tool ø450mm (based On A 225mm measuring radius). Maximum measuring length (Z-axis) 465mm.

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 99500007558, total width: 800 mm, total length: 1,100 mm, total height: 800 mm, input voltage: 230 V, overall weight: 150 kg, table length: 1,100 mm, table width: 800 mm, table height: 800 mm, input frequency: 50 Hz, compressed air connection: 8 bar, The machine is in very good condition and comes from an educational institution. Rcedpfx Abjz E A A Teaeh

Condition: used, Year of construction: 2017, Tool Presetter Manufacturer: ZOLLER Type: SMILE 420 Year of manufacture: 2017 Technical details Measuring range Z: 420 mm Measuring range D: 420 mm Tool holder: SK 50 Weight: approx. 215 kg Additional information: Condition: Used Redpsz Ek D Esfx Abajch Technical features & accessories: - Adapter SK 50 to SK 40 - Pilot 1.0 software Accessories, tools, and clamping devices shown are included in the scope of delivery only if specified in the additional information. Subject to technical changes, errors, and prior sale.

Condition: good (used), Year of construction: 2018, Machine is in good working condition. Rcedpfx Abjzyqh Nsaeh

Condition: like new (used), Year of construction: 2017, functionality: fully functional, Manufacturer KELCH GmbH, Weinstadt, Germany Type / Model KENOVA set line V646M Year of manufacture 2017 Design Vertical tool pre-setting and measuring device Measuring range Diameter X up to approx. Ø 430 mm (V6 series) Extended X range up to approx. -100 mm (V6 series) Rjdpfx Aszw Ef Rjbajch Measuring length Z, depending on V6 version, approx. 800 mm Repeatability of camera approx. ± 2 μm (series specification) Measuring system Optical camera system / CCD camera Optics Telecentric lens; features depend on version Tool holder Modular precision spindle; adapter depends on features Possible holders e.g. SK, HSK, PSC, VDI with matching inserts Positioning Coarse and fine positioning in X/Z, depending on features Operation A KELCH pico control terminal can be seen in the photo Mains voltage 90-260 V Mains frequency 50-60 Hz Maximum power consumption 1000 VA Marking CE / Made in Germany

Condition: good (used), Year of construction: 2000, measuring range X-axis 330 mm Redpezupmmofx Abaech measuring range Z-axis 400 mm dimensions 880 x 520 x 990 m Tool spindle: SK 50 Indexable (4× 90°), pneumatic Measuring system: Heidenhain LS series, optoelectronic Profile projector/optics: 0× magnification, cutting edge control using crosshairs Weight: approx. 250 kg

Condition: like new (used), Year of construction: 2023, Technical specifications: Rsdpfxjzrgdqo Abajch Measuring range, X-axis: 400 mm Measuring range, Z-axis: 500 mm Max. tool length: 600 mm Max. tool diameter: ∅ 400 mm CNC control Dimensions (width x depth x height): approx. 1200 x 900 x 2100 mm Condition: Condition is almost like new, very little use. The seller is not liable for typographical or data transmission errors. The machine's appearance, technology, and wear correspond to its age; used machines are sold without any warranty.

Condition: good (used), Year of construction: 2002, Tolerance: -10% to +6% Rjdpfszl Thvsx Abasch Pneumatics: 4 - 6 bar Power consumption: < 1000 VA

Condition: good (used), Year of construction: 2003, functionality: fully functional, Tolerance: -10% to +6% Pneumatics: 4 - 6 bar Power consumption: < 1000 VA Rcedpfjzl Thcox Abaeh

Condition: used, Year of construction: 2008, measuring range X-axis 320 mm measuring range Z-axis 720 mm - - - - - - - - - Tool presetter | DMG MICROSET - VIVA 720 The tool presetter is in a well-maintained condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VIVA720 | VIVA-720 Redpfxjzd Hdzj Abajch

Condition: like new (used), Year of construction: 2019, functionality: fully functional, Zoller Titan tool measuring machine: Rcodezd Acaepfx Abajh - Year of manufacture: 2019 - Software: titan/pilot 3.0 - Max. tool length (Z-axis) = 550 mm - Max. tool diameter = 260 mm - Tool holder: SK40, KSK63, etc., as required

Condition: used, Year of construction: 2017, functionality: fully functional, type of input current: AC, overall weight: 280 kg, input frequency: 60 Hz, compressed air connection: 8 bar, For sale is a fully functional, tested EZset tool presetter, type EZS420C2X, manufactured in 2017, complete with monitor and printer – tested and ready for immediate use. This system is of German manufacture (EZset GmbH & Co. KG, Pleidelsheim) and is designed for precise use in tool and machine construction. The unit has been regularly maintained, operated exclusively in a climate-controlled measuring room, and is in very good technical and visual condition. Technical data: - Manufacturer: EZset GmbH & Co. KG - Model: EZS420C2X-00074 - Year of manufacture: 2017 - Original purchase date: 23.11.2018 (invoice included) - Power: 600 VA - Voltage: 100–120 V / 200–240 V AC · 50/60 Hz - Pneumatics: 6–8 bar (80–110 PSI) - Weight: 280 kg - Tool holder: Adapter-SK 40 & Adapter-HSK 63 Measuring ranges: - Z = 420 mm - D = 420 mm - max. jaw diameter = 100 mm Rjdpfx Asy S Ti Nsbasch Operating monitor: MOSTRON PPC13-113286-F (12–24 V DC, 50 W) with touchscreen Operating system: Windows Embedded Standard (licensed) Backup software: Drive Snapshot 1.4 (licensed) Label printer: TSC Auto ID DT2205 (24 V, TÜV and CE certified) Equipment & Functions: - Precise measurement of tools in the X and Z directions - High-resolution camera and screen display - Pneumatic tool holder - Intuitive touch operation with EZset software - Label printer for tool identification - Fully integrated control and pneumatics - All original nameplates and CE certificates are available Condition: - Fully functional and ready for use - No error messages or defects - Clean, well-maintained overall condition - Directly from ongoing operation Scope of delivery: - EZset EZS420C2X unit - MOSTRON operating monitor - TSC label printer - Pneumatic connection - All connecting cables and accessories as shown in the pictures

Condition: used, Year of construction: 2009, machine/vehicle number: H400C3-0066, Zoller presetting device Hyperion 400 Versatile Flexible turret table configuration as needed Universal One single measuring device for almost all different tool holders Simple Convenient operating elements and user-friendly software Time-saving Turret table equipped with commonly required holders Stable Special alloy and robust construction Economical Consistent use of brand-name products and best price-performance ratio Rcedpfxsy D D U Hj Abaoh

Condition: used, Year of construction: 2003, machine/vehicle number: V420D2-0038, Zoller Venturion 500, Tool presetting device. Versatile: Flexible turret table configuration to suit your requirements. Universal: A single measuring device for almost all different tool holders. Simple: Comfortable controls and user-friendly software. Time-saving: Turret table equipped with frequently used holders. Stable: Special alloy and robust construction. Economical: Consistent use of branded components and excellent price-performance ratio. Rjdpfxoy D D Utj Abaoch

Condition: used, Year of construction: 2009, machine/vehicle number: V445C3-00236, Zoller Venturion 450 Precise measurement regardless of operator High degree of automation with CNC axes, autofocus, and rotary encoder Power-operated and universal tool clamping High-precision “ace” spindle clamps tools at the push of a button Rcsdpfxsy D D T Aj Abajh ZOLLER image processing “pilot 4.0” and large 24" monitor Industrial high-resolution camera Next to the CNC machine, in the workshop, in manufacturing cells User-friendly

Condition: used, Year of construction: 1986, measuring range X-axis 500 mm Rjdsy Ay Nwopfx Abajch measuring range Y-axis . mm Table dimensions . mm tool diameter . mm

Condition: used, Length 800 mm measuring range X-axis 520 mm Table dimensions 700 mm weight 900 kg The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. Redpfx Aeytx Rysbaech We look forward to your visit. Your Markus Hirsch Team

Condition: used, tool diameter 300 mm length 300 mm weight 80 kg range L-W-H 800x400x750 mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. Redsytx Rtopfx Abasch About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 2011, functionality: limited functionality, machine/vehicle number: 782, Technical characteristics: Measuring Capabilities - Measuring range (Z-axis): 600 mm (≈ 23.6") - Measuring range (X-axis): 200 mm (≈ 7.8") - Max. tool diameter: 400 mm (≈ 15.7") - Snap gauge diameter: Up to 100 mm (optional) Rcodpfx Aoyanf Tsbaoh Performance Features - Spindle type: High-precision SK50 spindle with integrated calibration surfaces - Spindle locking: Power-operated brake with 4 × 90° indexing - Image processing: ZOLLER »pilot« software (version 3.0) - Camera: CCD with telecentric lens and 20× magnification - Cutting edge detection: Automatic, including edges >90° - Focus system: Analog focus display with dynamic cross hairs Control & Interface - User interface: Touchscreen with graphical guidance - Manual control: Ergonomic »eQ« single-hand operating handle - Fine adjustment: Electronic control for X and Z axes - Data transfer: RFID tool identification, label printing, and CNC integration Construction & Environment - Frame: Lightweight metal with optimal thermal conductivity - Scales: Heidenhain glass scales for high measurement accuracy - Software options: Tool management, adapter calibration, concentricity/run-out programs - Mounting/Measurement interfaces: # HSK63 # HSK100 # ISO40 # ISO30/BBT30 # BMT55 Machine status: FUNCTIONAL in manual mode only. For optimal performance, overhaul by the machine supplier is recommended.

Condition: used, Technical details: Heating: 15 kW rated current: 28 A Heating capacity: 15 kW current: max.71 A cooling water consumption: 11 l/min frequency range: 10-25 kHz frequency range: 50/60 voltage: 400-480 +-10% V current- max.: 3020 A weight: 406 kg dimensions L x W x H: 1,25 x 0,8 x 1,6 m The device is a mobile induction heater with medium power (15 kW), suitable for: Local heating of metals (e.g., bearings, bolts, screws, pipes, sheet metal edges). Rcjdoxfvldspfx Abajh Preheating for welding processes Soldering and shrinking applications Heat treatments (e.g., tempering or hardening of smaller components). Due to its frequency range of 10–25 kHz, the device is more suitable for medium to large workpieces, as the penetration depth at these frequencies is higher than with high-frequency systems. *

Condition: good (used), Year of construction: 2002, measuring range X-axis 330 mm measuring range Z-axis 400 mm 1 tool presetting machine Make: KELCH, Model: Kalimat C34, Year of manufacture: 2002 Measuring range X/Z 330 x 400 mm Easy-Wrap Set measuring software 2 VDI / HSK adaptors, machine table --> Measuring axes Two precision guides per axis in a recirculating ball bearing system with maximum load capacity; each guide features two ball-recirculating shoes per guideway to prevent yawing and pitching of the measuring slides. --> Heidenhain LS optoelectronic measuring systems, centrally positioned on both measuring axes for position determination at the centre of the measuring slides. --> Tool holders Hardened SK 50 tool spindle with a taper of gauge quality, mounted in precision roller bearings for maximum concentricity and repeatability. Rjdew N S Epspfx Abaech --> Tool spindle rotation pneumatically clamped at the touch of a button, positioning in 4 x 90° increments for vertical tools via pneumatic indexing pins. --> Cutting edge scanning High-quality profile projector with a 150 mm screen diameter and 20x magnification for non-contact measurement and reliable reading of the cutting edge position in the projector. --> Rotatable and fixed crosshairs for checking the radius and angle of the tool cutting edge. - in working order - no repairs required Includes measuring computer, label printer, monitor and keyboard Translated with (free version)
