Creativ-Metall

Condition: used, Year of construction: 2011, total length: 5,000 mm, total width: 2,100 mm, total height: 1,650 mm, Weight: 7.800 kg - Year: 2011 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 02969-099B81 - Drive system: CNC - Control system brand: Cybelec - Control system type: - Drive type: Hydraulic - Configuration: Swing-beam - Power [kW]: 11.0 - Max. sheet thickness [mm]: 6 - Max. working width [mm]: 4100 - Backgauge type: Electric - Backgauge depth [mm]: 1000 - Sheet support system: Pneumatic - Finger guard: Fixed with lift-up guard - Angle adjustment: Motorized - Blade gap adjustment: Manual - Table type: Fixed table - Transport dimensions: 5000mm x 2100mm x 1650mm (l x w x h) - Transport weight [kg]: 7800kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum Ppodpfx Afeyxqruj Tsp

Condition: good (used), functionality: fully functional, Year of construction: 2024, control type: CNC control, Hezinger Cutline guillotine shear, year of manufacture 2024, NC control unit ELGO P 40 T touch screen, servo-controlled backgauge 5 - 1000 mm, positioning accuracy 0.1 mm, cutting gap adjustment, cutting length 4050 mm, sheet thickness 400 N/mm² - 6 mm, sheet thickness 700 N/mm² - 4 mm, Podpfx Aoyxgbxjf Tjpp motor power 11 kW, strokes per minute 13, traverse speed 80 mm/s, oil capacity 250 liters, machine weight 12,000 kg, machine dimensions (L/W/H) 5600/3400/2200 mm,

Condition: good (used), Year of construction: 1995, Sheet width 6040 mm Sheet thickness 4 mm Total power requirement 12 kW Machine weight approx. 22 t Additional information - Specification - Back stop - Roll shelf Podpfjyw Ixcex Af Tspp

Condition: good (used), Year of construction: 1992, Sheet metal shears, tin scissors, sheet metal scissors, hydraulic shears -Sheet shear: hydraulic Ppedeywzbdepfx Af Tep -Cutting width: 2000 mm -Max. cutting thickness: steel 6 mm -Features: Back gauge, cutting gap adjustment -Space requirement: 3280/2700/H2060 mm -Transport dimensions: 2280/2700/H2060 mm -Weight: 5980 kg

Condition: excellent (used), functionality: fully functional, Year of construction: 2008, machine/vehicle number: 32231, control type: CNC control, sheet thickness (max.): 6 mm, LVD MVS 6/4050 Guillotine Shear / Sheet Metal Shear – Year of Manufacture 2008 For sale is a robust and reliable guillotine shear from the renowned manufacturer LVD. Technical Data: Manufacturer: LVD Company n.v. Model: MVS 6/4050 Year of Manufacture: 05/2008 Ppjdpfoywpkajx Af Top Maximum Cutting/Pressing Force: 197 kN Max. Sheet Thickness / Capacity: approx. 6 mm (typical for the model, depending on material) Working Length: approx. 4050 mm Max. Force: 10,000 daN Connection: 400 V / 50 Hz Power: 10.1 kW Description: The machine is in good used condition and is fully functional. It is ideally suited for precise cutting operations in steel and metal construction as well as industrial sheet metal processing. Its solid construction ensures high cutting quality and long service life. Features / Highlights: Industrial design High cutting accuracy Easy to maintain Proven LVD quality Fields of Application: Metal construction Sheet metal processing Workshops & production Viewing by appointment. The machine is currently inbound from England. Export, import, and transport can be arranged by us for an additional fee.

Condition: used, Year of construction: 2021, machine/vehicle number: 168600, Reference No. 26029 Technical Data: - Max. cutting width: 2080 mm - Max. cutting capacity at 45 Kp/mm²: 6 mm - Throat depth: 150 mm - Automatic cutting angle adjustment: 0.3 – 2° - Automatic cutting gap adjustment - Number of hold-downs: 10 pcs - Strokes per minute: up to 22 1/min - Front angle gauge approx.: - 2 front support arms approx.: - Motorized backgauge with positioning control up to 1000 mm - Rear area safety device with light barrier - Cutting line illumination - Working height: 860 mm - Electric foot switch Ppsdsywhuwopfx Af Tsp - Drive: 400 V / 11 kW - Space requirement approx.: W 3150 x H 2150 x D 2300 mm - Weight approx.: 4.8 t

Condition: used, Year of construction: 1977, sheet width 3050 mm plate thickness 6 mm Pjdpjyv Nzcsfx Af Topp weight 7.000 kg range L-W-H 3450x2200x1750 mm Equipment/accessories: - adjustable support table - Sheet support - angle stop - Sheet support arms - foot switch

Condition: used, Year of construction: 1990, sheet width 2500 mm plate thickness 4 mm cutting angle 1,49 ° 40-80 column arm 200 mm Number of hold downs 13 Stück Ppodpfeyv Nx Iox Af Tsp back stop - adjustable 5-1000 mm table height 750 mm oil volume 85 l air pressure - required 5 bar range L-W-H 3100x1900x1500 mm weight of the machine ca. 3.600 kg Accessories: -Control RAS Multicut 2000 -Sheet metal holding device -Foot switch -Angle stop -Sheet metal support arms -Side protective grilles

Condition: new, sheet width 1350 mm 3 mm sheet thickness for stainless steel 1,5 mm rear stop 600 mm total power requirement 3 kW weight of the machine ca. 1150 kg dimensions 2030 x 1940 x 1220 mm Standard equipment: - All-steel welded construction with static and dynamic frame rigidity frame rigidity - Direct drive with brake motor - Specially alloyed cutting blades - 750 mm motorized, digitally adjusted backgauge with ball screws recirculating ball screws - Manual blade gap adjustment system - Mechanical sheet clamping system with plastic base - Work table with insert plates - foot switch for single and repeat cutting cycles - 1 x squaring arm 1000 mm long with metric scale Ppsdpfxjyv Nt Se Af Tjp - 2 x 800 mm front material support arms - Front stop - Finger protection - front and rear covers - Rear light guards - CE declaration of conformity

Condition: used, Year of construction: 1994, sheet width 4000 mm plate thickness 6 mm distance between columns 4010 mm machine weight ab. 7.500 kg total power requirement 16 kW rear stop 700 Ppjdpfjyv Nncox Af Top

Condition: used, Year of construction: 1971, sheet width 2550 mm Psdoyv Nmxspfx Af Tspp plate thickness 3,5 mm range L-W-H 3200x1300x1400 mm weight of the machine ca. 3.000 kg

Condition: good (used), functionality: fully functional, Hydraulic Guillotine Shear SAGITA Working width: 2500 mm Shearing capacity: 5 mm Electric back gauge Foot pedal, machine feet Condition: Good, blades OK, cuts cleanly. Ppodpfxsyv Ikcj Af Tsp Can be inspected under power. Loaded free of charge from D -88433 Schemmerhofen.

Condition: used, Max. cutting length: 2540 mm Max. sheet thickness: 6 mm steel Motor-adjustable rear stop (2 speeds) up to 1000 mm with display Side stops and table extensions cutting length limitation Cutting edge lighting Weight approx. 5500 kg Podsyvgcispfx Af Tjpp

Condition: good (used), functionality: fully functional, Year of construction: 2012, Used 3-meter guillotine shear from Ermaksan Model: HDG 3100 x 6 Ppedpfx Afeyu H Hxj Tsp Year of manufacture: 2012 Steel capacity: 3100 x 6 mm Cybelec control for the backgauge

Condition: good (used), Year of construction: 1993, machine/vehicle number: 93 G 229, Offer 25340 Technical Data: - Cutting length: 3070 mm - Cutting thickness: 6.5 mm - Adjustable cutting angle: 0.5 – 3° - Number of sheet holders: 18 pcs - Strokes per minute: 10 – 23 min - Motorized backgauge up to: 750 mm - Front angle stop + support arms - Pneumatically assisted sheet support Ppedpfx Aeyux Rcjf Tep - Automatic adjustment of cutting angle according to sheet thickness - Cutting length limitation - Automatic positioning of the backgauge - Automatic backgauge retraction - Drive: 400 V / 15 kW - Pneumatic connection: 6 bar - Electric foot switch - Space requirement approx.: W 3,850 x H 1,750 x D 1,800 mm - Weight approx.: 5,500 kg

Condition: used, Year of construction: 1995, sheet width 6000 mm plate thickness 6 mm distance between columns 610 mm Control Elgo 87 P2 total power requirement 15 kW weight of the machine ca. 22 t The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. Pedpfx Afjyutt Eo Topp We look forward to your visit. Your Markus Hirsch Team

Condition: new, functionality: fully functional, Year of construction: 2026, control type: PLC-controlled, degree of automation: automatic, actuation type: hydraulic, stroke rate (max.): 14 1/min, sheet thickness (max.): 6 mm, sheet thickness aluminum (max.): 6 mm, sheet thickness brass (max.): 6 mm, sheet thickness copper (max.): 6 mm, sheet thickness steel (max.): 6 mm, sheet thickness stainless steel (max.): 6 mm, input voltage: 400 V, type of input current: three-phase, overall weight: 7,380 kg, total length: 3,840 mm, total width: 1,675 mm, total height: 1,620 mm, warranty duration: 12 months, Equipment: documentation/manual, emergency stop, foot remote control, type plate available, HYDRAULIC GUILLOTINE SHEAR 6 × 3200 mm Hydraulic guillotine shears are used for straight-line cutting of sheets and strips made of steel, non-ferrous metals, and other materials. Technical data: Maximum sheet thickness: 6 mm Maximum cutting length: 3200 mm Blade rake angle: fixed −2° Number of strokes per minute: 14 Back gauge travel: 20–600 mm (standard) Distance between side frames: 3450 mm Table height: 800 mm Motor power: 7.5 kW Weight: 7380 kg Machine dimensions (L × W × H): 3840 × 1675 × 1620 mm Equipment: Controller E21 Motorized back gauge Back gauge with ball screws Hydraulic sheet hold-downs along the entire cutting length Segmented blades with the possibility to replace only the damaged segment Digital readout of the back gauge position Blade gap adjustment Set of blades Ball transfer units on the table 3 front support arms Front gauge with measuring scale Rear safety guard Front safety guard Illuminated cutting line Foot pedal CE declaration of conformity Manual in Polish Pedpjyt E Eksfx Af Topp Delivery conditions: The machine is brand new 12-month warranty Warranty service Post-warranty service CE declaration of conformity Operation and maintenance manual (English) Delivery to the customer is possible. Transport cost is calculated individually by the transport company. If you are interested in other machines, we encourage you to visit our website.

Condition: used, Year of construction: 2013, total length: 4,110 mm, total width: 2,400 mm, total height: 2,100 mm, Weight: 7.250 kg Price: On request - Year: 2013 Pedpeytgapefx Af Tjpp - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 607913428 - Drive system: CNC - Control system brand: Cybelec - Control system type: D-Touch-7 - Drive type: Hydraulic - Max. sheet thickness [mm]: 6 - Max. working width [mm]: 3100 - Cutting speed [mm/min]: 15 - Throat depth [mm]: 150 - Backgauge type: Electric - Backgauge depth [mm]: 1000 - Finger guard: Fixed - Transport dimensions: 4110mm x 2400mm x 2100mm (l x w x h) - Transport weight [kg]: 7250kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: good (used), functionality: fully functional, Year of construction: 2012, Expected in stock in approx. 3 weeks Safan M Shear 310 - 6 Capacity: 3100 x 6 mm TS1 Inox Touch control Return to sender Extra long back gauge of 1500 mm Scrap flap option Year of manufacture: 2012 Images are of another identical machine. Ppjdpjytb Tdsfx Af Tjp

Condition: good (used), functionality: fully functional, Year of construction: 1994, Used 3 meter guillotine shear by Volz Eurocut (Romanian manufacture) Model: Eurocut 6.5 Capacity: 3100 x 6.5 mm Electric back gauge Adjustable cutting angle Year of manufacture: 1994 Podpfxoytb Rps Af Tjpp

Condition: used, functionality: fully functional, Year of construction: 1980, Used 3 meter guillotine shear by Haco Model: Toolmaster 36 Capacity: 3100 x 6 mm Adjustable backgauge Ppsdpfxeytb Ins Af Top Year of manufacture: 1980

Condition: used, Year of construction: 2002, total length: 3,700 mm, total width: 2,150 mm, total height: 1,900 mm, Weight: 6.000 kg - Year: 2002 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: A10347 - Max. sheet thickness [mm]: 6 - Max. working width [mm]: 3000 - Throat depth [mm]: 200 - Backgauge depth [mm]: 1000 - Finger guard: Fixed Ppsdpfx Ajyr Scgsf Tsp - Transport dimensions: 3700mm x 2150mm x 1900mm (l x w x h) - Transport weight [kg]: 6000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: good (used), Hydraulic guillotine shear (used) Manufacturer: Fasti Model: TCHE 25/6 Max. cutting length: 2540 mm Max. sheet thickness (ST 40): 6.0 mm Distance between uprights: 2540 mm Backgauge travel: 0 – 750 mm Hold-downs: 16 units Motor power: 12 kW Machine weight: 5400 kg Required space: Width 3000 mm, Depth 2700 mm, Height 1900 mm Features: Foot switch, angle gauge, front support arms, motorized backgauge, cutting edge illumination, sheet lifting device. The machine is in very well-maintained condition and ready for immediate use. Forklift available, free loading onto truck. Affordable shipping possible. Location: 48477 Hörstel. Pedpfxeyrr E Uj Af Topp

Condition: used, Year of construction: 2002, sheet width 3050 mm plate thickness 6 mm rear stop 1000 mm cutting angle 0,5 - 3 ° down holder 18 Stk Ppsdpfx Aoyrhvvof Tsp no. of strokes 9-17 Hub/min total power requirement 7,5 kW dimensions of the machine ca. 3800 x 2000 x 1600 mm weight 4500 kg Equipment: - electric backgauge - electric cutting angle adjustment - manual cutting gap adjustment - SP 9 control unit - Safety guard behind the machine incl. light barrier - front finger guard - 1x side stop - operating instructions

Condition: used, Year of construction: 2018, sheet width 4050 mm plate thickness 20 mm distance between columns 4100 mm column daylight 4200 mm no. of strokes 10-20 Hub/min working pressure 250 bar total power requirement 85 kW weight of the machine ca. 43,6 t dimensions of the machine ca. 5,5x2,8x2,9 m No. 793 Please note: this machine has no electrical system. Pjdpfxsyqvche Af Tspp The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team
