Hauer-Schmidt GmbH

Condition: good (used), Year of construction: 1982, functionality: fully functional, Hydraulic Try-Out Press (Four-Column Press) Pressing force: 3.000 kN Maximum slide stroke: 1.20 mm Table size: 2.050 x 1.300 mm Distance between columns: 2.050 mm (long side), 700 mm (short side) Maximum distance from mounting surface to slide: 1.350 mm Minimum shut height: 250 mm Ibodpjz S H U Usfx Ad Njc Power requirement: 55 kW Tank capacity: 1.200 l Total weight: 55.000 kg Press height: 5.800 mm

Condition: good (used), Year of construction: 1979, functionality: unexamined, pressing force: 40 t, overall weight: 5,000 kg, Equipment: safety light barrier, SHC 40 Hans Schoen Ibsdpfx Adez S E S Se Nsc

Condition: used, Year of construction: 2001, pressure 200 t table surface area 1600 x 1300 mm ram stroke 600 mm dayligth 900 mm die cushion capacity 80 t die cushion stroke 150 mm die cushion area 1200 x 750 mm distance between columns 1650 mm table height over floor 1060 mm ram surface 1600 x 1300 mm oil volume 1250 l height over floor 4000 mm rapid drop speed 400 mm/sec drawing speed 42 (80 to) mm/sec drawing speed 20 (200 to) mm/sec return speed 410 mm/sec Control Siemens total power requirement 46,5 kW Iodpfx Adoz St Izo Nsbc weight of the machine ca. 15 t Machine is with cushion in table (80 t), light guards and Siemens control for presses.

Condition: like new (used), functionality: fully functional, pressing force: 250 t, total height: 4,800 mm, overall weight: 14,000 kg, Intemach TURI 250-H Ibjdoz Rprtspfx Ad Nsc 250-ton hydraulic press. Own weight is 14 tons, height is 4.8 meters. Table size: 1400 x 900 mm Main engine: 37 kW Auxiliary cylinder: 80 x 50 mm diameter Master cylinder: 340 mm diameter Ram stroke: 600 mm Working speed: 2 – 20 mm/sec

Condition: good (used), Year of construction: 1990, Bending length: 14,000 mm Column width: 10,500 mm Control: CYBELECCNC 7000 with graphic Iodpfx Adsz Rnn To Njbc Table width: 1,000 mm Distance between table and press beam: 1,800 mm Controlled axes: Y1; Y2; X1; X2 Control system was renewed in 2012 Total power requirement: 75 kW Machine weight approx. min.: 465 t Space requirement approx.: 14,600 x 4,200 x 7,200 mm Additional information - Distance between table and press beam: 1,800 mm

Condition: excellent (used), Year of construction: 1966, Exner 200 Pressure: 200 t Stroke: 180 mm Table length: 690 mm Table width: 530 mm Distance between columns: 420 mm Hydraulic four-column press for embossing, upsetting, Ibsdpfxsz N Tf Uo Ad Njc flow forming, calibrating, and punching Type H4SP 200 S 1101-3 Year of manufacture: 1966 _____ Downward pressure capacity: approx. 200 tons Upward retraction force: approx. 20 tons Usable table size: 420 x 220 mm Total table size: 700 x 530 mm Distance between columns at the front: 420 mm Laterally: 220 mm Installation height, table to ram (top): 380 mm Ram stroke: approx. 200 mm Piston / column diameter: 270/120 mm Piston bore: 50 mm Closing speed of the ram: - Rapid traverse / working stroke / ram at 330/10/180 mm/s Total power consumption: approx. 15 kW - 380 V - 50 Hz Weight: approx. 3,000 kg Machine dimensions: approx. 1.4 x 1.3 x approx. 2.75 m Accessories / special equipment: Sick light curtain

Condition: ready for operation (used), Year of construction: 1973, machine/vehicle number: 22123, functionality: fully functional, pressing force: 315 t, table width: 1,500 mm, table length: 2,500 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Pressing force: 315 t Table width: 1,500 mm Table length: 2,500 mm Maximum working area: 883 mm MACHINE DETAILS Ibedpfx Adsz Izcws Nsc Dimensions: 3.0 m x 1.6 m x 4.5 m EQUIPMENT Separate hydraulic unit Control panel

Condition: excellent (used), Year of construction: 2008, machine/vehicle number: 461/08, functionality: fully functional, For sale: Energo hydraulic NC press - Type: GTVS 400 NC - Year of manufacture: 2008 - Serial no.: 461/08 Ibsdpfx Asz Iymned Njc The hydraulic press is in like-new condition. It has 5,000 operating hours and has been used at minimal pressures, with a maximum force of 50 tons. It has been regularly serviced by the manufacturer, Energo. It offers high precision, with a ram depth accuracy of 0.01 mm and the capability for multi-step simultaneous programming, allowing you to set the depth, pressure, and pressing speed. It is connected to the power supply and ready for operation.

Condition: good (used), Year of construction: 1991, Hydraulic press, two-column press, oil hydraulic press, hydraulic press, high-speed press, high-speed hydraulic press -Manufacturer: Hans Schoen, Hydraulic press type SH 100 -Pressing force: 160 tons -Motor: 22 kW -Clamping table: 810 x 870 mm -Max. insertion height: 500 mm -Max. stroke: 250 mm -Hole: Ø 50 mm -Documents: Operating instructions/circuit diagram -Dimensions: 1900/1800/H4200 mm Iedjz H U Rfopfx Ad Nobc -Weight: kg

Condition: refurbished (used), Year of construction: 2000, functionality: fully functional, pressing force: 100 t, stroke length: 270 mm, oil tank capacity: 400 l, total length: 1,200 mm, total width: 1,100 mm, overall weight: 7,500 kg, year of last overhaul: 2026, LAUFFER double-acting hydraulic press, 100/30 tons. The press has been completely refurbished and has not been used. I am also including 400 liters of hydraulic oil, so it is ready for use. For more information and a video demonstrating its operation, please contact the phone number provided. Ijdpsz Hc A Nsfx Ad Nsbc

Condition: excellent (used), Year of construction: 2017, Pressing force: 8,000 kN Stroke: 2,000 mm Clamping area: 4,900 x 2,500 mm Max. tool weight: 50,000 kg Approach speed: 300 mm/s Working speed: max. 60 mm/s - min. 6 mm/s Weight without tool: 225,000 kg Ibedpfez A Tvxex Ad Njc

Condition: used, Double-column hydraulic press SCHÖN, type UTE 100 Special Special press with additional side press cylinders – vertical and horizontal, each with 100 tons capacity. Machine no. 1800, year of construction 1977 Rebuilt according to UVV standards in 09/1991 by Livenbrück Vertical pressure force: 100 tons Vertical ram stroke: 150 mm Vertical installation height: 375 mm (400 mm) Horizontal pressure force: 100 tons Horizontal ram stroke: 60 mm Horizontal installation width: 600 mm Table surface: 600 x 480 mm Table opening: Ø 100 mm Ibodez A R Irepfx Ad Noc Ram surface: Ø 200 mm (vertical and horizontal) Piston rod: Ø approx. 240 mm (vertical and horizontal) Clamping pin bore: Ø 50 mm Ram stroke: 150 mm Installation height: max. 435 mm Table height above floor: 820 mm Oil tank capacity: approx. 375 liters Motor power: 15 kW Mains connection: 400 volts, 50 Hz - Column guidance via the large piston with anti-rotation device - Stepless press force adjustment - Adjustable pressure holding time for vertical and horizontal - Switching for working movement: vertical only or combined vertical and horizontal - 2-hand operation for stroke release - Control cabinet located on the side, fixed to the machine - Light curtain SICK, type LVU 306, for safety operation Space required for the press L x W x H: 2050 x 1550 x 2230 mm Weight: approx. 5 tons Good condition

Condition: good (used), Year of construction: 1990, Power: 1.000 kN Isdpfx Adez Atv Ij Nsbc Size of bolster: 800 x 750 mm Distance betw. columns: 900mm Size of ram: 800 x 600mm Daylight: max. 800 mm Stroke: 480 mm Speed: Fast down: 300 mm/s Working: 30 mm/s Fast up: 300 mm/s Electric power total: app. 31 kW Weight: app. 13.000 kg Size of footprint: app. 1,6 x 2,90 x 3,8m (T x B x H) • die cushion, activ, 400kN, stroke 200mm • allowed for 2-hand working • equipped by oil - air chiller • ram guiding by 4 pc. hard chromed Guiding columns

Condition: ready for operation (used), Year of construction: 1991, machine/vehicle number: 4079, functionality: fully functional, power: 7.5 kW (10.20 HP), pressing force: 30 t, stroke length: 500 mm, table width: 1,200 mm, table length: 1,000 mm, table height: 850 mm, ram plate width: 600 mm, ram plate length: 400 mm, distance table to ram: 800 mm, oil tank capacity: 400 l, total length: 2,200 mm, total width: 2,400 mm, total height: 3,500 mm, overall weight: 4,000 kg, year of last overhaul: 2023, Equipment: CE marking, safety light barrier, For sale is a hydraulic double-column press. Manufacturer: Hans Schoen, Type: NH/D 30S. Ibodpfxezzd Rge Ad Njc The machine is in perfect working order and can be inspected while powered on.

Condition: excellent (used), Year of construction: 2001, - 1 Schuler press - Capacity: 1000 tons - Stroke: 1,300 mm - Die cushion tonnage: 30 - 200 tons - Die cushion stroke: 200 mm - Daylight between press frames (Pmi): 800 mm Ibedpfx Aszy Uuysd Nsc - Work area: 2,500 x 2,100 mm - Movable tables for press: 2 - Approach speed: 600 mm - Working speed at 50%: 96 mm - Working speed at 100%: 46 mm

Condition: used, Year of construction: 1990, Press force: 200 t Stroke: 300 mm Frame width: 1400 mm Ibedpfxszypkvs Ad Nsc Side frame opening: 770 mm Shut height (stroke up): 500 mm Table area: 1300 x 1100 mm Cushion force in table: 80 t Cushion stroke in table: 150 mm Cushion area in table: 700 x 700 mm Table height above floor: 930 mm

Condition: used, Year of construction: 1987, Press force: 315 t Stroke: 750 mm Frame width: 1700 mm Side frame opening: 1100 mm Shut height (stroke up): 1250 mm Table area: 1600 x 1300 mm Cushion force in table: 125 t Cushion stroke in table: 350 mm Ijdpjzynk Ijfx Ad Nebc Cushion area in table: 1000 x 900 mm Table height above floor: 750 mm

Condition: used, Year of construction: 1975, Press force: 200 t Stroke: 600 mm Frame width: 1910 mm Side frame opening: 1000 mm Shut height (stroke up): 800 mm Table area: 1900 x 1150 mm Cushion force in table: 80 t Cushion stroke in table: 300 mm Cushion area in table: 1500 x 950 mm Ibodpfezynf Esx Ad Njc Table height above floor: 800 mm

Condition: used, Year of construction: 1972, Press force: 150 t Stroke: 180 mm Frame width: 300 mm Side frame opening: 180 mm Shut height (stroke up): 300 mm Table area: 570 x 410 mm Ibedpfx Adezymlqe Nsc Table height above floor: 875 mm Ram area: 180 mm Downstroke speed: 250 mm/s Upstroke speed: 160 mm/s

Condition: used, Year of construction: 1987, Press force: 160 t Stroke: 200 mm Ibedpfx Ajzymdasd Nsc Throat depth: 360 mm Passage between frame columns: 590 mm Shut height (stroke up): 500 mm Table area: 920 x 700 mm Table opening: 150 mm Table height above floor: 960 mm Ram area: 620 x 560 mm Downstroke speed: 390 mm/s

Condition: used, Year of construction: 1980, Press force: 250 t Stroke: 250 mm Frame width: 1125 mm Side frame opening: 700 mm Shut height (stroke up): 800 mm Table area: 1100 x 900 mm Cushion force in table: 63 t Cushion stroke in table: 100 mm Cushion area in table: 700 x 400 mm Ijdpjzyl Hajfx Ad Nobc Table height above floor: 960 mm

Condition: used, Year of construction: 1978, Press force: 500 t Stroke: 600 mm Ibedpfxszyl Drj Ad Nsc Frame width: 1550 mm Side frame opening: 1250 mm Shut height (stroke up): 900 mm Table area: 1200 x 1300 mm Cushion force in table: 250 t Cushion stroke in table: 150 mm Cushion area in table: 950 x 950 mm Table height above floor: 1245 mm

Condition: used, Technical details: Total force (nominal): 1000 to Clamping surface (left-right): x mm Clamping surface (front-back): x mm table surface area: 4500 X 2400 mm Total force (nominal): 2-3-4-5- Presse - 1000 to. to table surface area: 2-3-4-5- Presse 4500 X 2200 mm Last overhaul 2010/2020, consisting of: Circuit board washing system, manufacturer Neuhäuser, with 6 cleaning rollers, system no. 0905200, control unit by Siemens Blank automation, manufacturer Neuhäuser, type 19711594-00-0, year 2002, SN 369507/002, system no. FK42282, consisting of: destacking device, oiler, pallet changer, empty pallet discharge Gripper automation, manufacturer Olofström, type Doppin Loader 2000, SN 37719974886, system no. 0602300 Double-column press, manufacturer Weingarten, type ZS 1200.34 Year 1972, order no. 113 021, pressing force approx. 800 t, double action, stroke 850 mm, stroke adjustment 350 mm, height between table surface and drawing slide 2,150 mm, blank holder force 400 t, stroke 600 mm, adjustment 350 mm, clear height between table surface and blank holder 1,950 mm, max. drawing depth 300 mm, 14 strokes/min, Siemens control unit, operating panel by Baluff, table size 3,200 × 2,200 mm, system no. 0185100 Gripper automation, consisting of: 2 press-mounted blank grippers, system no. 0602400, 0602500, with turning table and turning device Double-column press, manufacturer Raskin, type 6031AE4 Year 1979, SN 6031AE4.084, order no. 7810011, single action, pressing force approx. 600 t, 18 strokes/min, slide stroke 700 mm, distance between clamping plate and slide 1,200 mm, slide adjustment 400 mm, clear opening between columns 3,220 mm, slide surface 3,100 × 1,900 mm, tool clamping surface 3,260 × 1,900 mm, drawing cushion with 125 t force, stroke 0–200 mm, control by Siemens Press automation, consisting of: 2 press-mounted blank grippers, turning and rotary table, system no. 0602600, 0602700 Double-column press, manufacturer Raskin, type 0631AE4 Year 1979, SN 0631AE4085, order no. 7810012, single action, pressing force approx. 600 t, 18 strokes/min, slide stroke 700 mm, distance between clamping plate and slide 1,200 mm, slide adjustment 400 mm, clear opening between columns 3,220 mm, slide surface 3,100 × 1,900 mm, tool clamping surface 3,260 × 1,900 mm, drawing cushion with 125 t force, stroke 0–200 mm, Siemens control, system no. 0185300 Blank automation, consisting of: 2 grippers, system no. 0602800, 0602900, with tilting and turning table Double-column press, manufacturer Raskin, type 6031AE4 Year 1979, SN 06031AE4.086, order no. 7810013, single action, pressing force approx. 600 t, 18 strokes/min, slide stroke 700 mm, distance between clamping plate and slide 1,200 mm, slide adjustment 400 mm, clear opening between columns 3,220 mm, slide surface 3,100 × 1,900 mm, tool clamping surface 3,260 × 1,900 mm, drawing cushion with 125 t force, stroke 0–200 mm, Siemens control Blank automation, consisting of: 2 press-mounted blank grippers, turning and rotary table, system no. 0603000, 0603100 Double-column press, manufacturer Raskin, type 06031AE4 Year 1979, SN 6031AE4.087, order no. 7810014, pressing force approx. 600 t, 18 strokes/min, slide stroke 700 mm, distance between clamping plate and slide 1,200 mm, slide adjustment 400 mm, clear opening between columns 3,220 mm, slide surface 3,100 × 1,900 mm, tool clamping surface 3,260 × 1,900 mm, drawing cushion with 125 t force, stroke 0–200 mm, Siemens control Iedpozx Rmvofx Ad Nsbc 6-axis robot, manufacturer

Condition: used, Technical details: Total force (nominal): 800 to Clamping surface (left-right): x mm Clamping surface (front-back): x mm table surface area: 3200 X 2200 mm Total force (nominal): 2-3-4-5- Presse - 600 to. to table surface area: 2-3-4-5- Presse 3100 X1900 mm Last overhaul 2010/2020, consisting of: Circuit board washing system, manufacturer Neuhäuser, with 6 cleaning rollers, system no. 0905200, control unit by Siemens Blank automation, manufacturer Neuhäuser, type 19711594-00-0, year 2002, SN 369507/002, system no. FK42282, consisting of: destacking device, oiler, pallet changer, empty pallet discharge Gripper automation, manufacturer Olofström, type Doppin Loader 2000, SN 37719974886, system no. 0602300 Double-column press, manufacturer Weingarten, type ZS 1200.34 Year 1972, order no. 113 021, pressing force approx. 800 t, double action, stroke 850 mm, stroke adjustment 350 mm, height between table surface and drawing slide 2,150 mm, blank holder force 400 t, stroke 600 mm, adjustment 350 mm, clear height between table surface and blank holder 1,950 mm, max. drawing depth 300 mm, 14 strokes/min, Siemens control unit, operating panel by Baluff, table size 3,200 × 2,200 mm, system no. 0185100 Gripper automation, consisting of: 2 press-mounted blank grippers, system no. 0602400, 0602500, with turning table and turning device Double-column press, manufacturer Raskin, type 6031AE4 Year 1979, SN 6031AE4.084, order no. 7810011, single action, pressing force approx. 600 t, 18 strokes/min, slide stroke 700 mm, distance between clamping plate and slide 1,200 mm, slide adjustment 400 mm, clear opening between columns 3,220 mm, slide surface 3,100 × 1,900 mm, tool clamping surface 3,260 × 1,900 mm, drawing cushion with 125 t force, stroke 0–200 mm, control by Siemens Press automation, consisting of: 2 press-mounted blank grippers, turning and rotary table, system no. 0602600, 0602700 Double-column press, manufacturer Raskin, type 0631AE4 Year 1979, SN 0631AE4085, order no. 7810012, single action, pressing force approx. 600 t, 18 strokes/min, slide stroke 700 mm, distance between clamping plate and slide 1,200 mm, slide adjustment 400 mm, clear opening between columns 3,220 mm, slide surface 3,100 × 1,900 mm, tool clamping surface 3,260 × 1,900 mm, drawing cushion with 125 t force, stroke 0–200 mm, Siemens control, system no. 0185300 Blank automation, consisting of: 2 grippers, system no. 0602800, 0602900, with tilting and turning table Double-column press, manufacturer Raskin, type 6031AE4 Year 1979, SN 06031AE4.086, order no. 7810013, single action, pressing force approx. 600 t, 18 strokes/min, slide stroke 700 mm, distance between clamping plate and slide 1,200 mm, slide adjustment 400 mm, clear opening between columns 3,220 mm, slide surface 3,100 × 1,900 mm, tool clamping surface 3,260 × 1,900 mm, drawing cushion with 125 t force, stroke 0–200 mm, Siemens control Blank automation, consisting of: 2 press-mounted blank grippers, turning and rotary table, system no. 0603000, 0603100 Ibsdpszx Rmpofx Ad Nec Double-column press, manufacturer Raskin, type 06031AE4 Year 1979, SN 6031AE4.087, order no. 7810014, pressing force approx. 600 t, 18 strokes/min, slide stroke 700 mm, distance between clamping plate and slide 1,200 mm, slide adjustment 400 mm, clear opening between columns 3,220 mm, slide surface 3,100 × 1,900 mm, tool clamping surface 3,260 × 1,900 mm, drawing cushion with 125 t force, stroke 0–200 mm, Siemens control 6-axis robot, manufacturer Ku

Condition: like new (used), Year of construction: 2023, functionality: fully functional, PLEASE READ CAREFULLY!!! THIS OFFER IS EXCLUSIVELY FOR EUROPEAN END CUSTOMERS, AND THE FIRST INQUIRY MUST INCLUDE COMPLETE CONTACT INFORMATION. THANK YOU. The forging line consists of a hydraulic 1500-ton forging press, an induction unit with 1200 kW, and a robot with a load capacity of 300 kg. So far, prototypes have been manufactured; however, the line was actually designed for series production, which has not yet taken place. The line was built and installed in 2023. The technical specifications are as follows: Hydraulic press 1500 tons (year of manufacture 2023) SIEMENS control system - Pressing force: 1500 tons - Retraction force: 120 tons - Downward stroke: 300 mm/s - Pressing stroke: 100 mm/s - Upward stroke: 300 mm/s - Installation height: 3,000 mm - Ram stroke: 1,500 mm (!) - Ram size: 1,600 x 1,600 mm - Table size: 1,600 x 1,600 mm - Ejection force / 1 position: 40 tons - Stroke: 600 mm - Ejection speed: 250 mm/s - Return speed: 250 mm/s - Stroke: 400 + 400 mm - Traverse speed: 200 mm/s - Ram positions: 3 positions Including a 1200 kW induction unit (year of manufacture 2023) MITSUBISHI control system - 1200 kW / 450 Hz induction unit for billets - Coil size: Ø 215 / Ø 150 mm, two sets of coils - Material feeding system Including a Kawasaki robot (6 axes) – Model: ZX300S-D- (year of manufacture 2023) - Max. load capacity: 300 kg Iedpfszvnpisx Ad Njbc - Max. reach: 2500 mm Sample images of the machines are attached.
