MSG Maschinenservice Gera GmbH

Condition: good (used), Year of construction: 2010, functionality: fully functional, Unisign Uniport 6000, Year of manufacture 2010 / Commissioned 2011, Siemens 840 D control system, Travel distances X 10,000 mm, Y 1,500 mm, Increased spindle carriage stroke: Z 1,000 mm, Increased through-height 1,000 mm, Through-width 1,500 mm, Main drive 36 kW, n = 6,000 rpm, 720 Nm 2-stage gearbox 1:4 SK 50 tool holder Machining performance in C45: Full drilling D=120mm, threading M55, milling 100cm³/min Hodpfszua N Sjx Ah Esnr Gantry design with movable portal bridge and stationary machine table. Machine table with clamping bars in the transverse direction, each with 750 mm spacing. The standard plate fields are omitted. Gantry-style machine Hydraulic clamping device with clamping bridges for machining shafts, including hydraulic system Angle drilling & milling head, n = 4,000 rpm, SK50 High accuracy and stability due to Hirth gearing Automatic tool change in the angle head Measuring probe RWP20.50-M Swinging operation Safety fence with light curtains, manufacturer Sick Machine table with clamping bars in the transverse direction, each 750 mm Tool chain magazine on the portal stand with 30 positions Machine coolant system Water-air heat exchanger integrated in the control cabinet Unisign remote diagnostics for Siemens Sinumerik 840 D Makrolon curtains on both sides of the portal bridge, adjustable in height by motor Partition wall with viewing panel Chip conveyor with hinged belt design Installation and alignment elements

Condition: used, Year of construction: 2008, functionality: fully functional, machine/vehicle number: B-0312, travel distance X-axis: 3,200 mm, travel distance Y-axis: 2,600 mm, travel distance Z-axis: 920 mm, total length: 10,000 mm, table length: 3,200 mm, table width: 2,050 mm, total width: 6,400 mm, spindle speed (max.): 8,000 rpm, total height: 4,700 mm, distance between stands: 2,700 mm, type of input current: three-phase, table load: 11,000 kg, workpiece weight (max.): 11,000 kg, overall weight: 36,000 kg, spindle mount: MK 5, spindle motor power: 21,000 W, CNC Gantry Machining Center VISION WIDE VTEC VF-3026 We are offering for sale an advanced, heavy-duty, large-format Vision Wide VTEC VF-3026 gantry machining center. The machine was manufactured on September 15, 2008. Designed for precise and high-performance machining of large molds, dies, and heavy steel and cast iron components. Featuring a renowned Heidenhain iTNC 530 control and extensive, progressively added equipment (two factory heads, probe, CTS), the machine provides significant production capabilities, excellent rigidity, and machining dynamics. GEOMETRIC PARAMETERS AND WORK AREA: Table dimensions: 3200 x 2050 mm Travel in the X-axis: 3200 mm Travel in the Y-axis: 2600 mm Travel in the Z-axis: 920 mm Maximum table load: 11,000 kg (11 tons) Clearance between columns: 2700 mm Distance from the spindle nose to the table: 150 - 1070 mm SPINDLE AND DRIVE SYSTEM: CNC control: HEIDENHAIN iTNC 530 Series Spindle motor power (Heidenhain): 18 / 21 kW (high torque) Spindle taper: ISO 50 / BT-50 (compatible with P50T-1 pull studs) Maximum spindle speed: 10,000 rpm Minimum spindle speed: 50 rpm EXTENSIVE PREMIUM EQUIPMENT (INCLUDED IN THE MACHINE PRICE): Automatic 90-degree tilting head, indexed every 5 degrees (Year of manufacture: 11/2011) – a modern accessory dedicated to efficient side machining. Maximum head speed is 3000 rpm. Wireless Heidenhain workpiece measuring probe – a radio measuring system integrated with the machine, enabling automatic referencing and dimension control directly on the machine table. Extension head / Spindle extension (Model: VF-3026AC, Year of manufacture: 09/2008) operating at a maximum speed of 4000 rpm. Through-spindle cooling system (CTS - Coolant Through Spindle) – a high-pressure coolant delivery system directly through the tool. AUTOMATIC TOOL CHANGER (ATC): Magazine capacity: 40 positions Tool holder type: BT-50 / CAT-50 Maximum tool weight: 18 kg Maximum tool length: 450 mm Maximum tool diameter: diameter 125 mm (diameter 215 mm with adjacent empty slots) STANDARD EQUIPMENT: Spindle cooling system Dual chip removal system: screw conveyor and belt conveyor Remote manual pulse generator for the operator Hedeztzl Sjpfx Ah Ejnr Work area enclosure and work lighting Automatic lubrication system and Auto Power Off function Air blast through spindle Heat exchanger in the control cabinet Matching transformer Complete technical documentation and electrical diagrams DIMENSIONS AND POWER SUPPLY: Power consumption: 60 kVA (Three-phase AC power supply) Machine weight (net): 36,400 kg (36.4 tons) Overall footprint dimensions: approx. 10,000 x 6,400 x 4,700 mm

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: 917, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Spindle type: Z80-K530.04 Drive type: SIE / HD MACHINE DETAILS Power: 24.5 kW Voltage: 230 / 400 V Frequency: 50 Hz Motor type: SERVO EQUIPMENT Hnedpoztxgmjfx Ah Esr CE marking Measuring probe Tool holders (as shown in the picture)

Condition: good (used), Year of construction: 1999, Control: Siemens 840 D Powerline Tool holder: HSK-A63 Max. rpm: 16,000 X-travel: 3,000 mm Y-travel: 2,500 mm Hnedpfx Aeztpzbsh Eor Z-travel: 1,150 mm A-axis: +/- 100 mm C-axis: +/- 181.5 mm Table size: 3,000 mm x 2,500 mm Option: External blowing air Kinematics: Fork head

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, Technical details x-travel 2800 mm y-travel 2200 mm z-travel 800 mm Control Heidenhain iTNC 530 table surface area 3000 x 1200 mm tool taper HSK-A-63 spindle turning speed range 18000 U/min power capacity 18 kW feed range 35000 mm/min total power requirement 68,7 kW dimensions of the machine ca. 12,4 x 3,5 x 4,6 m Additional information The FPT DINO is a 5-axis portal milling machine designed for the precise machining of large components. With a cross travel of 2200 mm and a high-speed spindle with 12,000 rpm, this machine combines high machining volume with outstanding dynamics in finishing. Hodpjzr Nhfofx Ah Esnr Heidenhain iTNC 530 CNC path control Number of controlled axes (simultaneously): X/Y/Z/C/B Travels: X-axis (longitudinal travel) 2800 mm Y-axis (cross travel) 2200 mm Z-axis (vertical travel) 800 mm Machine length: 12,434 mm Machine width: 3,597 mm Machine height: 4,622 mm Coolant equipment (no coolant through spindle) Chip conveyor

Condition: good (used), Year of construction: 1996, Siemens 840-D SL, approximately 2012 Table: 2200 x 2250 mm Distance between columns: 3000 mm Hodpszq Ektofx Ah Eonr Max. workpiece height: 1200 mm Max. drilling depth: 600 mm Max. deep-hole drilling diameter: 35 mm Spindle speed: 3500 RPM Spindle power: 15 kW

Condition: ready for operation (used), Year of construction: 2016, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,530 mm, travel distance Z-axis: 750 mm, spindle speed (max.): 6,000 rpm, controller manufacturer: FANUC, number of slots in tool magazine: 30, number of axes: 3, This 3-axis Vision Wide Vision gantry milling machine was manufactured in 2016. It features an impressive X-axis travel of 2,000 mm, Y-axis travel of 1,530 mm, and Z-axis travel of 750 mm. The spacious work table size of 2,000 × 1,530 mm makes it ideal for large, flat workpieces. If you are looking to get high-quality milling capabilities, consider the Vision Wide Vision gantry milling machine we have for sale. Contact us for further details. • Highlights: • Modern machine (2016) designed for low maintenance and easy integration into production lines • Large work envelope suitable for large, flat workpieces (mold making, aerospace, mechanical construction) Hjdszqc A Tspfx Ah Eenr Technical Specification Taper Size BT 50

Condition: ready for operation (used), Year of construction: 2007, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 780 mm, spindle speed (max.): 6,000 rpm, table load: 6,000 kg, tool weight: 15,000 g, spindle motor power: 22,000 W, number of slots in tool magazine: 32, number of axes: 3, This 3-axis HARTFORD Infinity HSA-2215AD gantry milling machine was manufactured in 2007. It features an impressive X-axis travel of 2,000 mm, Y-axis travel of 1,500 mm, and Z-axis travel of 780 mm. The machine includes a robust table size of 2,200 x 1,400 mm and a maximum table load of 6,000 kg. If you are looking to get high-quality milling capabilities, consider the HARTFORD Infinity HSA-2215AD machine we have for sale. Contact us for further details. • Distance between columns: 1,700 mm • Spindle nose to table: 200 – 980 mm • Table • Size (X × Y): 2,200 × 1,400 mm • T-slots: 22 mm × 9 × 150 mm • Spindle & Drive • Taper: BBT-50 / ISO-50 Hjdpjzqcw Rjfx Ah Eenr • Speed: 6,000 rpm (gearhead) / 8,000–10,000 rpm (direct drive optional) • Motor power: 18.5 / 22 kW (continuous / 30 min) • Feed rates • Rapid (X / Y / Z): 20 / 20 / 15 m/min • Cutting feed: 1 – 10,000 mm/min • ATC • Tool magazine: 32 tools (optional 40 / 60) • Max tool diameter: 125 mm (215 mm without adjacent tools) • Max tool length: 350 mm Technical Specification Taper Size ISO 50

Condition: used, Year of construction: 1998, Portal Milling Machine JOBS JOMACH 241 Year of construction: 1998 Travel X: 3400 mm Travel Y: 2700 mm Hnodpszn Hhhefx Ah Ejr Travel Z: 1250 mm Numerical Command: CNC Siemens SINUMERIC 840 D Table size: 3000 x 1500 mm Distance between uprights: 1700 mm 1 Tool Changer 32 Tools ISO 50 + 1 Tool Changer 32 Tools HSK-63 3 Milling heads - Axe C: 2 heads TWIST - ISO 50 + HSK 63 A + 1 head 3 axes ISO 50 Weight: 44 T

Condition: ready for operation (used), Year of construction: 1999, travel distance X-axis: 5,500 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 3,000 rpm, spindle motor power: 22,000 W, number of slots in tool magazine: 24, number of axes: 5, This 5-axis MECOF DYNAMILL 3000L was manufactured in 1999. It features an impressive X-axis travel of 5,500 mm, Y-axis travel of 3,000 mm, and Z-axis travel of 1,500 mm. The machine is equipped with a powerful spindle taper of ISO 50 and a tool magazine capacity of 24 tools. If you are looking to get high-quality milling capabilities, consider the MECOF DYNAMILL 3000L gantry milling machine we have for sale. Contact us for further details. • Orthogonal head: 10–3,000 rpm speed range; 22 kW power; automatic tool clamping (20,000 N clamping force) • PDFTwin 15 head (GAMFIOR electrospindle): 600–24,000 rpm speed range; 17.5 kW motor power; E18 electrospindle • Indexed positioning platform: 360 positions; ±180° rotation range; ±0.02/300 mm positioning accuracy; 45,000 Nm axial clamping force • PDFContinuous positioning platform: 360,000 positions; ±185° C-axis rotation range; 0–2,400°/min C-axis rotation speed; 2,000 Nm clamping torque Additional equipment • Tool profile measurement device Hedpsznv Tgofx Ah Eenr • Cart-type head magazine • BLUM radio-transmitted laser probe • Air/oil tool cooling system • MECOF High-Speed Milling system Technical Specification Taper Size ISO 50

Condition: like new (used), Year of construction: 2000, Retrofitted: 2026 Hsdpfx Asznpczoh Ejnr Numerical control: NUEVO/NEW HEIDENHAIN TNC-i640 Technical features Dimensions Table dimensions: 5600 x 2000 mmNumber of T slots: 13T slots dimensions: 22 mm Traverses of axis X axis traverse: 5000 mmY axis traverse: 3250 mmZ axis traverse: 1000 mmVertical capacity (VC): 500 / 1500 mmDistance between columns: 2700 mm Milling head Milling head model 1: UAGA orthogonal auto-indexing BC (2,5º)Tool clamping system: HydraulicTaper nose: ISO-50 (DIN69871)   /   Pull stud: (DIN69872)Speed range: 3000 rpmSpindle power: 30 kW Milling head model 2: FA large vertical spindleTool clamping system: HydraulicTaper nose: ISO-50 (DIN69871)   /   Pull stud: (DIN69872)Speed range: 3000 rpmSpindle power: 30 kW Milling head model 3: Direct spindleTool clamping system: HydraulicTaper nose: ISO-50 (DIN69871)   /   Pull stud: (DIN69872)Speed range: 5000 rpmSpindle power: 37 kW Feedrates Rapid feedrate (X / Y,Z): 7200 / 12000 mm/min Weight and dimensions Maximum weight on table: 25000 KgMachine weight approximate: 56000 KgMachine dimensions approximate: 13200 x 5738 x 5850 mm Accessories Guarding: 2 sliding doors and new perimetral wire-mesh fenceMilling head changer: Semi-automatic with hinges on columnAutomatic tool changer: OptionalChip conveyor: 1 transversal hinge typeElectronic handwheel: New HR-510Coolant: External internal high-pressure through spindle (only in direct spindle) Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features

Condition: good (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 5,100 mm, travel distance Y-axis: 3,800 mm, travel distance Z-axis: 1,500 mm, total length: 14,000 mm, total width: 7,500 mm, total height: 6,400 mm, overall weight: 140,000 kg, - Year of manufacture: 2002/2003 - Control system: Fida M20 MNC594 - Power requirement: 3 x 400 V, 135 kVA - Includes 4 milling heads - Tool interface: ISO 50 - Total weight: approx. 140 t The machine has already been dismantled. Documentation and more detailed images are available upon request. Hnsdpezmu Rhefx Ah Eer

Condition: like new (used), Year of construction: 2002, Retrofitted: 2026 Numerical control: HEIDENHAIN TNC-i530 Technical features Dimensions Table dimensions: 2000 x 1000 mmNumber of T slots: 8T slots dimensions: 22 mm Traverses of axis X axis traverse: 2000 mmY axis traverse: 1250 mmZ axis traverse: 650 mmVertical capacity (VC): 150 / 800 mmDistance between columns: 1250 mm Milling head Kessler electrospindleTool clamping system: HydraulicTaper nose: HSK-63Speed range: 20 - 12000 rpmSpindle power: 25 kW Feedrates Rapid feedrate (X,Y,Z): 20000 mm/min Weight and dimensions Maximum weight on table: 5000 kgMachine weight approximate: 14000 KgMachine dimensions approximate: 6500 x 3934 x 4000 mm Accessories Guarding: PerimetralAutomatic tool changer: ATC-24Chip conveyor:2 longitudinal and 1 hinge type transversalElectronic handwheel: HR-410Coolant: External internal high pressure through spindle Sale conditions Warranty: 6 months mechanical spare partsPrice and sale conditions: On request View all technical features Hnsdpszlu Scsfx Ah Eor

Condition: ready for operation (used), Year of construction: 2016, travel distance X-axis: 2,100 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 100 mm, spindle speed (max.): 50,000 rpm, spindle motor power: 3,600 W, number of axes: 3, This 3-axis DELTA LGT2113 PRO gantry milling machine was manufactured in 2016. It features a working area of 2100 mm in the X-axis and 1300 mm in the Y-axis, equipped with a powerful 3.6 kW spindle capable of reaching 50,000 rpm. The machine includes a 12-position automatic tool changer and a 4-zone vacuum table, making it suitable for various milling and specialized cutting applications. If you are looking to get high-quality milling capabilities, consider the DELTA LGT2113 PRO machine we have for sale. Contact us for further details. • Tool taper: HSK 25 • Number of tool slots: 12-position automatic tool changer. • Main electronic connection: 380 V, 50/60 Hz • Pump drive power: 5.5 kW each • Gantry-type CNC milling machine • Italian-made machine • 4-zone vacuum table • Designed for specialized industrial applications, especially for the production of tooling used in the printing industry • Also suited for a wide range of general milling operations • X and Y axes: Rack and pinion drive • Z axis: Ball screw drive • Automatic centralized lubrication system • Liquid-cooled spindle • The spindle was completely overhauled a few months ago, including bearing replacement, and is currently in excellent working condition • Integrated Blum tool measurement system with optical transmitter/receiver (probe not included) • 2 vacuum pumps • Capacity: 250 m³/h each • Power supply for vacuum system: 230/400 V, 50 Hz • Windows 10 operating system • Proprietary 2.5D control software Hedpfezk Ipxox Ah Eonr • Deltacam CAM software • 17” TFT display • Dust extraction system (vacuum cleaner not included) • Oscillating knife head for precise cutting of rubber, foam and similar materials, allowing the machine to perform both milling and specialized cutting applications • Minimum Quantity Lubrication (MQL) system for improved machining performance and extended tool life • The machine is currently under power and can be inspected in operation • It is no longer fully utilized, which is the reason for its sale • The machine is in good technical condition and the recently refurbished spindle is operating flawlessly

Condition: excellent (used), Year of construction: 2008, operating hours: 82,500 h, functionality: fully functional, travel distance X-axis: 5,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,750 mm, feed rate X-axis: 65 m/min, feed rate Y-axis: 65 m/min, feed rate Z-axis: 65 m/min, spindle speed (max.): 20,000 rpm, rapid traverse X-axis: 65 m/min, rapid traverse Y-axis: 65 m/min, rapid traverse Z-axis: 65 m/min, torque: 63 Nm, overall weight: 90,000 kg, Equipment: rotational speed infinitely variable, First commissioning: 2008 Control system: Heidenhain iTNC 530 incl. handwheel HR420 X-axis: approx. 5,000 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,750 mm A-axis: -120 / +95° C-axis: ± 360° Maximum workpiece size 3,800 mm (X-direction) 1,800 mm (Y-direction) 1,150 mm (Z-direction) Can be machined in 5 axes (90° free A-axis) in a single setup using a 300 mm long tool. Machine operating hours: approx. 83,000 h Total spindle hours: approx. 37,000 h Machine bed (can be installed flush or above ground!) Dimensions: 5,000 x 2,250 x 300 mm - manufactured from EN-GJL-250 9 T-slots according to DIN 650-28H12 with a spacing of 250 mm and 125 mm from the edge 2-axis milling head, inspected by the manufacturer! Spindle power: 20 kW Spindle speed: max. 20,000 min-1 Torque: max. 63 Nm Tool holder: HSK 63A Tool clamping: hydraulic Holding torque (clamped) A & C axis: 2,000 Nm Drive system for linear axes Feed rate X, Y, and Z axes: up to 65 m/min Axis acceleration X, Y, and Z axes: up to 5 m/s2 Connection data Voltage: 400 V Frequency: 50 Hz Power consumption: 130 kW Dimensions, weights Machine footprint without peripherals: approx. 7,500 x 8,500 x 6,600 mm Total weight: approx. 90,000 kg Color Enclosure, portal, control cabinet: RAL 7035 light gray Milling head and applications: RAL color 5002 aquamarine blue Additional equipment - Minimum quantity lubrication - 50-position tool changer - Work area cover Condition of the machine The milling head has been freshly inspected by the machine manufacturer, thus partially overhauled and fully functional. Completely new machine bed from Stolle! The additional modules shown on the machine bed are not included in the scope of delivery. The extraction systems and ducts shown are also not included in the scope of delivery. The previous owner was an established Formula 1 team from Central Europe. The machine was always under a maintenance contract with the manufacturer. Currently, the machine is disassembled and stored. However, an inspection is still possible at any time by arrangement. Hedpfx Ahezkuirs Eonr

Condition: good (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 13,000 mm, travel distance Y-axis: 4,500 mm, travel distance Z-axis: 1,000 mm, X-axis: 13.000 mm Y-axis: 4.500 mm Z-axis: 1.000 mm Distance between columns: 6.500 mm C-axis: 190º A-axis: 110º Positioning speed XYZ: 15.000 mm/min. Positioning speed AC: 10 tpm CNC Controller: Siemens 840D Spindle nose: HSK A63 Spindle speed: 30.000 rpm Spindle power: 20 kW Toolchanger: 20 Pockets Torrestool tables: 16x X-axis: 11.500 mm Y-axis: 3.500 mm Z-axis: 750 mm Country of origin: Spain Machine size LxWxH: 19.000 x 11.000 x 6770 mm Machine weight: 70.000 kg Hjdpfx Ahszkmqns Eonr Originally installed in an Airbus production facility and used for precision trimming and milling of aircraft fuselage window openings. The Torresmill Gantry is a 5-axis CNC milling and drilling machine, specially designed to work on aeronautical materials (Composite, Aluminum, Titanium, Steel, ...). The Torresmill gantry is perfectly combined with the Torrestool universal clamping device, guaranteeing flexibility and process time.

Condition: good (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,700 mm, travel distance Z-axis: 916 mm, Used portal milling machine, model HG3000T, 6-axis milling robot for processing wood, plastic, and GRP parts with two movable tables, each 1000 x 1800 mm Travel ranges: X = 3000 / Y = 2700 / Z = 916 mm Working volume in tandem operation approx. 2400 x 1000 x 600 mm Working volume in synchronized operation approx. 2400 x 2100 x 600 mm Year of manufacture: 2000 / Commissioned in 2001 Further details, see pictures! The machine runs perfectly and is still in daily use; inspection possible during operation. Sale due to the purchase of a larger new machine. Dismantling, loading, and transport are to be organized by the buyer. (Location: D-88319 Aitrach, total weight approx. 5.5 tons) Hjdszh Uzpspfx Ah Eonr The sale is made as a used machine, excluding any warranty or guarantee, to commercial customers (B2B). You will receive a proper invoice with VAT shown.

Condition: excellent (used), Year of construction: 2001, travel distance X-axis: 4,500 mm, travel distance Y-axis: 2,700 mm, travel distance Z-axis: 1,250 mm, DISTANCE BETWEEN UPRIGHTS: 4000 MM RAM SECTION: 270 X 330 MM TABLE (T-SLOTS): 4500 X 2500 MM Hodpezhn Agofx Ah Esnr SPINDLE SPEED: 24,000 RPM CNC: FIDIA M 2

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 2,200 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 20,000 rpm, controller model: Heidenhain TNC 530, TECHNICAL DETAILS Work Area Table surface: 2,300 x 1,600 mm T-slots: 22 mm Distance between T-slots: 200 mm Workpiece weight with optimal distribution: max. 6,000 kg/m² Distance between columns: 2,700 mm Distance between table surface and spindle center: max. 1,220 mm Travel / Axes Travel X-axis: 2,200 mm Travel Y-axis: 1,500 mm Travel Z-axis: 1,000 mm Feed rate X/Y-axis: 0 - 60 m/min Feed rate Z-axis: 0 - 40 m/min C-axis rotation: ± 370° A-axis rotation: ± 105° A-axis torque: max. 830 N·m C-axis torque: max. 1,200 N·m Milling Head / Spindle Milling head: TOE 29 T, 5-axis orthogonal milling head Spindle connection: HSK 63 A Spindle power: 29 / 37 kW Spindle torque: 92 / 115 Nm Spindle speed: max. 20,000 rpm Constant torque range: 0 - 3,000 rpm Tool Changer Tool changer: Automatic tool changer Hsdpfszhnk Djx Ah Eonr Tool holder: HSK 63 A-100 Magazine capacity: 42 stations Tool diameter: max. 80 mm Tool length: max. 350 mm Tool weight: max. 8 kg MACHINE DETAILS Control model: Heidenhain TNC 530 Cooling / Measuring Systems Tool coolant supply through the spindle: 20 bar Coolant flow rate: 25 l/min Measuring system X/Y/Z-axis: Heidenhain glass scales Measuring system C-axis: Heidenhain angle measuring system EQUIPMENT Heidenhain TNC 530 CNC control 5-axis orthogonal milling head TOE 29 T Electro spindle HSK 63 A Automatic tool changer with 42 stations Tool coolant supply through the spindle Laser tool presetting BLUM Heidenhain glass scales on X, Y and Z axes Heidenhain angle measuring system on the C-axis Thermal insulation and stabilization of the crossbeam Central lubrication 2 chip conveyors Portable handwheel Heidenhain HR 520 15" TFT color monitor with soft keys Full enclosure with CE safety standard Control cabinet with air conditioning Rinsing gun Sliding roof for loading and unloading Note: The operating hours can be found in the last picture.

Condition: used, Year of construction: 1994, x-axis 7.300 mm y-axis 3.100 mm z-axis 1.250 mm control Heidenhain surface area B 2500 x L 7000 x H 750 mm no. of flutes 13 Stück flute distance 200 mm groove width 28H8 mm max. workpiece weight 4 t/m² Hnodpfxezhcine Ah Eer drive capacity - main spindle 40 kW tool taper ISO 50 max. spindle tunring speed 4.000 U/min work spindle adjustment 3600 mm stroke senkrecht 1.250 mm spindle diameter 120 mm In our assessment, the machine is in good used condition and can be inspected under power by appointment. Technical features & accessories: Double-column gantry: Gantry traverse speed 0–6,000 mm/min Feed rate 12 m/min - Heidenhain control system with handwheel - Spindle extension (VFL) - Angle milling head (WFKU) - Tool magazine - Auxiliary equipment magazine - Schmipke cooling system - Coolant tank - Chip conveyor - Hydraulic unit - Oil cooler - Operator platform - Comprehensive documentation available - Note: Operating conditions and installation layout in the appendix Accessories, tools, and clamping devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data/specifications, and prior sale.

Condition: used, Year of construction: 2022, x-travel 5.230 mm y-travel 2.750 mm z-travel 1.100 mm control Heidenhain TNC 640 Tool bore DIN69871 A50 BIG PLUS main drive 32/43 kW torque S1/S6-60% 752/1.011 Nm speeds Spindel stufenlos 6.000 U/min ca. 70 kw weight of the machine ca. ca. 43 t Installation dimensions (length x width x height) ca. 12,2 x 5,7 x 5,1 m Hnedezgxgmspfx Ah Ejr In our assessment, the machine is in good used condition and can be inspected under power by appointment. Technical features & accessories: - Heidenhain TNC640 control system with HR510 handwheel and digital drives - 60-station tool changer - Internal coolant supply (ICS) for vertical spindle with 1000L tank and automatic water/air switching - Direct axis measurement via Heidenhain linear scales - Coolant system with paper belt filter and magnetic separator - Automatic central lubrication - Rigid tapping (threading without compensating holder) - Oil-cooled ball screw (internal) in the X-axis - Spindle oil cooler - Automatic machine shut-off - Screw-type chip conveyors on both sides of the table - Hinged-belt cross chip conveyor Accessories, pictured tools, and workholding devices are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data/specifications, and prior sale.

Condition: used, Year of construction: 2016, x-axis 6.800 mm y-axis 4.000 mm z-axis 1.500 mm Control iTNC 530 HSCI Heidenhain distance between columns max. 5.090 mm distance spindle center to table 1.825 mm type 175149A-0007 turning speed range - main spindle max. 19.800 min/-1 power capacity - main spindel 20 kW tool taper HSK-A63 swivellable B: +115° / -115 ° rotatable C: +/- 200 ° type 178099-0005 turning speed range - main spindle max. 10.020 min/-1 power capacity - main spindel 20 kW tool taper HSK-A100 swivellable B: +115° / -115 ° rotatable C: +/- 200 ° table surface area 6.000 x 3.000 mm max. table load 50,0 t height over floor 100 mm number of T-slots 12 T-slot - width 28H12 mm T-slot - distance 250 mm number of toolpositions 62 (38+24) pos. number of toolpositions HSK A63: 37+1 pos. number of toolpositions HSK A100: 23+1 pos. max. tool diameter HSK A63: 52 mm max. tool length HSK A63: 250 mm max. tool weight HSK A63: - kg max. tool diameter HSK A100: 80 mm max. tool length HSK A100: 450 mm max. tool weight HSK A100: - kg rapid traverse ( X / Y / Z ) 40.000 mm/min rapid traverse B/C: 4.320 °/min feed speeds X/Y/Z: 30.000 mm/min Working speed B/C: 2.160 °/min Accelaration max. 3,2 m/s² x-axis 6.800 mm y-axis 4.000 mm z-axis 1.500 mm Hnodpszf Nn Ssfx Ah Esr b-axis +115° / -115 ° c-axis +/- 200 ° total power requirement 180 kVA dimensions of the machine ca. 12,5 x 15,0 x 7,0 m 5-Axis-High-Speed-Gantry-Big-Machining-Center DROOP & REIN - FOGS 40 60 C - Fork head

Condition: used, Year of construction: 2007, x-axis 10.100 (2x 5.000) mm y-axis 3.000 mm z-axis 1.500 mm Control Sinumerik 840 D Siemens distance between columns max. 3.000 mm passage max. 1.950 mm distance spindle center to table max. 1.800 mm distance spindle nose and table 1.350 / 1.500 mm type P 8005020/00-4 turning speed range - main spindle max. 18.000 min/-1 power capacity - main spindel 20 kW max. Torque 48 Nm tool taper HSK-A63 DIN 69063 Spindle Extension 450 mm swivellable B: +110° / -10 ° rotatable C: +/- 200 ° type P 8002320/00-4 turning speed range - main spindle 20 - 5.000 min/-1 power capacity - main spindel 40 kW max. Torque 1.100 Nm tool taper HSK-A100 DIN 69063 Spindle Extension 300 mm swivellable B: +110° / -10 ° rotatable C: +/- 200 ° table surface area 4.000 x 2.200 (2x) mm max. table load 12 / 20 t height over floor 700 mm number of T-slots 11 + 19 T-slot - width 28H7 mm T-slot - distance 200 mm Hedpfxszf Nn Ee Ah Ejnr number of toolpositions 327 pos. number of toolpositions HSK A63: 156 pos. number of toolpositions HSK A100: 171 pos. max. tool diameter HSK A63: 52 mm max. tool length HSK A63: 250 / 500 mm max. tool weight HSK A63: 5,0 kg max. tool diameter HSK A100: 315 mm max. tool length HSK A100: 500 / 800 mm max. tool weight HSK A100: 40,0 kg feed speeds X: max. 30.000 mm/min feed speeds Y/Z: max. 40.000 mm/min feed speeds B: 3.600 °/min feed speeds C: 2.160 °/min Accelaration X: max. 1,5 m/s² Accelaration Y/Z: max. 3,2 m/s² x-axis 10.100 (2x 5.000) mm y-axis 3.000 mm z-axis 1.500 mm b-axis +110° / -10 ° c-axis +/- 200 ° total power requirement 150 kVA dimensions of the machine ca. 25,0 x 12,0 x 7,0 m 5-Axis Gantry-Big-Machining-Center DROOP + REIN - TFS 22 40 DT D40 P - two Milling-Heads - ca. 4.000 Power On Hours - X-Achse 10.000mm (coupled) / 2x 5.000mm (single-table) - 3 axes simultaneously (X, Y, Z) - 2 positioning axes (B, C) - tools upon request

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, Double Column Milling M/C - Gantry Type Brand: FOREST-LINE ALBERT / Type: MODUMILL 300G / Year of construction: 1999 Extensive modernizations in 2008 and 2021 ! Machine with interchangeable vertical and horizontal milling heads with automatic indexing. The machine can be inspected by appointment. Very well-kept, continuously maintained condition! Hnodpfxszfbi Ie Ah Eor TECHNICAL DATA: - CNC Control: SINUMERIK 840D - Travels X/Y/Z: 11.450 / 3.500 / 1.250 mm Cross-section of the Z-axis slider: 360 x 360 mm - Gantry passage: 3.000 - Height below vertical spindle: 1.400 mm - Working clamping width: 2.500 mm - Fixed table dimensions: 5.000 x 2.500 mm - Longitudinal pallet system EQUIPMENT: - Tool changer (chain magazine): 80-positions - Cooling through the spindle centre - 2 chip conveyors - Gantry panelling - Touch probe, Brand: RENISHAW - Electronic hand wheel - Remote diagnosis - Tool management and wear management - CE marking Electrical connection values: - Total power requirement: 130 kVA - External dimensions of the machine: 22,6 x 8,0 x 6,3 m There is no guarantee for correctness and completeness of the technical details and accessoires. - Subject to prior sale - Detailed technical data sheet and information on equipment available on request.

Condition: ready for operation (used), Year of construction: 2006, travel distance X-axis: 650 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 450 mm, spindle speed (max.): 18,000 rpm, table load: 4,000 kg, spindle motor power: 30,000 W, number of slots in tool magazine: 40, number of axes: 5, This 5-axis Huron K2X 8 Five gantry milling machine was manufactured in 2006. It features an impressive X-axis travel of 2,000 mm, Y-axis travel of 1,600 mm, and Z-axis travel of 1,100 mm. The machine includes a robust table size of 2,300 × 1,500 mm and a maximum table load of 4,000 kg. If you are looking to get high-quality milling capabilities, consider the Huron K2X 8 Five machine we have for sale. Contact us for further details. Hjdpjzd Epiofx Ah Eenr • Simultaneous 5-axis machining • Rotary axis (B): ±110° • Rotary table axis (C): 360° continuous • Table size: 2,300 × 1,500 mm • Spindle taper: HSK-A63 • Through-spindle coolant Additional equipment • Chip conveyor • Portable MPG handwheel
