Condition: used, CINCINNATI R 327 is a Cylindrical grinder designed for precision, high accuracy and reliable performance. Capacities: centre height 390 mm; distance between centres 1600 mm; grinding wheel Ø600×80 mm, bore 305 mm; max. grinding Ø 600 mm; workpiece weight on centres max. 400 kg; table tilt ±10°. Specs: peripheral speed 30 m/s; spindle hole 38 mm, spindle taper 5 CM; workpiece spindle 6 steps 16–168 t/min; external grinding wheel motor 15 kW; workpiece spindle motor 2 kW; voltage 3x380 V 50 Hz; machine weight ≈8000 kg; overall L4400×W2300×H2250 mm. Accessories: coolant system 450 L, set of grinding wheels, flange with wheel, lamp, hydraulic tailstock. Achieves tight tolerances; suitable for automotive, aerospace, medical, machine tool and watchmaking sectors. Iedpfx Asytxu Eobnetd

Condition: used, KELLENBERGER KEL‑VARIA R175 x 1500 is a CNC cylindrical grinder engineered for precision, high accuracy and reliable operation. Capacity: centre height 175 mm, distance between centres 1500 mm, Z 1650 mm, max 150 kg; wheels Ø500×80 mm (Ø400×63 mm option). Specs: wheel speeds 1000–2150 rpm, peripheral 45 m/s, max travel 320 mm, feed 7500 mm/min, motors 7.5/2 kW, rapid 15 m/min, 3×400 V, weight ≈6000 kg, dims 4700×2300×2000 mm. Equipment: paper/coolant filtration, MOVOMATIC, Renishaw LP2H probe, wheel flange extractor, remote hand control, MPM balancing. Achieves tight tolerances; suited to automotive, watchmaking, machine tools, aerospace and medical. Itjdpfeyn N Edox Abnsd

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, Distance between centres: 2000 mm Centre height: 230 mm Max. swing diameter: 455 mm Max. workpiece weight between centres: 800 kg Max. workpiece weight cantilever (incl. clamping device): 200 Nm X-axis traverse movement: Electromechanical drive with ball screw X-axis traverse movement: Cross feed speed 0.01 – 8,000 mm/min X-axis traverse movement: Setup via electronic handwheel or direction push button X-axis traverse movement: Measuring system with glass scale, internal resolution 0.0005 mm Z-axis table movement: Table feed speed 0.01 – 10,000 mm/min Workpiece spindle motor: 3.0 kW at 0–300 rpm Workpiece spindle taper: MK5 and KK5 Control: SIEMENS 840 D solution line Operation via dialog-guided interface Electronic handwheel available Grinding spindle motor: 11 kW Peripheral grinding wheel speed: 35 (50) m/s Standard grinding wheel: 600 x 80 x 203.2 mm Right face grinding wheel: 300 x 40 x 127 mm Internal grinding spindle by customer specification Tailstock taper: MK4 Tailstock operation: manual (hydraulic) Tailstock foot switch with quill stroke 40 mm and MK5 Card index / data management for workpiece data, up to 100 grinding wheels and 40 dressers Cylindricity error correction program-controlled for all dressable grinding wheels Dressing from the workpiece spindle headstock or from the tailstock Dressing allowances automatically compensated Optional integration of diamond form rolls or swivel dressers Various dressing strategies available in the control system Integrated CAD program (optional) Itjdpfx Aboynubwened Import of existing CAD data (optional) B-axis infinitely adjustable Fast and repeatable positioning Available grinding spindle configurations: External grinding wheel left External grinding wheel left + right face grinding wheel External grinding wheel left + external grinding wheel right External grinding wheel left + internal grinding spindle External grinding wheel left + right face grinding wheel + internal grinding spindle Production machine Can be equipped with loading portal and in-process measurement control Modular system / options: Manual or fully stepless automatic B-axis swiveling Number and configuration of grinding spindles (external and internal) Positionar (Z-length measuring sensor) Spark-out detection In-process measurement control Controlled C-axis (non-circular grinding) Hydrostatic guideway in X-axis (infeed axis) Swivel dresser, diamond form roll Servo-controlled tailstock with programmable holding force Network integration Data backup Remote maintenance Universal paper band filter Compact air purification unit Grinding cycles: X-plunge grinding Z-plunge grinding Z-longitudinal grinding Angular plunge grinding Multi-X-plunge grinding Contour grinding Angular oscillation Positionar cycle Non-circular machining Face grinding Z-peel grinding Auxiliary function The machine was commissioned at the end of 2012 Modernizations 2022 Repair grinding table: €255.40 Removal of tailstock: €1,174.50 Removal of tailstock, 2nd technician: €868.50 Installation of overhauled tailstock: €1,875.00 Installation + overhaul tailstock: €12,073.42 Total documented work volume: €16,246.82

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 630005, center height: 305 mm, center width: 1,000 mm, travel distance X-axis: 350 mm, travel distance Z-axis: 1,160 mm, controller model: KELCO 90, TECHNICAL DETAILS Centre height: 225 mm / 305 mm Centre distance: 1,000 mm Travel Z-axis: 1,160 mm Travel X-axis: 350 mm Max. workpiece weight: 200 kg Workpiece diameter: 449 mm Left grinding wheel diameter: 500 mm Left grinding wheel width: 80 mm Left grinding wheel bore: 203 mm Right grinding wheel diameter: 400 mm Right grinding wheel width: 40 mm Right grinding wheel bore: 127 mm B-axis swiveling range: +30° / -190° Max. grinding wheel speed: 1,720 rpm Peripheral speed: 45 m/s Workpiece spindle speeds from: 5 rpm Workpiece spindle speeds up to: 500 rpm Spindle taper: Morse taper 5 (MT 5) Tailstock quill taper: 4 Morse (MT 4) Tailstock quill stroke: 50 mm Feed rate X-axis: 8 m/min Feed rate Z-axis: 16 m/min Max. table tilt: -1° / +11° MACHINE DETAILS Control: KELCO 90 Total power requirement: 25 kW Connection: 50 Hz, 3x 380 Volt Dimensions & Weight Machine dimensions (L x W x H): 2,850 x 2,200 x 2,100 mm Control cabinet dimensions (L x W x H): 550 x 450 x 900 mm Machine weight: approx. 6,000 kg EQUIPMENT 80 mm riser block Coolant system Automatic tool measurement KELSET Wheel dressing device Internal grinding device (without spindle) Set of flanges Set of grinding wheels Balancing arbor Lamp Isdpjyhnrvofx Abnstd Magnetic chuck diameter (2x): 300 mm / 500 mm Electronic hand-held control panel

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, center height: 150 mm, workpiece weight (max.): 200 kg, grinding length: 1,540 mm, grinding wheel diameter: 500 mm, total width: 2,400 mm, total length: 5,445 mm, total height: 1,580 mm, grinding diameter: 300 mm, workpiece length between centers: 1,623 mm, grinding wheel width: 63 mm, grinding spindle motor power: 5,500 W, overall weight: 4,900 kg, pivoting range: 90 °, rotational speed (min.): 32 rpm, rotational speed (max.): 500 rpm, workpiece spindle speed (max.): 500 rpm, Universal Cylindrical and Internal Grinding Machine E450NP x 1500. Manufacturer: JOTES Łódź – 1995. Nominal grinding length: 1500 mm. Max. workpiece length between centers: 1623 mm. Max. grinding length: 1540 mm. Iedpfeyhcpvox Abnjtd Center height: 150 mm. Center height above floor: 1012 mm. Headstock and tailstock taper: Morse 4. Max. workpiece weight between centers: 200 kg. Max. workpiece weight in chuck: 50 kg. Grinding wheel dimensions: external diameter 500 mm, width 63 mm, bore diameter 203 mm. Manual table traverse: 10 mm/rev. Smallest table increment: 2 mm. Grinding wheelhead swivel: +/- 90°. Spindle speed range: 32–500 rpm. Grinding wheel drive motor power: 5.5 kW. Total power requirement: 12.5 kW. Machine weight: 4900 kg. Dimensions (L x W x H): 5445 x 2400 x 1580 mm. Equipment (last photo): - 3-jaw self-centering chuck 200 mm, - steady rest 160 mm, - half steady rest, - diamond wheel dresser.

Condition: good (used), center height: 215 mm, grinding length: 1,500 mm, total width: 2,300 mm, total length: 5,530 mm, total height: 2,100 mm, grinding diameter: 430 mm, Matrix Okuma Universal Cylindrical Grinder Model: GU – 40 Max Dia Ground: 430mm Max Between Centres: 1500mm Itjdpfxoyglhfo Abnsd Wheel Size: 355 x 50 x 127mm Headstock Speed: 10-150 RPM Variable Table Swivels: 8 Degree Machine With: Coolant Filtration Tank Steadies Internal Grinding Attachment with Quill Dimensions: 5530 x 2300 x 2100mm High Weight: 6200 Kgs

Condition: good (used), center height: 200 mm, grinding length: 1,600 mm, grinding wheel diameter: 450 mm, grinding diameter: 400 mm, Mostana Horizontal Spindle Grinder Model: 3L722B-80 Iedpjyglc Aofx Abnotd Capacity: 1600 x 400 x 400mm Long Travel: 1780mm Cross Travel: 430mm VerticalTravel: 415mm Grinding Wheel: 450 x 80 x 203mm Spindle Motor: 11 KW Machine With: Rapid Traverse Vertical Incremental Downfeed Magnetic Chuck: 1575 x 400mm Coolant Clarifier Digital Readout Dimensions: 5940 x 2660 x 2600mm High Weight: 8000 KGS

Condition: used, Year of construction: 2019, functionality: fully functional, machine/vehicle number: RU2000, center height: 335 mm, workpiece weight (max.): 280 kg, grinding length: 2,100 mm, grinding wheel diameter: 610 mm, grinding diameter: 650 mm, quill diameter: 80 mm, feed length X-axis: 460 mm, grinding spindle speed: 4,420 rpm, overall weight: 20,000 kg, input frequency: 50 Hz, input voltage: 400 V, workpiece spindle speed (max.): 750 rpm, We offer this used AZ RU2000 cylindrical grinding machine, year of manufacture 2019. Rated voltage: 400 V Frequency: 50 Hz Pneumatic pressure: 6 bar Rated power: 110 kVA Maximum current draw: 160 A Machine weight: 20,000 kg The machine is configured for external grinding with CBN and Corundum wheels, featuring two wheel spindles on a freely positionable B-axis turret. CNC Siemens 840d. The machine is prepared for integration with automatic hydraulic steady rests and for connection with an automatic loading and unloading system. Itodpfx Abjydagdjnod

Condition: good (used), Year of construction: 1990, Ref. -No.: 10301 Manufacturer: TITAN Type: RU 350 x 1-1500 Year of construction: 1990 Type of control: Konventionell Storage location: Halberstadt Iedpoycpv Sofx Abnotd Country of origin: USA Max. Grinding length: 1.500 mm Max. Workpiece Weight: 300 kg Grinding Diameter: 350 mm Max. Dia. Of Grinding Wheel: 280-500 mm Grinding Wheel Width: 80-100 mm

Condition: used, Lumsden 92 ML Vertical Spindle Rotary Surface Grinder , 48 Inch dia chuck, autosizing, table jog facility, Filtermist unit fitted with (2) extraction vents to rear of table guards, fitted with segmented wheel, serial number 92ML/109/11821. Machine tools manuals. Coolant filtration tank. Also with unused grinding stones segmented. Table Diameter 48″ / 1219mm, Segmental Wheel Dia. 28” / 711mm, Max. Height Capacity 22.5″ / 572mm, Spindle Speed 550rpm, Table Speed 6 & 18rpm, Auto Feed 0.004-0.04 ins/min – 0.1-1.0 mm/min, Spindle Motor 50HP / 35Kw, Floor Space 14′ x 11′ / 4394 x 3353mm, Approx. Net Weight 12T/12200Kg, Approx. Gross Weight 13.5T /13700Kg Itedeyabc Espfx Abnod

Condition: refurbished (used), Year of construction: 1986, functionality: fully functional, center height: 150 mm, workpiece weight (max.): 130 kg, grinding length: 1,500 mm, grinding wheel diameter: 500 mm, total width: 2,155 mm, total length: 5,465 mm, total height: 1,700 mm, grinding diameter: 300 mm, grinding wheel width: 63 mm, The cylindrical grinding machine was fully overhauled in 2021 and has hardly been used since. The condition of the machine is practically like new. Equipment as shown in the photos. The machine is connected to power and can be inspected at any time by prior arrangement. Technical specifications: Grinding diameter: 300 mm Iodpfjx A Dfyjx Abnstd Grinding length: 1500 mm

Condition: good (used), Year of construction: 2009, Control: Siemens 828-D SL Max. grinding diameter: 500 mm Max. grinding length: 2000 mm Max. workpiece weight: 500 kg between centres Swiveling of grinding head: +45 / -15° (manual) Grinding wheel: 500/80/203 mm Iedpfoxyv Uzex Abnetd With steady rests With enclosure

Condition: used, KELLENBERGER KEL-VARIA R175 x 1500 is a CNC cylindrical grinder engineered for high precision, top accuracy and reliable production. Capacities: centre height 175 mm, distance between centres 1500 mm, Z-axis 1650 mm, workpiece weight on centres max. 150 kg; grinding wheel Ø500×80 mm (bore 203 mm) or Ø400×63 mm (bore 127 mm); max wheel travel 320 mm. Key specs: wheel speeds stepless 1000–2150 rpm (peripheral speed 45 m/s); feed 7500 mm/min; work spindle swivels -10/+100° with 8–800 rpm; permitted load 160 Nm; grinding spindle motor 7.5 kW; work spindle motor 2 kW; 3×400 V 50 Hz; rapid 15 m/min; approx. weight 6000 kg; dimensions 4700×2300×2000 mm; air 6 bar. Accessories: coolant system, paper filtration, MARPOSS touch probe, set of grinding wheels, rotary centre, set of centers, set of workpiece drivers, set of throat gauges, lamp, 2 tool cabinets, tailstock with fine adjustment, oil mist extractor, spindle nose for collets. Achieves tight tolerances; typical applications: automotive, watchmaking, machine tool Ijdpfsxx U S Asx Abnetd

Condition: used, KELLENBERGER KEL-VARIA 2RU 225/1500 is a CNC cylindrical grinder engineered for precision, high accuracy and reliability. Capacities: centre height 225 mm, distance 1500 mm, max grinding Ø 432 mm, workpiece weight 150 kg; wheels L 400×63×127, R 500×80×127. Wheel speeds 1000–2150 rpm (45 m/s); work spindle 8–800 rpm, taper 5 CM, permitted load 160 Nm. Tailstock taper 4 CM, stroke 50 mm, pressure 200–700 N; supply 3×400 V 50 Hz. Options: KEL‑ASSIST 100, MOVOMATIC, KEL‑SET, MOVOMATIC C25, KEL‑BALANCE, coolant through spindle, paper filtration, 400 mm magnetic chuck, dressing, swivel diamond holder. Enables tight tolerances; sectors: automotive, watchmaking, machine tools, aerospace, medical. Itjdpfsxx U Haox Abned

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 1845/455, Completely refurbished: Mechanics, geometry, hydraulics, and electrical components Wheelhead Disassembly, cleaning of parts, replacement of worn and defective components, motor overhaul, replacement of bearings, replacement of belts, spindle disassembly, replacement of seals and O-rings, plus adjustment. New paintwork. Workhead Disassembly, cleaning of parts, replacement of worn and defective components, motor replacement, replacement of belts. New spindle bearings. New paintwork. Tailstock Disassembly, cleaning of parts, replacement of worn and defective components, motor replacement, replacement of belts. New spindle bearings. New paintwork. Internal grinding attachment Disassembly, cleaning of parts, replacement of worn and defective components, installation of the support and geometry alignment. New paintwork. Hydraulics Disassembly, motor replacement, hose replacement, defective and worn parts replaced. Hydraulic block checked. X-Axis Disassembly, replacement of worn items such as O-rings, seals, rings, etc., overhaul of hydraulic piston, regrinding of tables. Z-Axis Disassembly, regrinding of tables, replacement of worn and defective parts, overhaul of hydraulic piston, scraping of V and flat guides. New paintwork. Measuring system Digital 2-axis display included. Electrical cabinet Replacement of motor contactors and relay controls. New wiring. New variable speed drive (frequency inverter) for the workhead. TECHNICAL SPECIFICATIONS Distance between centers: 1500 mm Distance between centers (workhead to tailstock overhang): 1650 mm Center height, standard: 125 mm Center height with riser blocks: 225/250 mm Maximum grinding diameter: Ø 250 mm Maximum grinding diameter with riser blocks: 450/500 mm Table Usable surface: 2060 x 140 mm Max. length and width for surface grinding: 1750 x 200 mm Longitudinal travel, manual or hydraulic: 1750 mm Manual table movement, 1 handwheel revolution – coarse: 20.006 mm Isdpfxjxt Ilfe Abnotd Manual table movement, 1 handwheel revolution – fine: 2.457 mm Table speed, continuously via hydraulics: up to 6 m/min Table swivelling: 6° Stop and return: 0–5 sec. Workspindle Workpiece speeds, continuously variable (electric): 20–400 rpm Swivelling: 360° Workspindle taper (internal): MT5 Tailstock Internal taper, tailstock spindle: MT3 Spindle retraction, manual or hydraulic: 30 mm Diamond dresser taper (internal): MT0 Universal grinding head Cross slide travel for wheel: 285 mm Rapid traverse for wheel slide, front and rear: 40 mm Grinding spindle speeds: 1500 – 1700 – 2200 – 3600 rpm Vertical grinding spindle movement, center heights: 125–330 mm Max. wheel for cylindrical grinding: 400 x 50 x 127 mm Max. wheel for surface grinding: 250 x 20 x 76 mm Head swivelling with locking at every 90°: 270° Wheel feed 1 division of the micrometer drum: 0.005 mm/Ø Automatic wheel feed, max.: 0.9 mm/Ø Motors Grinding spindle motor: 2,900 rpm / 4.0 hp Workspindle motor: 3,000 rpm / 2.0 hp Coolant pump motor: 2,850 rpm / 0.12 hp Internal grinding attachment Bore: 70 mm Internal grinding spindle speed Ø70 mm: 14,000 rpm Internal grinding spindle speed Ø50 mm: 21,000 rpm Subject to error or omission, the technical information is provided without obligation.

Condition: reconditioned (used), functionality: fully functional, center height: 250 mm, center width: 1,500 mm, grinding diameter: 500 mm, tailstock quill stroke: 30 mm, Equipment: documentation/manual, The machine has been partially overhauled and includes, among other things, new geometry and a new control cabinet. The bearings have been replaced. TECHNICAL DETAILS Working Area Centre distance: 1,500 mm Centre height: 250 mm Max. grinding diameter: 500 mm Table swivel range: ± 8° Grinding Head Grinding wheel dimensions: 400 x 50 x 127 mm Spindle speeds: 1,500 / 1,700 / 2,200 rpm Bore for internal grinding spindle: 90 mm Workpiece Headstock Workpiece headstock orientation: 180° Spindle speed: 20 - 400 rpm Spindle taper: Morse 5 Isdpfxexgrd Sj Abnotd Tailstock Tailstock taper: Morse 4 Tailstock quill stroke: 30 mm MACHINE DETAILS Drives Grinding head motor power: 3 kW Tailstock motor power: 0.9 kW Machine Data Dimensions: 2,860 x 1,680 x 1,670 mm Weight: 2,500 kg EQUIPMENT Automatic working cycle Coolant tank with pump Internal grinding spindle External grinding wheels Dressing device Documentation Note: A digital readout can optionally be purchased for €3,600.

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 510-1986, CYLINDRICAL GRINDER JOTES SCHAUDT A440X1500 Specifications Maximum longitudinal travel: 1500 mm Grinding diameter: 298 mm Itjdpfew T Ti Dox Abned External grinding: Yes Internal grinding: Yes Dimensions (L x W x H): 5400 × 2400 × 1600 mm Weight: 4800 kg Operating hours: — Power-on hours: — Condition: Rebuilt Compliant with local standards: — Status: Under power Technical features - Grinding length [mm]: 1500 - Grinding diameter [mm]: 300 - Manual table displacement [mm/rev]: 10 - Table speed range [mm/s]: 0.01–5 - Smallest table stroke [mm]: 3 - Wheelhead swivel [°]: ±90 - Centre sleeve taper [Morse No.]: 4 - Grinding wheel dimensions [mm]: 500 x 63 x 203 - Spindle speed [rpm]: 32–500 - Grinding wheel drive motor power [kW]: 5.5 - Workpiece drive motor power [kW]: 0.75 - Hydraulic pump motor power [kW]: 1.5 - Grinding attachment drive motor power [kW]: 0.75 - Machine dimensions [mm]: L=5400 / W=2400 / H=1580 / Machine weight [kg]: 4800

Condition: used, functionality: unexamined, Danobat Universal Grinder model 1200 RP with automatic diamond dressing device, capable of working in automatic cycle, maximum grinding diameter 270mm, maximum wheel diameter 400mm, maximum wheel width 60mm, head power 12 HP. Isdpfx Abow Iv Hujnotd

Condition: like new (used), Year of construction: 2024, functionality: fully functional, grinding length: 1,650 mm, grinding diameter: 400 mm, We offer a new BUB40 x 1500 NC machine equipped with a MITSHUBISHI NC controller. The machine is still under lease with ING Lease. It has been thoroughly refurbished based on the TOS HOSTIVAR BUB 40 model by FAS GŁOWNO. Technical data: • Maximum workpiece diameter: 400mm • Maximum workpiece length: 1500mm • Centre height: 200mm • Distance between centres: 1500mm • Minimum grindable workpiece diameter with a 380 mm grinding wheel: 20mm • Tailstock quill stroke: 40mm • Maximum tailstock clamping force: 4000N • Spindle headstock centre taper: ISO 296-1991/Morse 5 • Tailstock centre taper: ISO 296-1991/Morse 5 • Maximum workpiece weight between centres: 500kg • Maximum workpiece weight in chuck (including chuck): 100kg • Machine width (with enclosure): 6650mm • Machine depth (with enclosure, without control panel): 2400mm • Machine height (with enclosure): 1850mm • Machine weight: 7000kg Itedpfswzkywox Abned • Total power requirement: 38kVA Grinding spindle: • Standard grinding wheel dimensions: 500 x 80 x 203.2mm • Grinding spindle drive motor power: 11kW • Grinding spindle rated speeds (for 430 mm / for >430 mm and 500 mm wheels): 2000 / 1744 rpm • Grinding headstock traverse servo motor power: 2kW • Grinding headstock traverse servo motor torque: 9.5Nm • Maximum continuous X-axis traverse speed: 2m/min • Minimum X-axis grinding wheel increment: 0.001mm • Maximum continuous X-axis traverse speed: 6m/min • Minimum X-axis grinding wheel increment: 0.001mm • Maximum grinding wheel increment in INC mode: 0.1 mm • Table traverse servo motor power: 3.5 kW • Table traverse servo motor torque: 16.7 Nm Workpiece spindle: • Workpiece spindle speed range: 1 – 150 rpm • Workpiece spindle servo motor power: 3.5kW • Workpiece spindle servo motor torque: 16.7Nm More information available upon request via email or phone.

Condition: excellent (used), Year of construction: 2013, Siemens Sinumerik 840D control Max. workpiece diameter: 250 mm Max. workpiece length: 1500 mm Max. workpiece weight: 150 kg Internal grinding device Paper band filter Centre tip Diamond dressing plate Itedpfx Aowwtq Dsbned Grinding wheel change assist

Condition: refurbished (used), Kellenberger internal & external universal cylindrical grinding machine Iodpfx Abjwqlyksnotd Kellenberger 1500 U - 175 (internal grinding attachment included) Centre distance: 1500 mm - Centre height: 175 mm Siemens servomotor. Frequency converter internal & external, WSS Available with various accessories. Availability: immediately! Option 1000U: in overhaul process

Condition: used, Year of construction: 2017, grinding length 1000 mm centre height 180 mm length 3600 mm width 1650 mm height 1800 mm weight of the machine ca. 3,7 t Itjdpfx Aswp Tumobnsd

Condition: ready for operation (used), Year of construction: 1993, External cylindrical grinding machine Manufacturer: TOS Type: BUB 40-1000 Year: 1993 Control: Cetos K 51 Itsdpewp D Auofx Abnsd WORKING AREA CYLINDRICAL GRINDING Max. swing diameter 400 mm Workpiece weight between centers (max) 500 kg Workpiece weight one-side clamped (max) 100 kg WORKING AREA EXTERNAL GRINDING Max. grinding diameter 400 mm Min. grinding diameter 10 mm Grinding length 1000 mm TABLE – CYLINDRICAL GRINDING Swiveling (B-direction) from 8.5 ° Rotation range B-axis up to -4.5 ° Longitudinal travel 1200 mm WORKPIECE SPINDLE STOCK Swiveling (B-direction) from 0 ° Rotation range B-axis up to 90 ° Spindle bore 40 mm Number of gear stages 2 Drive power 9.5 kW Tool holder MK 5 TAILSTOCK Quill stroke 40 mm Quill fitting MK 5 Contact force (max.) 4 kN GRINDING SPINDLE STOCK Swiveling (B-direction) from -15 ° Rotation range B-axis up to 45 ° GRINDING WHEEL Type: grinding wheel, disc Diameter (max) 500 mm Bore: diameter 203 mm Width 80 mm ELECTRICAL CONNECTION DATA Connected load 16 kVA Connection voltage 400 V Network frequency 50 Hz DIMENSIONS / WEIGHTS Required space -left/right- 4700 mm Required space -front/back- 2050 mm Total height 1900 mm Total weight approx. 5400 kg ADDITIONAL EQUIPMENT (GRINDING) Balancing device yes Machine in well-maintained condition Workpiece spindle stock swivels 90° Grinding spindle stock swivels -15°, +45° Table swivels +8°30' - 4°30' Accessories: - hydrostatic spindle - various corundum grinding wheels - 2 diamond grinding wheels - Balancing head MPM, renewed in 2021 - Filter system - Extraction system

Condition: used, Year of construction: 2017, grinding length 1500 mm centre height 180 mm Ijdpfx Abswm Rqgenjtd weight of the machine ca. 3,9 t dimensions of the machine ca. L: 4900 x 1650x 1800 m

Condition: used, functionality: fully functional, Maximum workpiece length: 500 mm Minimum workpiece length approx.: 5 mm Maximum workpiece length for plunge grinding: 50 mm Itsdpfx Aowhp D Ujbnsd Max. grinding diameter without steady rests: 100 mm Max. diameter: 240 mm Workpiece Swivel: 90° Grinding spindle slide Min./max. swivel: 30° Min./max. transverse movement including 300 mm quick adjustment: 100 mm Wheel diameter after rotation 1st degree: 320 - 400 mm 2nd degree: 260 - 320 mm Max. workpiece weight between centers: 60 kg Max. workpiece weight in chuck: 20 kg Max. workpiece weight in faceplate: 20 kg 8 workpiece spindle speeds: 45 - 500 rpm Min./max. Tilt: 12° Min./max. longitudinal travel: 2 - 500 mm Infinitely variable table travel: 0.5 - 5 m/min Handwheel adjustment: 2 and 20/rev
