Waldemar Brumhardt

Condition: ready for operation (used), Year of construction: 2011, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 550 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, overall weight: 12,500 kg, spindle speed (max.): 18,000 rpm, number of slots in tool magazine: 42, number of axes: 5, This 5-axis HERMLE C42 U universal machining centre was manufactured in 2011. It features a travel of 800 x 800 x 550 mm and a spindle speed of 18,000 rpm. The machine includes a NC swiveling rotary table and a tool magazine with 42 positions. If you are looking to get high-quality machining capabilities, consider the HERMLE C42 U machine we have for sale. Contact us for further details. Dsdpfxsz Nf N Es Akcswc - Table / Rotary System: NC swiveling rotary table PW 800 with torque drive in C-axis and helical tandem drive in A-axis- Pallet Changing System: Included- Pallets Included: 3x Palette 630/STM320 Sternnut- Automatic Cabinet Doors: Included- Hydraulic & Pneumatic Expansion: Included- High Pressure Coolant (IKZ): Internal coolant supply 80 bar- Chip Conveyor: Scraper belt conveyor / Standard chip conveyor- Filtration: Paper band filter- Coolant System: Vario pressure limiting valve, standard coolant unit, sealing air for scales, bed flushing- Air Blow Devices: Air blow device, air blast through spindle center- Chip Flushing Gun: Included- Mist Extraction: Oil mist extraction- Enclosure Top: Automatic mechanical cabinet roof- Safety Glass: Laminated safety glass window- Compensation: Electrical thermal compensation iTNC- Handheld Control: Electrical hand control module iTNC- Measuring Probes: Heidenhain measuring probe incl. preparation, BLUM tool breakage/measurement A2- Tele-Service: Remote maintenance- Supply Voltage: 400 V / 3~- Mains Frequency: 50 Hz- Control Voltage: 24 V-- Nominal Current: 60 A- Power Consumption / Load: 37 kVA Technical Specification Taper Size HSK 63

Condition: not inspected (used), Year of construction: 2003, functionality: unexamined, machine/vehicle number: 1117000663, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 15 m/min, nominal power (apparent): 56 kVA, controller manufacturer: HEIDENHAIN, controller model: ITNC 530, total height: 2,600 mm, total length: 5,000 mm, total width: 4,000 mm, table width: 630 mm, table length: 900 mm, overall weight: 10,000 kg, number of slots in tool magazine: 60, mount diameter: 40 mm, tool length: 350 mm, tool diameter: 110 mm, tool weight: 10,000 g, input voltage: 400 V, input frequency: 50 Hz, Incl. 60-fold tool changer, NC rotary table, incl. tool holders located in the tool changer, incl. chip conveyor and coolant system.Attention: without the machine vise shown in the photos!Additional technical specifications:nominal current: 100 APath measuring system resolution: 0,001 mmInput resolution in X/Y/Z: 0.001 mmPosition tolerance in X/Y/Z: 0.010 mmmax. tool diameter with free adjacent places: 160 mmtool length from spindle nose without tool breakage monitoring: 350 mmwith tool breakage monitoring: 315 mmmax. tool weight at automatic tool change: 10 kgmax. total tool weight in magazine: 200 kgDistance of T-slots: 63 mmNumber of T-slots: 9/14 pcsCenter bore: 50 mmmax. rotation of the table top: 20 rpmFeed: 3600°/minResolution of the measuring system: 0.001° Dwjdpfx Akez Nd R Ijcec

Condition: like new (used), Year of construction: 2019, functionality: fully functional, -Travel ranges: X-axis: 800mm Y-axis: 800mm Z-axis: 600mm -A-axis swivel range (2 torque motors): +/- 140° -Swivel axis A speed: Max. 50 min-1 -C-axis rotary range (1 torque motor): 360° (continuous) -Rotary table speed: Max. 100 min-1 -Table load: Max. 1000kg -Path control: Heidenhain TNC 640 -Tool holder: HSK-A63 -Spindle speed range, stepless: Max. 18,000 min-1 -Rapid traverse speed: Max. 60m/min -Additional tool magazine: 224 tool positions -Main magazine: 11 tool positions -Max. tool length in changer: 400mm -Max. tool diameter in changer: 130mm -Chip flushing hose -Chip conveyor flushing -Emulsion mist extraction system Dwodpfx Akjz Iy Swjcoc -Chip conveyor -Protective guard automatic: 840mm opening width -Compressed air supply: Min. 6 bar -Stand-alone cooling unit -Remote maintenance -Machine weight: 15,500 kg -Tool measurement: Blum Laser -3D machine model -IKZ water cooling: Max. 80 bar -Coolant tank volume: 1100 liters The image is an example.

Condition: used, Year of construction: 2007, x-travel 880 mm y-travel 630 mm z-travel 630 mm B - axis -120 / + 30 ° Dedpfx Akez Ictkjcjwc NC- swivellable rotary table - Ø 700 mm control iTNC530 Heidenhain number of spindle speeds 10.000 1/min spindle taper SK 40 DIN 69871 max. torque at 40% / 100% load 28 / 19 kW tool change unit 2 x 16 Pos. table-size 1250 x 700 mm table load capacity 650 kp total power requirement 44 kW weight of the machine ca. 9,5 t dimensions of the machine ca. 3,50 x 3,20 x 2,60 m

Condition: excellent (used), Year of construction: 2017, operating hours: 7,000 h, functionality: fully functional, machine/vehicle number: 25787, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 500 mm, spindle speed (max.): 18,000 rpm, operating hours of spindle: 6,900 h, Equipment: chip conveyor, documentation/manual, Hermle C 400 U – 5-Axis Machining Center Year: 2017 Dedpez H Agbefx Akcswc Control: Heidenhain TNC 640 Condition: Very good Machine ON: 18,512 h Program: 9,268 h Spindle ON: 6,900 h Drive ON: 18,514 h Axes in motion: 7,147 h Technical specifications: X/Y/Z travel: 850 / 700 / 500 mm A-axis: 25 rpm C-axis: 30 rpm Spindle speed: up to 18,000 rpm Power: 20 kW Torque: 173 Nm Tool holder: HSK 63 Tool magazine: 38 + 50 positions NC swivel rotary table: Ø 650 mm Swivel range: +91° to −139° Equipment: Heidenhain touch probe BLUM tool measurement Electronic handwheel Chip conveyor Oil mist extraction Inspection possible by appointment.

Condition: used, Year of construction: 2014, Control Heidenhain x-travel 1.000 mm y-travel 1.100 mm z-travel 1.040 mm tool taper HSK 63 number of tool places 338 Pos. Condition: Used Dwsdpoz Hz N Iofx Akcoc Technical features & accessories: - TM218 tool changer - KNOLL FKA/750 cooling unit - KNOLL KF220 belt filter - KNOLL 850K-1 chip conveyor Accessories, tools, and workholding devices shown are included in the scope of delivery only if specified in the additional information. Subject to change and errors in technical data and specifications; subject to prior sale.

Condition: used, Year of construction: 2016, Control Heidenhain x-travel 800 mm y-travel 1.020 mm Dwjdsz Hz Nhspfx Akcsc z-travel 1.020 mm Condition: Used The machine has been overhauled by GROB. Technical features & accessories: - HYFRA cooling unit - KNOLL KF-220 belt filter - KNOLL 750K-1 chip conveyor - TM218-9 tool magazine - SCHULER LMC900 automatic pallet loader - 10 pallet stations - Movable robot arm Accessories, tools, and workholding devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data/specifications, and prior sale.

Condition: ready for operation (used), Year of construction: 2000, operating hours: 28,027 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain Mill Plus, spindle speed (max.): 18,000 rpm, No minimum price – guaranteed sale to the highest bidder! Vertical machining center with a virtually new spindle (the machine received a new spindle after 23,919 operating hours)! TECHNICAL DETAILS Travel in X-axis: 800 mm Travel in Y-axis: 700 mm Travel in Z-axis: 600 mm Spindle Dwsdpfjz Hu Siex Akcoc Spindle speed: 18,000 rpm Tool holder: HSK 63 MACHINE DETAILS Internal coolant supply: 40 bar Control system Control system manufacturer: Heidenhain Control system model: Mill Plus Spindle operating hours: 28,027 h Spindle replacement at: 23,919 h EQUIPMENT NC rotary table with C-axis NC swiveling head FD function (free-form machining) Pallet changer Infrared measuring probe for workpiece measurement Additional magazine with 120 positions

Condition: used, Year of construction: 2013, Control Heidenhain x-travel 800 mm y-travel 650 mm z-travel 550 mm b-axis -5 / +110 ° c-axis 360 ° table dimensions 800 x 700 mm max. workpiece weight 600 kg spindle tunring speed 18.000 U/min Dsdpfx Aksz Hqkzocewc Number of working hours ca. 71.618 h spindle hours ca. 33.508 h Condition: Used Includes ZERO CLAMP loading robot Accessories, tools, and workholding devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: good (used), Year of construction: 2011, functionality: fully functional, We offer you: CNC machining center, universal Manufacturer: DMG MORI Type: DMU 80 P duoBlock Year of construction: 2011 Control system: Heidenhain iTNC 530 Technical data: Travel ranges: X-axis: 800 mm Y-axis: 1,050 mm Z-axis: 800 mm Main spindle: Max. spindle speed: 18,000 rpm Rotary table: Table diameter: d 900 x 700 mm Dwedpoz Ebzuefx Akcec Tool changer: Tool holder: HSK-A63 Number of tool positions: 60 Operating hours: approx. 49,285 h Spindle hours: approx. 15,380 h Technical features & accessories: - Universal milling head with controlled B-axis - Coolant tank 500 l - Internal coolant supply 40 bar - Chip conveyor with integrated fabric band filter - Rotating viewing window - Infrared measuring probe, manufacturer Heidenhain TS 649 (if available) - Preparation for 3D quickSET - Signal tower, 4 colors - Flushing gun - Cooling system with compressed air through the spindle center - Electronic handwheel (if available) - Operating mode 4 Accessories, tools and clamping devices shown in the pictures are only included in the scope of delivery if this is stated in the additional information. Subject to changes and errors in the technical data and information, as well as prior sale!

Condition: good (used), Year of construction: 2007, Universal machining center Machine type: DMG DMU 80 P duoBLOCK Control: Heidenhain iTNC 530 Year: 2007 SPECIFICATIONS 5-axis-simultaneous Travel X-Axis: 800 mm Dodpsz Dkunsfx Akcowc Y-Axis: 800 mm Z-Axis: 800 mm B-Axes C-Axis Panning head Rapid motion: (X/Y/Z): 60 m/min. Spindle speeds: 12.000 rpm Spindle power: 28 / 19 kW Tool: SK 40 Toolchanger Tool capacity: 60 NC rotary table Table size: 900 x 700 mm Max. Table Load: 1.400 kg Equipment Internal cooling: bar Chip conveyor Electronical handwheel

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, We offer you: Manufacturer: DMG MORI Type: DMU 95 monoBlock Year of manufacture: 2019 Control system: Siemens 840D sl Operate Technical data: Travel distances: X-axis: 950 mm Y-axis: 850 mm Z-axis: 650 mm Dsdjz Ap N Djpfx Akcowc Rotational range C-axis: 360° Swivel range A-axis: +/- 120° Main spindle: Tool interface: HSK-63A Speed range - main spindle: 20,000 rpm Drive power - main spindle (100/40%): 35 / 25 kW Torque: 130 / 86 Nm Rotary table: Table dimensions: C-axis d850 x 750 mm integrated into Fixed table 1,000 mm x 750 mm Max. table load: 1,000 kg Max. workpiece dimensions: d 1,040 mm (clamping)/ d 850 mm (machinable) h 590 mm Tool changer: Number of tool positions: 60 Max. tool diameter: 80 / 160 mm Max. tool length: 420 mm Max. tool weight: 8 kg Chip-to-chip change time: 5.9 s Feed rates: Rapid traverse (x/y/z): 40 m/min Feed rate (x/y/z): 40,000 mm/min Technical features & accessories: - Tool changer system with dual gripper - MPC Machine Protection Control - Production package: - Chip conveyor with coolant unit 600 l / 160 gallons, - Paper band filter - Internal coolant supply, 40 bar / 23 l/min, through the spindle center (AD) - External coolant supply, 4 bar – 40 l/min, (theoretical pump capacity) - Chip flushing in the cabinet door (no standard coolant unit) - Spray gun 3 bar – 40 l/min - Oil and emulsion mist separator, mechanical filter, flow rate 600 m³/h - Infrared measuring probe Renishaw PP60 optical (OMP 60) (if available) - Blum laser, tool measurement in the machining area - 3D quickSET preparation - Electronic handwheel (if available) Accessories, tools and clamping devices shown in the pictures are only included in the scope of supply if this is stated in the additional information. Subject to change and errors in technical data and specifications, as well as prior sale!

Condition: excellent (used), HEIDENHAIN iTNC 530 HSCI control Working travels 875 x 700 x 450 mm A-axis table swivelling +/- 115° C-axis table turnable 360° Spindle taper HSK 63 Spindle speeds 50-20'000 rpm Tool changer 390 positions Robot for workpiece loading GOODJ WHS+ with approx 40 paletts 3D measuring tracer Laser tool setting system Misc. accessories MARCELS MASCHINEN AG Djdpfjzz I Ebex Akcswc

Condition: used, Year of construction: 2012, x-travel 800 mm y-travel 950 mm z-travel 1020 mm Dwjdezz Afcspfx Akcjc Control SIN840D sl B - axis 360 x 0,001 ° A - axis -180 / +45 x 0,001 ° feed x-axis 1 - 65.000 mm/min feed y- axis 1 - 50.000 mm/min Feed z- axis 1 - 80.000 mm / min. rapid traverse X/Y/Z 60 / 50 / 80 m/min spindle turning speed - stepless 1 - 16.000 U/min power capacity at 100 % load 25,00 kW power capacity at 40 % load 35,00 KW max. torque at 40% / 100% load 223 / 160 Nm spindle diameter in front bearing 80 mm tool taper HSK-A63 tool magazin: 50 tool length - max. 400 / 465 mm tool diameter 72 mm tool diameter with 2 vacant positions 160 mm tool total weight 8,00 kg size of pallet 630x630 mm workpiece weight 700 kg interference diameter 900 mm total power requirement 50,00 kW weight of the machine ca. 26,00 t dimensions of the machine ca. 7,00 x 4,50 x H3,50 m 5-axis machining center with SIEMENS Sinumerik 840D SL control, integrated KNOLL coolant unit, sitchable to minimal quantity lubrication coolant through the spindle max. 80bar, chip conveyor.

Condition: used, Year of construction: 2016, x-travel 800 mm y-travel 1020 mm Dwedozy Saajpfx Akcoc z-travel 1020 mm Control SIN840D sl B - axis 360 x 0,001 ° A - axis -185 / +45 x 0,001 ° feed x-axis 1 - 65.000 mm/min feed y- axis 1 - 50.000 mm/min Feed z- axis 1 - 80.000 mm / min. rapid traverse X/Y/Z 60 / 50 / 80 m/min spindle turning speed - stepless 1 - 16.000 U/min power capacity at 100 % load 25,00 kW power capacity at 40 % load 32,00 KW max. torque at 40% / 100% load 206 / 159 Nm spindle diameter in front bearing 70 mm tool taper HSK-A63 tool magazin: 272 tool length - max. 400 / 465 mm tool diameter 68 mm tool diameter with 2 vacant positions 160 mm tool total weight 8,00 kg Chip to chip time 4,2 sec. size of pallet 630x630 mm workpiece weight 700 kg interference diameter 900 mm total power requirement 50,00 kW weight of the machine ca. 32,00 t dimensions of the machine ca. 10,00 x 6,00 x H3,50 m 5-axis machining center with SIEMENS Sinumerik 840D SL control, integrated KNOLL coolant, coolant through the spindle, chip conveyor, RENISHAW measuring probe, BLUM-Laser, GROB Spindle-diagnosis (GSD) Additional Tool-Magazine TM218, Pallett-Storage PSS630-R13-12

Condition: good (used), Year of construction: 2011, operating hours: 19,000 h, functionality: fully functional, travel distance X-axis: 880 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 635 mm, spindle speed (max.): 12,000 rpm, operating hours of spindle: 19,000 h, spindle nose: HSK 63, number of slots in tool magazine: 32, Equipment: chip conveyor, documentation/manual, The machine will be available starting October 2026! Dwedpfx Akezx Ur Necjc

Condition: excellent (used), Year of construction: 2012, operating hours: 6,000 h, functionality: fully functional, Controller MITSUBISHI MELDAS M70 Table size 910 x 400 mm Max. table load 960 kg X travel 760 mm Y travel 445 mm Z travel 520 mm Spindle speed 12000 rpm Tool holder type MAS BT40 Spindle power 22 kW ATC Magazin 22-fold Weight 4400 kg Dimensions LxWxH = 2200 x 2200 x 2700 mm Features, accessories - 2 axis nc round table - Coolant unit Dodpfszxzwrex Akcowc - Chip conveyor - Manuals

Condition: used, Year of construction: 2004, Milling machines Travel distance X: 880 mm Travel distance Y :630 mm Travel distance Z: 630 mm HSC-machines Number of axis: 5 milling machine / machining center Dwodpszwqvnefx Akcjc Control: Heidenhain iTNC 530 table size X: 1250 mm table size Y: 700 mm tool changer: 32 - time Torque: 130 Nm control Heidenhain Universal machining center NC rotary table (C-axis) integrated into rigid table Swivel milling head (B-axis) SK40 tool holder Tool magazine: 32 (2x16 positions) Cooling unit Rotary table: 700 mm Max. table load: approx. 500 kg Speed range - main spindle: 20 - 12,000 rpm Feed rates: 20 - 15,000 mm/min Torque: 130 Nm Machine weight approx.: 9.0 tons Machine dimensions approx.: 4.0 x 3.0 x 2.5 meters

Condition: like new (used), Year of construction: 2025, functionality: fully functional, Universal milling machine, 3-axis machining: > Working area X = 805 mm > Working area Y = 1,015 mm > Working area Z = 220 mm > Small footprint: 1,800 x 1,500 x 1,980 mm > Spindle: 4.8 kW | max. 40,000 rpm | HSK Djdsztxmgepfx Akcjwc > Tool magazine: 15 positions > Aluminum vacuum table > 3D probe > Minimum quantity lubrication > Tool measuring system > Further optional equipment ...

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 880 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! The spindle was replaced on November 14, 2018. TECHNICAL DETAILS Travel in the X-axis: 880 mm Travel in the Y-axis: 630 mm Travel in the Z-axis: 630 mm Spindle speed: 12,000 rpm Controlled B-axis: -15° to +90° Tool holder: SK 40 Dwodpfxszpw Iue Akcsc Number of tool magazine slots: 32 MACHINE DETAILS Control system: Heidenhain iTNC 530 Spindle operating hours: 50,033 h EQUIPMENT Coolant system

Condition: reconditioned (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: U300625501192, travel distance X-axis: 800 mm, travel distance Y-axis: 950 mm, travel distance Z-axis: 1,020 mm, controller manufacturer: Heidenhain, controller model: iTNC 530, workpiece diameter (max.): 900 mm, workpiece weight (max.): 800 kg, table load: 800 kg, rotary table diameter: 770 mm, rotational speed (min.): 50 rpm, spindle speed (max.): 16,000 rpm, number of spindles: 1, number of slots in tool magazine: 208, tool length: 465 mm, tool weight: 8 g, input voltage: 400 V, input frequency: 50 Hz, warranty duration: 3 months, Equipment: documentation/manual, rotational speed infinitely variable, Base machine G550 AB, Generation 0 Travel in X: 800 mm Travel in Y: 950 mm Travel in Z: 1020 mm Power supply: 400 V, 50 Hz, TN-S Dust extraction port for connection to a work area extraction system Swiveling table (A' axis) Dedpfjzmabfex Akcowc Rotary table (B' axis), pallet clamping system GROB Machine control: HEIDENHAIN iTNC 530 Optimization of the machine kinematics with KinematicOpt GROB standard interface to the loading system V1.4 Swiveling table (A' axis) Rotary table with pallet clamping system GROB (B' axis) Motor spindle HSK-A 63, 16,000 min-1, 159/206 Nm, 25/32 kW GROB spindle diagnostics GSD Simple disc magazine HSK-A 63 with 50 tool positions Tool additional magazine TM167 HSK-A 63 with 167 tool positions Tool cleaning device Electromechanical tool length measuring device Palette 630 x 630 mm, grid hole pattern, without gripper claws Scraper belt chip conveyor, discharge height 1,100 mm Coolant high-pressure system (5-38 bar, internal coolant) Coolant low-pressure system Compressed air supply through the spindle center External compressed air supply via a flexibly adjustable hose Switchable coolant pressure booster for the nozzles in the motor spindle Oil skimmer for coolant maintenance Flushing device for the floor of the work area Blow-out gun in the work area Flushing gun in the work area Flushing device (Z-axis) Workpiece clamping system in the work area - KP1: Hydraulic oil, manual pressure reduction, 30-200 bar (H1) - KP2: Hydraulic oil, manual pressure reduction, 30-200 bar (H1) - KP3: Hydraulic oil, manual pressure reduction, 30-200 bar (H1) - KP4: Hydraulic oil, manual pressure reduction, 30-200 bar (H1) Machine status indicator, three-color Infrared measuring probe m&h IR25.41 Remote machine diagnostics with access control switch Warranty for 3 months

Condition: ready for operation (used), Year of construction: 2006, operating hours: 43,686 h, total height: 2,300 mm, overall weight: 7,000 kg, table width: 500 mm, table length: 870 mm, travel distance X-axis: 800 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 700 mm, controller manufacturer: SIEMENS, controller model: SINUMERIK 840D Powerline, working width: 500 mm, cutting length (max.): 870 mm, laser power: 100 W, number of axes: 3, This 3-axis DMG Sauer Lasertec80 FineCutting was manufactured in 2006. It features an X-axis travel of 800 mm, Y-axis travel of 500 mm, and Z-axis travel of 700 mm. The machine is equipped with a Siemens SINUMERIK 840D Powerline control and a high-precision cross table with linear drives. If you are looking to get high-quality laser fine cutting capabilities, consider the DMG Sauer Lasertec80 FineCutting machine we have for sale. Contact us for further details. Technical Data • Machine Type: Laser Fine Cutting, Laser Drilling and Laser Welding Machine • Control: Siemens SINUMERIK 840D Powerline • Table Type: Cross Table with Linear Drives • Maximum Sheet Size: 870 × 500 mm • Vertical Axis with Linear Guideways and Ball Screw Drive • Machine Base: Mineral Cast Construction • Laser Type: Lasag KLS246 Nd:YAG Laser • Average Laser Power: 100 W • Focal Length: 70 mm • Machine Dimensions (L × W × H): 6,000 × 5,000 × 2,300 mm • Machine Length: 6,000 mm (including aggregates, operation and maintenance space) • Machine Width: 5,000 mm (including aggregates, operation and maintenance space) • Operating Hours: 43,686 h • Laser Unit Condition: C Module Defect Additional Equipment • Precitec Processing Head • Automatic Height Control • Keller Dust Extraction System • Automatic Filter Cleaning System • KKT Kraus Water-Air Cooling Unit • Programmable Process Gas Pressure • Completely Overhauled Laser Cavity • New Pulse Lamp Dwjdpfx Akezl T R Dscec • Precitec Laser Head Mounting Tools Machine Benefits • Suitable for Laser Fine Cutting, Laser Drilling and Laser Welding • High-Precision Cross Table with Linear Drives • Automatic Height Control for Precise Processing • Comprehensive Maintenance Logbook Available • All Repairs and Component Replacements Documented • Inspection on Site Possible • Repair of the Laser Unit PossibleRepair will only be carried out if requested. Please note that the selling price may vary accordingly.

Condition: good (used), Year of construction: 2006, Parts shown by hand not come. Machine is in good working condition. Djdpfx Aozk U Unokcjwc

Condition: good (used), functionality: fully functional, CNC milling machine Deckel Maho DMU 80 T Control system: Heidenhain TNC426 Spindle speed: 20-6300 rpm Feed rate x, y, z: 20-10000 mm/min Rapid traverse rate x, y, z: 15000 mm/min Work area: x 800 mm, y 650 mm, z 550 mm Tool holder: Djdjzhpzqjpfx Akcewc SK40 DIN 2079 Clamping bolt DIN 69 872 Tool changer: 25 positions Max. tool diameter 160 mm Max. overhang length from the spindle nose 315 mm Work table: Dimensions 1100 x 600 mm T-slots 9 x M14 Permissible weight 500 kg Transport data: Weight 5800 kg Dimensions (length x width x height) 3.05 x 2.40 x 2.45 m

Condition: ready for operation (used), Year of construction: 2018, operating hours: 4,231 h, functionality: fully functional, machine/vehicle number: 107.44.00.407, travel distance X-axis: 800 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 500 mm, controller model: Heidenhain iTNC 530, overall weight: 11,000 kg, TECHNICAL DETAILS Travel range, X-axis: 800 mm Travel range, Y-axis: 650 mm Travel range, Z-axis: 500 mm C-axis swivel range: 360° Tool interface: HSK-E63 MACHINE DETAILS Control system: Heidenhain iTNC 530 Dedjzf E I Iepfx Akcjwc Spindle types: NCD 150 PL, NCD 200 PL Operating hours, control ON: 30,064 h Operating hours, machine ON: 10,322 h Operating hours, program execution: 4,159 h Operating hours, drives ON: 7,331 h Operating hours, spindle ON: 4,231 h Dimensions & Weight Dimensions (L x W x H): 3,400 x 3,000 x 2,800 mm Total weight: 11,000 kg EQUIPMENT Chip conveyor Coolant system with filter system Documentation available
