Rommelmann GmbH

Condition: excellent (used), Year of construction: 1991, Drilling diameter in St 60/GG 20: 28/32 mm Spindle taper: MT 3 Throat: 250 mm Spindle stroke: 120 mm Isdpfx Afsyk T A Ejajan Table size: 400 x 415 mm Maximum distance between table and quill: 665 mm Spindle speeds: 140 - 2000 rpm Drive motor: 380 V, 1.1/1.3 kW Weight: 210 kg Space requirements: 800 x 420/600 x 1790 mm

Condition: ready for operation (used), GILLARDON GB 20 – Column Drilling Machine from University - Infinitely variable speed control - Equipped with MK 3 adapter - Maximum drilling capacity in steel: 30 mm - Throat: 285 mm - Quill travel: 150 mm - Table clamping surface: 400x400 mm - Table height adjustment approx. 650 mm - Adjustable drill depth stop - Speed display - Emergency stop - Work lamp - Foot switch - Documentation Iodpoyk Dl Rjfx Afasan Dimensions (LxWxH): 0.7x0.6x1.8 meters / Weight: 650 kg Subject to errors and input mistakes

Condition: good (used), Stock number: 3075 Manufacturer: Alzmetall Machine number: 11495 Type / Model: AB3 ES Iasdpeyifmwefx Afasn Quill stroke: 180 mm Spindle taper: MK3 Drilling capacity: 30 mm Speed range: 160 to 1,420 rpm, stepless Throat: 280 mm Table diameter: 450 mm Clamping surface diameter: 360 mm Table height adjustment: – mm Column diameter: 110 mm Footprint: 450 x 650 mm Total connected load: 2 kW Accessories/Equipment: Condition: good Weight: 0.3 t Machine dimensions: 600 x 900 x 1,850 mm

Condition: used, Column Drill Gillardon Type GSB 32 V Machine No.: Year of manufacture approx. 1975 Drilling capacity: 32 mm Taper: MK 4 – long quill Throat: 350 mm Quill travel: 170 mm Table size: 570 x 470 mm Column diameter: 140 mm Spindle speed Motor speed step 1, Belt step 1: 50 – 300 rpm, stepless Spindle speed Motor speed step 2, Belt step 1: 100 – 600 rpm, stepless Spindle speed Motor speed step 1, Belt step 2: 100 – 500 rpm, stepless Spindle speed Motor speed step 2, Belt step 2: 150 – 1000 rpm, stepless Motor power: 1 / 1.5 kW Power supply: 380 Volt, 50 Hz - automatic feed approx. 0.1 / 0.16 / 0.25 mm/rev, 3 steps - spindle speed via 2 motor speeds, 2 V-belt stages and variator gearbox - adjustable drilling depth stop - table height adjustment via rack and hand crank - tiltable drilling table with angle scale - drill chuck RÖHM Ø 1 to 13 mm - machine lamp Required space (L x W x H): 1000 x 750 x 2000 mm Weight: 470 kg Iedpfx Afsyhf Izoasan Good condition

Condition: good (used), Year of construction: 1977, machine/vehicle number: 1314, Radial Drilling Machine ALZMETALL - AB 30 R Arm reach: 800 mm Spindle taper: MK 4 Drilling capacity in steel: 45 mm Iajdpoyhbnksfx Afaen Thread cutting device - up to M30 Spindle stroke: 160 mm Spindle speeds: 8 steps, 56 to 1,250 rpm Thread cutting steps: 4 - 0.15 / 0.2 / 0.3 / 0.35 mm/rev Clamping cube with T-slots: 550 x 480 x H - 500 mm Machine vice on rotary table - jaw width: 200 mm Space requirements: 1,600 x 700 x H - 2,250 mm Weight: 1,370 kg

Condition: good (used), Year of construction: 1978, 1 used column drilling machine Manufacturer: Alzmetall Model: AB 35 S Year of manufacture: 1978 Drilling capacity: 35 mm Spindle taper: MK 4 Automatic feed: 0.1 – 0.2 – 0.3 mm/rev Spindle speed: 65 – 1750 rpm, stepless Arm reach: 300 mm Quill stroke: 160 mm Table: 620 x 470 mm Clamping surface: 500 x 370 mm Column diameter: 140 mm Iasdpfx Aeyhazvofajn Mains connection: 380 Volt, 50 Hz Coolant system Required space (L x W x H): 1070 x 650 x 1880 mm Weight: 480 kg

Condition: used, Year of construction: 2012, bore capacity in steel (diameter) 32 mm throat 300 mm bore stroke 150 mm MK 4 480 x 480 mm 0,1 - 0,2 mm/U M 22 (St 60) 35 mm 80-1170 U/min 2,3 kW 350 kg 800 x 1000 x 2000 mm Accessories: Iajdsygm Sfopfx Afajn - Automatic feed - Coolant device in the foot - Automatic thread cutting reversal - stepless speed adjustment - adjustable drilling depth stop - spindle protection

Condition: used, Year of construction: 1993, bore capacity in steel (diameter) 40 / 23 mm throat 320 mm Ijdpfx Aoyfwzusfaean bore stroke 180 mm 4 speeds 30 - 765 U/min table-size 720 x 550 mm weight 480 kg dimensions 750 x 900 x 1900 mm Equipment: - Multi-spindle head, drill Ø 23 mm - automatic feed - coolant device - infinitely variable speed - adjustable drilling depth stop

Condition: used, bore capacity in steel (diameter) 25 mm Iedpfx Aoyfwy Rjfajan throat 220 mm bore stroke 110 mm taper MK 3 MK table-size 350 rund mm turning speeds 100 - 2080 U/min connected load frequency 400 V total power requirement 0,9 KW weight of the machine ca. 0,2 t dimensions 0,8 x 0,6 x 1,9 m

Condition: excellent (used), functionality: fully functional, type of input current: three-phase, spindle mount: MK 4, drilling capacity: 45 mm, spindle speed (max.): 2,400 rpm, A MAXION column drill in good, used condition is for sale, as shown in the pictures. Technical data: • Manufacturer: Zimmer MAXION • Model: UNIMAX 4 • Cycle-programmable column drilling machine, also for complex work processes, with programmable speeds and feeds. As simple as a conventional machine, with the functionality of a controlled machine. • Continuous drilling capacity: approx. 40 mm • Normal drilling capacity: approx. 45 mm Isdeydvlvspfx Afaoan • Thread cutting capacity: up to M 36 • Spindle: MK 4 • Stepless feed: approx. 30-1,650 mm/min. • Automatically programmable feeds • Drilling depth: approx. 175 mm • Reach: approx. 300 mm • Spindle/table 70 to 830 mm • Table surface: approx. 460 x 340 mm • Spindle speed continuously variable 30-2,400 rpm • Motor power: approx. 7.5 kW • Power connection: 32A CEE plug • External dimensions: approx. 110x60x200 cm • Weight: approx. 480 kg • Condition: Used, in working order Shipping costs by freight forwarder: approx. €180 You will receive an invoice with VAT shown separately. Viewing/collection is possible by arrangement in 42855 Remscheid. Sale from location 42855 Remscheid, free loading. Subject to errors in technical data and prior sale.

Condition: used, Year of construction: 2013, functionality: fully functional, Equipment: lighting, Very few operating hours, 95% used for aluminium. Iasdpeydum Esfx Afaen

Condition: good (used), Column drilling machine ALZMETALL AB 3 ES from training facility - Well-maintained original condition - Drilling capacity / steel: 35 mm - Throat depth: 280 mm - Table size: 600x470 mm - Drilling stroke: 180 mm - Morse taper MK 3 - Infinitely variable speed control - Drill depth stop - Speed display - Drill chuck - Documentation Dimensions: LxWxH 1.2x0.8x2 meters / Weight 450 kg Iaodjycv Tdspfx Afasn Errors and omissions excepted.

Condition: used, Year of construction: 1996, bore capacity in steel (diameter) 32 mm throat 295 mm bore stroke 140 mm 3 Iajdpfxjyclu Re Afaen speeds 160 - 2250 U/min table-size 375 x 415 mm total power requirement 1,5 / 1,9 kW weight 350 kg dimensions 590 x 500 x 1900 mm Equipment: - Automatic feed - Thread cutting device - coolant device - infinitely variable speed - Adjustable drilling depth stop - EMERGENCY STOP switch

Condition: like new (used), Year of construction: 2023, - Year of construction 2023 (lightly used) - MK4 - 95–1600 rpm - Thread cutting function - Height-adjustable drill head - Swiveling drill head - Table 580 x 190 mm - Gear-driven Iaodpsya U R Aofx Afaon - Cooling - Safety guard - Emergency stop - Documentation - 400V

Condition: good (used), functionality: fully functional, Data : Continuous drilling capacity in ST 60 30 mm 12 speed levels 60 - 2240 rpm Iaedpfjyapv Hex Afasn Spindle motor 1.1 / 1.6 kW . Projection approx. 320 mm Spindle stroke 170 mm Column diameter approx. 120 mm .

Condition: ready for operation (used), Year of construction: 2002, machine/vehicle number: 30282, functionality: fully functional, Alzmetall AB 32/SV-RFT20 drilling machine with fixed table in very neat condition. Specifications: Drilling capacity in steel ST60: 32/40mm Spindle travel: 160mm Tapping capacity: M24/M30 Spindle taper: MK4 Automatic feed in 3 steps: 0.1/0.2/0.3mm Ijdpfx Aeyanmqofaean Minimum distance spindle-table: 300mm Maximum distance spindle-table: 950mm Distance spindle-column: 300mm Speed: 62-2000rpm variable in 4 steps Table clamping area: 760x770mm Weight: 760kg

Condition: used, Year of construction: 1995, Technical details: bore capacity in steel (diameter): 32 mm throat: 293 mm Iajdpfsx U Dkcjx Afasn bore stroke: 120 mm bore capacity in St 60 - full boring: 40 mm bore capacity in cast iron: Ø 38 mm spindle taper MT: MK 3 spindle throat: 293 mm spindle speed:: 160 - 2250 / seples U/min feed: 0,10 - 0,20 / manuell+automatisch mm/U Distance spindle/table max.: 55 - 642 mm table clamping surface:: 300 x 300 mm drill table adjustment: ja mm column diameter: 115 mm distance spindle center to floor plate:: 1207 mm total power requirement: 1,9 kW weight of the machine ca.: 280 kg dimension machine xH: 0,7 x 1,0 x 1,9 m

Condition: new, functionality: fully functional, Drilling capacity in steel St 60: 25 mm Drilling capacity in cast iron GG 20: 30 mm Boring capacity in St 60: 30 mm Thread cutting in ST 60: M 16 Thread cutting in GG 20: M 20 Short spindle: MK 3 Spindle stroke: 140 mm Throat: 293 mm Column diameter: 115 mm Machine table – usable surface: 514 x 360 mm T-slot quantity – width – spacing: 2 x 14 x 224 mm Distance spindle-table min./max.: 132 / 724 mm Feed: manual Spindle speeds – stepless: 100 – 1,800 rpm Total power requirement: 1.0/1.6 kW Machine weight approx.: 260 kg Standard equipment: - Mushroom pushbutton (latching) for emergency stop - Reversing switch for clockwise and counterclockwise rotation - Motor protection switch - Stepless speed adjustment - Digital speed display - Protection class IP 54 - Plug connector (pre-installed) - Spindle guard with electrical interlock - Paint finish: DD textured varnish signal white RAL 9003, Pantone 7545c, black Special equipment: Pos. 12 LED machine lamp Iedpfx Ajx Sqt Ssfaean with radially adjustable light beam, connection power 230 V, protection class IP65

Condition: used, functionality: fully functional, Piling drill in very good condition Iodpex Sqigofx Afaoan

Condition: good (used), Column drilling machine GILLARDON GB 25 Iajdpfx Asx Hr D Iefajn - Drilling capacity / steel: 32 mm - Drilling capacity / cast iron: 35 mm - Speed range – stepless: 60 - 1800 rpm - Rotational direction / right - left - Morse taper MT 3 - Throat depth: 290 mm - Quill stroke: 175 mm - Table size: 450x360 mm - Table height adjustment via hand crank - Thread cutting device - Coolant system - Drill chuck - Analog speed display - Foot switch - Emergency stop - Documentation Dimensions: LxWxH 0.7x0.7x2 meters / Weight: 470 kg Subject to errors and typographical mistakes

Condition: excellent (used), Year of construction: 1989, Column drilling machine, make GILLARDON, type: GB 45 VE, year 1989, in good condition. Equipped with thread cutting device, coolant system, machine lamp, machine documentation. Spindle taper: MT 4 Spindle speeds: 40–1100 rpm, motor power: 2.2 kW Maximum drilling capacity in steel: 45 mm – 55 mm Maximum drilling stroke: 200 mm 3 feeds: 0.1–0.16–0.25 mm/rev Maximum thread cutting in steel: M42 / M60 Table size: 560 mm x 450 mm Iajdex Hr Akspfx Afajn Required space: 1.3 m x 0.8 m x 2.1 m, weight approx. 740 kg.

Condition: used, Year of construction: 1988, bore capacity in steel (diameter) 32 mm throat 295 mm bore stroke 120 mm 3 Iaedjx Haxyspfx Afaen speeds 125 - 3000 U/min table-size 300 x 300 mm column diameter 115 mm total power requirement 0,75 kW weight 225 kg dimensions 900 x 600 x 1800 mm Equipment: - V-belt driven pillar drill - Adjustable drilling depth stop - height-adjustable work table with T-slots - drill chuck

Condition: new, Year of construction: 2025, bore capacity in steel (diameter) 32.0 mm 35.0 mm bore stroke 150 mm M 22 (St 60) Iodpfjx Dngkjx Afaoan throat 300 mm 0.1 - 0.2 mm/U MK 4 480 x 480 mm 80.0 - 1.170 U/min 0.90 / 1.35 kW 340 kg 800 x 1000 x 2000 mm Manufacturer's list price: 8.665.00 EURO Special price on request Equipment: - Column drilling machine - "V-belt drive" - infinitely variable speed adjustment - Manual automatic spindle feed - Thread cutting device * automatic feed reversal RS for thread cutting - pole-changing drive motor - depth scale and adjustable depth stop - Height-adjustable work table * Adjustment with hand crank - Right/left rotation of the drill spindle - Machined machine base incl. coolant device - Machine/work light - Folding drill spindle guard - Emergency stop button at the front - CE marking + instruction manual

Condition: new, Bernardo Gear-Driven Pillar Drilling Machine GB 32 S Vario Technical Specifications • Drilling capacity max.: 32 mm • Tapping capacity max.: M22 • Drill chuck: 1 – 13 mm / B16 • Morse taper: MK 4 • Spindle speed / 2 ranges: 90 – 980 / 1000 – 3000 rpm • Feed range: 0.06 / 0.12 / 0.18 mm/rev • Throat depth: 300 mm • Max. spindle to table distance: 670 mm • Spindle to base plate distance: 1285 mm • Quill stroke: 160 mm • Column diameter: 125 mm • Table size / T-slot size: 460 x 460 mm / 14 mm • Base working area: 420 x 340 mm Iaodpfx Aox Agiuofaon • Motor output (S1 100%): 1.5 kW / 400 V • Motor input (S6 40%): 2.2 kW / 400 V • Machine dimensions (W x D x H): 540 x 900 x 2120 mm • Weight: approx. 360 kg Features • Infinitely variable speed control, ideal for adjusting the desired cutting speed • Machined base (420 x 340 mm) with integrated coolant pump • Integrated digital display for speed and drilling depth • Heavy-duty cast iron table with rotatable and tiltable work surface • Supplied as standard with 3 automatic spindle feeds • Guaranteed concentricity ≤ 0.02 mm measured in the quill • User-friendly membrane keypad operation • Standard with automatic quill feed and tapping device • Robust, ground steel column designed for heavy-duty use Scope of Delivery • Gear-driven drill chuck 1 – 13 mm / B16 • Drill chuck arbor MK 4 / B16 • Reducing sleeves MK 4 / 3, MK 3 / 2 • Delta VFD frequency converter • Automatic tool ejector • Coolant system • Electromagnetic spindle feed • Tapping device • LED machine lamp • Digital speed display • Digital drilling depth display • Height-adjustable safety guard

Condition: used, Year of construction: 1995, bore capacity in steel (diameter) 40 mm throat 230 mm Ijdpfsxz Hg Rsx Afaoan bore stroke 130 mm taper MK 4 MK table-size 400 x 315 mm turning speeds 105 - 1257 U/min total power requirement 2,55 KW weight of the machine ca. 0,35 t dimensions 0,8 x 0,6 x 1,95 m
