Condition: excellent (used), Year of construction: 2009, operating hours: 8,000 h, functionality: fully functional, travel distance X-axis: 730 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, controller manufacturer: Heidenhain, controller model: iTNC 530, rotational speed (max.): 12,000 rpm, spindle motor power: 12,000 W, number of slots in tool magazine: 60, Equipment: chip conveyor, documentation/manual, Available: End of October/Beginning of November Manufacturer: DECKEL MAHO (DMG MORI) Model: DMU 60 monoBLOCK Year of manufacture: 2009 Operating hours: approx. 30,000 h Spindle hours only: approx. 8,000 h Control system: HEIDENHAIN iTNC 530 Axes: 5-axis simultaneous machining Technical data & spindle: Travels: X = 730 mm | Y = 560 mm | Z = 560 mm 4th axis (B-axis – swivel head): +30° to -120° (NC swivel milling head with hydraulic clamping) 5th axis (C-axis – rotary table): 360° (endlessly rotatable NC rotary table, resolution 0.001°) Main spindle: max. 12,000 rpm (high-torque version) Tool interface: SK 40 Tool changer: 60-position chain magazine (large expansion stage) Csdpjzwx Aijfx Agtohb Equipment & accessories: Cooling: Internal coolant supply (IKZ) including paper band filter system Chip conveyor Measuring probe available - DMG TS 649 Documentation and key available Videos available

Condition: used, Year of construction: 2019, functionality: fully functional, Control System (Standard) - HEIDENHAIN TNC-640 HSCI control unit with software option 1&2 (see control system options), DCM collision protection function - 5-axis simultaneous operation - Block processing time 0.5 sec. - NC memory capacity 21 GB on SSDR memory card - USB interface - Ethernet network interface - 1024-block look-ahead function - 3D tool length compensation function - DCM (Dynamic Collision Monitoring) - TSC (Spindle Thermo-Compensation) - Tool center point control (TCPC) - smarT.NC (alternative operating mode for dialog and plain text programming in a mix, particularly suitable for beginners) Linear axes: - Travel ranges X/Y/Z: 600/600/500 mm Cjdpszwxicofx Agtehb Linear roller guides: - Manufacturer: INA - Size: 45x45 mm Linear axis accuracy: - Manufacturer: HEIDENHAIN length measuring systems - Resolution linear glass scale: 0.0001 mm - Positioning accuracy X/Y/Z axis: 0.005 mm - Repeatability X/Y/Z axis: ±0.0025 mm Rotary axis accuracy: - High-precision angle encoder for A- and C-axis - A-axis positioning accuracy: ± 30" - C-axis positioning accuracy: ± 5" Ball screw (oil-lubricated): - Manufacturer: INA - Pitch: 12 mm - Max. speed X/Y/Z axis: 36,000 mm/min Swivel and rotary axis: - Swivel axis (A): - Swivel range: +120° / -120° - Drive: Worm gear (optional: direct drive) - Brake: hydraulic (1,200 Nm / 50 bar) - Speed: 16.6 min-1 - Rotary axis (C): - Rotation angle: 360° (0.001° increments) - Drive: Direct drive (torque motor) - Brake: hydraulic (2,900 Nm / 50 bar) - Speed: 90 min-1 Swivel and rotary table: - Table diameter: Ø500 x 420 mm - Max. table load: 600 kg - Max. load height: 430 mm - T-slots (number / size / slot spacing): 7 x 14 mm x 75 mm Spindle: - Manufacturer: ROYAL Precision Tools Corporation - Drive type: direct - Spindle motor / SIEMENS motor 1PH8133 - Power S1/S6 (40%): 25/35 kW - Max. torque S1/S6 (40%): 134/261 Nm - Max. speed 15,000 min-1 - Spindle taper: DIN SK-40 / MAS BBT-40 (Option: HSK-A63) - Spindle oil cooler Coolant management: - External coolant supply around the spindle nose - Internal coolant supply through the spindle 20 bar with cartridge filter 40 µm, pumps adapted in the coolant tank - Number of magazine positions: 30 (optional: chain with 32, 48, or 60) - Magazine type: Carousel / Fixed position, coded - with tool change arm (double gripper) - Max. tool length: 300 mm - Max. tool diameter: Ø78 mm - Max. tool diameter: Ø120 mm with locked neighboring positions - Max. tool weight: 7 kg Chip management: - Hinged band chip conveyor Other standard equipment features: - Automatic central lubrication - High-pressure chip flushing / chip shower - Coolant gun - Control cabinet air conditioning - Coolant flushing gun - Work area lighting - 3-color warning light (cycle active / completed / alarm message) - Hand tool kit, leveling bolts, nuts, shims - EMC and safety modules for CE compliance - Portable, electronic handwheel - CE compliant with European directives - Hydraulic and pneumatic supply prepared through the table (3x 80 bar hydraulic and 1x 6 bar pneumatic connection). - Oil skimmer

Condition: good (used), Year of construction: 2004, operating hours: 38,930 h, functionality: fully functional, machine/vehicle number: 16495, spindle speed (max.): 18,000 rpm, Make: HERMLE Type: C600U Control: HeidenHain iTNC 530 Year: 2004 X - Travel 600 mm Y - Travel 450 mm Z - Travel 400 mm A - Axis 110 ° B - Axis 360 ° Table Ø 280 mm Feed rate X-Axis 35000 mm/min. Feed rate Y-Axis 35000 mm/min. Feed rate Z-Axis 35000 mm/min. Feed rate A-Axis 10 Degrees/min Feed rate B-Axis 15 Degrees/min Spindle Taper 40 ISO/Bt/Mk Power on spindle 15 kW Speeds / ranges 18000 Rpm Chodszwt Hpspfx Agteb ATC / revolver 30 Chip conveyor No

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, CNC machining center Kunzmann WF 650 Control system: Heidenhain iTNC 640 Year of manufacture: 2015 Internal machine number: 67 Travel ranges: X-axis 650 mm Y-axis 500 mm Z-axis 450 mm Rotary table C-axis: Ø 400 mm Tilting range A-axis: +120/-95° Rotational range C-axis: 360° Tool holder: SK 40 DIN69871 Tool magazine: 40 positions Chedpfxezwmbgj Agteb Spindle speed: 1 – 12,000 rpm Spindle tilting range: +5 / -92° - Coolant system - Internal coolant - Electronic handwheel HR 510 FS - Chip conveyor

Condition: excellent (used), Year of construction: 2024, operating hours: 1,080 h, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 460 mm, torque: 120 Nm, controller manufacturer: Heidenhain, controller model: TNC640, total height: 3,000 mm, total length: 3,600 mm, total width: 3,000 mm, table load: 300 kg, rotary table diameter: 650 mm, rotational speed (max.): 25 rpm, overall weight: 9,800 kg, spindle speed (max.): 12,000 rpm, operating hours of spindle: 700 h, coolant supply: 30 bar, spindle motor power: 23,000 W, spindle nose: SK40, number of spindles: 1, number of slots in tool magazine: 48, Equipment: chip conveyor, documentation/manual, The machine was used as a bridging machine because the customer ordered an MT EVO UDS80. This is already his second one. UDS65-5A 5-axis universal machining center with Rotary table with Heidenhain TNC640 - 12,000 rpm hybrid bearing direct drive, water-cooled - Torque 120 Nm (25% ED) - Drive power 23 kW (25% ED) - Separate spindle cooling for constant temperature - Tool holder DIN SK40 with blow-out function Rotary table: - Ø 650 mm - Direct measuring systems in C and A axes General: - 48-position tool changer with dual-arm gripper - Travel ranges X/Y/Z: 620/520/460 mm - Coolant and compressed air gun - Chip conveyor as a scraper conveyor - Coolant system - Electronic handwheel - Work area light IKZ, 30 bar, including paper band filter Heidenhain TS460 for SK40, Workpiece probing system with radio and infrared transmission Heidenhain TT460, tool probing system with radio and infrared transmission for tool measurement Heidenhain KinematicsOpt #48 Chedpfszwkwljx Agtjb Machine cover that can be opened, mechanically operated Incl. a large number of – approx. 100 – SK40 holders.

Condition: repair required (used), Year of construction: 2009, 5-axis CNC machining center – universal – Manufacturer: RÖDERS Machine model: RXP 800 DS Year of manufacture: 2009 TECHNICAL DATA Travels - X-axis (mm): 475 - Y-axis (mm): 600 - Z-axis (mm): 400 - A-axis (swivel table): +/- 95 Cedpfx Aozt Rd Dsgtjhb - C-axis (rotary table): 360 EQUIPMENT FEATURES + RC 4 automation + Chip conveyor

Condition: excellent (used), Year of construction: 2013, operating hours: 20,000 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 1,000 mm, controller manufacturer: Siemens, controller model: 840 D-SL, rotational speed (max.): 16,000 rpm, coolant supply: 50 bar, number of slots in tool magazine: 240, Equipment: chip conveyor, documentation/manual, Heller FP 4000 + SCHULER LoadMaster Compact Year of manufacture: 2013 Control system: Siemens 840 D SL Operating hours: approx. 40,000 h Spindle hours: approx. 20,000 h Spindle: SCU 63 unit, 16,000 1/min, 40 kW, 80 Nm X-axis: 800 mm, Y-axis: 800 mm, Z-axis: 1000 mm 4th axis (table/C-axis): NC rotary table, pallet size 500 x 630 mm 5th axis (head/B-axis): Swivel milling head (swivel range approx. +15° to -105°) Rotary table: 360,000° x 0.001° Chsdpjztmhlefx Agteb Power dynamic: 60 m/min 2x pallets GRM with DIN hole pattern Tool holder: HSK 63 A Wireless measuring probe, manufacturer: RENISHAW Tool magazine: 240 positions (chain type) PMS multiple clamping Chip conveyor for wet machining - Monitoring + collision detection Fast drill breakage detection NC rotary table Special design KMA Interface for extraction system Schuler Loadmaster Compact: LMC 900/FP4000 19x additional pallets with DIN hole pattern Siemens control system Available very soon Loading and disassembly possible

Condition: ready for operation (used), Year of construction: 2014, operating hours: 15,662 h, functionality: fully functional, travel distance X-axis: 620 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 460 mm, controller model: Heidenhain TNC530i, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 620 mm Travel range, Y-axis: 520 mm Travel range, Z-axis: 460 mm C-axis: 360° B-axis: -50° / +110° Rotary table diameter: 500 mm Spindle speed (max.): 12,000 rpm Spindle type: SK40 Number of spindles: 1 Chodpfx Aezr Nmbogteb Number of tool positions in the tool magazine: 30 MACHINE DETAILS Control system: Heidenhain TNC530i Operating hours (see image) Control system operating hours: 38,569 h Machine operating hours: 37,263 h Spindle operating hours: 15,662 h EQUIPMENT Documentation/Manual Speed infinitely adjustable Chip conveyor Scraper-type chip conveyor Workpiece measuring probe Coolant system Compressed air via M-command Heidenhain handwheel Kinematic optimization cycle Note: The machine is sold without tools, vise, and clamping plate.

Condition: good (used), DMG Mori Sauer Lasertec 65 Shape Year of manufacture: 2014 X-axis travel: 650 mm Y-axis travel: 650 mm Z-axis travel: 560 mm Control system: Siemens 840D sl Main spindle: Speed range – main spindle: 20 - 10,000 min/-1 Drive power – main spindle: 13 / 9 kW Max. torque: 83 / 57 Nm Tool interface: HSKA63 DIN 69893 NC rotary table: Table clamping surface: 800 x 650 mm Max. table load: Swiveling range: +/- 120° Rotary range: 360° T-slots: 600 Max. workpiece dimensions: 650 (840) x 500 mm Tool magazine: Number of tool positions: 30 Max. tool weight: 6 kg Max. tool diameter: 80 mm Max. tool diameter with free adjacent tool pocket: 160 mm Max. workpiece length: 315 mm Tool change time (tool to tool): 1.6 sec Chip-to-chip time: 8.0 sec Feed rates: Cjdpfxszqddxo Agtehb Rapid traverse: 40 m/min Feed force: 7/13/10 kN Feed rate: 1 - 40,000 mm/min Total power consumption: 24 kVA Machine weight (approx.): 11.5 t Space requirement (approx.): 4.5 x 3.5 x 2.3 m Documentation Coolant system Electric handwheel Laser head: 100 watts Laser hour meter: 6177 h / 2802 h Machine hour meter: 18703 h / 4738 h

Condition: ready for operation (used), Year of construction: 2002, operating hours: 18,419 h, functionality: fully functional, travel distance X-axis: 630 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, workpiece weight (max.): 350 kg, number of slots in tool magazine: 24, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 630 mm Travel range, Y-axis: 560 mm Travel range, Z-axis: 560 mm Tool magazine slots: 24 Tool holder: SK 40 Rotary range, C-axis: 360° Table clamping surface: 600 x 1,000 mm Table diameter: 600 mm Maximum table load: 350 kg Table weight: 800 kg Number of T-slots: 8 / 1 T-slot width: 14 H12 / 14 H7 T-slot spacing: 63 mm MACHINE DETAILS Number of axes: 5 (3+2) EQUIPMENT Chodpfx Agezpxdwstjb Controlled NC swivel milling head (B-axis) NC rotary table integrated in the fixed table (C-axis)

Condition: good (used), Year of construction: 2012, functionality: fully functional, Hedelius RS 605 K 20, Year of manufacture: 2012, Heidenhain iTNC 530 control unit, Travel range right work area: 420/385/520 mm, Travel range left work area: 1330/650/520 mm, 2-axis NC rotary-swivel table 520 x 420 mm / right, Fixed table 1400 x 600 mm / left, Spindle speed up to 12,000 rpm, Water-cooled milling spindle, Chodpfxjzm Sfcs Agtsb Water-cooled A + C axis / rotary table, Tool shank: SK 40, 30-position tool changer, Coolant pressure: 25 bar, Filter system: 500 liters, Partition for pendulum machining, Chip conveyor.

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, We offer you: Manufacturer: GGF / MAG Type: SPECHT 500 DUO Year of manufacture: 4 x 2011 / 1 x 2014 Control system: Siemens 840D sl Csdpfx Aezl D Hvogtshb Technical data: Travel distances: X-axis: 750 mm Y-axis: 650 mm Z-axis: 560 mm Main spindle: Spindle speed: max. 16,000 rpm Drive power: 40 / 26 kW Table dimensions: Working area diameter: max. A 1,100 / B 710 mm B-axis table plate diameter: 2x 450 mm Load weight: max. 2x 290 kg Tool changer: Tool holder: HSK-A63 Feed rates: Axis speed: max. 60 m/min A total of 5 machines are available. 4 units manufactured in 2011, 1 unit manufactured in 2014. Accessories, tools and clamping devices shown in the images are only included in the scope of delivery if this is noted in the additional information. Subject to changes and errors in the technical data and information, as well as prior sale!

Condition: ready for operation (used), Year of construction: 2007, Make: MIKRON / GF AGIECHARMILLES Type of machine: UCP 600 Vario Year of manufacture: 2007 Control system: Heidenhain iTNC 530 Machine's weight: 7.700 kg Tool holder: HSK-A63 spindel speed: 20.000 1/min x-travel: 600 mm y-travel: 450 mm z-travel: 450 mm Speed range: 20.000 1/min max. Table load: 200 kg Spindle lock: HSK-A63 Max. workpiece weight: 200 kg Codpfozkr Tnex Agtohb Operating time: 57.098 h Chip removal device: Ja Cooling system: Ja Spindle operating time: 3.003 h Tailstock: Nein Overall dimensions: 6.820 × 4.800 × 2.810 mm Traverse Z-axis: 450 mm Table dimensions: Ø 450 mm Number of tools in the magazine: 30 Internal coolant supply: Ja Clamping assembly: HSK-A63 3D Measuring probe: Ja (Blum) : Ja : Nein

Condition: used, Year of construction: 1999, x-travel 630 (875) mm y-travel 500 mm z-travel 500 mm Control Heidenhain TNC 430 turning speeds 20-7.000 U/min feed 0-15.000 mm/min tool change unit 16-fach Chodpfx Aszh N T Hsgtob rapid power traverse in X-and Z direction 15 m/min tool taper SK 40 table surface area 900 x 528 mm max. table load 400 kg spindle diameter in front bearing 55 mm swivellable 0-90 ° quill stroke 75 mm spindle hours 9.546 h total power requirement 12/7,5 kW weight of the machine ca. 4,8 t dimensions of the machine ca. 4 x 3,6 x 2,2 m HERMLE U 630T 3-axis machining centre, built in 1999 The X-axis, with a stroke of 630 mm, can be extended to 875 mm by swivelling the tool changer out of the way. Accessories: Tool holders, see pictures

Condition: like new (used), Year of construction: 2023, operating hours: 100 h, functionality: fully functional, OKUMA MU-6300V (2023.11) – Technical Specifications Model: MU-6300V Simultaneous 5-axis Vertical Machining Center Water-soluble coolant CNC Control: OSP-P500M Display language: Korean Power supply: 220V / 60Hz Operating voltage: 100V CE + EMC compliant Axis Travels X-axis: 925 mm Y-axis: 1,150 mm Z-axis: 600 mm A-axis: +90° / −120° C-axis: 360° continuous Simultaneous 5-axis machining Feed Rates Rapid traverse (X/Y/Z): 50 m/min Cutting feed: 50 m/min A-axis rapid speed: 10,800°/min C-axis rapid speed: 32,400°/min Table diameter: Ø630 mm Table configuration: 6 radial T-slots (18H7) Spindle taper: BT40 (MAS BT40) BIG PLUS dual-contact spindle Spindle speed: 50–15,000 rpm Main motor: 22 kW (10 min) / 18.5 kW (continuous) Spindle oil cooling TAS-S spindle thermal compensation TAS-C ambient thermal compensation Tool Magazine 32-tool Automatic Tool Changer (ATC) Air blow for ATC Taper cleaning air blow Standard tool release system JIS pull studs Measuring System Absolute linear scales on X/Y/Z axes Renishaw TS27R automatic tool setter and tool breakage detection Renishaw RMP60 wireless workpiece probing system Calibration reference tool included Manual measurement function 5-Axis Functions Tool Center Point Control II (TCP/RTCP) Hyper-Surface II Slope Machining Function Inverse Time Feed Manual Tool Center Point Transfer Table Coordinate System Transfer DNC-DT Accuracy & Compensation Five Tuning Kit Geometric error measurement Geometric error compensation Straightness compensation Dynamic displacement compensation Coolant System Through-Spindle Coolant (TSC): 1.5 MPa Through-spindle air blow Standard coolant pump: 390 W Wash-down pump: 800 W Through coolant pump: 1.1 kW Cyclone + sintered bag filtration system Chip Handling Floor-type hinge chip conveyor Conveyor height: 750 mm Right-side chip discharge Safety & Protection Full enclosure with roof Y-axis guide cover CE-compliant door interlock CE + EMC export specification 220–480V transformer KCS machine nameplate Operator Interface 21.5-inch adjustable OSP control panel Smart OSP Servo Navigation AI Servo Navigation SF ECO Suite Plus ECO Power Monitor OSP Software Features 4 GB program storage 10 MB operation buffer 999 tool offsets 200 work coordinate systems Tool Life Management Tool Wear Compensation Real 3D Simulation NC Operating Monitor Simple Load Monitor Tool Damage Detection Programmable Messages Programmable Mirror Image Program Stroke Limit Automatic Program Update Automatic Power-Off Function Digital Twin Functions Chsdpezhgh Iofx Agtsb Digital Twin DMC Kit Hyper Simulation Quick Modelling Interactive MAP (I-MAP) OPC UA for Machine Tools Additional Equipment LED work lights Three-color status indicator Mist collector connection (Ø150 mm) Virus protection system

Condition: used, Year of construction: 2023, operating hours: 100 h, functionality: fully functional, machine/vehicle number: 6LUD00308, travel distance X-axis: 620 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 460 mm, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, rapid traverse Z-axis: 36 m/min, nominal power (apparent): 45 kVA, torque: 180 Nm, controller manufacturer: Siemens, controller model: Sinumerik 840D, workpiece height (max.): 430 mm, workpiece diameter (max.): 580 mm, workpiece weight (max.): 300 kg, total height: 3,300 mm, total length: 3,225 mm, total width: 2,256 mm, table load: 300 kg, rotary table diameter: 500 mm, overall weight: 8,500 kg, spindle speed (min.): 5 rpm, spindle speed (max.): 15,000 rpm, operating hours of spindle: 40 h, coolant supply: 42 bar, distance table center to spindle nose: 150 mm, spindle motor power: 3,400 W, number of spindles: 1, number of slots in tool magazine: 60, tool length: 250 mm, tool diameter: 127 mm, tool weight: 7,000 g, coolant supply through spindle: 42 bar, swivel angle B-axis (min.): -50 °, swivel angle B-axis (max.): 110 °, swivel angle C-axis (max.): 360 °, number of axes: 5, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, An Era Ends: Our Last Siemens 840D on the LU 620 With the introduction of the new Siemens SINUMERIK ONE, the proven 840D control system is now available in combination with our LU 620 just once. Demonstration Machine at Used Machine Price Chodpjzdf Hvofx Agteb Equipment of the Axon LU 620 - Siemens 840D – 5-Axis Simultaneous - Heidenhain glass scales on all 5 axes - Kinematic Optimizer - 15,000 rpm Direct Drive spindle with 34 kW and max. 180 Nm (25% duty cycle) - Production Package I with 42 bar through-spindle coolant (IKZ) - Air through spindle - Media supply through the center of the table - Automatic workpiece measurement Renishaw OMP 40 - Blum NT A-3 Split laser tool breakage detection - Paper band filter system - Spindle ring flush system - Automatic side door - 60-tool magazine – SK40 - Scraper belt chip conveyor - Chip rinsing system - Extraction unit

Condition: as good as new (ex-display), Year of construction: 2025, operating hours: 50 h, functionality: fully functional, machine/vehicle number: 6LUD-321, travel distance X-axis: 620 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 460 mm, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, rapid traverse Z-axis: 36 m/min, nominal power (apparent): 45 kVA, torque: 180 Nm, controller manufacturer: Siemens, controller model: Sinumerik ONE, workpiece height (max.): 430 mm, workpiece diameter (max.): 580 mm, workpiece weight (max.): 300 kg, total height: 3,300 mm, total length: 3,225 mm, total width: 2,256 mm, table load: 300 kg, rotary table diameter: 500 mm, overall weight: 8,500 kg, spindle speed (min.): 5 rpm, spindle speed (max.): 15,000 rpm, operating hours of spindle: 40 h, coolant supply: 42 bar, distance table center to spindle nose: 150 mm, spindle motor power: 3,400 W, number of spindles: 1, number of slots in tool magazine: 60, tool length: 250 mm, tool diameter: 127 mm, tool weight: 7,000 g, coolant supply through spindle: 42 bar, swivel angle B-axis (min.): -50 °, swivel angle B-axis (max.): 110 °, swivel angle C-axis (max.): 360 °, number of axes: 5, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Demonstration machine Axon LU 620 features: - Siemens Sinumerik ONE - 5-axis simultaneous machining - Heidenhain glass scales in all 5 axes - Kinematic Optimizer - 15,000 rpm direct drive spindle with 34 kW and max. 180 Nm (25% duty cycle) - Production Package I with 42 bar internal coolant system - Air supply through the spindle - Media supply through the center of the table - Automatic workpiece measurement system Renishaw OMP 40 - Laser tool breakage detection system Blum NT A-3 Split - Paper band filter system - Ring flushing system on the spindle - Automatic side door - 60 magazine positions - SK40 Chedszdddgepfx Agtsb - Drag chain chip conveyor - Chip flushing - Dust extraction system

Condition: excellent (used), Year of construction: 2021, operating hours: 11,514 h, functionality: fully functional, machine/vehicle number: 20210202, travel distance X-axis: 670 mm, travel distance Y-axis: 820 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain TNC 640, spindle speed (max.): 18,000 rpm, TECHNICAL DETAILS Travel X-axis: 670 mm Travel Y-axis: 820 mm Travel Z-axis: 600 mm Spindle speed (min.): 18,000 rpm Spindle operating hours: 11,514 h Coolant supply: 40 bar MACHINE DETAILS Chsdpezb A Eksfx Agtsb Apparent power rating: 90 kVA Control manufacturer: Heidenhain Control model: TNC 640 Total weight: 20,000 kg Input voltage: 400 V Full load current: 125 A Max. current load: 200 A Short-circuit resistance: 25 kA Voltage: 400.50 V/Hz Net weight: 20,000 kg Machine number: 20210202 EQUIPMENT Documentation/Manual Chip conveyor

Condition: ready for operation (used), Year of construction: 2005, Make: KUNZMANN Type of machine: WF 650 Year of manufacture: 2005 Control system: HEIDENHAIN iTNC 530 Machine's weight: 4.000 kg Tool holder: SK40 x-travel: 650 mm y-travel: 500 mm z-travel: 450 mm Speed range: 10.000 U/min Cjdpszawibsfx Agtohb max. Table load: 350 kg Overall dimensions: 3,0 x 2,5 x 2,6 m Table dimensions: 900 x 500 mm

Condition: new, Year of construction: 2026, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, feed length X-axis: 650 mm, feed length Y-axis: 500 mm, feed length Z-axis: 500 mm, controller manufacturer: Siemens, controller model: Sinmerik One, workpiece height (max.): 500 mm, workpiece diameter (max.): 675 mm, workpiece weight (max.): 500 kg, total height: 3,610 mm, total length: 3,970 mm, total width: 3,523 mm, table load: 500 kg, rotary table diameter: 600 mm, rotational speed (max.): 14,000 rpm, overall weight: 11,800 kg, spindle speed (max.): 14,000 rpm, coolant supply: 15 bar, distance table to spindle center: 175 mm, distance table center to spindle nose: 400 mm, spindle motor power: 37,000 W, number of spindles: 1, number of slots in tool magazine: 30, tool length: 300 mm, tool diameter: 80 mm, tool weight: 8 g, Equipment: chip conveyor, documentation/manual, HWACHEON D2-5AX Anniversary Model – The intelligent entry point into 5-axis machining The new HWACHEON D2-5AX was specifically developed to enable companies to make an economical and simultaneously high-performance entry into modern 5-axis machining. As the official anniversary model from HWACHEON, it combines the highest manufacturing quality, modern control technology and maximum flexibility for a wide range of applications. Whether it's single-part production, toolmaking, prototype construction or automated series production – the D2-5AX impresses with its high precision, reliable processes and compact design, while still offering a generous working area. With travel distances of 650 x 500 x 500 mm and a powerful rotary table with a diameter of 600 mm, complex HWACHEON D2-5AX 5-axis machining centers can be accommodated. New machine with state-of-the-art HWACHEON technology The HWACHEON D2-5AX is a compact and powerful 5-axis machining center for modern manufacturing requirements. It is a new machine that impresses with its precision, stability and economy. 5-axis machining allows complex workpieces to be manufactured in a single setup. This reduces setup times, improves accuracy and increases productivity sustainably. The standard equipment includes an automatic BLUM tool measurement ZX Speed and a BLUM workpiece measurement system. This minimizes setup times and ensures a high level of process reliability. Technical highlights • Travel distances X/Y/Z: 650 / 500 / 500 mm • Rotary table Ø 600 mm • Powerful 37 kW main spindle drive • 30-tool magazine • Automatic tool measurement BLUM ZX Speed • Automatic workpiece measurement BLUM • Compact and stable machine construction • High dynamics and precision • Suitable for single parts, small series and series production • Optimized for modern manufacturing requirements Control options The HWACHEON D2-5AX is available with: • Siemens Sinumerik ONE for maximum networking and digitization • Fanuc 31i-B5+ for high reliability and comfortable operation in 5-axis mode • Also available as an economical Fanuc 4+1-axis version as an option Your advantages • New machine with state-of-the-art HWACHEON technology • Economical entry into 5-axis machining • Complete machining of complex workpieces in a single setup • Reduced setup times and increased productivity • High manufacturing quality and process reliability • Future-proof control technology • Ideal for training centers, toolmaking, contract manufacturers and production companies The HWACHEON D2-5AX offers a strong combination of precision, performance and economy. This makes it the ideal solution for companies that want to make their manufacturing more efficient, more precise and more future-proof. Cedpfx Aozaql Njgtehb Further information, technical data and individual equipment options are available upon request. Contact: Benjamin Hoffmann ACROLOC Werkzeugmaschinen GmbH

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 460 mm, controller model: HEIDENHAIN ITNC 530, spindle speed (max.): 28,000 rpm, TECHNICAL DETAILS Number of axes: 5 Travel range, X-axis: 450 mm Travel range, Y-axis: 650 mm Travel range, Z-axis: 460 mm Swivel angle (A-axis): -10 / +110 ° Tool magazine Number of positions: 60 Maximum tool diameter: 80 mm Maximum tool length: 250 mm Maximum tool weight: 6 kg Tool holder and spindle Tool holder: HSK 63 Minimum spindle speed: 2 rpm Maximum spindle speed: 28,000 rpm MACHINE DETAILS Operating time according to counter: 94,552 h Operating hours according to counter: 24,219 h Connection voltage: 400 V Spindle power: 38 / 28 kW Total power consumption: 70 kVA Dimensions & Weight Chjdpfxezaqhqe Agtsb Dimensions (L x W x H): 3,210 x 2,930 x 2,900 mm Machine weight: approx. 9,500 kg

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, X-axis: 650 mm Y-axis: 325 mm Z-axis: 350 mm B-axis: 130 degrees C-axis: 360 degrees Spindle speed: 30,000 rpm Spindle interface: HSK 50 Tool changer: 60 positions Control system: Makino Professional 5 Includes hybrid length measuring system Includes measuring probe Includes approximately 60 HSK 50 tool holders (MST + Rego Fix) Csdpfxezapp He Agtohb Spindle has been replaced Ball screws for X and Y axes replaced in 2024 Machine currently has approximately 32,000 spindle hours and is still in active production Available from approximately week 46/2026 An inspection with the machine powered on can be arranged at any time.

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 172822005, travel distance X-axis: 600 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, controller model: Heidenhain TNC530i, spindle speed (max.): 18,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 600 mm Travel range, Y-axis: 500 mm Travel range, Z-axis: 500 mm Swivel axis A: ±120° Rotary axis C: 360° Chsdpfx Agey S Ua Njteb Rotary table diameter: 500 mm Spindle speed (max.): 18,000 rpm Rapid traverse rate, X-axis: 36 m/min Rapid traverse rate, Y-axis: 36 m/min Rapid traverse rate, Z-axis: 36 m/min Number of tool slots in the tool magazine: 24 Positioning accuracy: 0.01 / 300 mm Repeatability: ±0.01 mm MACHINE DETAILS Control system: Heidenhain TNC530i Coolant supply: 20 bar Dimensions & Weight Dimensions (L x W x H): 3,015 x 5,050 x 3,000 mm Total weight: 9,000 kg Type of input current: Three-phase Power: 60 kVA Frequency: 50 Hz Rated voltage: 400 V Number of phases: 3 + PE Rated current at full load: 100 A Short-circuit strength: 25 kA Maximum load current: 200 A Fuse protection / rated current: 80 A Operating hours Spindle hours: 6,940 h Program runtime: 7,686 h Machine operating hours: 17,193 h Control system operating hours: 19,880 h EQUIPMENT Chip conveyor

Condition: ready for operation (used), Year of construction: 2001, operating hours: 18,391 h, functionality: fully functional, machine/vehicle number: 11160000853, travel distance X-axis: 600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller manufacturer: Heidenhain, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-Axis Travel: 600 mm Y-Axis Travel: 700 mm Z-Axis Travel: 600 mm Maximum Spindle Speed: 12,000 rpm X-Axis Feed Rate: 20 – 15,000 mm/min Y-Axis Feed Rate: 20 – 15,000 mm/min Z-Axis Feed Rate: 20 – 15,000 mm/min Rapid Traverse X-Axis: 40 m/min Rapid Traverse Y-Axis: 40 m/min Rapid Traverse Z-Axis: 40 m/min Linear Scale Resolution X-Axis: 0.001 mm Linear Scale Resolution Y-Axis: 0.001 mm Linear Scale Resolution Z-Axis: 0.001 mm Input Increment X-Axis: 0.001 mm Input Increment Y-Axis: 0.001 mm Input Increment Z-Axis: 0.001 mm Positioning Accuracy X-Axis: 0.01 mm Positioning Accuracy Y-Axis: 0.01 mm Positioning Accuracy Z-Axis: 0.01 mm Tool Holder: SK 40 NC Rotary Table Clamping Surface Diameter: 630 mm Max. Table Rotation Speed: 10.7 rpm Table Feed Rate: 3,600 /min Table Scale Resolution: 0.001 MACHINE DETAILS Control Manufacturer: Heidenhain Recorded Spindle Hours: 18,391 h Operating Voltage: 400 V Cjdpfxsy Ni Aaj Agtshb Frequency: 50 Hz Rated Current: 80 A Connected Load: 44 kVA Dimensions & Weight Dimensions (L x W x H): 5,500 x 4,500 x 2,500 mm Machine Weight: 10,000 kg EQUIPMENT 60-station tool changer Chip conveyor Cooling system

Condition: ready for operation (used), Year of construction: 2017, operating hours: 11,206 h, functionality: fully functional, machine/vehicle number: 20170708, travel distance X-axis: 670 mm, travel distance Y-axis: 830 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain 530, spindle speed (max.): 18,000 rpm, The machine underwent maintenance in April 2025, during which the rotary union was replaced at a cost of €8,600! TECHNICAL DETAILS Travel X-axis: 670 mm Travel Y-axis: 830 mm Travel Z-axis: 600 mm Swivel range A-/C-axis: approx. -100 to +120° / -120 to +120° C-axis rotation range: 360° Table diameter: 800 mm T-slots (number x width): 9 x 90 mm Maximum table load: 1,200 kg Kessler spindle: 18,000 rpm Maximum tool length: 300 mm Maximum tool diameter: 75 mm Maximum tool diameter (with adjacent stations empty): 125 mm Maximum tool weight: 7 kg Tool change time: 3 s Rapid traverse X/Y/Z: 60 m/min Max. A-axis speed: 50 rpm Max. C-axis speed: 100 rpm Acceleration X/Y/Z: 7 m/s² Repeatability: 0.004 mm Positioning accuracy: 0.008 mm Rotational drive system: Integrated direct drives Tool holder: HSK 63 Tool stations: 96 Csdpfoy I Tvnsx Agtehb MACHINE DETAILS Control: Heidenhain 530 Dimensions & Weight Weight: 19,000 kg Layout with accessories (L x W x H): 4,150 x 5,000 x 3,500 mm Tank capacity: max. 330 l Total coolant capacity: max. 425 l Operating Hours Control on-time: 20,248 h Machine on-time: 19,424 h Program run: 11,331 h Spindle hours: 11,206 h EQUIPMENT Spindle chiller Kessler swing, 800 mm turning diameter, fully utilizable with zero-point clamping system Note: The touch probe is not included in the offer. The holders, however, are part of the offer.
