Condition: good (used), Year of construction: 2001, functionality: fully functional, grinding length: 450 mm, grinding width: 150 mm, total height: 2,129 mm, total length: 1,940 mm, total width: 1,317 mm, workpiece weight (max.): 120 kg, grinding height: 510 mm, grinding wheel diameter: 205 mm, distance table to spindle center: 510 mm, table length: 510 mm, table load: 120 kg, type of input current: three-phase, table width: 150 mm, overall weight: 1,250 kg, grinding spindle motor power: 1,500 W, travel distance X-axis: 530 mm, travel distance Y-axis: 175 mm, rotational speed (max.): 2,400 rpm, grinding spindle speed: 2,400 rpm, input voltage: 400 V, Equipment: rotational speed infinitely variable, 2001 Okamoto ACC-450DXA Surface Grinder | 450 x 150mm Fjdpfx Aez Rqk Rjhdjpn Used 2001 Okamoto ACC-450DXA Hydraulic Surface Grinding Machine for Sale – 450 x 150mm Grinding Capacity – Automatic Grinding Cycle – Spare Grinding Wheels Included Manufacturer: Okamoto Model: ACC-450DXA Machine Type: Hydraulic Surface Grinder Year: 2001 Condition: Working Well Includes: Coolant Equipment Magnetic Chuck Cross Feed Digital Display Vertical Digital Display Wheel Guard Spare Grinding Wheels Machine Description Used 2001 Okamoto ACC-450DXA precision surface grinder available for sale. The Okamoto ACC-450DXA is a compact, high-quality hydraulic surface grinding machine designed for accurate flat and form grinding applications in precision engineering, toolrooms, mould and die shops and general manufacturing environments. The machine provides an approximate 450 x 150mm grindable surface, with 530mm longitudinal table travel and 175mm cross travel, making it particularly suitable for precision grinding of small and medium-sized components. The DXA version features an automatic grinding cycle, combining hydraulic table movement with controlled crossfeed and vertical grinding functions to provide repeatable production grinding while remaining straightforward to set and operate. This machine is supplied with a selection of spare grinding wheels. Main Specifications Manufacturer: Okamoto Model: ACC-450DXA Year: 2001 Machine Type: Precision Hydraulic Surface Grinder / Surface Grinding Machine Grinding Capacity Maximum Grindable Surface: Approx. 450 x 150mm Table Working Area: Approx. 510 x 150mm Longitudinal Travel: Approx. 530mm Cross Travel: Approx. 175mm Distance from Grinding Wheel to Table: Approx. 60–510mm Maximum Table Load: Approx. 120kg The generous longitudinal movement relative to the 450mm grinding length allows the wheel to clear the component during the grinding cycle. Grinding Wheel & Spindle Grinding Wheel Diameter: Approx. 205mm Grinding Wheel Peripheral Speed: Approx. 2,400m/min Grinding Spindle Motor: Approx. 1.5kW The spindle arrangement is designed for precision surface grinding where good finish, flatness and dimensional accuracy are required. Additional Drive Motors Hydraulic Pump Motor: Approx. 0.75kW Crossfeed Motor: Approx. 0.75kW Grinding Head Up/Down Motor: Approx. 0.4kW DXA Automatic Grinding Cycle The ACC-450DXA version is designed to provide an automatic grinding cycle, making it suitable for repetitive precision surface grinding operations. The DX-series design incorporates features aimed at both rough and finish grinding, including: Automatic grinding-cycle capability Hydraulic longitudinal table movement Powered crossfeed Powered vertical grinding-head movement Coarse and fine vertical feed Precision feed adjustment Robust saddle-type construction Hand-finished precision guideways Automatic lubrication system These features make the ACC-450DXA suitable for both one-off toolroom work and repetitive component grinding. Approximate Machine Dimensions Overall Length: Approx. 1,940mm Overall Width: Approx. 1,317mm Overall Height: Approx. 2,129mm Machine Weight: Approx. 1,250kg

Condition: excellent (used), Year of construction: 2018, Geibel & Hotz FS 640 SC Surface grinding machine Geibel & Hotz FS 640 SC with BR control, manufactured in 2018, in SUPER condition. CE compliant!! The machine comes from the testing department of an engineering company. Technical data: Year of manufacture: 2018 Brand: G+H SCHLEIFTECHNIK Model: FS 640 SD Clamping area: 600 x 400 x 375 mm Table load max.: 600 kg Distance table - spindle center min./max.: Fedpoz Rnh Tofx Ahdopn 140-525 mm Grinding wheel dimensions: 300 x 50 x 76.2 mm Length x Width x Height: 3000 x 2800 x 2500 mm Motor power: 3.7 kW Weight: 2300 kg About the machine: Offered is a surface grinding machine Geibel & Hotz FS 640 SC with BR control. This universal surface grinding machine is in very good original condition. It comes from a company where it was only used for testing purposes. It features a very easy-to-use control system. A grinding travel of 600 mm in the longitudinal axis and a transverse travel of 400 mm make it suitable for toolmaking, jig and fixture construction, and small-series production. A comprehensive standard equipment and the easy operation of the machine characterize this series. The stable design of the spindle head and the guide principle with double V-guides in the longitudinal and transverse axes guarantee lasting precision. The intuitive operation of the controls simplifies operation and significantly increases productivity. The guides are regularly lubricated by the central lubrication system. The Geibel & Hotz FS 640 SC with BR control has been mechanically and electrically inspected by us. Take the opportunity to inspect and test the Geibel & Hotz FS 640 SC on site under power. You can find more surface grinding machines from well-known manufacturers on our website.

Condition: excellent (used), Year of construction: 2009, Geibel & Hotz FS 840 SD Surface grinding machine Geibel & Hotz FS 840 SD with B&R control, manufactured in 2009, in SUPER condition. CE compliant!! This machine comes from the training workshop of a renowned German mechanical engineering company. Technical data: Year of manufacture 2009 Max. grinding area (mm) 800 x 400 x 375 Travel in X (mm) 800 Travel in Y (mm) 400 Travel in Z (mm) 375 Clamping surface, magnetic (mm) 800 x 400 Grinding wheel (mm) 300 x 50 x 76.2 Power of grinding spindle motor (kW) 3.7 Grinding spindle speed (rpm) 1400 Manufacturer Geibel & Hotz Year of manufacture 2008 Control system B&R RPS Type of control system Cycle-controlled Total power consumption (kW) 12 kW Fedpfx Ahjz Rmufjdspn Space requirement (mm) 3600 x 2750 x 2470 Weight (kg) 2700 About the machine: We offer a Geibel & Hotz FS 840 SD surface grinding machine with B&R control. This universal surface grinding machine is in very good, original condition. It comes from a company where it was only used to a small extent for training purposes. It has a very easy-to-use control system. A grinding travel of 800 mm in the longitudinal axis and a transverse travel of 400 mm make it suitable for toolmaking, jig and fixture construction, and small-batch production. The rich standard equipment and the simple operation of the machine are characteristic of this series. The stable design of the spindle head and the guide system with double V-guides in the longitudinal and transverse axes guarantee lasting precision. The intuitive operation of the control elements simplifies operation and significantly increases productivity. The guides are regularly lubricated by the central lubrication system. The Geibel & Hotz FS 840 SD has been mechanically and electrically inspected by us. Take advantage of the opportunity to inspect and test the Geibel & Hotz FS 840 SD on site under power. You can find more surface grinding machines from well-known manufacturers on our website.

Condition: used, Year of construction: 1990, grinding length 600 mm grinding width 375 mm workpiece height 325 mm grinding height 325 mm table load max. 300 kg table longitudinal travel max. 650 mm table speeds 1 - 30 m/min grinding spindle speed 1440 / 2900 U/min grinding wheel size 300 x 50 x 76,2 mm Fpjdoz N Hvajpfx Ahdsn grinding spindle drive 3,7 / 4,7 kW vertical feed grinding spindle max. 180 mm/min. cross travel 350 mm cross adjustment 1 - 40 mm rapid traverse cross 1200 mm/min total power requirement 9 kW weight of the machine ca. 3,3 t dimensions of machine L x W x H 2,75 x 2,10 x 2,05 m - with autom. positioning - Accessories: magnetic plate 600 x 350 mm, grinding wheel with flange, wheel trueing attachment, DRO on Y-and Z-axis, 1 grinding wheel and various flanges separate, balancing scale, wet grinding attachment

Condition: used, Year of construction: 2006, machine/vehicle number: 65126, Grinding area: 630x350 mm, grinding wheel diameter: 350 mm, magnetic clamping plate, size: 600x300 mm, with coolant system, fleece filter system and automatic depth feed. Fpsdpfx Ajz Nhqxehden

Condition: used, functionality: fully functional, Coolant system manufactured by JUNG, type HF 50. Fsdsz Ndp Aepfx Ahdepn

Condition: good (used), Year of construction: 1992, overall weight: 2,500 kg, Geibel & Hotz FS 635 Surface Grinder Fodpfez Ibd Iox Ahdepn Magnetic table 600 x 350 mm Enclosed housing for CE compliance Vertical automatic feed system (SA) Automatic lubrication Coolant tank X-axis travel: 650 mm Y-axis travel: 525 mm Z-axis travel: 350 mm Table length: 600 mm Table width: 350 mm

Condition: used, Year of construction: 1981, functionality: fully functional, Surface Grinding Machine JONES & SHIPMAN 540 L Travel X: 406 mm Travel Y: 470 mm Travel Z: 168 mm Year of construction: 1981 Magnetic chuck dimensions: Length 355 mm x Width 150 mm Grinding wheel diameter: Ø 180 mm Spindle motor: 2 speeds motor Motorised raising/lowering Equipped with: Lubricant tank Fsdsz H Rzmepfx Ahdopn Voltage: 220 V Tri Dimensions (L x W x H): 1300 x 1300 x 1900 mm Total width with lubricant tank: 2000 mm Weight: approx 1,2 T

Condition: used, functionality: fully functional, grinding spindle motor power: 4 W, input voltage: 380 V, Universal surface grinding machine with a horizontal grinding spindle and cross table. Designed for precision grinding of flat surfaces using the periphery of the grinding wheel. Suitable for grinding various metal components. Manufacturer: “Krasny Borets”, USSR Model: 3E711V Table size: 630 × 200 mm Grinding wheel: Ø250 × 40 × 76 mm Fpsdpjz Hi Skjfx Ahdon Spindle motor power: 4 kW Power supply: 380 V Complete with hydraulic unit GS-3E711V-1-UHL4

Condition: used, Year of construction: 2001, Grinding length 600 mm Grinding width 400 mm Workpiece height 375 mm Psc Ha N Ssz D Itnev Dsgt Longitudinal travel of the table max. 660 mm Fpsdpfjz Hduasx Ahdsn Transverse travel of the table max. 410 mm Distance from spindle center to table max. 525 mm Table speed 2 - 28 m/min Table load max. 400 kg Intermittent transverse feed of the table 3 - 40 mm Rapid traverse in the transverse direction 1 m/min Grinding wheel dimensions max. 300 x 50 x 76.2 mm Total power requirement 8 kW Machine weight approx. 2.1 t Machine dimensions L x W x H 2.75 x 1.7 x 2.42 m

Condition: used, functionality: fully functional, KNUTH HFS 4080VC Surface Grinder Work table dimensions: 406 × 813 mm Max. longitudinal travel: 910 mm Distance between spindle center and table: 580 mm Hydraulic table feed: 7–25 m/min Automatic transverse feed: 0.1–8 mm Fjdsz E Nylopfx Ahdopn Rapid transverse travel: 990 mm/min Y-axis handwheel graduation: 0.02 mm Rapid vertical travel: 460 mm/min Z-axis handwheel graduation: 0.005 mm Grinding wheel dimensions: 350 × 40 × 127 mm Grinding wheel motor: 5.5 kW Hydraulic pump motor: 2.2 kW Coolant pump motor: 0.125 kW

Condition: good (used), Year of construction: 2004, functionality: fully functional, grinding length: 400 mm, grinding width: 210 mm, automatic infeed electro magnet plate dressing device Fodpfx Ahez Entkodjpn coolant device Technische Daten / technical details: max. Schleiflänge / max. grinding length 400 mm max. Schleifbreite / max. grinding width 210 mm X-Achse, Tischlängshub / X-axis table longitudinal travel 420 mm Z-Achse, Querweg / Z-axis cross travel 190 mm Schleifscheibenabmessungen / grinding wheel dimensions 225x25x51 mm Anschlussleistung / drive capacity 7 kW Gewicht ca. / weight ca. 1200 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, ABA precision surface grinding machine with accessories, machine used very little. Magnet size: 400x250 mm Infinitely adjustable grinding spindle Grinding wheel dressing device (Diaform) Automatic feed Feed rate infinitely adjustable Fedpfxjz Ehmdj Ahdopn Inch mode Coolant system with belt filter system Dust extraction for wheel dressing device Balancing device, centering arbor, Wheel removal device Tool cabinet with various new grinding wheels Operating manual.

Condition: used, Year of construction: 2000, grinding length 600 mm grinding width 400 mm workpiece height 375 mm table adjustment - longitudinal max. 660 mm table cross movement max. 410 mm distance spindle center to table max. 525 mm table speeds 2 - 28 m/min table load max. 400 kg cross feed of table intermittent 3 - 40 mm rapid traverse cross 1 m/min Fedpfx Aoz D Itnjhdopn grinding wheel size max. 300 x 50 x 76,2 mm total power requirement 8 kW weight of the machine ca. 2,1 t dimensions of machine L x W x H 2,75 x 1,7 x 2,42 m Accessories: magnetic plate 600 x 400 mm, grinding wheel with flange, 1 flange separate, DRO on Y-axis (vertical), wheel trueing attachment, balancing scale, wet grinding attachment

Condition: new, Year of construction: 2023, functionality: fully functional, total height: 2,700 mm, total length: 2,900 mm, total width: 3,350 mm, overall weight: 6,500 kg, travel distance X-axis: 800 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 600 mm, ELB smartLine microcut SURFACE GRINDER (MACHINE IN NEARLY NEW CONDITION) TECHNICAL SPECIFICATIONS Brand: ELB Model: smartline BD6 ZRT XC Year: 2023 X: 600 mm Z: 600 mm Y height: 500 mm (+/- 200 mm) Table load 800 mm (Without magnetic table) Maximum longitudinal travel: 800 mm Maximum transverse travel: 600 mm Grinding wheel outer diameter: 400 mm Grinding wheel width: 100 mm Coolant filtration unit Automatic grinding wheel dressing Magnetic chuck PRICE AND FURTHER INFORMATION AVAILABLE UPON REQUEST Fpsdpsz D D Dpjfx Ahdjn (CNC, SIEMENS, HASS, LAGUN, FAGOR, CINCINNATI, HEIDENHAIN, MACHINING, PINACHO, MORISEIKI, MILLING MACHINE, LATHE, GRINDER, BORING MACHINE, PRESS, LASER, SHEAR)

Condition: good (used), grinding wheel diameter: 300 mm, type of input current: three-phase, grinding wheel width: 40 mm, overall weight: 1,850 kg, rotational speed (max.): 400 rpm, External cylindrical grinding machine Fsdpfjz Dv E Eex Ahdepn Brand: GER Model: RHL-450 Fagor dimension display Grinding wheel dimensions: 300x40mm Drive: Hydraulic Distance between centers: 450mm Center height: 130mm Maximum workpiece diameter: 250-255mm Workpiece spindle speeds: 55-400 rpm Motor: 3Hp Weight: 1850kg

Condition: good (used), Year of construction: 2008, 1 used surface grinding machine Manufacturer: STÖCKEL Type: FX 60/30 SPS Year of manufacture: 2008 Grinding area: approx. 600 × 300 mm Magnetic chuck: approx. 600 × 250 mm Speed: 1900 rpm Fsdpfx Ahez Dkuuodspn Grinding height: 400 mm Drive power: 9 kW Operating voltage: 400 V / 50 Hz Table load: 250 kg Control: PLC Weight: 3000 kg

Condition: repair required (used), Year of construction: 1989, functionality: limited functionality, machine/vehicle number: BO 15263, total width: 2,300 mm, total length: 2,300 mm, total height: 1,700 mm, travel distance X-axis: 500 mm, travel distance Z-axis: 200 mm, grinding diameter: 150 mm, grinding length: 500 mm, input frequency: 50 Hz, Equipment: documentation/manual, J&S 1096 grinder: issues with the CNC control system. Fjdsz Dgphjpfx Ahdopn

Condition: like new (used), Year of construction: 2023, functionality: fully functional, total height: 2,650 mm, total length: 4,100 mm, total width: 2,420 mm, feed length X-axis: 1,190 mm, feed length Z-axis: 390 mm, workpiece weight (max.): 525 kg, feed rate X-axis: 30,000 m/min, feed rate Y-axis: 1,600 m/min, feed rate Z-axis: 2,000 m/min, table speed: 30,000 mm/min, spindle speed (max.): 4,000 rpm, overall weight: 5,400 kg, grinding spindle motor power: 37 W, travel distance X-axis: 1,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 400 mm, Equipment: documentation/manual, rotational speed infinitely variable, ELB Smartline, fully functional, available for sale due to business closure. Please refer to the machine description for technical details. Fpjdpfez Dabwsx Ahdon Additionally, oil mist separator, original packaging.

Condition: ready for operation (used), functionality: fully functional, Grinding length: 600 mm Grinding width: 250 mm Workpiece height: 450 mm Electromagnetic clamping table: 600 x 250 mm Grinding wheel diameter: 300 x 50 x 76.2 mm Spindle speed - stepless: 800 - 4200 rpm Total power requirement: 4 kW Fpsdpfx Aez Ayrvohdsn Machine weight: approx. 2.9 t

Condition: ready for operation (used), functionality: fully functional, grinding length, max. 600 mm Table clamping surface 600 x 200 mm Fedpfsz Ayqxsx Ahdepn Magnet dimensions 500 x 200 mm Maximum distance between table surface and center of the grinding spindle 495 mm Grinding wheel dimensions (D x b x d) 250 x 25 x 51 mm Grinding spindle drive 5.5 kW

Condition: ready for operation (used), functionality: fully functional, grinding length 500 mm Fpodpfxoz Aynwj Ahdsn grinding width 200 mm workpiece height 250 mm table surface 600 x 200 mm grinding wheel dimensions 225 x 20 x 51 mm grinding spindle drive 1.5 kW table feed 1 - 20 m/min total power requirement 2.6 kW machine weight approx. 2 t machine dimensions approx. 2.6 x 1.6 x 1.8 m

Condition: excellent (used), Year of construction: 1989, Jung JF 520 Jung JF 520 surface grinding machine, manufactured in 1989 / 2019, mechanically overhauled, very good original condition. The machine comes from the technical department of a renowned German die-casting company. Technical data: Year of manufacture 1989 / 2019 Technical data Clamping area (L x W in mm) 600 x 200 Oversize grinding area (L x W in mm) 600 x 250 Magnet size max. mm 500 x 200 Grinding wheel dimensions max. mm 225 (250) x 25 x 51 Distance table/spindle center mm Max. 400 Table longitudinal feed, oscillating m/min 1 – 20 Creep feed mm/min 0 – 500 Grinding spindle drive, speed rpm 800 – 4200 Power kW (with creep feed) 1.6 – 2.2 Machine weight approx.: 2.0 t Accessories and equipment: Magnet Coolant system Fodpfxjz Agz Re Ahdopn Machine feet Grinding wheel About the machine: We offer a Jung JF 520 surface grinding machine, manufactured in 1989 / 2019, in very good condition. The machine is, of course, fully functional and has approximately 250 operating hours since its overhaul. All slides run very smoothly and evenly. Even at high speeds, the Jung runs very quietly. This newer generation of surface grinding machines is very user-friendly, and surfaces with a low Ra value can be produced. Take advantage of the opportunity to inspect this machine on site under power and see for yourself the condition of the machine. Video: Jung JF 520 You can find more surface grinding machines from well-known manufacturers on our website.

Condition: used, Year of construction: 2014, Surface grinding machine, Geibel + Hotz, type FS 420 SD. Fjdpfx Aoz Affushdjpn

Condition: good (used), Year of construction: 2007, functionality: fully functional, Technical details grinding length 600 mm Fpsdpszzw Rtjfx Ahden grinding width 400 mm workpiece height 375 mm workpiece weight 400 kg table longitudinal travel 650 mm table speeds 2 - 28 m/min table cross travel 400 mm speed 100 - 1000 mm/min grinding wheel size 300 x 50 x 76,2 mm grinding spindle drive 3,7 kW peripheral speed 10 - 32 m/sec total power requirement 11 kW weight of the machine ca. 2,1 t dimensions of the machine ca. 2,95 x 2,65 x 2,47 m Additional information CNC Precision Surface Grinding Machine Table drive: hydraulic Cross-axis drive: electromechanical Electromagnetic plate: 600 x 400 mm with holding force control and automatic magnetic pole reversal for demagnetizing Features: Partially enclosed, open-topped loading compartment with a sliding door Cleaning kit for cleaning the work area with hand-held impulse nozzle Holder for prism arm with single-point diamond, MK 0 Grinding spindle speed control with V-constant controller Universal paper filter unit UPF 100, tank capacity approx. 280 liters Coolant pump: 20 liters/minute at 1.5 bar Machine light Without grinding wheels and flanges.
