GP Trading & Services GmbH

Condition: ready for operation (used), Year of construction: 1977, Immediately available ex location: Universal profile steel shear with punch station Peddinghaus Type 210 / 16 Year of manufacture: 1977 Press force: 60 t Punch: 27 x 19 mm Round steel: 50 mm Square: 45 x 45 mm Flat steel: 150 x 19 mm Punching: 27 x 19 mm L profile 90°: 130 x 13 mm L profile 45°: 100 x 11 mm T profile 90°: 130 x 15 mm T profile 45°: 100 x 11 mm Drive: 5.5 kW Weight: 3 t Many punching tools included Priced at €1,750 plus VAT ex location Fgsdpjx E Rvasfx Aduok

Condition: excellent (used), Year of construction: 2017, 1 used hydraulic 5-station combined high-performance profile steel shear Technical Specifications: Punching Station Punching force: 45 t Cutting capacity (steel 400 N/mm²): Ø 22 x 15 mm Ø 38 x 8 mm Fgodpjxz Dn Eefx Adujk Throat depth: 175 mm Max. stroke: 50 mm Number of strokes: 20 / min Working height: 955 mm Notching Station Max. material thickness: 8 mm Max. notch width: 35 mm Max. notch depth: 75 mm V-notch tool size: 100 x 100 x 8 mm Flat Steel Shear Max. material width x thickness: 200 x 15 mm 300 x 12 mm Blade length: 316 mm Mitre cut 45° (leg length x thickness): 80 x 10 mm Working height: 955 mm Bar Steel Shear Capacity round material: 30 mm Square material: 25 mm Angle Steel Shear Cutting capacity 90° L-profile: 100 x 100 x 10 mm Cutting capacity 45° L-profile: 70 x 6 mm Cutting capacity U/I-profile (accessory): 80 x 45 mm Cutting capacity T-profile (accessory): 40 x 5 mm Working height: 1140 mm Motor power: 4 kW Machine dimensions: approx. 1500 x 950 x 1680 mm Machine weight: approx. 1400 kg Accessories / Special Features: • Punching station, flat steel shear, angle steel shear, profile steel shear, notching station • Stepless stroke adjustment • Heavy-duty and robust welded construction • Powerful 400 Volt motor • Jog mode • Triangle notching station / V-notch tool • With MUBEA holder for punch No. 1, No. 2 and No. 3 as well as die No. 30, No. 45 and No. 60; use of punch and die No. 4 and No. 80 possible as option • Punch holder with bayonet coupling • Advantages of punching over drilling: - Significant time savings – short cycle times - No chips - No coolant required • CE-compliant Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: as good as new (ex-display), Year of construction: 2023, Technical data Strokes per minute with 15 mm stroke: 24 /min Punching force: 450 kN Motor power: 2.2 kW Hole diameter and thickness up to max.: 27×13 mm Flat steel up to max.: 300 x10/ 200×13 mm Fgjdpfoxyyz Sox Aduek Angle steel 90 degrees up to max.: 80x80x8 mm Angled steel 45 degrees up to max.: 60x60x6 mm Notching up to max.: 7 mm Machine weight: 760 kg

Condition: used, Punching force: 350 kN (punches e.g. 23 m in 12 mm material) Cuts 150 x 10 mm on the flat steel shears Two separate foot switches for the punching and shearing sides, allowing independent punching and shearing Fgodpfx Aexqqphsdujk Support table on the punching side with stop cams A range of tools is included in the price

Condition: used, functionality: fully functional, operating hours: 1,249 h, Peddinghaus 210A/13 combined section steel shear with punch, flat bar shear, rod shear, profile shear, and notching device. Equipped with infeed and outfeed conveyor. Bending capacity: 42 mm Punching capacity: 16 mm Motor power: 3 kW Fgsdpfxjxqph Nj Aduek Round steel max: 25 mm Square steel max: 38 mm

Condition: like new (used), functionality: fully functional, Year of construction: 2024, actuation type: hydraulic, throat depth: 175 mm, punching force: 45 t, punching diameter: 28 mm, overall weight: 800 kg, Equipment: CE marking, Condition: demo Pressure, tn: 45 Punching capacity: Ø28 mm. in 13 mm. Throat/reach: 175 mm. Flat bar: 300 x 10 /200 x 13 mm. Round bar: Ø30 mm. Square bar: 25 x 25 mm. Angle iron: 80 x 80 x 8 mm. Notching unit: Triangular. Year: 2024 Fgedpfxexn Squo Aduok Country of origin: Spain. Size (L x W x H): 1360 x 1100 x 1500 mm. Weight: 800 kg. Delivered with punching table, notching table and 10 sets of round punches and dies tool no. 6 (Ø4-Ø28 mm.). Has only been used for display. Machine uses Geka tools size no. 6.

Condition: used, Year of construction: 2004, punching pressure 40.0 t square edge steel 28.0 mm L-beam 80 x 8.0 mm round bar steel 30,0 mm punch diameter 30 in 10 mm square material 28 x 28 mm shear: flat material 150 x 10 oder 100 x 15 mm adjustment of stroke 35.0 mm strokes per minute max. 24 H/min. Fgodpfx Adsxau Uaousk voltage 400 V weight 1020 kg dimensions 910 x 670 x 1930 mm from a maintenance workshop well-maintained condition (!!) Equipment: - electro-hydraulic profile steel shears - punching station, flat steel shears, angle steel shears, profile steel shears - stepless adjustment of the stroke - very compact design - support table at the notching and punching station - various MUBEA punches + dies - flat steel station with manual material hold-down device - protective devices at work stations - 1x freely movable foot switch - operating instructions (PDF)

Condition: used, punching pressure 45.0 t punch diameter 22 in 15.0 mm punch diameter 38 in 8.0 mm round bar steel 30.0 mm square edge steel 25.0 L-beam 100 x 10.0 mm shear: flat material 300 x 12.0 mm adjustment of stroke 0 - 55 mm work height max. 940 / 1140 mm strokes per minute 34 punch diameter max. 110 mm voltage 400 V total power requirement 4.5 kW weight 1245 kg dimensions 1520 x 590 x 1700 mm In good condition (!!) New price ~ 13.000 Euro Fedpfxexaat Uo Aduegk Special price upon request Features: - Robust electro-hydraulic profile steel shear - With multiple workstations: * Punching station * Flat steel shear * Angle/profile steel shear * Notching station - Continuously adjustable stroke - Very compact design - Support table at the notching and punching station - Side support surfaces - 1x freely movable foot switch - Central lubrication system - Connection cable + connector

Condition: used, Pressure: ± 28 tons Punching capacity: Ø 20 mm at 10 mm / Ø 30 mm at 6.5 mm Flat bar capacity: 50 × 15 mm Angle iron cutting capacity: 65 × 6 mm Shear width: 175 mm Fjdsw N Nadspfx Adujgk

Condition: used, Profile shear for steel with notching unit Ideal for construction sites as it is mobile; of course also suitable for indoor use Peddinghaus 13 RP / 10 Angle profile: 60x7mm T-profile: 60x7mm Solid square: 20x20mm Round: 22mm Flat: 90x14mm Lever shear: Tmax: 10mm Pickup location: 28755 Bremen _____ Our general terms and conditions apply; the seller is not liable for typographical or data transmission errors. The appearance of the offered items corresponds to their age and the images shown. Technology and wear of the offered items are age-appropriate. Used machines are sold exclusively to tradespeople and without warranty. Fgsdpfx Adjw Ip D Heuok

Condition: used, Punching force: 400 kN (punches e.g. 20 m in 15 mm steel) Cuts 150 x 10 mm on the flat steel shears With pipe notcher on the bar shear Fgodsw Im Shspfx Adujk Foot switch for stroke activation Support table on the punching side Quick change device Range of tools is included in the price

Condition: good (used), – Mechanical – 5 stations – 380V Fgodswt Urzspfx Aduek

Condition: used, Technical details: throat: 250 mm number of strokes: 42 Hub/min sheet thickness - max.: 13 mm round bar steel: 36 mm square edge steel: 30 mm angle steel: 100 x 10 bei 90° mm flat steel: 100 x 18 mm U-H profile: NP 10 knife length: 230 mm total power requirement: 2,5 kW weight of the machine ca.: 1,7 t dimension machine xH: 2,1 x 1,0 x 1,6 m Application: Shearing - notching - punching Notching: material thickness = angle 50 x 8mm and rectangle 50 x 50 x 8mm Punching: max. 20 : 15mm, throat 250mm Foot control no longer available on both sides! Fgjdpfx Aswp Edajdusk Accessories various dies and various punches and small punches (see photo) *

Condition: used, Year of construction: 1976, round bar steel 28 mm Fgodpfx Adewm Rmneusk square edge steel 25 mm L-beam 80 x 8 mm notching cap. mild steel max. 7 mm cutting capacity of the vertical shear 350 kN Punch power 190 kN shear: flat material 100 x 11 mm shear: length of knifes ca. 175 mm total power requirement 1,5 kW weight of the machine ca. 0,5 t dimensions of machine L x W x H 1,0 x 0,5 x 1,5 m

Condition: used, Max. punching and shearing power: 400 kN Punches e.g. 20 mm holes in 15 mm steel Shears on the flat steel shear on 120 mm to 12 mm steel Fgedpewfrc Isfx Aduok Further technical data on request With a range of punches and dies as desired

Condition: used, functionality: unexamined, Year of construction: 1979, cutting range square steel at 90°: 55 mm, cutting range round steel at 90°: 63 mm, overall weight: 7,350 kg, Equipment: documentation/manual, emergency stop, type plate available, Peddinghaus Caddy 63 Bar Shear Year of manufacture: 1979 Overhaul: 1999 Shear force: 20,000 kN Cycle rate: 59/min Machine dimensions: 2260 x 2920 x 1770 mm Weight: 7350 kg Shears: Round bar up to Ø63 mm, square bar up to Ø55 mm (depending on the material to be sheared) Included: Bar feeder with separator Dimensions: 6800 x 1750 x 2250 mm Weight: 4900 kg Fgsdpjwbfn Nsfx Adusk The machine can currently be inspected while running. Delivery: ex works

Condition: used, functionality: fully functional, Year of construction: 1987, machine/vehicle number: 3009.87, peddinghaus punching and cutting machine. for specifications and capacities see nameplate on images. Fedpfx Ajwazncsduogk

Condition: excellent (used), Year of construction: 1979, Overhauled: 1999 Shear force: 2000 kN Cycle speed: 59 rpm Performance: Round bar up to 63 mm in diameter, square bar up to 55 mm Machine weight: 7350 kg Dimensions: 2260 x 2920 x 1770 mm Bar feeder with separation: Fgodjv Ta Ucepfx Aduek Max. bar length: 6 m Dimensions: 6.3 x 1.75 x 2.25 m Weight: 4000 kg Machine is still powered.

Condition: ready for operation (used), functionality: fully functional, Peddinghaus profile steel shears type 210 / 11 Technical details, see photos Accessories: all punching tools, see photo Fodpfxov H Ub Ro Adusgk

Condition: used, Year of construction: 1979, round bar steel 28 mm square edge steel 25 mm L-beam 80 x 8 mm cutting capacity 35 t shear : steel sheet max. 10 mm shear: flat material 100 x 11 mm blade length 175 mm triangle notching device for sheet until 8 mm Fedpfx Asvw Dvlsduogk no. of strokes max. 35 Hub/min work stroke ca. 35 mm total power requirement 1,5 kW weight of the machine ca. 535 kg dimensions of the machine ca. 0,97 x 0,45 x 1,55 m Motorized 4-way profile steel shear on a rotating base and mobile. The machine can also be used for hole punching by purchasing a hole punching device (instead of a notcher). Photo 5 shows which tools the punching device can optionally be equipped with. All performance specifications refer to a material strength of 450N/mm². Machine dealer with own stock of 1600 m².

Condition: used, Technical details: round bar steel: 32 mm square edge steel: 30 angle steel: 90 x 8 mm flat steel: 100x18 mm Knife length: 220 mm number of cutting strokes max.: max. 30 Hübe/min p.Min. Fedpou Icghjfx Adusgk voltage: 220/380-50 V rated current: 15,8/8,55 connected load: 4,8 kW weight of the machine ca.: ca. 1,1 t Dimensions (LxWxH): 0,8 x 1,2 x 1,3 m Capacity: - Steel sheet: 16mm - Flat steel: 100 x 18mm - T profile: at 45°: 65 x 7mm, right angle: 90 x 8mm. Machine is in working condition *

Condition: good (used), punching force: 45 t, - Capacity 45 tons Fgedpfju Havwex Adujk - Hydraulic - 4 stations - Foot control - Emergency stop - 400V

Condition: excellent (used), Year of construction: 2003, The machine has very few working hours and has been in storage for many years) Performance: Hole diameter and thickness up to max.: approx. 28×13 mm Angle steel 90 degrees up to max.: 80x80x8 mm Angle 100x 100 x 10 Flat steel up to max.: 300 x10/ 200×13 mm Fjdjupzf Ropfx Aduogk (See also rating plate in the appendix). Machine weight: approx. 750 kg Various punches are also included with the machine

Condition: excellent (used), machine/vehicle number: 4077953297009, Max. Punching and shearing capacity: 380 kN Fedpfjqlaifex Aduogk Punches e.g. 30 mm holes in 10 mm steel Shears 300 mm to 12 mm steel on the flat steel shear

Year of construction: 1998, condition: ready for operation (used), machine/vehicle number: 2131, Max. pressure: 55 kN Fgsdpfx Adjnacy Tsuok Throat: 175 mm Adjustable punching stroke: 0 - 28 mm Number of strokes at 15 mm stroke: 30 Notching stroke adjustable: 0 - 60 mm Hydraulic drive: 380 V, 3 kW Floor space required: 1170 x 620 x 1470 mm weight: 930 kg
