Condition: used, Year of construction: 2008, Technical details: turning diameter: 190 mm turning length: 503 mm control: Fanuc 31i - TA Travel x/z turret 1: 135 / 503 mm Travel x/z turret 2: 135 /503 mm c-axis: Sp. 1 / 2 Spindle 1 RPM: 6000 1/min Spindle 1 Power: 11/7,5 kW Spindle 1 max. bar diameter: 42 mm Spindle 2 RPM: 6000 1/min Spindle 2 power: 11/7,5 kW Turret No.1 stations / rotary tools: 12/12 Turret 1 tool RPM: 6000 1/min Turret 1 power rotary tools: 7,1 / 2,2 kW Turret No.2 stations / rotary tools: 12/12 Turret 2 tool RPM: 6000 1/min Turret 2 power rotary tools: 7,1 / 2,2 kW total power requirement: 53 kVA weight of the machine ca.: 5700 t dimensions of the machine ca.: 2,3 x 1,6 x 1,94 m Isdpfozd T I Hjx Adroau Accerories Chip conveyor right discharge Robot interface High precision cnc turning center, rotary tools and y-axis on upper turret, Robot loader for shafts. *

Condition: used, Year of construction: 2007, Technical details: turning diameter: 160 mm turning length: 300 mm control: Siemens 840D Spindle 1 Power: 22 kW Spindle 1 RPM: 5000 1/min Spindle 1 max. bar diameter: 65 Spindle 1 Torque: 150 Nm Spindle 2 power: 16,8 kW Spindle 2 RPM: 5000 1/min Spindle 2 torque: 100 Nm Travel for pick up of 2nd Spindle: W2=690 mm dimensions of the machine ca.: ´4,5x2,0x2,3 m weight of the machine ca.: 9 t Iaedpozd Tcwjfx Adrou Accerories Spindle 1 Collet chuck Spindle 2 Collet Chuck Chip Conveyor CNC turning center with 3 turrets and 2 spindles. There is an internal coolant system for the turrets with individual pumps *

Condition: used, Year of construction: 2008, Technical details: standard turning dia.: 200 turning length: max. 810 mm control: MSX-701 MAPPS III greates pass round over bed: 800 mm Max. distance between centres: 1130 mm max. turning diameter: 320 mm max. workpiecediameter: 300 mm bar material dia.: 65 mm Traverse X-Axis 1: 210 Traverse X-Axis 2: 210 mm Traverse X-Axis 3: 210 mm Traverse Y-Axis 1: 110 (+65/-45) mm Traverse Y-Axis 2: 110 (+45,/-65) mm Traverse Z-Axis 1: 300 mm Traverse Z-Axis 3: 300 mm Traverse Z-Axis 2: 810 mm Traverse B-Axis: 870 mm turning speed range - spindle: 5.000 1/min Number of spindle speed ranges: 2 . spindle nose: JIS A2-6 spindle bore: 73 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° turning speed range - spindle: 5.000 1/min spindle nose: JIS A2-6 spindle bore: 73 mm bar material dia. max: 65/52 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° Number of Turrets: 3 . Number of tool stations: 16 x 3=48 pos Schank height for square tool: 20 mm Diameter of boring bar: 32 mm turret changing time (4-stations): 0,18 sec Number of driven tools: 16 x 3=48 pos max. spindle speed driven tools: 6.000 U/min. Iedpfx Adozd Su Ejrsau Rotary tool machining ability: M16 / Ø16 . rapid traverse X-axis: 30 m/min rapid traverse Y-axis: 20 m/min rapid traverse Z-axis: 50 m/min drive capacity - spindle motor: 25 / 22 kW power capacity - driven tools: 7,5 / 5,5 kW total power requirement: 92,7 kVA weight of the machine ca.: 9,4 t dimensions of the machine ca.: 4,0 x 2,8 x 2,4 m Accerories Chip conveyor Coolantsystem C-axis in main and sub spindle Y-axis 2 x part counter total counter tool setting Overhead partsgripper with conveyor belt. Spindle 1 Chuck SMW KNCS-N 210 / 52 mm Spindle 2 Collet Chuck Hainbuch Spanntop nova Kombi Axfix 65 Robot interface Lehmann Robot with parts belt for feeding and disposal CNC Turning- and Milling Center MORI SEIKI NZ 2000 T3Y2 The NZ2000 T3Y has 2 spindles and 3 turrets, and 2 turrets have the Y-axis function and built-in milling motors. This not only allows synchronized machining using 3 turrets, but also achieves heavy-duty cutting and high-speed machining using rotary tools thanks to the built-in motor turrets. For shaft parts loading and unloading there is a Lehmann Robot with conveyor belts for loading and unloading. The machine can also be sold without robot. *

Condition: used, Year of construction: 2011, pricing can only be given out if you send me an email writing your email address. As machine seeker encrypts your email address. MACHINE: GILDEMEISTER CTX Alpha 300 V3S YEAR: 2011 SERIAL NUMBER: 00400003392 CONTROL: Siemens Sinumerik 840D sl ShopTurn ERGOline MACHINE TYPE: CNC Turning Center with C-Axis and Live Tooling CAPACITY: Maximum Turning Diameter: 200 mm Ijdpfx Aszd R S Asdrjau Maximum Swing Diameter: 500 mm Maximum Turning Length: 300 mm Bar Capacity: 51 mm MAIN SPINDLE: Spindle Nose: A2-5 Chuck Size: 165 mm Hydraulic 3-Jaw Chuck Spindle Bore: 65 mm Maximum Spindle Speed: 6,000 rpm Spindle Motor Power: 16.5 kW (100% duty) 25 kW (40% duty) Maximum Spindle Torque: 192 Nm AXES: X-Axis Travel: 190 mm Z-Axis Travel: 335 mm Rapid Traverse X: 30 m/min Rapid Traverse Z: 30 m/min TURRET: Turret Type: VDI 30 Number of Stations: 12 Live Tool Stations: 12 Maximum Live Tool Speed: 5,000 rpm Live Tool Power: 3.7 kW C-Axis Resolution: 0.001° TAILSTOCK: Hydraulic Tailstock (optional depending on machine configuration) COOLANT SYSTEM: Flood Coolant Chip Conveyor Compatible ACCURACY: Positioning Accuracy: ±0.005 mm Repeatability: ±0.003 mm ELECTRICAL: Power Requirement: 400 V / 50 Hz / 3 Phase Connected Load: Approx. 30 kVA DIMENSIONS: Length: 4,260 mm Width: 2,510 mm Height: 1,825 mm MACHINE WEIGHT: Approx. 4,000 kg

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, * Mori Seiki NL 2500 SY. * Year 2009. * Y-axis. * C-axis. * 5-axis machine. * 1.5-meter Lns Quick Load bar feeder. * Sub-spindle. * 12-station turret, all stations motorized. Iaodpfx Adjzd Nv Hsrsu * Y-axis travel: ±60 mm. * C-axis on both spindles. * Integrated main spindle motor: 18 kW. * Integrated sub-spindle motor: 15 kW. * Direct-drive motor for powered tools: 5.5 kW. * Motor starting torque: 640 N·m. * Motors without belts or gearboxes. * Main spindle size: A2-8. * Sub-spindle size: A2-6. * Bar capacity: 80 mm. * 250 mm Kitagawa B-210 main spindle chuck with metric system. * 210 mm Kitagawa B-208 sub-spindle chuck with metric system. * Prismatic guides on all axes. * Main spindle speed: 4,000 rpm. * Motorized tool speed: 6,000 rpm. * Daikin oil cooler for both spindles. * Mapps 4 conversational automatic programming system. * Automatic force control and tool wear monitoring. * Rapid traverse speed: 30 m/min on the X and Z axes. * Turret indexing time: 0.2 seconds. * Two Renishaw arms for automatic tool measurement. * Communication ports via USB, PCMCIA card, and RS-232. * Installation interface for bar feeder. * Automatic workpiece collector. * Dual pedal for independent opening and closing of the main spindle and sub-spindle. * Side-mounted hinged chip extractor. * Extensive range of static and motorized tool holders. Iasdbq Hnuozcdf Uepeu * Electrical transformer. * Documentation, parts list, electrical schematics, programming, and operating manual. * Weight: 5,800 kg. * Machine is currently in operation. * It is essential to check the precision videos. * Immediate delivery, unless sold immediately.

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, * Mori Seiki ZT 1500 YB. * Opposed-spindle machine. * Spindle size A2-6, twin spindles. * 2 stacked turrets. * 9-axis controlled turning and milling center. * 2 turrets. * 2 C-axes. * Bar capacity: 65 mm. * Y-axis on upper turret. * Two integrated 15 kW motors. * Tool life management and tool wear monitoring. * Two Renishaw automatic tool measurement arms. * Mapps 4 conversational automatic programming system. * Automatic force control and tool wear monitoring. * Oil cooler for both spindles. * 340 Nm cutting torque. * 15-position turret, all positions motorized. * Automatic workpiece collector. * 1.5-meter bar loader. * Interface for bar loader installation. * Rear automatic part pick-up with special gripper for long parts. * Max. turning diameter: 320 mm. * Turning length: 810 mm. * Mori Seiki MSX-701 III control. * Max. distance between main spindle and counter spindle: 920 mm. * Main spindle speed: 5000 rpm. * Counter spindle speed: 5000 rpm. * X1 travel: 210 mm. * Y1 travel: +50 / -50 mm. * X2 travel: 210 mm. * Counter-spindle travel: 920 mm. * Number of powered tool stations: 2 x 15. * Capable of holding 30 tools per turret. Iajdszd H I Tepfx Adrju * Large selection of external and internal tool holders. * Large selection of axial and radial motorized blocks. * Approximate value of equipment: 18,000 euros. * Speed range of powered tools: 5,000 rpm. * Drive motor for powered tools: 5.5 kW. * Rapid traverse X1, X2: 25,000 mm/min. * Rapid traverse Y1: 20,000 mm/min. * Rapid traverse Z1, Z2: 30,000 mm/min. * C-axis resolution: 0.001°. * High-precision Hainbuch collet chucks on both spindles. * External and internal tool holders. * Motorized axial and radial blocks. * Communication ports via USB, PCMCIA card, and RS-232. * Rear chip conveyor. * Power transformer, documentation, parts list, electrical schematics, programming, and operating manual. * Machine in very good condition. * Machine weight: 6.5 metric tons. * Machine available for inspection while in operation. * Immediate delivery, unless sold prior to listing.

Condition: repair required (used), Year of construction: 2005, operating hours: 20,000 h, functionality: not functional, Machine Type: CNC Turning and Milling Center Manufacturer: GILDEMEISTER Type: GMX 200 linear Year of Manufacture: 2005 Control System: Siemens 840 D powerline Location: Ober Ramstadt Technical Details Turning Diameter: max. 560 mm Turning Length: 1,070 mm Control System: Siemens 840 D powerline Distance between Spindles: 1,000 mm Main Spindle: Max. Speed: 5,000 min/-1 Drive Power - Main Spindle: 25 / 37 kW Max. Torque: 390 Nm Spindle Diameter in Front Bearing: 120 mm Spindle Bore: 79 mm Max. Bar Diameter: 68 mm C-Axis: 0.001 ° Chuck Diameter: 200 - 315 mm Milling Spindle: Speed: max. 12,000 min/-1 Drive Power - Milling Spindle: 13.2 / 22 kW Max. Torque: 100 Nm Tool Interface: capto Holding Torque: Y-Axis: +/- 80 mm B-Axis: +/- 120 ° C-Axis: 1 ° X-Axis Travel: 485 mm Bearing Diameter: 80 / 55 mm Counter Spindle: Max. Speed: 5,000 min/-1 Drive Power - Counter Spindle: 25 / 37 kW Max. Torque: 320 Nm Spindle Diameter in Front Bearing: 120 mm Spindle Bore: 79 mm Max. Bar Diameter: 68 mm C-Axis: 0.001 ° Max. Chuck Diameter: 315 mm Tool Magazine: Number of Tool Positions: 46 pos.HSK 63 A Tool Interface: Max. Tool Diameter: 80 mm Max. Tool Diameter with Free Neighbor Position: 150 mm Max. Tool Length: 300 mm Total Power Requirement: 75 kVA Machine Weight Approx.: 14.0 t Space Requirement Approx.: 8.0 x 4.5 x 3.1 m Accessories Documentation: Chip Conveyor: Coolant System: 8 / 20 bar C-Axis: B-Axis: Y-Axis: Tool Magazine: Isdpfxozd Dw Es Adreau Counter Spindle: Milling Spindle:

Condition: reconditioned (used), Year of construction: 2018, functionality: fully functional, CNC turning machine GILDEMEISTER CLX 350 V3 With DMG MORI SLIMline Multi Touch Fanuc I series control Year of manufacture: 2018 Turning diameter: 320 mm Travel in X: 242 mm Travel in Z: 540 mm Spindle bore: 65 mm Speed range: 20 – 5000 rpm With the following accessories: Sliding safety shield with interior lighting Iasdpfxjzd Dlps Adrou 12-station turret with 12 driven tool stations VDI 30 C-axis, tailstock with quill Programmable tailstock via M function Tool measurement in the work area Electronic handwheel Chip conveyor 3-jaw chuck, hydraulic, Schunk ROTA THW plus 0 210 mm Foot switch for chuck adjustment Parts catcher Glass scale in the X axis Coolant system with high-pressure pump 12 bar Coolant spray gun Operating manuals

Condition: like new (used), Year of construction: 2023, operating hours: 343 h, functionality: fully functional, machine/vehicle number: G3791-0010, turning length: 705 mm, turning diameter over cross slide: 290 mm, turning diameter: 230 mm, spindle motor power: 20 W, spindle speed (min.): 10 rpm, spindle speed (max.): 6,000 rpm, spindle bore: 51 mm, travel distance X-axis: 190 mm, travel distance Z-axis: 700 mm, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 40 m/min, bar diameter (max.): 51 mm, overall weight: 8,200 kg, • High-performance, integrated spindle motor • High productivity through simultaneous use of the upper and lower turrets • Robust BMT turret • Integrated machining through synchronized control of the main and counter spindle Specifications: • Max. turning diameter 230 mm • Max. turning length 705 mm • Chuck size, main/auxiliary 6" / 6" • Drive type: Integrated • Spindle speed 6,000 rpm • Spindle power 15/11 kW • Spindle torque 208/140 Nm • Travel distances (X1/X2/Z1/Z2/ZB) 65/195/700/720/700 mm • Rapid traverse (X1/X2/Z1/Z2/ZB) 20/20/40/40/40 m/min • Guide type: LM (linear motion) • Number of tools 2 x 12 • Tool size 20/32 mm Iedozd Dizspfx Adroau • Milling spindle speed 5,000 rpm

Condition: reconditioned (used), Year of construction: 2011, functionality: fully functional, CNC turning machine GILDEMEISTER CTX 510 ECOLINE With Siemens control Year of manufacture: 2011 Travel in X: 300 mm Travel in Z: 1050 mm Spindle bore: 103 mm Speed range: 20 – 3250 rpm With the following accessories: Sliding guard 12-station turret with 6 driven tool stations Tool measurement in the working area 3-jaw chuck, hydraulic, SMW Autoblock 0, 315 mm Foot switch for chuck, foot switch for tailstock Various tool holders VDI 40 Signal light, 4-color Tailstock with quill Chip conveyor with coolant tank 4 machine feet Operating manuals Iodszd Dczopfx Adrjau

Condition: ready for operation (used), Year of construction: 2025, spindle speed (max.): 4,000 rpm, travel distance X-axis: 240 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, total height: 2,289 mm, total width: 2,377 mm, overall weight: 11,000 kg, product length (max.): 2,860 mm, number of axes: 10, This 10-axis CMZ TTL66 turn-mill centre was manufactured in 2025. It features a maximum swing diameter of 800 mm and a maximum turning diameter of 515 mm. The machine is equipped with twin spindles and twin Y-axis turrets, allowing for simultaneous 4-tool machining capability. If you are looking to get high-quality turning and milling capabilities, consider the CMZ TTL66 machine we have for sale. Contact us for further details regarding this machine. • General • Maximum swing diameter: 800 mm • Maximum turning diameter: 515 mm • Distance between spindle noses: 614 mm • Installed power: 35.5 kVA • Tank capacities: Coolant 510 L, Lubrication oil 18 L, Hydraulic oil 100 L • Axis travels • Upper turret (T1): X1 240 mm, Z1 800 mm, Y1 ±45 mm • Lower turret (T2): X2 240 mm, Z2 800 mm, Y2 ±45 mm • Sub-spindle axes: X3 mm, Z3 580 mm • Rapid traverse rates • X axes: 30 m/min • Z axes: 30 m/min • Y axes: 20 m/min • Axis acceleration • All linear axes: 1G (9.8 m/s²) • Main spindle • Type: Integrated built-in motor • Chuck size: 210 mm • Spindle nose: ASA A2-6 • Bar capacity: 66 mm • Spindle bore: 72.5 mm • Draw tube I.D.: 66 mm • Bearing O.D.: 170 mm • Power (Max / S3 25% / S1): 35.5 / 28.3 / 23.5 kW • Torque (Max / S3 25% / S1): 205 / 180 / 150 Nm • Sub-spindle • Max speed: 4,000 rpm • Bar capacity: 66 mm • Spindle bore: 72.5 mm • Draw tube I.D.: 66 mm • Bearing O.D.: 170 mm • X3 travel: ±120 mm • Z3 travel: 580 mm • Power (Max / S3 25% / S1): 35.5 / 28.3 / 23.5 kW • Torque (Max / S3 25% / S1): 205 / 180 / 150 Nm • Turrets (upper & lower) • Number of stations: 24 • Live tool positions: 12 • Tool size: 20×20 mm / 25×25 mm • Indexing time: 0.1 sec • Clamping force: 3,200 kgf • Curvic coupling diameter: 150 mm • Live tooling • Motor type: Built-in synchronous motor • Max speed: 12,000 rpm • Power (Max / S1): 14 / 10 kW • Max torque (Max / S1): 42 / 32 Nm • Cooling: Full oil cooling • Standard tool interface: NT-55 • Construction • Heavy-duty GG-25 cast iron 60° slant bed, FEA-optimized • Bed weight: 4,450 kg • NSK roller linear guideways and pre-tensioned ballscrews • 8 built-in oil-cooled motors • Thermal-stable design with spindles at 90° to X–Z plane • Coolant & thermal management • Oil chiller capacity: 5,000 W • Standard coolant pump: 6 bar / 60 l/min • Coolant tank capacity: 510 L • Oil cooling for both spindles, all X/Y built-in motors, and both live-tool motors • Thermal compensation via controlled oil temperature • CNC control • Fanuc 31i-T Plus with iHMI, 15" touchscreen • Manual Guide i conversational programming • Ethernet & USB connectivity • Remote assistance capability • Industry 4.0 ready • 14 controlled axes: X1, X2, X3; Y1, Y2; Z1, Z2, Z3; T1, T2; M1, M2; C1, C2 • Simultaneous control of 4 axes per channel • Functions: Rigid tapping, polygon turning, cylindrical interpolation, polar coordinate interpolation, gear hobbing and power skiving capability • Key selling points • Twin spindle + twin Y-axis turrets • Simultaneous 4-tool machining capability • Full built-in motor architecture (no belts) • 66 mm bar capacity on both spindles Iajdpezd Aarofx Adrju • 12,000 rpm live tooling • Superimposed machining with movable sub-spindle • Suitable for high-volume automotive, hydraulic, aerospace, and precision turned parts production Additional equipment • Optional high-pressure coolant pump: 15 bar • Optional tailstock • Not specified in the provided information: robots, automation, chip conveyor, bar feeder Technical Specification

Condition: good (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 1114S49, rapid traverse X-axis: 5 m/min, rapid traverse Y-axis: 5 m/min, rapid traverse Z-axis: 10 m/min, bar passage: 26 mm, total height: 1,700 mm, total length: 7,000 mm, total width: 2,000 mm, overall weight: 3,000 kg, feed force Z-axis: 310 N, controller manufacturer: FANUC, controller model: SERIES 18i-TB, MANURHIN KMX 3260 CNC turning center - Stroke of the moving spindle carriage: 160 mm - Type of cross slide: two turret heads, 6 positions - Number of tool stations: 12 - For external machining: 1 - 12, for internal machining: 1 - 11 - With workpiece ejector - Stroke of the cross slide: 35 mm - Max. cross-section for external tools: 16 x 16 mm - Diameter of the internal tool holder: 25.4 mm - Ball screw diameter: 25 mm - Pitch: 5 mm - With C-axis - Driven tools - Incl. bar feeder FMB, type: TURBO 3-36 Note: The item must be collected between August 4th and August 13th, 2026, on a date to be confirmed. FCA D-79268 Bötzingen - loaded onto a truck. Iajdszdzfaspfx Adrju

Condition: used, Year of construction: 2000, Hardinge VMC 600 II CNC Vertical Machining Centre with Fanuc Series O-MD CNC Control, Table Size 750mm x 500mm, 20 Tool ATC, BT40 Spindle Taper, Manuals & BT40 Spindle Tools. S/No. NVAAOF0060 (2000) Location: This lot is located in Burton on Trent, UK. A charge of £300 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. Iaodpfx Adozdtkhjrsu

Condition: used, Year of construction: 2004, Doosan Mecatec S550LM Slant Bed CNC Lathe with Fanuc Series 21i – TB CNC Control, Swing Over Bed 710, Distance between both Centres 1230mm, Max Turning Diameter 480mm, Max Turning Length 1130mm, Spindle Speeds 30 – 2500rpm, 12 Tools VDI40 Turret, X Axis Travel 300mm, Z Axis Travel 1150mm, Live Driven Tools, C Axis, Machine Weight 8000kg. S/No. LNY – 1008 (2004). Country of Origin: Korea Iaodpfxszdthms Adreu Location: This lot is located in Birmingham, UK. A charge of £550 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser.

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, turning diameter: 460 mm, spindle speed (max.): 3,500 rpm, spindle bore: 86 mm, bar passage: 78 mm, controller model: Fanuc 32iTB iHMI, center width: 689 mm, CMZ turning and milling center including GL20II gantry loader! TECHNICAL DETAILS Turning diameter over bed: 760 mm Turning diameter over cross slide: 600 mm Maximum turning diameter: 460 mm Distance between centers: 689 mm Travel distance tailstock: 640 mm Travel distance X-axis: 310 mm Travel distance Z-axis: 640 mm Travel distance Y-axis: +70/-50 mm Travel distance B-axis: 640 mm Rapid traverse rates: 30/30/15/30 m/min Spindle speed max.: 3,500 rpm ASA 8" A2 Iodpfx Aozdrzxodroau Spindle bearing outer diameter: 200 mm Spindle bearing inner diameter: 130 mm Spindle bore: 86 mm Bar passage: 78 mm Number of tool stations: 12, all driven, 12,000 rpm Tool holder: 25x25 (50) MACHINE DETAILS Operating hours: 43,712 h Total operating hours: approx. 35,000 h Control system: Fanuc 32iTB iHMI Dimensions & Weight Machine dimensions (L x W x H): 2,542 x 1,760 x 1,880 mm Machine weight: 6,500 kg EQUIPMENT Gantry loader

Condition: used, Year of construction: 2000, Gildemeister CNC universal lathe Type/Model: CTX 600 E Condition: Used Operating hours: 99,831 h Year of manufacture: 2000 Technical data Swinging diameter: 680 mm Distance between centers: 2000 mm Spindle speed: 2800 rpm Chuck: Ø 315 mm Tool turret: 12 stations; incl. 3 stations for driven tools Tool holder: VDI 50 Tailstock: NC-controlled Dimensions approx. 5560 x 240 x 213 mm Weight approx. 10,000 kg Equipment: - Power chuck, type SMW Autoblok 315 BH-FX, Ø 315 mm - Control system: Heidenhain CNC Pilot Ijdszdrrkspfx Adrsau

Condition: used, Year of construction: 2007, Turning diameter 300 mm Turning length 600 mm Control FANUC, 18i-TB Turning diameter over bed slide 230 mm Iaedpfx Adszdrpperju Travel x1 165 mm Travel z1 700 mm Travel x2 190 mm Travel z2 720 mm Travel -y axis +/- 50 mm Main spindle bore 76 mm Main spindle speed 5.000 U/min Main spindle drive 22 kW Max. torque on the spindle 208 Nm Sub spindle bore 76 mm Sub spindle speed 5.000 U/min Sub spindle drive 22 kW Max. torque on the spindle 208 Nm Tool turret 2 x 12 Stat. Number of driven tool stations 2 x 12 Speed of driven tools 5.000 U/min Max. torque 47 Nm Work piece power 5,5 kW C-axis resolution 0,001 ° Rapid traverse x + z axis 20 / 40 m/min Rapid traverse y-axis 7,5 m/min Total power requirement 68,4 kVA Included Bar feeder, Tools and driven tools.

Condition: used, Year of construction: 2007, turning diameter 65 mm turning length 150 mm control Siemens 840D spindle passage 75 mm turning length 150 mm c-axis 2x 0,001 ° gripping station 65 mm speeds 5000 U/min rapid traverse 30 m/min turret (x-stations) 3x12 Number of axles 10 St. number of toolholder-holes 36 chip conveyor ja / yes kW Iaodpfx Adozdk Everju coolant filtering unit ja / yes kW total power requirement 22 kW weight of the machine ca. 9 t dimensions of the machine ca. 4,4 x 2 x 2,3 + Iemca m DMG Sprint 64 Linear CNC lathe, built in 2007, 10 axes, 2 spindles, 3 turrets with Iemca Master 880 loading magazine Accessories: a large number of tool holders

Condition: defective spare-parts repository (used), Year of construction: 1997, functionality: not functional, machine/vehicle number: 128124, Mazak Super Quick Turn 18MS Mark II CNC lathe including Samsys bar feeder magazine – for hobbyists / defective Technical specifications (for the search function) Manufacturer: Mazak / Yamazaki Machinery UK Ltd Model: Super Quick Turn 18MS Mark II (SQT 18MS) Year of manufacture: 1997 Control: Mazatrol T Plus Machine weight: approx. 5,800 kg Condition: Sold as defective / for spare parts (turret malfunction) Accessories: Bar feeder magazine Samsys Multisam 2000 (Type MUS 2000, year of manufacture 1999) Detailed description (copy text) For sale: a CNC lathe Mazak Super Quick Turn 18MS Mark II (year of manufacture 1997) as a package with a matching Samsys Multisam 2000 bar feeder magazine (year of manufacture 1999). The machine comes from a well-maintained company and was primarily used for prototype construction. Accordingly, it only ran in a single-shift operation, if at all, and has been used very little in recent times. No heavy continuous use in mass production! IMPORTANT NOTE REGARDING THE CONDITION (sold expressly AS DEFECTIVE): The machine is sold as defective or as a project for hobbyists / for spare parts. Currently, the tool turret does not index/lock. However, for a service technician, specialist or someone familiar with this type of machine, this error should be easily rectified. Otherwise, we are not aware of any other errors or defects. Up to this error, the machine ran reliably. Scope of delivery & details: CNC lathe: Mazak SQT 18MS Mark II (weight approx. 5,800 kg) Control: Mazatrol T Plus Equipment: Main and counter spindle, C-axis Bar feeder magazine: Samsys Multisam 2000 (Type MUS 2000, S/N 087, year of manufacture 08/1999) with its own control unit Condition: Not operational due to the turret malfunction. Sold as is at the location, as inspected, with exclusion of any warranty. Ideal for companies with their own maintenance department or for technicians who would like to restore a high-quality machine with top equipment (counter spindle & driven tools not included). An on-site inspection is possible by prior arrangement. Assistance can be provided with loading, upon request. The transport is to be organized by the buyer. Ijdpfxezdi N Te Adreau If you have any questions or need more information, please send us a message or call us.

Condition: ready for operation (used), Year of construction: 1999, turning length: 600 mm, turning diameter over cross slide: 350 mm, rotational speed (max.): 3,500 rpm, Fanuc 21T 3 axes Isdpfx Adezdiy Eoroau C-axis for rotating tools 12-position turret chip conveyor tool set

Condition: excellent (used), Year of construction: 2017, operating hours: 9,982 h, functionality: fully functional, turning length: 1,250 mm, turning diameter over cross slide: 500 mm, turning diameter: 500 mm, spindle speed (max.): 12,000 rpm, spindle bore: 76 mm, rotational speed (max.): 5,000 rpm, bar diameter (max.): 76 mm, Equipment: documentation/manual, rotational speed infinitely variable, We are not a dealer. More detail photo's are coming soon. We have for sale, this exceptional machine, fully loaded and ex-demo in perfect condition. It is possible to buy machine turn-key: including all tools and clamping devices, postprocessor. Even training is possible. machine is under power and is still operating. You can visit machine under working condition. Any inspection is possible. DMG MORI CTX BETA 1250 TC Gen2 Siemens 840. Main spindle ISM76. Sub spindle . Tailstock machine. Milling head 12.000 rpm B-axis compactmaster2. 5-axis simultaneous machining!! Capto C6 – 80 tools chain magazine!! Robot/barfeeder/automation package : +automation interface +Signal light +electrical door +barfeeder inferface +parts catcher +coolant flush mainspindle +coolant flush subspindle Chip conveyer Machine cooler system external ()Tropical package) Oil mist extraction system Coolant spray gun Hydraulic differential clamping pressure 8/20/80 bar coolant supply with filter and cooling unit (biggest tank): +80bar high pressure +filterunit +coolant water chiller a/c +internal coolant +external coolant Measuring/monitoring: 3D Probe Heidenhain Tool probe Heidenhain DMG technology cycles: +Tool sorting cycle +Multitool +Alternating speed +Retraction cycle +5-Axis simultaneous machining +MPC (machine protection control) +Excentric Machining +oval turning +Probing Iodezdck Sepfx Adroau Barfeeder (shortloader). Fusion 360 postprocessor possible Main spindle chuck: Schunk 315 Subspindle chuck: Hainbuch 65 Toolholders: Sandvik/Hoffmann Capto C6 tools Spindle liners different sizes (oem DMG) Original DMG lifting gear. All documentation complete. Max turning length: 1200mm Max. turning diam: 470mm Tool magazine: 80 tools Main spindle speed: 5000 rpm Subspindle speed: 5000 rpm Milling spindle speed: 12000 rpm (Best TC ever made, stronger than new CTX450TC). Please feel free to ask any question. Machine is for sale turnkey. Machine is for sale as base machine (without tooling etc).

Condition: like new (used), Year of construction: 2024, operating hours: 500 h, functionality: fully functional, DN Solutions PUMA 4100LMA Manufactured: November 2023 Only 550 hours of actual cutting time FANUC i Plus / iHMI control unit 12-station servo turret 8 live tools (driven tools) C-axis Programmable hydraulic tailstock Maximum turning diameter: Ø550 mm Maximum turning length: 2,060 mm Swing over bed: Ø790 mm Bar capacity: Ø102 mm Maximum workpiece weight: 500 kg X-axis travel: 352 mm Z-axis travel: 2,155 mm X-axis rapid traverse: 16 m/min Z-axis rapid traverse: 20 m/min 12-inch (315 mm) hydraulic chuck Spindle nose: ASA A2-11 Maximum spindle speed: 3,000 rpm Main motor power (continuous): 22 kW Ijdpfszdartjx Adrjau Main motor power (30 min rating): 37 kW Maximum spindle torque: 832 Nm Live tool speed: 4,000 rpm C-axis indexing increment: 0.001° Chip conveyor Chip bucket Automatic centralized lubrication system Coolant system Tool life management Spindle load monitoring Manual Pulse Generator (MPG) Working lamp Machine dimensions: 5,774 × 2,275 × 2,272 mm Machine weight: 11,050 kg

Condition: good (used), For sale is the lathe shown in the pictures, manufactured by the Japanese brand Mazak, model Quick Turn 8n, with Mazatrol T32-2 control. The machine is equipped with a bar feeder and a collet chuck. We can arrange for machine loading at the location. Net price: 23,000 (plus 23% VAT) Iaodpjzc Ri Tjfx Adrju Turning diameter: 160 mm Maximum turning length: 285 mm Spindle bore: 40 mm Maximum spindle speed: 6000 rpm 8-position turret Tailstock included Tool measuring probe Weight: 2700 kg

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, turning length: 500 mm, turning diameter over cross slide: 290 mm, spindle speed (max.): 5,500 rpm, spindle bore: 73 mm, travel distance X-axis: 210 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 550 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 22 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (max.): 6,000 rpm, chuck outer diameter: 225 mm, swing diameter over cross slide: 290 mm, spindle nose: FL 140h5, overall weight: 4,300 kg, Equipment: documentation/manual, rotational speed infinitely variable, A complete DMG MORI CTX alpha 500 V6 model, fully equipped! This machine features a C-axis, powered tooling, Y-axis, sub-spindle, and more. We acquired this machine in working order from production, and it can be inspected in working condition by appointment. Additional options & accessories: - Band filter system including high-pressure pump - DMG CELOS software - 3-jaw chuck (SMW Autoblok KNCS-N-225-66) on the main spindle - 3-jaw chuck (SMW Autoblok KNCS-N-170-43) on the sub-spindle - Chip conveyor - Coolant gun - Various VDI-30 tool holders (6 powered, 4 static) - Original DMG mist extraction system - All original documentation Iedpfx Ajzc Nlasdrsau Weight & dimensions: 4,300 kg 4066x2583x1829 mm (LxWxH)

Condition: excellent (used), Year of construction: 2018, 2018 Haas ST-25 CNC Slant Bed Lathe Samchully MH-212 Ø250mm 3 Jaw Power Chuck. Maximum Swing Ø806mm. Maximum Swing Over Cross Slide Ø527mm. Swing Over Tailstock Ø584mm Maximum Cutting (Varies With Turret) Ø381mm. Maximum Cutting Length (Without Workholding) 826mm. Bar Capacity Ø102mm. Distance Between Centre 762mm. Axis Traverses 'X'=318mm, 'Z'=660mm. Rapid Traverses 'X'=24m/min, 'Z'=24m/min. Spindle Bore Ø117.3mm. Maximum Spindle Speed 3,200rpm (29.8kW Motor). Spindle Nose A2-8. 12 Station Turret. S/No. 3112177 (2018). Isdpfx Adjzc Id Usrjau With Coolant System (Tank Capacity 208L), Tool Setting Arm, Tailstock, Jorgensen Chip Conveyor, Footswitch & Signal Tower.
