Condition: used, Year of construction: 2001, overall weight: 10,000 kg, total length: 3,000 mm, total width: 2,300 mm, total height: 2,500 mm, REISHAUER RZ 362 A – CNC Gear Grinding Machine Year of Manufacture: 2001 Dsdjzy Tkmspfx Akcsku Serial No.: 75523 Max. Workpiece Diameter: approx. 360 mm Max. Module: 7 Max. Gear Width: approx. 175 mm Max. Workpiece Weight: depending on configuration, approx. 60 kg Grinding Worm Diameter: approx. 270–350 mm Helix Angle: up to approx. ±45° CNC Control: Reishauer Connected Load according to Nameplate: 26 kVA Dimensions (LxWxH) approx.: 3000 x 2300 x 2500 mm Weight approx.: 10,000 kg Year of construction: 2,001 Condition: in working order Terms of payment: 100% prepayment before pick-up Terms of delivery: Loaded on truck under power: No

Condition: excellent (used), Year of construction: 1979, Kapp AST‑305B – Technical Specifications Machine type: automatic hob and gear cutter sharpening machine Year of manufacture: circa 1979 Machine function: resharpening of hobs, spiral or straight gash cutters; wet or dry grinding Maximum tool diameter capacity: 12 inches (300 mm) Maximum tool length between centers: 27 inches (700 mm) Dsdpjwwkt Aefx Akceku Maximum table traverse: 21.56 inches (550 mm) Maximum grinding wheel diameter: 12 inches (300 mm) Maximum center height: 6.1 inches (155 mm) Table speed (infinitely variable): – deep grinding: 30 to 1000 mm/min – surface grinding: 3 to 16 mm/min Flute lead angle range: 0° to 45° Flute lead range: selectable, up to 24‑inch to zero or 12‑inch to zero Grinding spindle speed: 2200 rpm (optional 1000–4000 rpm) Axial grinding spindle adjustment: 16.54 inches (420 mm) Vertical grinding head adjustment: 11.81 inches (300 mm) Spindle taper: Morse 4 or steep taper 40 Preselectable single in-feed: range 0 to 9999 (units) Machine dimensions: length 118 in × depth 82 in × height 93 in (≈3000 × 2080 × 2360 mm) Machine weight: approximately 7,500 lbs (3,000 kg) Control system: originally manual/analog, often upgraded with Allen‑Bradley PLC

Condition: used, Year of construction: 2000, Technical details: max. wheel diameter: 180 mm max. module: 5 min. module: 1 Dksdpfx Ajwv Ug Rskcju weight of the machine ca.: 14 t dimensions of the machine ca.: 4,5 x 2,84 x 2,8 m min. number of teeth: 7 toolpiece turning speed range: 4000-10000 U/min tool length: 210 mm With tail stock No dressing device Only CBN *

Condition: used, Year of construction: 1988, Technical details: max. wheel diameter: 210 mm total power requirement: 60 kW weight of the machine ca.: 8 t dimensions of the machine ca.: 2,85 x 2,60 x 1,80 m grinding slide feed: 700 mm grinding slide feeds: 1-15.000 m/min Dkodpfewrzutjx Akceu max. workpiece weight: 150 kg centre height: 260 mm grinding wheel diameter: 240 mm

Condition: used, Year of construction: 2001, Technical details: max. wheel diameter: 280 mm Dkodpfx Akswh Dlmeceu max. module: 5 min. module: 1 min. number of teeth: 7 toolpiece turning speed range: 4.000...10.000 U/min tool length: 210 mm CBN *

Condition: used, Year of construction: 1999, max. wheel diameter 280 mm gear width 330 mm max. module 5 min. module 1 Control LIEBHERR CNC total power requirement 28 kW weight of the machine ca. 12 t dimensions of the machine ca. m Dkjdet Hwu Aepfx Akceu

Condition: used, Year of construction: 1980, max. wheel diameter 2500 mm gear width 1200 mm Dkedpfx Akot Hwqqjceu max. module 32 min. module 3 total power requirement 25 kW weight of the machine ca. 60 t dimensions of the machine ca. m Gear , min. / max. 180 / 2,500 mm Module 3 - 32 Helix angle, max. 10 - 35 ° Gear width for straight gears 1,200 mm Stroke length, approx. 100 - 1,200 mm No. of strokes 80 - 350 /min Stroke position adjustable 300 mm Stroke speed 4 - 40 mm Max. weight of workpiece, approx. 18,000 kg Min. / max. no. of teeth 16 / 576 Table size x bore 1,400 x 500 mm Grinding wheel Ø, approx. 500 mm Grinding wheel peripheral speed 34 m/s Total electrical load, approx. 45 kW - 380 V - 50 Hz Weight of machine, approx. 60,000 kg Accessories / Special Features: * Hydrostatic guides in grinding slide, table and in all other guideways. * Completely covered working area with sliding doors. * Automatic grinding process for various cycles, with settings for roughing, finishing, fine finishing and automatic dressing cycle after preset number of teeth. * Profile correction is possible via appropriate dressing, as well as additional movement of grinding slide (depth and width crowning). * Approx. 50 change gears. * Grinding slideTilt display device. * Large coolant device with band filter and oil mist exhaust. * Separate switch cabinet. * Separate hydraulic unit. * Separate oil cooling unit. Condition : Very good. Machine can soon be inspected in our showrooms. It is not under power at present. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. The machine comes directly from a first class gear factory, where it was grinding Quality 5 - 6. Grinding diagrams are available. This type and quality of machine is rarely available. Thank you for your interest. We always have a good selection of gear machines available. Please let us know what you need.
