A.Hangarter

Condition: good (used), Milling machine, universal milling machine, tool milling machine, drilling and milling machine -Clamping table: 800 x 400 mm -Clamping table: rotatable/tiltable/swivelable Fgsdpfx Aoxvraxjc Hei -Travel range X/Y/Z: 600/400/400 mm -Spindle mount: SK40 with hydraulic clamping -Speeds: from 63 - 3150 rpm -Feed rate X/Y: 16-800 mm/min -Feed Z: 8-400 mm/min -Quick stroke: 100 mm -Rapid traverse X/Y: 2000 mm/min -Rapid traverse Z: 1000 mm/min -Coolant system: yes -Dimensions: 1740/1670/H1940 mm -Weight: 2200 kg

Condition: good (used), Margin scheme taxation according to §25a German VAT Act. Internal item number: 25083 Universal Milling Machine Union USF 3.1 The machine is in very well-maintained condition and comes from a training workshop within a rehabilitation clinic. + Röhm vise BB110mm + SK40 tool holders + Counter support + Various cams Swivel head: +/- 50° Table: 900 x 220mm Feed on X-axis with cam switch Feed speed infinitely variable Y- and Z-axes manually operated Spindle mount: SK40 Fgjdpexvqwisfx Ac Hsi Travel distances: X 600 / Y 160 / Z 300mm Max. distance spindle mount to table: approx. 330mm Dimensions (LxWxH): 160 x 150 x 190cm Weight: 1000kg

Condition: used, Tool milling machine STEINEL SH4, speeds 63 - 1,250 rpm, table size approx. 900 x 200 mm Fodoxva S Nspfx Ac Hjgi

Condition: new, – ISO40 – 115/1750 rpm – Table 800 x 240 mm – Automatic feed on X, Y, and Z axes – Rapid traverse – Digital readout on X, Y, and Z axes – Swivelling milling head – Coolant system – Lighting Fodpfxsxq N Hro Ac Hsgi – Safety guard – Emergency stop – Documentation – 400V

Condition: excellent (used), Year of construction: 1994, Machine in good working condition, including digital readout. Clamping table area mm 400 x 800 Working stroke: longitudinal mm 600 cross mm 400 vertical mm 400 Taper in spindle ISO 40 Range of revolutions r.p.m. 40 - 2000 Number of revolutions steps 18 Main motor output kW 3,0 Total machine input kVA 6,5 Machine dimensions mm 1675 x 1680 x 1740 Machine weight kg 1725 Fsdpfsxdxp Nex Ac Hjgi

Condition: ready for operation (used), Year of construction: 1996, ORADEA FUS 32 tool milling machine with 3-axis digital readout. The machine is in operational condition and ready for demonstration under power. Fgedpfxsxdr Ulj Ac Hei

Condition: new, The Servomill® FPK 600 is a state-of-the-art Conventional Vertical Milling Machine designed for precision and versatility, making it an indispensable tool in mechanical manufacturing, particularly for tools and molds. This machine features a compact design that enhances flexibility and ease of operation, blending modern technology with traditional milling techniques. Equipped with advanced electronics, including electronic stops and handwheels, the Servomill® FPK 600 allows users to experience the benefits of CNC technology without the need for programming. This ensures not only high precision but also efficiency in production and education settings. With robust ball screws in all axes and powerful servomotors, the machine delivers smooth, precise movements and rapid traversing. Operators will appreciate features like the easily accessible control panel, automatic feed with programmable limit stops, and comprehensive standard equipment, including a coolant system, LED work light, and an extensive tool package. Trust in KNUTH's commitment to quality and reliability, and elevate your machining capabilities with the Servomill® FPK 600. Explore the advantages of this Conventional Vertical Milling Machine by requesting a quote today! Fodpsxb Dwgefx Ac Hogi

Condition: used, Year of construction: 2009, x-travel 560 mm y-travel 320 mm z-travel 400 mm turning speeds 25 - 2000 U/min turning speeds 18 Stufen spindle taper ISO 40 quill stroke 100 mm table: 320x1000 / 450x950 mm table load 125 kg feed range 5 - 400 mm/min feed 18 Stufen rapid traverse 1.400 mm/min workpiece weight max. 125 kg T-slots 7x 14.0 mm total power requirement 4.2 kW weight of the machine ca. 1650 kg. range L-W-H 1800 x 1500 x 1780 mm from a training workshop - good condition (!!) New price ~ 25.000 euros Equipment: - electro-motorized universal milling machine - ACURITE 3-axis digital display - electro-motorized adjustment of all axes (X/Y/Z axis) * ball screws X and Y axis * rapid traverse in all 3x directions * electrical locking of all axes - electromagnetic brake for spindle stop * foldable milling spindle guard - coolant system - lower chip tray - vertical milling head with quill adjustment * milling head rotation 90° * tool holder ISO 40 with internal thread M16 - fixed box table 950 x 450 mm * number / size of T-slots 7 pieces / 14.0 mm * distance between T-slots 63.0 mm * minimum distance between base table / spindle axis 163 mm - Counterholder block for horizontal milling - Halogen lighting - Slatted cover on the vertical column guide - 4x machine feet - Central lubrication including container Fsdpfx Ajxacc Esc Hogi - Original operating instructions

Condition: ready for operation (used), x-travel 510 mm y-travel 450 mm z-travel 410 mm taper in main spindle MAS BT 45° (SK40) table surface area 800 x 395 mm T-slots 6 Stk. turning speeds 50 - 2500 U/min feed stepless 4-1600/4-1000 mm/min voltage 400 V total power requirement 5.0 kW weight of the machine ca. 1400 kg range L-W-H 2300 x 2300 x 1800 mm from a training workshop maintained condition (!!) - in checked conditions - machinevideo - ?v=iSTVEdv2fO8 Furnishing : - robust universal milling machine - swiveling control panel, right front - rotatable universal milling head (re/li = 90°) * with hydraulic tool clamping - manual milling spindle feed, with locking - swiveling milling spindle protection - Stable T-slot clamping/angle table - Axis feeds with rapid traverse - Central lubrication unit - Control cabinet, installed on the left Fjdpfxexaam Uo Ac Hsgi * Digital display - without function

Condition: used, Year of construction: 1973, x-travel 550 mm y-travel 155 mm z-travel 350 mm taper in main spindle SK 30 / DIN 2080 table surface area 640 x 200 mm turning speeds 50 - 1500 U/min feeds 30 - 340 mm/min distance spindle - column 165 mm distance spindle nose and table 245 mm voltage 380 V total power requirement 1.3 kW weight ca. 1250 kg range L-W-H 950 x 1000 x 1600 mm from a vocational school (!) Furnishing : - robust / conventional universal milling machine - rotatable / swiveling vertical milling head - Stable T-slot clamping/angle table - automatic table longitudinal movement - Feed range adjustable - 8x steps Fgsdpfx Acew U U S Ao Hoi - Pole-changing drive motor

Condition: good (used), Year of construction: 1999, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, space requirement width: 1,975 mm, space requirement length: 1,800 mm, space requirement height: 1,900 mm, Equipment: documentation/manual, Machine is in very good condition - used as a training machine until 2018; since then, the machine has hardly been in operation. Operating voltage 400 V Spindle mount ISO 40 Quill stroke 100 mm Spindle speeds 63 – 3150 rpm Fixed table Fgsdpfjw U Aahox Ac Hei

Condition: used, Year of construction: 1992, functionality: fully functional, machine/vehicle number: 2202, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, total height: 1,740 mm, total width: 1,740 mm, total length: 2,090 mm, overall weight: 1,725 kg, Equipment: documentation/manual, The machine is in very good condition – it was used as a training machine until 2018; since then, it has rarely been in operation. Operating voltage: 380 V. Spindle mount: ISO 40. Quill stroke: 100 mm. Spindle speeds: 40 - 2000 rpm. Rotary table. Fodpfx Acow Urirj Hjgi

Condition: used, Year of construction: 2017, Akira Seiki PC700 HSC Control unit mitsubishi m70 control RPM: 15.000 inline servo spindle Rapid traverse: 40m/min Working range: 700mm x 400mm x 330mm Tool changer: 21 atc Maximum tool diameter: 80mm Maximum tool length: 200mm Cooling tank capacity: 200l Available connection interfaces: ethernet/usb Fgodew Tqvnopfx Ac Hsi External coolant External air cooling Minimum Quantity lubrication Oil Skimmer Spindle Chipper Coolantgun washdown Airgun Manuals included All toolholders included Haimer 3D Taster Mistaway mist extraction unit Zero point workholding on the table Postprocessor for Fusion360 included Machine will be cleaned off chips and coolant before transport

Condition: excellent (used), Year of construction: 2021, feed length X-axis: 680 mm, feed length Y-axis: 365 mm, feed length Z-axis: 370 mm, spindle speed (max.): 4,000 rpm, quill stroke: 125 mm, rapid traverse X-axis: 5 m/min, rapid traverse Y-axis: 3 m/min, rapid traverse Z-axis: 2 m/min, total height: 2,240 mm, total width: 2,160 mm, total length: 2,540 mm, rotational speed (max.): 4,000 rpm, rotational speed (min.): 50 rpm, table load: 350 kg, overall weight: 1,800 kg, input voltage: 380 V, Equipment: documentation/manual, conventional milling machine, sold without the vise and without the drill chuck. Collets available. Fedow D Rrropfx Ac Hogi

Condition: good (used), machine/vehicle number: 5387, travel distance X-axis: 500 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 45 rpm, mount diameter: 40 mm, total height: 1,900 mm, total width: 1,200 mm, total length: 1,500 mm, table width: 280 mm, table length: 700 mm, overall weight: 1,000 kg, Including three-axis digital readout Fjdpjwxpx Hefx Ac Hjgi

Condition: like new (used), Year of construction: 2013, Emcomat FB600L Milling Machine Welcome to view prior to sale Year 2013 Excellent condition X Axis - 600mm Y Axis - 400mm Z Axis - 400mm EMCO Easy Cycle control system Table size: 800 x 400 mm Fgodpfewwk Tcox Ac Hsi Spindle mount: ISO40 Spindle speeds: 10 – 5,000 rpm Stroke of the pinole: 80 mm Feed on all axes: 10 – 2000 mm/min. Rapid traverse: 5000 mm/min Weight approx. 2100kg

Condition: new, The UWF 1.1, a top-tier Conventional Vertical Milling Machine in the Universal Milling Machines group, showcases the precision and robustness that KNUTH is known for. Equipped with a large clamping table and a swiveling universal milling head that pivots in two planes, it effectively meets the diverse needs of a universal milling machine, making it ideal for individual production, repair, and training workshops. The heavy machine frame is complemented by wide, adjustable dovetail guides across all axes, ensuring stability and accuracy. An automatic feed system operates through a gearbox, driving the X- and Y-axes, while rapid traverse is available for the Z-axis. With features such as a motorized height adjustment in the Z direction and an outer arbor support for horizontal milling, the UWF 1.1 stands out with its extensive standard equipment. Request a quote today to enhance your machining capabilities with this exceptional Conventional Vertical Milling Machine and Universal Milling Machine from KNUTH. Fodjwub Acjpfx Ac Hjgi

Condition: used, Year of construction: 1973, Empty weight: 1.200 kg - Year: 1973 - Documentation available: Yes - Serial number: 1626 - Drive system: Conventional - Power [kW]: 1.5 - Number of axes [pcs]: 3 - X-axis travel [mm]: 640 - Y-axis travel [mm]: 405 - Z-axis travel [mm]: 435 - Table length [mm]: 1220 - Table width [mm]: 250 - Tool holder: ISO40 - Min. spindle speed [rpm]: 67 - Max. spindle speed [rpm]: 4600 - Options: Digital readout Fjdpfx Acownihmo Hogi - └ Type of digital readout: ACURITE III - Transport weight [kg]: 1200kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: excellent (used), 3-axis visualization Universal spatial head milling machine, “HURON” type, 360° orientation 3-axis visualization Vertical spindle power: 2.2 kW X-axis travel: 600 mm manual / 480 mm automatic Y-axis travel: 270 mm manual Z-axis travel: 380 mm manual / 340 mm automatic Feed rate: 24 – 402 mm/min Number of spindle speeds: 11 Spindle speed: 45 – 1600 rpm Dimensions: 1540 x 1355 x 1650 mm Fedowlgguepfx Ac Hsgi Weight: 1500 kg

Condition: used, Manufacturer: Prvomajska Model: AG-400 CNC Fodpfewfrrijx Ac Hsgi Control system: Schneider Operation is unstable; the PLC is working, but the machine does not start Spindle power: 9 kW Table size: 800 × 500 mm Travel ranges: X-axis: 600 mm Y-axis: 400 mm Z-axis: 400 mm

Condition: good (used), functionality: fully functional, Universal milling machine Deckel FP4M Active Manufacturer: Deckel Type: FP4M Condition: used, good Digital readout: 3 - axis digital readout Heidenhain Travels: X - axis: approx. 500 mm Y - axis: approx. 400 mm Z - axis: approx. 400 mm Table clamping surface: approx. 700 x 400 mm Speed range: approx. 50 - 2500 rpm Tool holder: ISO 40 Hydraulic tool clamping Drive power: approx. 6.0 kW Feed rates & rapid feeds: in all 3 axes Feed range: approx. 8 - 630 mm/min Rapid traverse: approx. 3.0 m/min L x W x H: approx. 2300 x 1800 x 1800 mm Weight: approx. 1750 kg Machine light Spindle guard Scope of delivery: - 10x tool holders - Allmatic high-pressure vice - documentation Fsdpfx Acjwbqnno Hogi - Spindle guard

Condition: new, The Servomill® FPK 500 is a state-of-the-art Conventional Vertical Milling Machine from KNUTH, designed for superior performance in toolmaking and mechanical manufacturing. This versatile tool seamlessly integrates modern electronics, making it intuitive and capable of operating with exceptional precision. Its robust construction features a console design made of high-quality grey cast iron, ensuring durability and dimensional stability during operation. Noteworthy attributes include powerful servo feed technology with electronic handwheels, enabling infinite variability in feed speeds and precise control across all axes, accompanied by ball screws that eliminate backlash for enhanced accuracy. With a comprehensive variety of standard equipment such as a coolant system, LED worklight, and an automatic lubrication system, the Servomill addresses operational efficiency while minimizing maintenance needs. Perfect for both skilled operators and training environments, this machine exemplifies the best in modern milling technology. Whether you're looking to enhance your production capabilities or train the next generation of machinists, the Servomill® FPK 500 is an ideal choice. Request a quote today to elevate your milling operations with this advanced Conventional Vertical Milling Machine. Fsdpfxswa Ah Ro Ac Hogi

Condition: used, Year of construction: 1994, x-travel / mm Fjdpfsv T Nthox Ac Hegi y-travel / mm z-travel / mm total power requirement 2,3 kW

Condition: used, Technical details: x-travel: 1000 mm y-travel: 350 mm z-travel: 400 mm distance between column - table edge: min.150 / max. 550 mm turning speed range: 28 - 1400 / 18 step U/min tool taper: SK40 Fodpfx Asv Sz Dijc Hjgi spindle head swivable left - right: 90° und vor/zurück: 45° ° feed:: X/Y-Achse: 16 - 800 / 18 step mm/min Table dimensions: 1600 x 400 mm table surface area: 1400 x 330 mm total power requirement: 14,5 kW weight approx.: 4000 kg dimension machine xH: ca. 2,0 x 2,4 x 1,85 m

Condition: excellent (used), Year of construction: 2008, Stock number: 2971 Manufacturer: Optimum Year of manufacture: 2008 Machine number: 03111 Type / Model: OPTI 100 Travel x-y-z: 625 - 220 - 430 mm Table: 1,120 x 265 mm Fgodpjv Rvtcsfx Ac Hoi Speed range: 40 to 2,000 rpm Spindle mount: SK 40 Feed rates: Rapid traverse: Power supply: 2.2 kW Accessories/equipment: Digital display Condition: Good Weight: 1.5 t Dimensions: 2,000 x 2,000 x 1,700 mm
