LONG REACH excavator arm 14m + bucket

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 110532, turning length: 1,980 mm, spindle bore: 105 mm, spindle speed (max.): 2,500 rpm, turning diameter over bed slide: 600 mm, controller model: Siemens 840DSL mit ShopTurn, TECHNICAL DETAILS Swing diameter over bed: 600 mm Distance between centers: 2,000 mm Bwodjy Ex Hmspfx Abbel Turning length: 1,980 mm Spindle bore: 105 mm Speed: 2,500 rpm Power: 18.5 kW MACHINE DETAILS Control: Siemens 840DSL with ShopTurn Number of gear stages: 2

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, workpiece length (max.): 3,048 mm, workpiece width (max.): 1,524 mm, sheet thickness (max.): 3 mm, table load: 5,000 kg, The machine's control system and software have been renewed! TECHNICAL DETAILS Sheet thickness for blanks with tensile strength 400 N/mm² max.: 3.5 mm Minimum sheet thickness: 0.5 mm Punch head force max.: 40 presses with max. force 7 t & 4 presses with max. force 26 t Lower cylinder force max.: 6 t Double punch force: 12 t (2 hydraulic punches) Minimum input table length: 370 mm Maximum input table length: 3,048 mm Minimum input table width: 300 mm Maximum input table width: 1,524 mm Maximum input table diagonal: 3,408 mm Minimum output table length: 250 mm Maximum output table length: 3,048 mm Minimum output table width: 60 mm Maximum output table width: 1,524 mm Vertical stroke of scissor lift table: 550 mm Usable load capacity of scissor lift table: 5,000 kg Minimum size of transportable sheet stacks: 300 x 100 mm MACHINE DETAILS Electrical Data Voltage: 380 V Frequency: 50 Hz Current: 119 A Rated power: 61 kW Cooling capacity of the unit: 32.2 kW Bwjdpfx Aboy Emr Djbjl EQUIPMENT Scissor lift table TC27155C Motorized roller conveyor PRL3814F Universal destacking device DUF15 Punch head H2 Hydraulic power unit C1515 (3-unit pump system) Lower cylinder EI09 Double rotary punch P2R36 Water-air cooling unit R121 Refrigerant R407C Software RIO Control and management system MMACHNT-MICROMach Processor PENTIUM INTEL II 400 MHz WINDOWS NT Documentation

Condition: ready for operation (used), Year of construction: 1994, functionality: fully functional, machine/vehicle number: 14219, travel distance X-axis: 1,250 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 560 mm, spindle diameter: 75 mm, spindle speed (max.): 1,800 rpm, With digital position display! TECHNICAL DETAILS X-axis: 1,250 mm Y-axis: 900 mm Z-axis (or W-axis): 560 mm Bwodpfx Ajy Emq Tjbbol Spindle diameter: 75 mm Spindle speeds: 18–1,800 rpm Spindle taper: SK-40 Table size: 950 mm x 950 mm MACHINE DETAILS Weight: 10,000 kg EQUIPMENT All accessories shown in the photos, including tools, tool cabinets, and clamping devices

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: 7001203, turning diameter over cross slide: 438 mm, spindle bore: 152 mm, turning diameter over bed slide: 860 mm, center width: 2,300 mm, spindle speed (max.): 680 rpm, bed width: 510 mm, TECHNICAL DETAILS Centre distance: 2,300 mm Swing diameter over bed: 860 mm Swing diameter over cross slide: 438 mm Bed width: 510 mm Spindle mounting: A2-11 Spindle bore: 152 mm Spindle speed range: 8 - 680 rpm Number of speeds: 12 Tailstock quill diameter: 120 mm Tailstock quill travel: 165 mm Bwodoy Edw Rjpfx Abbsl Quill taper: MT6 MACHINE DETAILS Motor power: 22 kW

Condition: ready for operation (used), Year of construction: 2010, operating hours: 5,002 h, functionality: fully functional, machine/vehicle number: NT100JG0126, turning length: 424 mm, turning diameter: 370 mm, travel distance X-axis: 380 mm, bar passage: 52 mm, controller model: FANUC FS-31iA5 (MAPPS 4), TECHNICAL DETAILS Turning length: 424 mm Maximum turning diameter: 370 mm (270 mm with turret 2) Bar capacity: 52 mm Turn-mill spindle Full indexing specifications: Yes X-axis travel: 380 mm Y-axis travel: ±105 mm Z-axis travel: 460 + 155 mm (ATC) B-axis: ±120º Spindle speed: 12,000 rpm Drive power: 9/5.5 kW Tool magazine Magazine positions: 38 Tool holder: Capto C5 Maximum tool length: 250 mm (210 mm for tools under Ø70 mm) Maximum tool diameter: Ø70/Ø130 mm (with/without adjacent tools) Maximum tool weight: 5 kg Lower Turret X-axis travel: 155 mm Z-axis travel: 610 mm Number of tool stations: 10 Tool rotational speed: 6,000 min⁻¹ Driven tool power: 1.5/1.2 kW Main Spindle Spindle speed: 6,000 rpm Drive power: 11/7.5 kW Spindle bore: 73 mm Chuck type: Hollow chuck (8") Manufacturer: KITAGAWA Spindle nose: JIS A2-5 Maximum torque: 223 Nm Sub Spindle Spindle speed: 1,000 rpm BW axis: 4 fixed positions, 0º, -30º, -180º (-225º for overhang to conveyor, if equipped) MACHINE DETAILS Control: FANUC FS-31iA5 (MAPPS 4) Potential rated output: 39.24 kVA Dimensions & Weight Dimensions (L x W x H): 2,705 x 2,425 x 2,385 mm Weight: 8,800 kg Operating Hours Powered on: 54,061 hours Spindle 1 operating hours: 9,813 hours Spindle 2 operating hours: 5,002 hours EQUIPMENT Chip conveyor Signal lamp High-pressure pump Air blower outside the spindle Bwodpjy Edc Hefx Abbsl Foot switch (double) for main and sub spindle

Condition: ready for operation (used), Year of construction: 2005, operating hours: 19,229 h, functionality: fully functional, machine/vehicle number: 8043943123C, turning length: 1,050 mm, turning diameter: 465 mm, travel distance X-axis: 300 mm, travel distance Z-axis: 1,050 mm, controller model: Siemens 840 D, TECHNICAL DETAILS Turning diameter: 465 mm Turning length: 1,050 mm Swing diameter: 680 mm Chuck diameter: 325 mm X-axis travel: 300 mm Z-axis travel: 1,050 mm Spindle speed range: 3,500 rpm Rapid traverse X/Z: 30 m/min MACHINE DETAILS Control: Siemens 840 D Number of tool positions: 12 positions Bwsdpfx Aoy D I Ttjbbsl Tool holder: VDI 40 Weight: 7,500 kg Operating hours Spindle hours: 19,229 h Power-on hours: 81,347 h Note: The machine can be inspected under power upon request.

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2004, laser power: 4,000 W, sheet thickness steel (max.): 22 mm, sheet thickness aluminum (max.): 9 mm, travel distance X-axis: 3,420 mm, travel distance Y-axis: 1,550 mm, CO2 laser cutting machine with pallet changer, loading/unloading system, and sheet metal storage Bjdpfoy D Izqsx Abbowl TECHNICAL DETAILS X travel: 3,420 mm Y travel: 1,550 mm Z travel: 200 mm Working area: 3,070 x 1,550 x 200 mm Laser power: 4,000 W Cutting thickness steel / stainless / aluminum: 22 / 12 / 9 mm Table load: 920 kg Traverse speed X/Y/Z: 80 / 80 / 60 m/min MACHINE DETAILS Control unit: Fanuc 160 iLB Machine weight: 15,500 kg EQUIPMENT Double storage tower LKI UL300FO TWIN, year of manufacture 2004 Extraction and filter unit Torit Chiller unit MTA 201

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2007, operating hours: 15,000 h, controller model: BySOFT, laser power: 2,200 W, travel distance X-axis: 1,562 mm, travel distance Y-axis: 772 mm, travel distance Z-axis: 100 mm, TECHNICAL DETAILS X-axis travel: 1,562 mm Y-axis travel: 772 mm Z-axis travel: 100 mm Material thickness (iron): 15 mm Bwodpfx Aoy D Iklebbol Rapid traverse X-Y-Z: 100 - 100 m/min Working area: 1,500 x 3,000 mm MACHINE DETAILS Control unit: BySOFT Laser source: Bylaser 2200 Laser power: 2,200 W Weight: 13,500 kg Operating hours: 15,000 h

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, pressing force: 150 t, stroke length: 415 mm, throat depth: 400 mm, clearance between the columns: 2,600 mm, working range: 3,100 mm, The hydraulic system has been completely overhauled; the cylinders were removed and reconditioned, and seals, oil, and filters were replaced. New light barriers were installed, the CNC control unit was tested, and the machine was repainted. TECHNICAL DETAILS Press force: 150 t Bending length: 3,100 mm Throat depth: 400 mm Distance between uprights: 2,600 mm Stroke: 415 mm Axes: Y1 - Y2 - X - R - Z1 - Z2 MACHINE DETAILS Control unit: CYBELEC DNC 900 Motor power: 15 kW Dimensions & Weight Overall dimensions (L x W x H): 4,000 x 2,400 x 3,200 mm Machine weight: 12,800 kg EQUIPMENT Hydraulic tool clamping Hydraulic crowning Bjdjy D Ih Rspfx Abbjwl

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, pressing force: 32 t, working height: 200 mm, controller model: Siemens 840D, working length: 2,150 mm, TECHNICAL DETAILS Bending length: 2,150 mm Maximum bending height: 200 mm Minimum length/width between bends: 160–350 mm Pressing force: 32 t MACHINE DETAILS Control: Siemens 840D Dimensions & Weight Dimensions (L x W x H): 8,500 x 7,000 x 2,850 mm Weight: 30,000 kg EQUIPMENT Automatic tool changer Bwsdpfx Abjy D Ihwebsl Manipulator Reverse bending cycle Sheet centering system Additional top tools Loading and unloading system
