Condition: good (used), Year of construction: 2014, machine/vehicle number: U 000984, Offer 25355 Hydraulic Positioner – Welding Rotating and Tilting Table Technical Data approx.: - Max. load capacity approx.: 7,000 kg - Faceplate diameter approx.: 1,650 mm - Faceplate hydraulically tiltable - Hydraulic height adjustment of the faceplate - Min./max. table height in horizontal position: approx. 1,290 / 2,100 mm Gkjdjxv Shispfx Ah Sjd - Rotation electrically powered with clockwise and counterclockwise operation - Electric foot switch for clockwise/counterclockwise operation - Electric controller for rotation speed, clockwise/counterclockwise rotation, lift/lower, tilt - Drive: 400 V / 6 kW - Required space approx.: W 4,000 x H 1,300 x D 2,000 mm - Weight approx.: 7,500 kg

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, load capacity: 80,000 kg, rotary table diameter: 2,500 mm, table load: 60,000 kg, disc diameter: 6,500 mm, DIESSE Positioner model DS 2A 60T Load capacity in all positions: 80 T Gkedpexuq D Hefx Ah Sod Workable capacity: 6,500 mm Load capacity in all positions with clamping equipment mounted: 59 T Rotary table diameter: 2,500 mm Min.–max. diameter of spherical shells: 2,500 – 6,500 mm Min.–max. thickness of spherical shells: 30 – 200 mm Neck height of spherical shells: 0 – 600 mm Tilting speed for 6,500 mm diameter: 0 – 1,000 mm/min Tilting speed for 2,500 mm diameter: 0 – 850 mm/min Rotation speed for 450 mm diameter: 0 – 350 mm/min Installed power: 130 kW Complete with: - Dished end clamping device - Rotating platform, max load 2,000 kg USED EQUIPMENT

Condition: excellent (used), functionality: fully functional, load capacity: 45,000 kg, total height: 4,450 mm, total length: 4,600 mm, total width: 11,800 mm, table load: 45,000 kg, pivoting range: 360 °, N.02 AVAILABLE BODE CRADLE-TYPE WELDING POSITIONER Capacity: 50 t Maximum workpiece diameter: 5,000 mm Table with through central hole Ø 500 mm Table diameter: 5,814 mm, 8 guideways Table rotation: 360° Table tilting: +90° / -30° Eccentricity: 300 mm Variable rotation speed: 0.0045–0.18 rpm Variable table tilting speed: 0.0030–0.12 rpm Overall dimensions approx.: 10,200 x 4,300 x 3,700 mm USED EQUIPMENT BODE CRADLE-TYPE WELDING POSITIONER Capacity: 45 t Maximum workpiece diameter: 6,500 mm Table with through central hole Table diameter: 7,314 mm, 8 guideways Table rotation: 360° Table tilting: +105° / -30° Eccentricity: 230 mm Variable rotation speed: 0.00675–0.27 rpm Variable table tilting speed: 0.003–0.12 rpm Overall dimensions approx.: 11,800 x 4,600 x 4,450 mm USED EQUIPMENT Gkjdpfx Ajxuq Acjh Ssd

Condition: good (used), Year of construction: 2013, machine/vehicle number: KA 046062, Offer 25357 Technical Data: - Max. load capacity including work table: 4000 kg - Faceplate hydraulically tiltable: 0 - 180° - Hydraulic height adjustment of the faceplate - Faceplate with holes D 28 + threaded holes, Ø 1600 mm - Table travels in the last driven tilt angle or in the horizontal position - Rotational movement electrically hydraulically actuated, reversible (right/left rotation) - Min. / max. rotational speed: 0.1 - 1.4 rpm - Min. / max. table height in horizontal position: approx. 1040 / 2140 mm - Welding current transmission: approx. 600 A - Drive: 400 V - Manual remote control + electric footswitch Gedsxufxfopfx Ah Sekd - Space required: approx. W 2000 x H 1100 x D 3200 mm - Weight: approx. 5000 kg

Condition: good (used), Year of construction: 2012, machine/vehicle number: 038491-01, Offer 25352 Hydraulic Manipulator - Positioning - Welding Turn and Tilt Table Technical Specifications: - Max. load capacity incl. worktable: 2,000 kg - Effective payload: 1,700 kg - Face plate hydraulically tiltable: 0 - 180° Gkedpoxufntsfx Ah Sed - Hydraulic height adjustment of the face plate - Table can be moved in the last positioned angle or horizontal position - Rotation electrically hydraulic with clockwise and counterclockwise motion - Min. / max. rotational speed: 0.75 – 2.0 rpm - 3D worktable DEMMLER: 800 x 800 mm - Min. / max. table height in horizontal position: approx. 600 / 1,550 mm - Welding current transmission: approx. 600 A - Drive: 400 V - Hand remote control + electric foot switch - Space requirements: approx. W 2,100 x H 600 x D 1,500 mm - Weight: approx. 1,200 kg

Condition: good (used), Year of construction: 2017, machine/vehicle number: KA 061957-01, Offer 25347 Gkjdpfx Ajxufhgsh Sjd Hydraulic Manipulator – Positioning – Welding Rotating and Tilting Table Technical Data: - Max. load capacity incl. work table: 4000 kg - Faceplate hydraulically tiltable: 0 – 180° - Hydraulic height adjustment of faceplate - Faceplate with holes D 28 + threaded holes, Ø 1600 mm - Table operates in the last set tilt position or horizontal - Rotational movement electrically hydraulic with clockwise & counterclockwise rotation - Min. / max. rotational speed: 0.1 – 1.4 rpm - Min. / max. table height in horizontal position: approx. 1040 / 2140 mm - Welding current transfer: approx. 600 A - Drive: 400 V - Hand remote control + electrical foot switch - Space requirement: approx. W 2000 x H 1100 x D 3200 mm - Weight: approx. 5700 kg

Condition: new, Year of construction: 2025, load capacity: 10,000 kg, pivoting range: 135 °, Equipment: foot remote control, 3-axis welding positioner Protec KT 10 000 HV Complete set incl. hand and dual foot remote controls Digital speed display Hydraulic height adjustment Tilting range 0 to 130° Dimensions: Min. tilted height: 1050 mm Max. tilted height: 2200 mm Gkodpfx Aext Tgneh Sod Min. horizontal height: 1360 mm Clamping plate diameter: 2000 mm Length: 3250 mm, width: 1700 mm Speed from 0.05 to approx. 0.6 rpm (range from 0.05 to 1.2 rpm possible)

Condition: good (used), Offer 25332 Technical specifications: - Length approx. 1500 mm - Width approx. 1000 mm - Thickness of top plate approx. 50 mm - Plate thickness incl. ribbing approx. 200 mm Gjdpfx Ajxta Eqsh Sjkd - Table height approx. 900 mm - Table base frame - Total weight approx. 550 kg

Condition: good (used), Offer 25349 Godpfxoxtazrs Ah Sekd Technical data: - Length approx.: 3000 mm - Width approx.: 2000 mm - Ribbed plate height approx.: 400 mm - Top plate thickness approx.: 80 mm - Table height with substructure approx.: 820 mm - Weight approx.: 6500 kg

Condition: new, functionality: fully functional, load capacity: 10,000 kg, pivoting range: 360 °, Column lift turning device, 10-ton load capacity, available as a set or individually 2 sides driven Machine offered as synchronized set or individually Protec turning device / positioner Syncrolift Double column, handheld remote control wireless and manual Column adjustment 2x electrically movable Load capacity 10,000 kg, 360° Minimum working height: 800 mm Maximum working height: 1,700 mm Gjdpfx Ahjxq S Rge Sokd Speed 0.5 rpm Clamping plate diameter 900 mm Rotary drive 2 x 2.2 kW Torque 18,950 Nm The machine is also offered individually as mono model (more affordable) Available on request with articulated flange (cardan flange)

Condition: new, Year of construction: 2025, load capacity: 1,200 kg, 1200 kg Load Capacity Welding Positioner, CE Certificate Load capacity horizontal: 1200 kg Load capacity tilted: 1200 kg with a load center at 250 mm Very robust Continuously adjustable speed from 0.05 to 0.7 rpm (higher speeds available at extra conversion cost) Turntable diameter: 1200 mm Tilting up to 120° Height horizontal: 1,050 mm, tilted up to center: 880 mm Hand and foot remote control Dimensions: 1.35 m (length) x 1.2 m (width) Gedpfx Asxq S Nish Sskd Chuck or quick-change chuck available for extra charge, depending on size As shown, diameter 1000 mm, price: €2,900 (special price, only available when purchased with the welding positioner) Counter bearing with steps: €480, counter bearing with screw adjustment: €880; load capacity 4000 kg

Condition: ready for operation (used), functionality: fully functional, load capacity: 2,000 kg, Welding positioner, turntable, Strähler KT 2000 Machine description: welding positioner, turntable Manufacturer: Strähler Model: KT 2000 Condition: ready for operation (used) 2-ton load capacity welding positioner Adjustable speed and tilt With hand and foot remote control Clamping plate diameter: 1300 mm Horizontal height: 1100 mm Height when tilted to center: 850 mm Gkedpfx Asxq S I Soh Sjd Length: 2300 mm Width: 1300 mm

Condition: new, Table length: 2000 mm Table width: 1000 mm Table height: 200 mm Bore diameter: 28 mm Bore grid pattern: 100 x 100 mm Material thickness: approx. 24.5 - 27 mm Height of side panel: 200 mm Working height: 850 mm Weight: 850 kg Product description: Siegmund Retro Special Offer incl. accessories: Welding table as it was 25 years ago, now also with plasma nitriding and modern table legs. - High-quality steel S355J2+N with plasma nitriding - Diagonal grid bore holes in side panels Gkodpfx Ahexqy Imj Sjd - Corners, edges, and bores beveled at 45° - Rib-reinforced construction - Incl. basic foot set (working height 850 mm) Accessories: - 6 x Professional screw clamps, nitrided - 12 x Quick-release bolts, double blackened, without slot - 8 x Universal stop 225 L, nitrided - 2 x Clamping and stop angle 175 L, nitrided - 2 x Clamping and stop angle 500 G, nitrided - 1 x Accessories set - Eccentric stop Ø 60 with M10 thread, nitrided - Hexagon key size 6 - Brush Ø 30 with protective cap - CleanBasic 1 liter in spray bottle - Anti-spatter 1 liter in spray bottle - Torch holder, blackened

Condition: new, table length 1220 mm table width 760 mm table height 910 mm weight of the machine ca. 226 kg Gsdpfx Ahoxqrhls Sekd

Condition: refurbished (used), functionality: fully functional, load capacity: 8,000 kg, table height: 1,170 mm, table width: 1,700 mm, overall weight: 8,800 kg, Equipment: documentation/manual, Extremely compact rotary tilting table by PASSERINI with a 12.5 t load capacity. Refurbished machine (new electrical system including control cabinet, mechanics overhauled, newly painted). Complete and up-to-date documentation in German with EU Declaration of Conformity. The special feature of this machine is its very low overall height (faceplate height in horizontal position only 1,170 mm) and the far-rearward center of gravity. This allows for a very short design of the front outriggers, which on standard rotary tilting tables are often longer, thereby restricting access to the component and posing a tripping hazard. Please note when comparing offers that we can also ensure long-term service and spare parts availability for the used machines we offer. This machine can also be rented prior to purchase. We offer attractive financing models (independent of banks). Gjdpexqg D Iofx Ah Sekd We are also happy to handle transportation for you.

Condition: refurbished (used), functionality: fully functional, load capacity: 8,000 kg, overall weight: 8,800 kg, height adjustment type: hydraulic, Equipment: documentation/manual, foot remote control, Extremely robust 3-axis rotary tipping table by TECNOMEC. Fully refurbished machine (new hydraulic pump and hoses, new electrics including control cabinet, overhauled mechanics). New paintwork upon purchase. Complete and updated documentation in German with EU Declaration of Conformity. This machine can also be rented prior to purchase. We offer attractive financing models (without bank involvement). We are happy to take care of the transport for you. Gedpfx Ahexqgy Ae Sskd

Condition: like new (used), functionality: fully functional, load capacity: 8,000 kg, total height: 1,200 mm, total length: 2,900 mm, total width: 1,800 mm, type of input current: AC, table width: 1,200 mm, rotary table diameter: 1,200 mm, overall weight: 3,300 kg, height adjustment type: electric, table load: 8,000 kg, pivoting range: 135 °, torque: 8,000 Nm, Welding Positioner NewFiro 8000 HHT A powerful and reliable solution for heavy-duty welding applications. The NewFiro 8000 HHT combines strength, precision, and flexibility making it ideal for rotating and positioning large workpieces with ease and accuracy. Technical Specifications: Load Capacity: 8,000 kg Gedsxpxwqspfx Ah Sjkd Table Diameter: 1,200 mm Table Height: 1,250–2,050 mm (adjustable) Tilting Range: 135° Rotation Torque: 8,000 Nm Tilting Torque: 26,000 Nm Rotation Speed: 0.04–1.2 rpm (variable) Dimensions: Length: 2.9 m Width: 1.8 m Height: 1.2–2.0 m Weight: 3,300 kg Built for performance and durability, the NewFiro 8000 HHT ensures smooth operation and precise contro. The perfect choice for demanding welding and assembly tasks.

Condition: new, table length 2990 mm table width 1490 mm table height 850 - 900 mm weight of the machine ca. 0,8 t Welding table / perforated table: Gkedpfsxpxrhex Ah Sjd with milled and deburred holes Hole diameter: 28 mm The table is made of 15 mm thick, high-alloy steel S355 JR T=15 The surface is untreated. Side panels 165 mm Height adjustable from approx. 880 - 980 mm Ribbed underside for reinforcement. Including floor bearings Accessories optional! Surface flatness 0.2 - 0.5 mm over 1000 mm.

Condition: new, table length 2400 mm table width 1200 mm Gedpfx Asxpxrbjh Sekd table height 850 - 900 mm weight of the machine ca. 0,65 t Welding table / perforated table: with milled and deburred holes Hole diameter: 28 mm The table is made of 15 mm thick, high-alloy steel S355 JR T=15 The surface is untreated. Side panels 165 mm Height adjustable from approx. 880 - 980 mm Ribbed underside for reinforcement. Including floor bearings Accessories optional! Surface flatness 0.2 - 0.4 mm over 1000 mm. The table can be moved with a pallet truck. Pallet truck is not included.

Condition: used, Year of construction: 2008, table diameter 1100 mm table load 1,2 t Gksdexpi Akspfx Ah Sjd swivelling range 0 - 135 Grad turning speeds 0,15 - 3,4 U/min table height adjustment von 780 bis 1560 mm max. torque on the faceplate 1300 Nm Dimensions (LxWxH) 2,8 x 1,6 x 1,6 m Welding turntable with new remote control • Self-locking gear system, no pre- or post-running under eccentric loads • Hydraulic height adjustment allows for virtually unlimited positioning • Frequency-controlled, infinitely variable speed of the rotary table

Condition: refurbished (used), Year of construction: 1980, functionality: fully functional, For sale is a drilling and milling machine from Alzmetall type Plus 3 DG The machine has been completely dismantled and overhauled. Inspection and test run possible at any time. Gsdpfxoxn T S Hj Ah Sekd Forklift available for loading

Condition: used, Year of construction: 2012, Welding Rotator SAF ROTOMATIC ST6W - No 1 Rotation: from 12 to 120 RPM Max Year of construction: 2012 Maxi loading capacity: 6 T Gsdpjxnibdofx Ah Sjkd Trainer dimensions: L 2100 mm x W 800 mm x H 400 mm Simple rotator dimensions: L 1900 mm x W 300 mm x H 400 mm Mini ferrule diameter: Ø 300 mm Maxi ferrule diameter: Ø 300 mm Rotation by speed variator Voltage: 380 V Drive wheels dimensions: Ø 250 x W 80 mm Weight: approx 300 kg

Condition: new, Year of construction: 2022, functionality: fully functional, Brand New Nimo-KG SKV 300 C4 meat bin lifter year of construction 2022 Gsdpfx Asxl Tvgjh Sekd Tipping height 183 cm.

Condition: ready for operation (used), Welding positioner, turning table, rotary work table, used machine Manufacturer: Heinrichsglück Gkjdoxk Rt Topfx Ah Ssd Type: TB 10 E Overall dimensions: Width: 2300 mm Depth: 3100 mm Height: 2500 mm Weight: 10,000 kg Year of manufacture: 1984 Table size: 1800 mm Load capacity: 10 tons

Condition: excellent (used), Year of construction: 2018, load capacity: 500 kg, max. load capacity 500 kg table diameter 700 mm table rotation speed 0.11 - 1.2 rpm net weight 750 kg foot pedal (start-stop/left-right) Little used, very good condition Remote control (wired) Gjdpfx Ahsxg Iwne Sokd
